CAUTION!
²Replacing fuel system components with non-
ethanol compatible components can damage your
vehicle.
²Do not use ethanol mixture greater than 85% in
your vehicle. It will cause difficulty in cold start-
ing and may affect drivability.
FUEL REQUIREMENTS (DIESEL ENGINES)
Use good quality diesel fuel from a reputable supplier.
For most year-round service, No. 2 diesel fuel meeting
ASTM specification D-975 Grade S15 will provide good
performance. If the vehicle is exposed to extreme cold
(below 20É F or -7É C), or is required to operate at
colder-than-normal conditions for prolonged periods,
use climatized No. 2 diesel fuel or dilute the No. 2 dieselfuel with 50% No. 1 diesel fuel. This will provide better
protection from fuel gelling or wax-plugging of the fuel
filters.
This vehicle is fully compatible with biodiesel blends
up to 5% biodiesel meeting ASTM specification D-975.
NOTE: Federal law requires that you must fuel this
vehicle with Ultra Low Sulfur Highway Diesel fuel (15
ppm Sulfur maximum) and prohibits the use of Low
Sulfur Highway Diesel fuel (500 ppm Sulfur maxi-
mum) to avoid damage to the emissions control system.
344 STARTING AND OPERATING

Towing Tips Ð Automatic Transmission
The ªDº range can be selected when towing. However, if
frequent shifting occurs while in this range, the ºTow/
Haulº mode (if equipped) or a lower gear range should
be selected.
NOTE:Using the ºTow/Haulº mode (if equipped) or a
lower gear range while operating the vehicle under
heavy operating conditions will improve performance
and extend transmission life by reducing excessive shift-
ing and heat build up. This action will also provide better
engine braking.
The automatic transmission fluid and filter should be
changed if you REGULARLY tow a trailer for more than
45 minutes of continuous operation. Refer to the ªMain-
tenance Scheduleº in Section 8 of this manual for trans-
mission fluid change intervals.
NOTE:Check the automatic transmission fluid level
before towing.
Towing Tips Ð Electronic Speed Control (If
Equipped)
þ
Don't use in hilly terrain or with heavy loads.
þWhen using the speed control, if you experience speed
drops greater than 10 mph (16 km/h), disengage until
you can get back to cruising speed.
þUse speed control in flat terrain and with light loads to
maximize fuel efficiency.
Towing Tips Ð Cooling System
To reduce potential for engine and transmission over-
heating, take the following actions:
þCity Driving
When stopped for short periods of time, put transmission
in N (Neutral) and increase engine idle speed.
þHighway Driving
Reduce speed.
STARTING AND OPERATING 363
5

MAINTAINING YOUR VEHICLE
CONTENTS
mEngine Compartment ± 3.7L...............386
mEngine Compartment ± 4.7L...............387
mEngine Compartment ± 5.7L...............388
mEngine Compartment ± 3.0L Diesel..........389
mOnboard Diagnostic System Ð OBD II........390
NLoose Fuel Filler Cap Message............391
mEmissions Inspection And Maintenance
Programs............................391
mReplacement Parts......................393mDealer Service.........................393
mMaintenance Procedures..................394
NEngine Oil..........................394
NDrive Belts Ð Check Condition And Tension . . 398
NSpark Plugs.........................398
NSpark Plug Wires.....................398
NEngine Air Cleaner Filter................398
NCatalytic Converter....................399
NCrankcase Emission Control System........400
7

