JEEP GRAND CHEROKEE 2007 WK / 3.G SRT Owners Manual

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months.X X XXX
Inspect the engine air cleaner filter, replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.LX
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid. X
Drain and refill the automatic transmission fluid,
and replace filter.X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze at
120 months, if not replaced at 102,000 miles (170
000 km).X
SCHEDULE ªBº 361
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
LThis maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.* This maintenance is not required if the belt was
previously replaced.
362 SCHEDULE ªBº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Schedule ªAº
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Inspect the engine air cleaner filter, and replace if
necessary.X
Inspect the brake linings. X
Drain the transfer case and refill.X
SCHEDULE ªAº 363
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (60 000) (70 000) (80 000) (90 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Inspect the brake linings. X X
364 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.LX
Inspect the drive belt, replace if necessary. X
Flush and replace the engine coolant/anti-freeze at 60
months.X
Inspect the brake linings. X
Drain the transfer case and refill. X
SCHEDULE ªAº 365
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 84,000 90,000 96,000 102, 000
(Kilometers) (140 000) (150 000) (160 000) (170 000)
[Months] [84] [90] [96] [102]
Change the engine oil and engine oil filter. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary.LX
Replace the spark plugs.X
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X
Flush and replace the engine coolant/anti-freeze if not
replaced at 60 months.X
Drain the transfer case and refill. X
366 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Inspect the engine air cleaner filter, and replace if necessary.X
Inspect the PCV Valve, replace if necessary.LX
Inspect the drive belt, replace if necessary.* X
Inspect the brake linings. X
Flush and replace the engine coolant/anti-freeze if not done at
102,000 miles (170 000 km).X
Drain the transfer case and refill.X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
LThis maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.* This maintenance is not required if the belt was
previously replaced.
SCHEDULE ªAº 367
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the proper equipment. If you have any
doubt about your ability to perform a service job,
take your vehicle to a competent mechanic.
368 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
mSuggestions For Obtaining Service For Your
Vehicle..............................370
NPrepare For The Appointment............370
NPrepare A List........................370
NBe Reasonable With Requests.............370
mIf You Need Assistance...................370
mWarranty Information (U.S. Vehicles Only).....373
mMopartParts.........................373mReporting Safety Defects..................373
NIn Canada..........................373
mPublication Order Forms..................374
mDepartment Of Transportation Uniform Tire
Quality Grades........................375
NTreadwear..........................375
NTraction Grades......................375
NTemperature Grades...................376
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you're having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle's
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle's problems or the
specific work you want done. If you've had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer's dealers have the facilities, factory-trained
370 IF YOU NEED CONSUMER ASSISTANCE
