JEEP GRAND CHEROKEE 2005 WK / 3.G Owners Manual

•Guard against carbon monoxide with proper mainte-
nance. Have the exhaust system inspected every time
the vehicle is raised. Have any abnormal conditions
repaired promptly. Until repaired, drive with all side
windows fully open.
•Keep the liftgate closed when driving your vehicle to
prevent carbon monoxide and other poisonous ex-
haust gases from entering the vehicle.
FUEL TANK FILLER CAP (GAS CAP)
The fuel cap is located on the left side of the vehicle. If the
fuel cap is lost or damaged, be sure the replacement cap
is for use with this vehicle.
Fuel Filler Cap Location
STARTING AND OPERATING 281
5

CAUTION!
Damage to the fuel system or emission control
system could result from using an improper fuel cap
(gas cap). A poorly fitting cap could let impurities
into the fuel system. Also, a poorly fitting after-
market cap can cause the MIL (Malfunction Indica-
tor Light) to illuminate, due to fuel vapors escaping
from the system.
•Turn the engine off.
•Rotate the fuel cap to the left to remove.
•To replace the cap, insert it into the filler neck and
tighten the cap about 1/4 turn until you hear one click.
This is an indication that the cap is properly tightened.
•Make sure that the fuel cap tether strap is not caught
under the fuel cap.
CAUTION!
To avoid fuel spillage and overfilling, do not “top
off” the fuel tank after filling.
NOTE:When the fuel nozzle “clicks” or shuts off, the
fuel tank is full.
Loose Fuel Filler Cap Message
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged, a
“CHECK GAS CAP” message will be displayed in the
EVIC (Electronic Vehicle Information Center). Refer to
“Electronic Vehicle Information Center” in Section 4 of
this manual. Tighten the fuel filler cap properly and press
the odometer reset button to turn the message off. If the
problem continues, the message will appear the next time
the vehicle is started. Refer to “Onboard Diagnostic
System — OBDII” in Section 7 of this manual for more
information.
282 STARTING AND OPERATING

WARNING!
•Remove the fuel cap (gas cap) slowly to prevent
fuel spray from the filler neck which may cause
injury.
•The volatility of some gasoline may cause a
buildup of pressure in the fuel tank that may
increase while you drive. This pressure can result
in a spray of gasoline and/or vapors when the cap
is removed from a hot vehicle. Removing the cap
slowly allows the pressure to vent and prevents
fuel spray.
•Never have any smoking materials lit in or near
the vehicle when the fuel cap is removed or the
tank filled.
•Never add fuel to the vehicle when the engine is
running.
WARNING!
A fire may result if gasoline is pumped into a
portable container that is inside of a vehicle. You
could be burned. Always place gas containers on the
ground while filling.
TRAILER TOWING
In this section you will find information on limits to the
type of towing you can reasonably do with your vehicle.
And you will find safety tips. Before towing a trailer
carefully review this information to tow your load as
efficiently and safely as possible.
To maintain warranty coverage, follow the requirements
and recommendations in this manual concerning ve-
hicles used for trailer towing.
Perform maintenance services as prescribed in the appro-
priate “Maintenance Schedule.” Refer to Section 8 of this
STARTING AND OPERATING 283
5

manual. When your vehicle is used for trailer towing,
never exceed the gross axle weight rating (GAWR) by the
addition of:
•The tongue weight of the trailer.
•The weight of any other type of cargo or equipment
put in or on your vehicle.
WARNING!
Improper towing can lead to an injury accident.
Follow these guidelines to make your trailer towing
as safe as possible:
•Be sure a trailer is loaded heavier in front, about 10%
to 15% of gross trailer weight. Loads balanced over the
wheels or heavier in the rear cause the trailer to sway
severelyside to side which will cause loss of control ofthe vehicle and trailer. Failure to load trailers heavier
in front is the cause of many trailer related accidents.
•Donotinterconnect the hydraulic brake system of
your vehicle with that of the trailer. This could cause
inadequate braking and possible personal injury.
•Trailer brakes are required for trailers in excess of
2,000 lbs (907 kg).
•Donotconnect a trailer lighting system directly to the
lighting system of your vehicle. Use an approved
trailer wiring harness. Failure to do so could damage
the vehicle electrical system and/or result in personal
injury.
•When hauling cargo or towing a trailer,do notover-
load your vehicle or trailer. Overloading can cause a
loss of control, poor performance or damage to brakes,
axle, engine, transmission, steering, suspension, body
structure or tires.
284 STARTING AND OPERATING

