GETTING TO KNOW YOUR VEHICLE79
(Continued)
ignition switch is in the ON/RUN position, while the
outlets labeled with a battery symbol are
connected directly to the battery and powered at
all times.
NOTE:
All accessories connected to the battery
powered outlets should be removed or turned
off when the vehicle is not in use to protect the
battery against discharge.
Do not exceed the maximum power of 160 W
(13 Amp) at 12 Volt. If the 160 W (13 Amp)
power rating is exceeded the fuse protecting the
system needs to be replaced.
Power outlets are designed for accessory plugs
only. Do not insert any other object in the power
outlets as this will damage the outlet and blow
the fuse. Improper use of the power outlet can
cause damage not covered by your New Vehicle
Limited Warranty.
The front power outlet is located inside the storage
area on the center stack of the instrument panel,
below the climate controls.
Front Power Outlet

The rear cargo power outlet is located in the right
rear cargo area when the vehicle is equipped with
third row seating. When the vehicle is equipped
with only two row seating, the cargo area outlet is
located on the left side trim panel.

Rear Cargo Power Outlet (Third Row Seating)

NOTE:The rear cargo power outlet can be changed from
battery powered to powered by ignition in the ON/
RUN position by switching the cargo area power
outlet fuse from F44B to F44A in the rear power
distribution center Ú page 352.
WARNING!
To avoid serious injury or death:
Only devices designed for use in this type of
outlet should be inserted into any 12 Volt
outlet.
Do not touch with wet hands.
Close the lid when not in use and while driving
the vehicle.
If this outlet is mishandled, it may cause an
electric shock and failure.
CAUTION!
Many accessories that can be plugged in draw
power from the vehicle's battery, even when
not in use (i.e., cellular phones, etc.). Eventu -
ally, if plugged in long enough, the vehicle's
battery will discharge sufficiently to degrade
battery life and/or prevent the engine from
starting.
2

23_WL_OM_EN_USC_t.book Page 79

80GETTING TO KNOW YOUR VEHICLE
POWER INVERTER — IF EQUIPPED
There is a 115 Volt, 150 W inverter outlet located
on the back of the center console to convert DC
current to AC current. This outlet can power cellular
phones, electronics and other low power devices
requiring power up to 150 W. Certain video game
consoles exceed this power limit, as will most
power tools.
Power Inverter

The power inverter is designed with built-in
overload protection. If the power rating of 150 W is
exceeded, the power inverter automatically shuts
down. Once the electrical device has been
removed from the outlet the inverter should
automatically reset. To avoid overloading the
circuit, check the power ratings on electrical
devices prior to using the inverter.
WIRELESS CHARGING PAD —
I
F EQUIPPED

Wireless Charging Pad

Your vehicle may be equipped with a 15 W3 Amp
Qi wireless charging pad located inside of the
storage area below the climate controls. This
charging pad is designed to wirelessly charge your
Qi enabled mobile phone. Qi is a standard that
allows wireless charging of your mobile phone.
Your mobile phone must be designed for Qi
wireless charging. If the phone is not equipped
with Qi wireless charging functionality, an
aftermarket sleeve or a specialized back plate can
be purchased from your mobile phone provider or
a local electronics retailer. Please see your
phone’s owner’s manual for further information.
Accessories that draw higher power (i.e.,
coolers, vacuum cleaners, lights, etc.) will
degrade the battery even more quickly. Only
use these intermittently and with greater
caution.
After the use of high power draw accessories,
or long periods of the vehicle not being started
(with accessories still plugged in), the vehicle
must be driven a sufficient length of time to
allow the generator to recharge the vehicle's
battery.
CAUTION!
WARNING!
To avoid serious injury or death:
Do not insert any objects into the receptacles.
Do not touch with wet hands.
Close the lid when not in use.
If this outlet is mishandled, it may cause an
electric shock and failure.

