JEEP GRAND CHEROKEE 2006 WK / 3.G SRT Owners Manual

Miles 18,000 21,000 24,000 27,000 30,000
(Kilometers) (30 000) (35 000) (40 000) (45 000) (50 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.X
Drain and refill the front and rear axles. X
Inspect the brake linings. X
Drain the transfer case and refill.X
SCHEDULE “B” 351
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 33,000 36,000 39,000 42,000 45,000
(Kilometers) (55 000) (60 000) (65 000) (70 000) (75 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Drain and refill the front and rear axles. X
Inspect the brake linings. X
352 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (80 000) (85 000) (90 000) (95 000) (100 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.X
Inspect drive belt, replace if necessary. X
Inspect the brake linings. X X
Drain and refill the front and rear axles. X
Drain and refill the transfer case fluid. X
Drain and refill the automatic transmission fluid,
and replace filter.X
Flush and replace engine coolant/anti-freeze. X
SCHEDULE “B” 353
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 63,000 66,000 69,000 72,000 75,000
(Kilometers) (105 000) (110 000) (115 000) (120 000) (125 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Inspect the drive belt, replace if necessary. X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid. X
354 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers) (130 000) (135 000) (140 000) (145 000) (150 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.X
Inspect the drive belt, replace if necessary.* X
Drain and refill the transfer case fluid. X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid. X
SCHEDULE “B” 355
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (155 000) (160 000) (165 000) (170 000) (175 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Replace the spark plugs.X
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid. X
Flush and replace the engine coolant/anti-freeze, if
not done at 60 months.X
356 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change the engine oil and engine oil filter, if not replaced
at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if necessary.X
Inspect the PCV Valve, replace if necessary.X
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid. X
Drain and refill the automatic transmission fluid, and re-
place filter.X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze at 120
months, if not replaced at 102,000 miles (170 000 km).X
Inspection and service should also be performed anytime a
malfunction is observed or suspected. Retain all receipts.
This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.* This maintenance is not required if the belt was
previously replaced.
SCHEDULE “B” 357
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule “A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Inspect the engine air cleaner filter, and replace if
necessary.X
Inspect the brake linings. X
Drain the transfer case and refill.X
358 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (60 000) (70 000) (80 000) (90 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Inspect the brake linings. X X
SCHEDULE “A” 359
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.X
Inspect the drive belt, replace if necessary. X
Flush and replace the engine coolant/anti-freeze at 60
months, if not replaced at 102,000 miles (170 000 km).X
Inspect the brake linings. X
Drain the transfer case and refill. X
