Cavity Fuse/Color Description
1 40 Amp Green HVAC Blower
2 30 Amp Pink Power Outlets
3 30 Amp Pink Rr Wiper/Ign R/O
4 30 Amp Pink ABS Pump
5 Spare
6 50 Amp Red ASD
7 Spare
8 40 Amp Green Acc Delay/Seats
9 Spare
10 40 Amp Green Starter/JB Power
11 30 Amp Pink Cig Ltr/T-Tow
12 40 Amp Green EBL/Htd Mirror
13 40 Amp Green JB Power
14 Spare
15 SpareCavity Fuse/Color Description
16 25 Amp Natu-
ralIPM/Coils
17 Spare
18 20 Amp Yellow TCM/AC Clutch
19 20 Amp Yellow Ign Sw
20 20 Amp Yellow PCM Batt (Gasoline Only)
21 30 Amp Pink ABS Valves
22 Spare
23 20 Amp Yellow FDCM
24 20 Amp Yellow Fuel Pump
25 20 Amp Yellow FDCM/E-Diff.
26 Spare
27 15 Amp Blue Brake/Stop Lamps
28 25 Amp Natu-
ralNGC/Injectors
29 Spare
MAINTAINING YOUR VEHICLE 331
7

Cavity Fuse/Color Description
30 Spare
31 Spare
32 Micro Relay TCM Rly (Gasoline Only)
33 Micro Relay Starter Rly
34 Micro Relay AC Clutch Rly
35 Micro Relay Fuel Pump Rly
36 Spare
38 Spare
39 Mini Relay HVAC Blower Rly
40 Mini Relay ASD RlyUnderhood Fuses (Integrated Power Module)
Integrated Power Module
332 MAINTAINING YOUR VEHICLE

Cavity Fuse/Color Description
1 Micro Relay Wiper On/Off Rly
2 Micro Relay Wiper Hi/Lo Rly
3 Micro Relay Horn Rly
4 Spare
5 Micro Relay Lt T-Tow Stop/Turn Rly
6 Micro Relay Rt T-Tow Stop/Turn Rly
7 Micro Relay Park Lamps Rly
8 10 Amp Red Lt Park Lamps
9 10 Amp Red T-Tow Park Lamps
10 10 Amp Red Rt Park Lamps
11 Mini Relay Rad Fan Hi Rly
12 20 Amp Yellow FCM Batt #4
13 20 Amp Yellow FCM Batt #2
14 20 Amp Yellow Adjustable Pedal
15 20 Amp Yellow Ft Fog Lamps
16 20 Amp Yellow HornCavity Fuse/Color Description
17 20 Amp Yellow Rear Fogs
18 20 Amp Yellow FCM Batt #1
19 20 Amp Yellow Lt T-Tow Stop/Turn
20 20 Amp Yellow FCM Batt #3
21 20 Amp Yellow Rt T-Tow Stop/Turn
22 30 Amp Pink FDCM Mod
23 50 Amp Red Rad Fan
24 Mini Relay Rad Fan Lo Rly
25 Micro Relay Ft Fog Lamps Rly
26 Micro Relay Adjustable Pedal Rly
27 15 Amp Blue IOD #1
28 20 Amp Yellow IOD #2 (Audio)
29 10 Amp Red ORC (Ign R/.S)
30 10 Amp Red ORC (Ign R/O)
MAINTAINING YOUR VEHICLE 333
7

VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove fuse #27 in the Intelligent Power Module
labeled Ignition-Off Draw (IOD#1).
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT BULBS
Interior Lights Bulb Type
Glove Box Light......................... 194
Grab Handle Light................L002825W5W
Overhead Console Reading Lights..........VT4976
Rear Cargo Light.......................214–2
Visor Vanity Light.....................V26377
Underpanel Courtesy Lights................. 906
Instrument Cluster (General Illumination)....... 103
Telltale/Hazard Light...................... 74
* Available only from authorized dealers.
334 MAINTAINING YOUR VEHICLE

Exterior Lights Bulb Type
Backup Lights.........................3157K
Front Fog Lights........................9145
Front Park/Turn Light...................3157K
Front Side Marker.......................2825
Headlights (Low Beam)...................9006
Headlights (High Beam)...................9005
Rear License Plate Light.................... 168
Rear Stop/Tail Lights....................3157K
Rear Turn/Tail Lights (2)..................3157
NOTE:Numbers refer to commercial bulb types that
can be purchased from your authorized dealer.
If a bulb needs to be replaced, visit your authorized
dealer or refer to the applicable Service Manual.BULB REPLACEMENT
Head Light
1. Open the hood.
2. Remove the headlamp cover.
MAINTAINING YOUR VEHICLE 335
7

3. Turn the low or high beam bulb 1/4 turn counter
clockwise to remove from housing.4. Disconnect the electrical connector and replace the
bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
336 MAINTAINING YOUR VEHICLE

Front Turn Signal
1. Open the hood.
2. Remove the headlamp cover.
3. Turn the turn signal bulb 1/4 turn counter clockwise
to remove from housing.4. Disconnect the electrical connector and replace the
bulb.
MAINTAINING YOUR VEHICLE 337
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
Front Fog Light
1. Reach behind the front fascia from under the vehicle.
2. Turn the front fog light bulb 1/4 turn counter clock-
wise to remove from housing.
3. Disconnect the electrical connector and replace bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean
the bulb with rubbing alcohol.
338 MAINTAINING YOUR VEHICLE

Rear Tail, Stop, Turn Signal, and Back-Up Lights
1. Raise the liftgate.
2. Remove the two Torx fasteners.
3. Squeeze the socket assembly tabs to remove it from the
housing.4. Pull the bulb to remove it from the socket.
5. Replace the bulb, reinstall the socket, and reattach the
light assembly.
MAINTAINING YOUR VEHICLE 339
7

Center High Mounted Stop Light (CHMSL)
1. Remove the two screws securing the CHMSL.2. Twist the bulb socket to remove from the CHMSL
housing.
3. Pull the bulb out of the socket.
4. Replace the bulb, reinstall the socket and reattach the
CHMSL.
