Advanced Front Air Bags are designed to provide addi-
tional protection by supplementing the seat belts in
certain frontal collisions depending on the severity and
type of collision. Advanced Front Air Bags are not
expected to reduce the risk of injury in rear, side, or
rollover collisions.
The Advanced Front Air Bags will not deploy in all
frontal collisions, including some that may produce sub-
stantial vehicle damage — for example, some pole colli-
sions, truck underrides, and angle offset collisions. On
the other hand, depending on the type and location of
impact, Advanced Front Air Bags may deploy in crashes
with little vehicle front-end damage but that produce a
severe initial deceleration.
The side air bags will not deploy in all side collisions.
Side air bag deployment will depend on the severity and
type of collision.Because air bag sensors measure vehicle deceleration
over time, vehicle speed and damage by themselves are
not good indicators of whether or not an air bag should
have deployed.
Seat belts are necessary for your protection in all colli-
sions, and also are needed to help keep you in position,
away from an inflating air bag.
The ORC monitors the readiness of the electronic parts of
the air bag system whenever the ignition switch is in the
START or ON/RUN position. If the key is in the OFF
position, in the ACC position, or not in the ignition, the
air bag system is not on and the air bags will not inflate.
The ORC contains a backup power supply system that
may deploy the air bags even if the battery loses power or
it becomes disconnected prior to deployment.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73

CAUTION!
Do not use a portable battery booster pack or any
other booster source with a system voltage greater
than 12 Volts or damage to the battery, starter motor,
alternator or electrical system may occur.
WARNING!
Do not attempt jump-starting if the battery is frozen.
It could rupture or explode and cause personal injury.
Preparations For Jump-Start
The battery in your vehicle is located under the passen-
ger’s front seat. There are remote locations located under
the hood to assist in jump-starting.
Remote Battery Posts
1 — Remote Positive(+) Post (covered with protective cap)
2 — Remote Negative (-) Post
560 WHAT TO DO IN EMERGENCIES

Fluid Level Check................. 602,603
Fluid Type ......................... 601
Special Additives ..................... 602
Autostick ........................... 428,437
Auxiliary Electrical Outlet (Power Outlet) ...... 258
Auxiliary Power Outlet ................... 258
B-Pillar Location ........................ 483
Battery ............................... 583
Keyless Transmitter Replacement (RKE) ..... 27
Belts, Seat ............................ 52,96
Blind Spot Monitoring .................... 112
Body Mechanism Lubrication ............... 586
Brake Assist System ...................... 465
Brake Control System, Electronic ............. 464
Brake Fluid ............................ 598
Brake System ........................... 597
Anti-Lock (ABS) ..................... 464
Fluid Check ........................ 598 Master Cylinder
..................... 598
Parking ........................... 462
Warning Light ....................... 290
Brake/Transmission Interlock ............... 421
Break-In Recommendations, New Vehicle ........ 93
Bulb Replacement ..................... 616,617
Bulbs, Light ............................ 98
Calibration, Compass ..................... 319
Camera, Rear ........................... 237
Capacities, Fluid ........................ 622
Caps, Filler Fuel .............................. 517
Power Steering ...................... 461
Radiator (Coolant Pressure) ............. 595
Car Washes ............................ 605
Carbon Monoxide Warning ...............95,513
Cargo (Vehicle Loading) ................... 521
Cargo Area Cover ....................... 271
10
INDEX 657