23_WL_OM_EN_USC_t.book Page 80

GETTING TO KNOW YOUR VEHICLE81
The wireless charging pad is equipped with an
anti-slip mat to hold your mobile phone in place,
and an LED indicator light.
LED Indicator Status:
No Light: Charging pad is idle or searching for a
device.
Blue Light: Device is detected and is charging.
Red Light/Flashing: Internal error or foreign
object is detected.
Important Notes Regarding This Vehicle’s Wireless
Charging Pad:
All vehicle doors must be closed for the wireless
charging pad to operate.
If the phone moves on the pad causing the red
light to illuminate, the phone will have to be
picked up and placed back on the charging pad
to resume charging.
Wireless charging is not as fast as when the
phone is connected to a wired charger.
The phone’s protective case must be removed
when placed on the wireless charging pad.
iPhone® 12 (including iPod®) is equipped with
software to protect the device from overheating.
When the software is active, the rate of charge
is slowed down to protect the device.
Phones must always be placed on the wireless
charging pad within the outline shown on the
pad so that its charging parts connect with the charging coils of the system. Movement of the
phone during charging may prevent or slow the
rate of charge.
Having multiple applications open on the phone
while charging will reduce the charging effi
-
ciency, and may even shut down an application
that is actively running (i.e. Apple CarPlay®).
This may also cause the phone to overheat.
Wireless chargers may implement certain
methods to prevent the phone from overheating
during charging such as slowing down the rate
of charge. In certain instances, the device may
shut down for a brief period of time (when the
device reaches a certain temperature). If this
happens, it does not mean there is a fault with
the wireless charing pad. This may just be a
protective measure to prevent damage to the
phone.
WINDOWS
POWER WINDOW CONTROLS
The power window controls, located on the driver's
door trim panel, operate the window movement for
all four power windows.
There is a single switch on the front passenger
door and rear passenger doors which operates the
windows for only that door.

Driver’s Door Power Window Switches

NOTE:
The power window switches remain active for up
to 10 minutes after the ignition has been placed
in the OFF position. Opening a vehicle front door
will cancel this feature.
CAUTION!
The key fob should not be placed on the
charging pad or within 6 inches (15 cm) of it.
Doing so can cause excessive heat buildup and
damage to the fob. Placing the fob in close
proximity of the charging pad blocks the fob from
being detected by the vehicle and prevents the
vehicle from starting.
2

23_WL_OM_EN_USC_t.book Page 81

82GETTING TO KNOW YOUR VEHICLE
The window controls will operate only when the
vehicle’s ignition is placed in the ON/RUN posi -
tion.
The power windows may be operated from
outside of the vehicle by using the key fob. For
more information, see Ú page 19.
Automatic Window Features
Both the driver and front passenger windows, and
if equipped, both rear windows, may have
Auto-Down and Auto-Up operations.
Auto-Down Feature
For windows equipped with the AUTO feature, push
the window switch down to the second detent,
release, and the window will go down
automatically. To stop the window from going all the way down
during the Auto-Down operation, pull up or push
down on the switch briefly.
Auto-Up Feature With Anti-Pinch Protection
For windows equipped with the AUTO feature, lift
the window switch up to the second detent, and
release; the window will go up automatically.
To stop the window from going all the way up
during the Auto-Up operation, push down on the
switch briefly.
To close the window part way, lift the window
switch briefly and release it when you want the
window to stop.
For vehicles equipped with anti-pinch protection, if
the window runs into any obstacle during
auto-closure, it will reverse direction and then go
back down. Remove the obstacle and use the
window switch again to close the window.
NOTE:Any impact due to rough road conditions may
trigger the auto-reverse function unexpectedly
during auto-closure. If this happens, pull the switch
lightly and hold to close the window manually.
Reset Auto-Up
Should the Auto-Up feature stop working, the
window may need to be reset. To reset Auto-Up:
Front Doors

1. Pull the window switch up to close the window
completely and continue to hold the switch up
for an additional two seconds after the
window is closed.

Rear Doors

1. Pull the window switch up to close the window completely and continue to hold the switch up
for an additional two seconds after the
window is closed.

