JEEP GRAND CHEROKEE 2005 WK / 3.G Owners Manual

3. Assemble the jack and jacking tools as shown. Connect
jack handle driver (A) to two extensions (B), then to the
lug wrench (C).
4. Locate the jack as shown. For the front axle, place it
under the front lower control arm as shown. For the rear
axle, place it under the axle near the wheel to be changed.Ensure the jack is closest to the inside of the wheel when
jacking on the rear axle.Do not raise the vehicle until
you are sure the jack is fully engaged.
Front Jacking Location
WHAT TO DO IN EMERGENCIES 301
6

5. Raise the vehicle by turning the jack screw clockwise.
Raise the vehicle only until the tire just clears the surface
and enough clearance is obtained to install the spare tire.
Minimum tire lift provides maximum stability.
WARNING!
Raising the vehicle higher than necessary can make
the vehicle less stable. It could slip off the jack and
hurt someone near it. Raise the vehicle only enough
to remove the tire.
6. Remove the lug nuts and wheel.
7. Position the spare wheel/tire on the vehicle and install
the lug nuts with the cone-shaped end toward the wheel.
Lightly tighten the nuts. To avoid the risk of forcing the
vehicle off the jack, do not tighten the nuts fully until the
vehicle has been lowered.
8. Lower the vehicle by turning the jack screw counter
clockwise, and remove the jack and wheel blocks.
9. Finish tightening the lug nuts. Push down on the
wrench while tightening for increased leverage. Alternate
Rear Jacking Location
302 WHAT TO DO IN EMERGENCIES

nuts until each nut has been tightened twice. Correct
wheel nut tightness is 130 N·m (95 ft. lbs). If in doubt
about the correct tightness, have them checked with a
torque wrench by your authorized dealer or at a service
station.
10. Lower the jack to it’s fully closed position.
WARNING!
A loose tire or jack, thrown forward in a collision or
hard stop could endanger the occupants of the ve-
hicle. Always stow the jack parts and the spare tire in
the places provided.
11. Secure the tire, jack, and tools in their proper loca-
tions.
NOTE:Tire should be stowed with the “beauty” side
up. Storing the tire upside down may result in scratchingor damage to the wheel face. Continue winching up the
tire until you hear the winch “ratchet” three times.
Double check to ensure the tire is snug against the
underbody of the vehicle. Damage to the winch cable
may result if the vehicle is driven with the tire loose.
12. Reinstall the rubber plug into the floor of the cargo
area.
JUMP STARTING PROCEDURE
NOTE:Check the test indicator on top of battery for
battery fluid level. If the indicator is clear, the level is low.
Add water to the proper level and reinstall the vent caps
before attempting to jump start the vehicle.
1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
unintended electrical contact.
2. When boost is provided by a battery in another
vehicle, park that vehicle within booster cable reach but
WHAT TO DO IN EMERGENCIES 303
6

without letting the vehicles touch. Set the parking brake,
place the transmission in P (Park), and turn the ignition
to OFF for both vehicles.
3. Turn off the heater, radio and all unnecessary electrical
loads.
4. Connect one end of a jumper cable to the positive
terminal of the discharged battery. Connect the other end
of the same cable to the positive terminal of the booster
battery.
5. Connect the other cable, first to the negative terminal
of the booster battery and then connect the other end to
a non-paint metal surface on the engine of the vehicle
with the discharged battery. Make sure you have a good
contact on the engine.
6. Start the engine in the vehicle which has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.7. When removing the jumper cables, reverse the above
sequence exactly. Be careful of the moving belts and fan.
NOTE:To start the vehicle following connection of a
booster battery, the Security Alarm System must first be
disabled by cycling a front door key cylinder or by using
the keyless entry transmitter.
WARNING!
Jump starting can be dangerous. To avoid personal
injury or damage to electrical components in vehicle,
observe the following warnings:
•Battery fluid is a corrosive acid solution and can burn
or even blind you. Don’t allow battery fluid to contact
your eyes, skin, or clothing. Don’t lean over a battery
304 WHAT TO DO IN EMERGENCIES