•Make certain that the load is secured in the trailer and
will not shift during travel.
•It is recommended thatanyhitches installed on your
vehicle be factory installed, or installed by a dealer
using factory approved parts. Factory approved parts
are specifically engineered with your vehicle’s perfor-
mance in mind, including the possibility that it will be
involved in an accident. Other hitches may not have
been so engineered. Vehicle performance, including
vehicle damage in an accident situation, may therefore
be different.
•If trailer towing is required and your vehicle is not
equipped with a trailer tow package, the Mopar
accessory towing harnesses are the only approved
method to provide for trailer lights. These harnesses
are designed to provide current to the trailer lights but
bypass the module designed to monitor tail lights.
Refer to the package instructions for details.
Trailer and Tongue Weight
Gross Trailer Weight (GTW) means the weight of the
trailer plus the weight of all cargo, consumables and
equipment loaded on the trailer when in actual under-
way towing condition. The best way to measure GTW is
to put your fully loaded trailer on a vehicle scale. The
entire weight of the trailer must be supported by the
scale.
Always load a trailer with 60% of the cargo weight in the
front of the trailer. This places approximately 10% to 15%
of the GTW on the tow hitch of your vehicle. This portion
of the GTW becomes the tongue weight.
Trailer sway control and equalizing hitch are required for
tongue weights above 350 lbs (159 kg)., i.e., trailer
weights heavier than 3,500 lbs (1 587 kg).
STARTING AND OPERATING 285
5

Trailer Tow Wiring
The Trailer Tow Package includes a 4 and 7 pin wiring
harness located at the rear underbody of the vehicle.
NOTE:Connect trailer lighting and brakes using factory
harnesses only. Do not cut or splice wiring to the brake
circuits.
The electrical connections are all complete to the vehicle
but you must mate the harness to a trailer connector.
Refer to the following illustrations.
4–Pin Connector
286 STARTING AND OPERATING

Cooling System Tips—Trailer Towing
To reduce potential for engine and transmission over-
heating in high ambient conditions, take the following
actions:
•City Traffic
When stopped, put transmission in N (Neutral) and
increase engine idle speed.
•Highway Driving
Reduce speed.
•Air Conditioning
Turn off temporarily.
To reduce the potential for transmission overheating,
turn the “TOW/HAUL” feature on when driving in hilly
areas or downshift the transmission to the next lower
gear range to eliminate excessive transmission shifting.
This action will also reduce the possibility of transmis-
sion overheating and provide better engine braking.
7–Pin Connector
STARTING AND OPERATING 287
5

TRAILER CLASSIFICATIONS
Class Max. GTW (Gross Trailer Wt.) Frontal Area Length
Class I - Light Duty 2,000 lbs. (907 kg) 32 ft2 20 ft
Class II - Medium Duty 3,500 lbs. (1 587 kg) 40 ft2 20 ft
Class III - Heavy Duty 5,000 lbs. (2 268 kg) 60 ft2 25 ft
Class IV - Extra Heavy Duty (See Note 1) 60 ft2 30 ft
Note 1 – Refer to the Trailer Towing Capability chart for
the Max. GTW towable for a given drivetrain.
288 STARTING AND OPERATING

TRAILER TOWING CAPABILITY
Engine Model GVWR
(Gross Vehice Wt.
Rating)GCWR
(Gross Combined
Wt. Rating)Hitch Type Max. GTW
(Gross Trailer Wt.)Max. Tongue Wt.
(See Note 1)
3.7L 4x2 5,700 lbs (2 585 kg) 8,000 lbs (3 629 kg) Class II 3,500 lbs (1 587 kg) 525 lbs (238 kg)
3.7L 4x4 5,900 lbs (2 676 kg) 8,200 lbs (3 719 kg) Class II 3,500 lbs (1 587 kg) 525 kbs (238 kg)
4.7L 4x2 6,010 lbs (2 726 kg) 11,200 lbs (5 080 kg) Class IV 6,500 lbs (2 948 kg) 720 lbs (327 kg)
4.7L 4x4 6,100 lbs (2 767 kg) 11,450 lbs (5 194 kg) Class IV 6,500 lbs (2 948 kg) 720 lbs (327 kg)
5.7L 4x4 6,150 lbs (2 789 kg) 12,200 lbs (5 534 kg) Class IV 7,200 lbs (3 266 kg) 720 lbs (327 kg)
Note 1 – The towing vehicle payload should be reduced
by the tongue load (for a dead weight hitch) to keep the
rear axle loading below GAWR (Gross Axle Weight
Rating) of 3,200 lbs (1 451 kg).
STARTING AND OPERATING 289
5

RECREATIONAL TOWING (BEHIND
MOTORHOME, ETC.)
Towing – 2WD Models
Recreational towing is allowed ONLY if the driveshaft
is removed.Towing with the rear wheels on the ground
while the driveshaft is connected can result in severe
transmission damage which is not covered under the
Limited Warranty.
Towing — Quadra-Trac I (Single-Speed Transfer
Case) 4WD Models
Recreational towing is not allowed.This model does not
have a N (Neutral) position in the transfer case.
Towing — Quadra–Trac II /Quadra–Drive II 4WD
Models
CAUTION!
Internal damage to the transfer case will occur if a
front or rear wheel lift is used when recreational
towing.
NOTE:The transfer case must be in the N (Neutral)
position, and the transmission must be in the P (Park)
position for recreational towing.
Shifting Into Neutral (N)
Use the following procedure to prepare your vehicle for
recreational towing.
290 STARTING AND OPERATING