2. Release the window switch, and within five seconds, pull the window switch up again for
an additional two seconds.
WARNING!
Never leave children unattended in a vehicle,
and do not let children play with power windows.
Do not leave the key fob in or near the vehicle, or
in a location accessible to children, and do not
leave the Keyless Enter ‘n Go™ Ignition in the
ON/RUN position. Occupants, particularly
unattended children, can become entrapped by
the windows while operating the power window
switches. Such entrapment may result in serious
injury or death.
WARNING!
There is no anti-pinch protection when the
window is almost closed. To avoid personal
injury be sure to clear your arms, hands, fingers
and all objects from the window path before
closing.

23_WL_OM_EN_USC_t.book Page 82

GETTING TO KNOW YOUR VEHICLE83
Window Lockout Switch
The window lockout switch on the driver's door trim
panel allows you to disable the window controls on
the rear passenger doors. To disable the window
controls, push and release the window lockout
button (the indicator light on the button will turn
on). To enable the window controls, push and
release the window lockout button again (the
indicator light on the button will turn off).

Power Window Lockout Switch

WIND BUFFETING
Wind buffeting can be described as the perception
of pressure on the ears or a helicopter-type sound
in the ears. Your vehicle may exhibit wind buffeting
with the windows down, or the sunroof (if
equipped) in certain open or partially open
positions. This is a normal occurrence and can be
minimized. If the buffeting occurs with the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting
occurs with the sunroof open, adjust the sunroof
opening to minimize the buffeting or open any
window.
POWER SUNROOF — IF EQUIPPED
SINGLE PANE POWER SUNROOF —
I
F EQUIPPED
The power sunroof switches are located on the
overhead console between the courtesy/reading
lights.

Power Sunroof Switches

1 — Opening/Closing Sunroof
2 — Venting Sunroof
WARNING!
Never leave children unattended in a vehicle,
or with access to an unlocked vehicle. Never
leave the key fob in or near the vehicle, or in a
location accessible to children. Do not leave
the Keyless Enter ‘n Go™ Ignition in the ON/
RUN position. Occupants, particularly unat -
tended children, can become entrapped by
the power sunroof while operating the power
sunroof switch. Such entrapment may result
in serious injury or death.
In a collision, there is a greater risk of being
thrown from a vehicle with an open sunroof.
You could also be seriously injured or killed.
Always fasten your seat belt properly and
make sure all passengers are also properly
secured.
Do not allow small children to operate the
sunroof. Never allow your fingers, other body
parts, or any object, to project through the
sunroof opening. Injury may result.
2

23_WL_OM_EN_USC_t.book Page 83

84GETTING TO KNOW YOUR VEHICLE
Opening And Closing The Sunroof
Express Open/Close
To open the sunroof, push OPEN on the sunroof
switch and release it within one-half second and
the sunroof will open automatically from any
position.
To close the sunroof, push CLOSE on the sunroof
switch and release it within one-half second and
the sunroof will close automatically from any
position.
During Express Open or Express Close operation,
any other actuation of the sunroof switch will stop
the sunroof.
Manual Open/Close
To open the sunroof, push and hold OPEN on the
sunroof switch.
To close the sunroof, push and hold CLOSE on the
sunroof switch.
Any release of the switch during open or close
operation will stop the sunroof movement in a
partially open position. The sunroof will remain in a
partially opened position until the switch is
operated and held again. Express Venting The Sunroof
To vent the sunroof, push TILT on the vent switch
and release within one half second. The sunroof
will open to the vent position regardless of its initial
position. During Express Vent operation, any other
actuation of the switch will stop the sunroof.
NOTE:If the sunshade is in the closed position when
Express/Manual Open or Vent operation is
initiated, the sunshade will automatically open
with the sunroof glass.
Pinch Protect Feature
This feature will detect an obstruction in the
opening of the sunroof during Express Close
operation. If an obstruction in the path of the
sunroof is detected, the sunroof will automatically
retract. Remove the obstruction if this occurs.
NOTE:If three consecutive sunroof close attempts result
in Pinch Protect reversals, Pinch Protect will
disable and the sunroof must be closed in Manual
Mode.
Sunshade Operation
The sunshade can be opened manually. However,
the sunshade will open automatically as the
sunroof opens.
NOTE:The sunshade cannot be closed if the sunroof is
open.
Ignition Off Operation
The power sunroof switch will remain active for up
to approximately 10 minutes after the ignition
switch is placed in the OFF position. Opening either
front door will cancel this feature.
NOTE:Ignition Off timing is programmable through the
Uconnect system Ú
page 204.
Sunroof Maintenance
Use only a non-abrasive cleaner and a soft cloth to
clean the glass panel. Periodically check for and
clear out any debris that may have collected in the
tracks.

