JEEP LIBERTY 2002 KJ / 1.G Workshop Manual

A/C-HEATER CONTROL C2 - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1 C35 20DG/YL MODE DOOR DRIVER (A)
2 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
3- -
4- -
5- -
6 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
7- -
8 Z12 20BK/TN GROUND
9- -
10 - -
11 - -
12 C16 20LB/YL FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
ACCELERATOR PEDAL POSITION SENSOR (DIESEL) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 K4 18BK/LB SENSOR GROUND
5 K151 20WT LOW IDLE POSITION SWITCH SENSE
6- -
7 K81 20VT/TN ACCELERATOR PEDAL POSITION SENSOR SIGNAL
8 K255 20WT/DG ACCELERATOR PEDAL POSITION SENSOR GROUND
9- -
10 K852 20VT/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER SQUIB 1 LINE 2
2 R43 18BK/LB DRIVER SQUIB 1 LINE 1
3- -
4- -
5 R53 18OR/YL DRIVER SEAT BELT TENSIONER LINE 2
6 R55 18OR/BK DRIVER SEAT BELT TENSIONER LINE 1
7 R61 18OR/LB DRIVER SQUIB 2 LINE 1
8 R63 18TN/LB DRIVER SQUIB 2 LINE 2
9 R62 18OR/YL PASSENGER SQUIB 2 LINE 2
10 R64 18TN/YL PASSENGER SQUIB 2 LINE 1
11 R42 18BK/YL PASSENGER SQUIB 1 LINE 1
12 R44 18DG/YL PASSENGER SQUIB 1 LINE 2
13 - -
14 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
15 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
16 Z6 18BK/PK GROUND
8Wa - 80 - 6 8W-80 CONNECTOR PIN-OUTSKJ

AIRBAG CONTROL MODULE C1 (ORC C1) - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
17 - -
18 - -
19 - -
20 - -
21 D25 18YL/VT/OR PCI BUS
22 - -
23 - -
AIRBAG CONTROL MODULE C2 (ORC C2) - BLACK 12 WAY
CAV CIRCUIT FUNCTION
1- -
2 R59 20LB DRIVER SEAT BELT SWITCH GROUND
3 R57 20DG DRIVER SEAT BELT SWITCH SENSE
4- -
5 R60 20VT PASSENGER SEAT BELT SWITCH GROUND
6 R58 20GY PASSENGER SEAT BELT SWITCH SENSE
7 R48 20TN RIGHT FRONT IMPACT SENSOR SIGNAL
8 R46 20BR/LB RIGHT FRONT IMPACT SENSOR GROUND
9- -
10 - -
11 R47 20DB/LB LEFT FRONT IMPACT SENSOR GROUND
12 R49 20LB/OR LEFT FRONT IMPACT SENSOR SIGNAL
AMBIENT TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G31 18VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
2 G32 18DB/OR AMBIENT TEMPERATURE SENSOR RETURN
ANTENNA (EXCEPT BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-7

ANTENNA MODULE C1 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 F85 16VT/WT FUSED IGNITION SWITCH OUTPUT (RUN--ACC)
2- -
ANTENNA MODULE C2 (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 X30 BK RADIO ANTENNA CORE
2 X31 BK RADIO ANTENNA SHIELD
ASH RECEIVER LAMP-2WAY
CAV CIRCUIT FUNCTION
1 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z158 20BK/GY GROUND
BACK-UP LAMP SWITCH (M/T) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
2 L10 18BR/LG BACK-UP LAMP FEED
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K118 18PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
8Wa - 80 - 8 8W-80 CONNECTOR PIN-OUTSKJ

BLEND DOOR ACTUATOR - WHITE 4 WAY
CAV CIRCUIT FUNCTION
1 Z12 18BK/TN GROUND
2 C35 20DG/YL MODE DOOR DRIVER (A)
3 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
4- -
BLOWER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
2 A111 12RD/LB BLOWER MOTOR RELAY OUTPUT
BLOWER MOTOR RESISTOR BLOCK - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
3 C6 12LB BLOWER MOTOR M2 DRIVER
4 C5 14LG BLOWER MOTOR M1 DRIVER
5 C4 14TN BLOWER MOTOR LOW DRIVER
6- -
7- -
8- -
9- -
10 - -
BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 Z103 16BK/OR GROUND
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4 G75 20TN DRIVER DOOR AJAR SWITCH SENSE
5 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
6 G70 20BR/TN (EXCEPT BASE) HOOD AJAR SWITCH SENSE
7 G78 20TN/BK TAILGATE AJAR SWITCH SENSE
8 G26 20LB KEY-IN IGNITION SWITCH SENSE
9 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
10 M3 20PK/DB REAR COURTESY LAMP CONTROL
11 V10 18BR WASHER PUMP DRIVER
12 L91 20DB/PK HAZARD LAMP CONTROL
13 V21 20DB/RD REAR WIPER ON DRIVER
14 Z231 16BK/WT SIGNAL GROUND
15 D25 18YL/VT/WT PCI BUS
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-9

BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
16 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
17 P101 20OR/PK FLIP-UP GLASS RELEASE SWITCH SENSE
18 - -
19 - -
20 B22 18LG/YL VEHICLE SPEED OUTPUT
21 G69 20BK/OR VTSS INDICATOR DRIVER
22 - -
23 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
24 C19 18BR A/C ON/OFF CONTROL
25 Z3 16BK/OR GROUND
26 P100 18OR/BR FLIP-UP GLASS RELEASE MOTOR DRIVER
BODY CONTROL MODULE C2 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 Y66 20GY (EXCEPT BASE) RKE ANTENNA
2 G910 20VT/BR TAILGATE SWITCH GROUND
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 G72 18DG/OR (LHD PREMIUM) RIGHT CYLINDER LOCK SWITCH MUX
6 G73 18LG/OR (RHD) RIGHT CYLINDER LOCK SWITCH MUX
7 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
8 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
9 G72 18DG/OR (RHD) LEFT CYLINDER LOCK SWITCH MUX
9 G73 18LG/OR (LHD PREMIUM) LEFT CYLINDER LOCK SWITCH MUX
10 V52 20DG/RD FRONT WIPER SWITCH MUX
11 X10 20RD/DB (EXCEPT BASE) RADIO CONTROL MUX RETURN
12 Y66 20GY (EXCEPT BASE) RKE ANTENNA
13 - -
14 - -
15 G32 20DB/OR (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR RETURN
16 - -
17 G71 18VT/YL TAILGATE CYLINDER LOCK SWITCH MUX
18 G31 20VT/LG (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR SIGNAL
19 L324 20WT/LG HIGH BEAM SWITCH SENSE
20 F512 18PK/OR VEHICLE SPEED SENSOR SUPPLY
21 B12 18DG/OR VEHICLE SPEED SIGNAL
22 X20 20RD/BK (EXCEPT BASE) RADIO CONTROL MUX
BODY CONTROL MODULE C3 (PREMIUM)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 10 8W-80 CONNECTOR PIN-OUTSKJ

BOOST PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
3 K6 18VT/WT SENSOR REFERENCE VOLTAGE B
4 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
BRAKE LAMP SWITCH - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F32 18PK/DB FUSED B(+)
2 L50 18WT/TN (GAS) BRAKE LAMP SWITCH OUTPUT
2 L50 18WT/TN (DIESEL) PRIMARY BRAKE SWITCH SIGNAL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 V32 18YL/RD SPEED CONTROL SUPPLY
5 Z3 18BK/OR GROUND
6 K29 18WT/PK (GAS) BRAKE SWITCH SENSE
6 K29 18WT/PK (DIESEL) SECONDARY BRAKE SWITCH SIGNAL
BRAKE PRESSURE SWITCH (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
C100 (RHD) - GRAY (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 L43 18VT
2 F1 20DB
3 M1 18PK
4 B22 18LG/YL
5 L44 18VT/RD
6 V16 18VT/YL
7 V55 16TN/RD
8 G32 20DB/OR
9 D20 20LG
10 D25 18YL/VT/BR
11 V14 18RD/VT
12 L13 18BR/YL
13 G70 20BR/TN
14 G11 20WT/BK
15 K4 20BK/LB
16 L50 18WT/TN
17 L62 18BR/RD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-11

C100 (RHD) - GRAY (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
18 L62 18DG/RD
19 V30 18DB/RD
20 D32 20LG/DG
21 V32 18YL/RD
22 G29 20BK/TN
23 X2 18DG/RD
24 F15 18DB/WT
25 G18 20PK/BK
26 D24 18WT/DG
27 B12 18DG/OR
28 R46 20BR/LB
29 R48 20TN
30 R47 20DB/LB
31 R49 20LB/OR
32 -
33 -
34 -
35 F512 18PK/OR
36 -
37 Z252 18BK/GY
38 Z252 18BK/GY
39 V10 18BR
40 -
41 T6 20VT/WT
42 V37 20RD/LG
43 V20 18BK/WT
44 K29 18WT/PK
45 D25 18YL/VT/GY
46 -
47 X75 18DG
48 L10 18BR/LG
49 D21 20PK/RD
50 F22 18DB/PK
51 L33 18LG/BR
52 L39 18LB
53 L78 18DG/YL
54 F20 18WT
55 V6 14DB/YL
56 G31 20VT/LG
57 -
58 L34 18RD/OR
59 L77 18BK/YL
60 -
61 A41 12YL
62 A21 12RD/DB
63 A1 12RD
64 A111 12RD/LB
65 A12 10RD/TN
66 A13 10PK/WT
67 A18 10PK
68 A7 10RD/BK
69 A2 12PK/BK
70 A25 12DB
71 A4 12BK/PK
72 A99 14RD/VT
8Wa - 80 - 12 8W-80 CONNECTOR PIN-OUTSKJ