Engine Oil Viscosity (3.7L/4.7L/5.7L Engines)
SAE 5W-20 engine oil is recommended for all operating
temperatures. This engine oil improves low temperature
starting and vehicle fuel economy.
The engine oil filler cap also shows the recommended
engine oil viscosity for your vehicle. For information on
engine oil filler cap location, see the ªEngine Compart-
mentº illustration in this section.
NOTE:Vehicles equipped with a 5.7L engine must use
SAE 5W-20 oil. Failure to do so may result in improper
operation of the Multiple Displacement System (MDS).
Refer to ªMulti Displacement Systemº in Section 5 for
more details.
Lubricants which do not have both, the engine oil certi-
fication mark and the correct SAE viscosity grade num-
ber should not be used.
Engine Oil Viscosity (3.0L Diesel Engine)
CAUTION!
Your vehicle is equipped with an advanced technol-
ogy Diesel Engine and an emission device designed
to limit Diesel Particulate Emissions from being
released into the atmosphere. The durability of your
engine and life expectancy of this diesel particulate
filter emission device is highly dependent on the use
of the correct engine oil.
In order to protect your engine and emission system, use
only SAE 5W-30 Synthetic Engine Oil that meets
DaimlerChrysler Material Standard MS-11106, Mercedes
Benz MB 229.31 or MB 229.51, and ACEA C3 qualified
engine oils.
396 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (Approximate)
3.7/4.7/5.7L Gasoline Engines 21 Gallons 79 Liters
3.0L Diesel Engine 22 Gallons 83 Liters
Engine Oil with Filter
3.7 Liter Engine (SAE 5W-20, API Certified) 5 Qts 4.7 Liters
4.7 Liter Engine (SAE 5W-20, API Certified) 6 Qts 5.7 Liters
5.7 Liter Engine (SAE 5W-20, API Certified) 7 Qts 6.6 Liters
3.0 Liter Diesel Engine (SAE 5W-30 Synthetic, API Certified Low Ash) 10 Qts 9.5 Liters
Cooling System *
3.7 Liter Engine (MopartEngine Coolant/Antifreeze 5 Year/100,000 Mile Formula) 9 Qts 10 Liters
4.7 Liter Engine (MopartEngine Coolant/Antifreeze 5 Year/100,000 Mile Formula) 14.5 Qts 13.7 Liters
5.7 Liter Engine (MopartEngine Coolant/Antifreeze 5 Year/100,000 Mile Formula) 14.5 Qts 13.7 Liters
3.0 Liter Diesel Engine (MopartAntifreeze/Engine Coolant 5 Year/100,000 Mile
Formula)14 Qts 13.2 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
440 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluid, Lubricant, or Genuine Part
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy-
brid Organic Additive Technology)
Engine Oil (3.7L/4.7L/5.7L Engines) Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of
DaimlerChrysler Material Standard MS-6395. Refer to your engine oil
filler cap for correct SAE grade.
Engine Oil (3.0L Diesel Engine)
Use API Certified SAE 5W-30 Synthetic Low Ash Engine Oil, meeting the
requirements of DaimlerChrysler Material Standard MS-11106, Mercedes
Benz MB 229.31 or 229.51, and ACEA C3 qualified engine oils.
Oil Filter (3.7/4.7/5.7L Gasoline Engines) MopartOil Filter (P/N 05281090)
Oil Filter (3.0L Diesel Engine) MopartOil Filter (P/N 05175571AA)
Spark Plugs (3.7L Engine) ZFR6F-11G (Gap 0.043º)
Spark Plugs (4.7L Engine) Upper Bank Ð FR8TE2 (Gap 0.040º) Lower Bank Ð FR8T1332 (Gap
0.050º)
Spark Plugs (5.7L Engine) REC14MCC4 (Gap 0.043º)
Fuel Selection (3.7L and 4.7L Engines) 87 Octane
MAINTAINING YOUR VEHICLE 441
7

²Check all lights and all other electrical items for correct
operation.
At Each Oil Change
²Change the engine oil filter.
²Inspect the exhaust system.
²Inspect brake hoses.
²Check the engine coolant/anti-freeze level, hoses, and
clamps.
²Inspect engine accessory drive belts. Replace as neces-
sary.
²Inspect for the presence of water in the fuel filter/
water separator unit.
MAINTENANCE SCHEDULES 451
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 6,250 12,500 18,750 25,000 31,250
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
Change the engine oil and engine oil filter. X X X X X
Rotate the tires. X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect the engine air filter element. Replace as
necessary.XXX
Replace the engine air filter element.XX
Replace the fuel filter/water separator unit. X
Inspect the brake linings. X X
Drain the transfer case and refill.X
Drain and refill the front and rear axles. X X
SCHEDULE ªBº Ð DIESEL ENGINE 453
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 37,500 43,750 50,000 56,250 62,500
(Kilometers) (60 000) (70 000) (80 000) (90 000) (100 000)
Change the engine oil and engine oil filter. X X X X X
Rotate the tires. X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Inspect the engine air filter element. Replace as
necessary.XX
Replace the engine air filter element.XXX
Replace the fuel filter/water separator unit. X
Replace the engine accessory drive belt. X
Inspect the brake linings. X X X
Drain and refill the front and rear axles. X X X
Drain and refill the transmission fluid, and change
the filter.X
Drain the transfer case and refill.X
454 SCHEDULE ªBº Ð DIESEL ENGINE
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 68,750 75,000 81,250 87,500 93,750 100,000
(Kilometers) (110 000) (120 000) (130 000) (140 000) (150 000) (160 000)
Change the engine oil and engine oil filter. X X X X X X
Rotate the tires. X X X
Check spare tire for proper pressure and cor-
rect stowage.XXXXXX
Inspect the engine air filter element. Re-
place as necessary.XXX
Replace the engine air filter element.XXX
Replace the engine accessory drive belt. X
Replace the fuel filter/water separator unit. X X
Flush and replace the engine coolant/anti-
freeze.X
Inspect the brake linings. X X
Drain the transfer case and refill. X
Drain and refill the front and rear axles. X X
SCHEDULE ªBº Ð DIESEL ENGINE 455
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