23_WL_OM_EN_USC_t.book Page 84

GETTING TO KNOW YOUR VEHICLE85
DUAL PANE POWER SUNROOF —
I
F EQUIPPED
The power sunroof switches are located on the
overhead console between the courtesy/reading
lights.

Power Sunroof Switches

Opening And Closing The Sunroof
The sunroof has two programmed automatic stops
for the sunroof open position: a comfort stop
position and a full open position. The comfort stop
position will minimize wind buffeting in the interior. Express Open/Close
To open the sunroof, push OPEN on the sunroof
switch and release it within one-half second. The
sunroof will open to the comfort stop position and
stop automatically. Push and release OPEN again
to continue to the full open position.
To close the sunroof, push CLOSE on the sunroof
switch and release it within one-half second. The
sunroof will close automatically from any position.
During Express Open or Express Close operation,
any other actuation of the sunroof switch will stop
the sunroof.
Manual Open/Close
To open the sunroof, push and hold OPEN on the
sunroof switch. The sunroof will open to the
comfort stop position, then automatically stop.
Release the switch then push and hold again to
continue to the full open position.
To close the sunroof, push and hold CLOSE on the
sunroof switch.
Any release of the switch during open or close
operation will stop the sunroof movement in a
partially open position.
1 — Opening/Closing Sunroof
2 — Venting Sunroof
3 — Opening/Closing Sunshade
WARNING!
Never leave children unattended in a vehicle,
or with access to an unlocked vehicle. Never
leave the key fob in or near the vehicle, or in a
location accessible to children. Do not leave
the Keyless Enter ‘n Go™ Ignition in the ON/
RUN position. Occupants, particularly unat
-
tended children, can become entrapped by
the power sunroof while operating the power
sunroof switch. Such entrapment may result
in serious injury or death.
In a collision, there is a greater risk of being
thrown from a vehicle with an open sunroof.
You could also be seriously injured or killed.
Always fasten your seat belt properly and
make sure all passengers are also properly
secured.
Do not allow small children to operate the
sunroof. Never allow your fingers, other body
parts, or any object, to project through the
sunroof opening. Injury may result.
2

23_WL_OM_EN_USC_t.book Page 85

86GETTING TO KNOW YOUR VEHICLE
Express Venting The Sunroof
To vent the sunroof, push TILT on the vent switch
and release within one half second. The sunroof
will open to the vent position regardless of its initial
position. During Express Vent operation, any other
actuation of the switch will stop the sunroof.
NOTE:If the sunshade is in the closed position when
Express/Manual Open or Vent operation is
initiated, the sunshade will automatically open to
the half open position prior to the sunroof opening.
Opening And Closing The Power Sunshade
The sunshade has two programmed open
positions: half open and full open positions. When
operating the sunshade from the closed position,
the sunshade will always stop at the half open
position regardless of express or manual open
operation. The switch must be pushed again to
continue on to full open position.
If the sunroof is open or vented, the sunshade
cannot be closed beyond the half open position.
Pushing the sunshade close switch when the
sunroof is open/vented and the sunshade is at half
open position will first automatically close the
sunroof prior to the sunshade closing. Express Open/Close
To open the sunshade, push OPEN on the
sunshade switch and release it within one-half
second, the sunshade will open to the half open
position and stop automatically. Push and release
OPEN again to continue to open the sunshade to
the full open position.
To close the sunshade, push CLOSE on the
sunshade switch and release it within one-half
second.
During Express Open or Express Close operation,
any other actuation of the sunroof switches will
stop the sunshade in a partially open position.
Manual Open/Close
To open the sunshade, push and hold OPEN on the
sunshade switch, the sunshade will open to the
half open position and stop automatically. Push
and hold OPEN again to continue to open the
sunshade to the full open position.
To close the sunshade, push and hold CLOSE on
the sunshade switch.
Releasing the switch while the sunshade is in
motion will stop the sunshade in a partially open
position.
Pinch Protect Feature
This feature will detect an obstruction in the
opening of the sunroof during Express Close
operation. If an obstruction in the path of the
sunroof is detected, the sunroof will automatically
retract. Remove the obstruction if this occurs.
NOTE:If three consecutive sunroof close attempts result
in Pinch Protect reversals, Pinch Protect will
disable and the sunroof must be closed in Manual
Mode.
Ignition Off Operation
The power sunroof switch will remain active for up
to approximately 10 minutes after the ignition
switch is placed in the OFF position. Opening either
front door will cancel this feature.
NOTE:Ignition Off timing is programmable through the
Uconnect system Ú
page 204.
Sunroof Maintenance
Use only a non-abrasive cleaner and a soft cloth to
clean the glass panel. Periodically check for and
clear out any debris that may have collected in the
tracks.