when attaching clamps. If acid splashes in eyes or on
skin, flush the area immediately with large amounts of
water.
•Do not use a booster battery or any other booster
source that has a greater than 12–volt system, i.e., do
not use a 24–volt power source.
•Never attempt to jump start a discharged battery that
is frozen, because it could rupture or explode during
jump starting.
•Be sure your vehicle is not touching the jump start
vehicle.
•Observe all Battery Warnings in Section 7 of this
manual, while jump starting your vehicle.
WARNING!
Do not attempt to push or tow your vehicle to get it
started. Unburned fuel could enter the catalytic
converter and, once the engine has started, ignite and
damage the converter and vehicle.
EMERGENCY TOW HOOKS — IF EQUIPPED
If your vehicle is equipped with tow hooks, there will be
one in the rear and two mounted on the front of the
vehicle. The rear hook will be located on the driver’s side
of the vehicle.
NOTE:For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of
damage to the vehicle.
WHAT TO DO IN EMERGENCIES 305
6

CAUTION!
Tow hooks are for emergency use only, to rescue a
vehicle stranded off road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle.
WARNING!
Stand clear of vehicles when pulling with tow
hooks. Tow straps and chains may break, causing
serious injury.
TOWING A DISABLED VEHICLE
2WD Models Only
Provided the transmission is operable, tow only in N
(Neutral) at speeds not exceeding 30 mph (48 km/h), for
distances of not more than 15 miles (24 km). Towing at
more than 30 mph (48 km/h) or for more than 15 miles
(24 km) can cause severe transmission damage. If the
transmission is not operable, or the vehicle must be
towed faster than 30 mph (48 km/h) or farther than 15
miles (24 km), remove the driveshaft or tow with all four
wheelsOFFthe ground. Acceptable methods are to tow
the vehicle on a flatbed or with one end of the vehicle
raised and the other end on a towing dolly.
4WD Models Only
The manufacturer recommends towing with all four
wheelsOFFthe ground. Acceptable methods are to tow
the vehicle on a flatbed or with one end of the vehicle
raised and the other end on a towing dolly.
306 WHAT TO DO IN EMERGENCIES

MAINTAINING YOUR VEHICLE
CONTENTS

3.7L Engine...........................310

4.7L Engine...........................311

5.7L Engine...........................312

Onboard Diagnostic System — OBD II........313
▫Loose Fuel Filler Cap Message............313

Emissions Inspection And Maintenance
Programs............................314

Replacement Parts......................315

Dealer Service.........................316
Maintenance Procedures..................316
▫Engine Oil..........................316
▫Drive Belts - Check Condition And Tension . . . 320
▫Spark Plugs.........................321
▫Catalytic Converter....................321
▫Ignition Cables.......................323
▫Crankcase Emission Control System........323
▫Fuel Filter..........................323
▫Air Cleaner Filter.....................323
7

▫Maintenance-Free Battery................324
▫Air Conditioner Maintenance.............325
▫Power Steering Fluid Check..............326
▫Body Lubrication.....................327
▫Windshield Wiper Blades................327
▫Windshield Washers — Front And Rear.....328
▫Exhaust System......................328
▫Cooling System.......................329
▫Hoses And Vacuum/Vapor Harnesses.......334
▫Brake System........................334
▫Automatic Transmission................336
▫Transfer Case........................339
▫Front/Rear Axle Fluid..................340▫Appearance Care And Protection From
Corrosion...........................340

Fuse Panel...........................345
▫Interior Fuses........................345
▫Underhood Fuses
(Power Distribution Center)..............346
▫Underhood Fuses
(Integrated Power Module)..............348

Vehicle Storage........................350

Replacement Bulbs......................350

Bulb Replacement......................351
▫Head Light..........................351
▫Front Turn Signal.....................353
▫Front Fog Light......................354
308 MAINTAINING YOUR VEHICLE

▫Rear Tail, Stop, Turn Signal, And Back-Up
Lights.............................355
▫Center High Mounted Stop Light (CHMSL) . . . 356

Fluid Capacities........................357
Recommended Fluids, Lubricants And Genuine
Parts................................358
▫Engine.............................358
▫Chassis............................359
MAINTAINING YOUR VEHICLE 309
7

3.7L ENGINE
310 MAINTAINING YOUR VEHICLE