C100 (LHD) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 B1 18YL/DB
2 B2 18YL
3 K226 18DB/WT
4 B22 18DG/YL
5 K106 18WT/DG (GAS)
6 K107 18OR (GAS)
7 K125 18WT/DB (GAS)
8 G32 18DB/OR
9 D20 18LG (GAS)
10 D25 18YL/VT
11 -
12 L13 18BR/YL (BUILT-UP-EXPORT)
13 G70 18BR/TN (BUILT-UP-EXPORT)
14 G11 18WT/BK
15 K4 18BK/LB
16 -
17 L62 18BR/RD
18 L63 18DG/RD
19 V30 18DB/RD (GAS)
20 D32 18LG (GAS)
21 V32 18YL/RD (GAS)
22 G29 18BK/TN
23 -
24 F15 18DB/WT
25 G18 18PK/BK (DIESEL)
26 D24 18WT/DG (ABS)
27 B12 18DG/OR (ABS)
27 B1 18YL/DB (EXCEPT ABS)
28 R46 18BR/LB
29 R48 18TN
30 R47 18DB/LB
31 R49 18LB
32 -
33 -
34 -
35 B2 18YL (EXCEPT ABS)
36 -
37 Z252 18BK/GY
38 Z252 18BK/GY
39 V10 18BR
40 T138 18GY/LB (DIESEL)(M/T)
41 T6 18VT/WT (GAS)
42 V37 18RD/LG
43 V20 18BK/WT
44 K29 18WT/PK
45 D25 18YL/VT
46 -
47 X75 18DG (BUILT-UP-EXPORT)
48 L10 18BR/LG
49 D21 18PK
50 -
51 -
52 -
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-13

C100 (LHD) - GRAY (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
53 -
54 -
55 -
56 G31 18VT/LG
57 -
58 -
59 -
60 A32 14RD/DB (A/T)
61 A41 12YL
62 A21 12RD/DB (M/T)
63 A1 12RD
64 A111 12RD/LB
65 A99 14RD/VT
66 -
67 -
68 -
69 A2 12PK/BK
70 A25 12DB
71 -
72 A141 16DG/WT (GAS)
C100 (LHD) - GRAY (INSTRUMENT PANEL
SIDE)
CAV CIRCUIT
1 B1 18YL/DB
2 B2 18YL
3 K226 18DB/WT
4 B22 18LG/YL
5 K106 18WT/DG
6 K107 18OR
7 K125 18WT/DB
8 G32 20DB/OR (EXCEPT BASE)
9 D20 20LG
10 D25 18YL/VT/BR
11 -
12 L13 18BR/YL (BUILT-UP-EXPORT)
13 G70 20BR/TN (EXCEPT BASE)
14 G11 20WT/BK
15 K4 18BK/LB
16 -
17 L62 18BR/RD
18 L63 18DG/RD
19 V30 18DB/RD
20 D32 20LG/DG
21 V32 18YL/RD
22 G29 20BK/TN
23 -
24 F15 18DB/WT
25 G18 20PK/BK
26 D24 18WT/DG
27 B12 18DG/OR
8Wa - 80 - 14 8W-80 CONNECTOR PIN-OUTSKJ

C100 (LHD) - GRAY (INSTRUMENT PANEL
SIDE)
CAV CIRCUIT
28 R46 20BR/LB
29 R48 20TN
30 R47 20DB/LB
31 R49 20LB/OR
32 -
33 -
34 -
35 F512 18PK/OR
36 -
37 Z252 18BK/GY
38 Z252 18BK/GY
39 V10 18BR
40 -
41 T6 20VT/WT
42 V37 20RD/LG
43 V20 18BK/WT
44 K29 18WT/PK
45 D25 18YL/VT/GY
46 -
47 X75 18 DG (EXCEPT BASE)
48 L10 18BR/LG
49 D21 20PK/RD
50 -
51 -
52 -
53 -
54 -
55 -
56 G31 20VT/LG (EXCEPT BASE)
57 -
58 -
59 --
60 -
61 A41 12YL
62 A21 12 RD/DB
63 A1 12RD
64 A111 12RD/LB
65 A99 14RD/VT
66 -
67 -
68 -
69 A2 12PK/BK
70 A25 12DB
71 -
72 A141 16DG/WT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-15