23_WL_OM_EN_USC_t.book Page 86

GETTING TO KNOW YOUR VEHICLE87
HOOD
OPENING THE HOOD
To open the hood, two latches must be released.

1. Pull the release lever located at the bottom of
the driver’s side of the instrument panel.

Hood Release
2. Reach under the hood from outside the
vehicle, move the safety latch to the left and
lift the hood.

Safety Latch Location

NOTE:
Vehicle must be at a stop and the gear selector
must be in PARK.
While lifting the hood, use both hands.
Before lifting the hood, check that the wiper
arms are not in motion and not in the lifted posi -
tion.
CLOSING THE HOOD
In one continuous motion, pull down on the front
edge of the hood with moderate force until the
angle is below the crossover point (where the gas
props are no longer resisting) and let the hood
continue to fall closed from its own inertia.
WARNING!
Be sure the hood is fully latched before driving
your vehicle. If the hood is not fully latched, it
could open when the vehicle is in motion and
block your vision. Failure to follow this warning
could result in serious injury or death.
2

23_WL_OM_EN_USC_t.book Page 87

88GETTING TO KNOW YOUR VEHICLE
LIFTGATE
TO UNLOCK/OPEN THE LIFTGATE
The power liftgate may be opened by
pushing the liftgate button on the key fob
or by pushing the electronic liftgate
release button.
Push the liftgate button on the key fob twice within
five seconds to open the power liftgate. Once the
liftgate is open, pushing the button twice within
five seconds a second time will close the liftgate.

Liftgate Entry

NOTE:
When you push the electronic liftgate release button,
either only the liftgate will unlock, or all the doors and
the liftgate will unlock, depending on the selected
setting in the Uconnect system
Ú
page 204.

NOTE:
Use the power door lock switch on either front
door trim panel or the key fob to lock and unlock
the liftgate.
The driver's door lock cylinder will not lock or
unlock the liftgate.
NOTE:The liftgate can also be opened manually by
pushing the electronic liftgate release button and
pulling upward in one fluid motion.
TO LOCK/CLOSE THE LIFTGATE
There are several different ways to close the
liftgate:
Manually (grab the liftgate closing handle and
pull in a downward motion)
Key fob
Hands-free (if equipped)
Liftgate close button in the cargo area
With a valid Passive Entry key fob within 5 ft
(1.5 m) of the liftgate, pushing the Passive Entry
button located to the left of the electronic liftgate
release button, will lock the vehicle only.
If the liftgate is fully open, the liftgate can be closed
by pushing the liftgate close button located in the
cargo area on the left rear trim panel, near the
liftgate opening. If the liftgate is in motion, pushing
the liftgate close button a second time will reverse
the liftgate operation.

Liftgate Close Button

1 — Passive Entry Button
2 — Electronic Liftgate Release Button
WARNING!
Driving with the liftgate open can allow
poisonous exhaust gases into your vehicle. You
and your passengers could be injured by these
fumes. Keep the liftgate closed when you are
operating the vehicle.

23_WL_OM_EN_USC_t.book Page 88
