Drivers must be careful when backing up
even when using ParkSense. Always check
carefully behind your vehicle, look behind
you, and be sure to check for pedestrians,
animals, other vehicles, obstructions, and
blind spots before backing up. You are
responsible for safety and must continue to
pay attention to your surroundings. Failure
to do so can result in serious injury or
death.
Before using ParkSense, it is strongly
recommended that the ball mount and
hitch ball assembly be disconnected from
the vehicle when the vehicle is not used for
towing. Failure to do so can result in injury
or damage to vehicles or obstacles
because the hitch ball will be much closer
to the obstacle than the rear fascia when
the vehicle sounds the continuous tone.
Also, the sensors could detect the ball
mount and hitch ball assembly, depending
on its size and shape, giving a false indica-
tion that an obstacle is behind the vehicle.
CAUTION!
ParkSense is only a parking aid and it is
unable to recognize every obstacle,
including small obstacles. Parking curbs
might be temporarily detected or not
detected at all. Obstacles located above or
below the sensors will not be detected
when they are in close proximity.
The vehicle must be driven slowly when
using ParkSense in order to be able to stop
in time when an obstacle is detected. It is
recommended that the driver looks over
his/her shoulder when using ParkSense.
WARNING ALERTS
Distance
(inches/cmyf Less than
12 inches (30 cmyf 12–24 inches
(30–60 cmyf
Arcs-Left Flashing Flashing
Arcs-Right Flashing Flashing
Audible Alert Chime Continuous Fast audible
chime as the objects get
close to the vehicle.
Radio Volume Reduced Yes
Yes
4
21_WL_OM_EN_USC_t.book Page 169
: $ 5 1 , 1 *
Drivers must be careful when backing up
even when using ParkSense. Always check
carefully behind your vehicle, look behind
you, and be sure to check for pedestrians,
animals, other vehicles, obstructions, and
blind spots before backing up. You are
responsible for safety and must continue to
pay attention to your surroundings. Failure
to do so can result in serious injury or
death.
: $ 5 1 , 1 *
Drivers must be careful when performing
parallel or perpendicular parking maneu-
vers even when using the ParkSense Active
Park Assist system. Always check carefully
behind and in front of your vehicle, look
behind and in front of you, and be sure to
check for pedestrians, animals, other vehi -
cles, obstructions, and blind spots before
backing up and moving forward. You are
responsible for safety and must continue to
pay attention to your surroundings. Failure
to do so can result in serious injury or
death.
WARNING!
4
