JEEP LIBERTY 2002 KJ / 1.G Workshop Manual

REAR POWER WINDOW SWITCH (MIDLINE/HIGHLINE) - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 Q28 14DG/WT RIGHT REAR WINDOW DRIVER DOWN
2 Q14 14GY RIGHT REAR WINDOW DRIVER UP
3 Q24 14DG RIGHT REAR WINDOW DRIVER DOWN
4 Q18 14GY/BK RIGHT REAR WINDOW DRIVER UP
5 Q1 16YL POWER WINDOW SWITCH FEED
6 Q1 16YL POWER WINDOW SWITCH FEED
7 Q17 14DB/WT LEFT REAR WINDOW DRIVER UP
8 Q23 14RD/WT LEFT REAR WINDOW DRIVER DOWN
9 Q27 14RD/BK LEFT REAR WINDOW DRIVER DOWN
10 Q13 14DB LEFT REAR WINDOW DRIVER UP
REAR WHEEL SPEED SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B2 18YL REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
2 B1 18YL/DB REAR WHEEL SPEED SENSOR SIGNAL
REAR WIPER MOTOR - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z235 18BK GROUND
2 V21 20DB/RD REAR WIPER ON DRIVER
3 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
4 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
5 F70 18PK/BK FUSED B(+)
6- -
RED BRAKE WARNING INDICATOR SWITCH - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 G11 18WT/BK RED BRAKE WARNING INDICATOR DRIVER
2 Z142 18BK/WT GROUND
REMOTE KEYLESS ENTRY MODULE (EXCEPT BASE)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 86 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT COURTESY LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL COURTESY LAMP DRIVER
RIGHT CURTAIN AIRBAG - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R76 18YL/DB RIGHT CURTAIN SQUIB LINE 2
2 R74 18YL/BR RIGHT CURTAIN SQUIB LINE 1
RIGHT CYLINDER LOCK SWITCH (EXCEPT BASE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 P37 18LG DOOR LOCK SWITCH GROUND
2 G72 18DG/OR (LHD) RIGHT CYLINDER LOCK SWITCH MUX
2 G73 18LG/OR (RHD) RIGHT CYLINDER LOCK SWITCH MUX
RIGHT DOOR LOCK SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 P36 20PK/VT DOOR LOCK SWITCH MUX
2 Z351 18BK/LG GROUND
3 F89 20OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 P37 20LG DOOR LOCK SWITCH GROUND
RIGHT FOG LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A Z142 18BK/WT GROUND
B L39 18LB FOG LAMP RELAY OUTPUT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-87

RIGHT FRONT DOOR AJAR SWITCH (BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z351 20BK/LG GROUND
RIGHT FRONT DOOR LOCK MOTOR/AJAR SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G75 20TN (RHD) DRIVER DOOR AJAR SWITCH SENSE
1 G74 20TN/WT (LHD) PASSENGER DOOR AJAR SWITCH SENSE
2 Z351 20BK/LG GROUND
3 P34 18PK/BK (RHD) DRIVER DOOR UNLOCK RELAY OUTPUT
3 P35 18OR/VT (LHD) PASSENGER DOOR UNLOCK RELAY OUTPUT
4 P33 18OR/BK DOOR LOCK RELAY OUTPUT
RIGHT FRONT DOOR SPEAKER (BASE)-2WAY
CAV CIRCUIT FUNCTION
1 X54 18VT RIGHT FRONT SPEAKER (+)
2 X56 18DB/RD RIGHT FRONT SPEAKER (-)
RIGHT FRONT DOOR SPEAKER (PREMIUM) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 X54 18VT RIGHT FRONT SPEAKER (+)
2 X56 18DB/RD RIGHT FRONT SPEAKER (-)
3 Z9 16BK GROUND
4 X86 18OR/RD AMPLIFIED HIGH RIGHT FRONT SPEAKER (-)
5 X92 18TN/BK AMPLIFIED LOW RIGHT REAR SPEAKER (-)
6 X58 18DB/OR RIGHT REAR DOOR SPEAKER (-)
7 X52 18DB/WT RIGHT REAR DOOR SPEAKER (+)
8 X13 16BK/RD RADIO CHOKE OUTPUT
9 X84 18TN/BK AMPLIFIED HIGH RIGHT FRONT SPEAKER (+)
10 X94 18TN/VT AMPLIFIED LOW RIGHT REAR SPEAKER (+)
RIGHT FRONT IMPACT SENSOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 R46 18BR/LB RIGHT FRONT IMPACT SENSOR GROUND
4 R48 18TN RIGHT FRONT IMPACT SENSOR SIGNAL
8Wa - 80 - 88 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT FRONT PARK/ TURN SIGNAL LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L62 18BR/RD RIGHT TURN SIGNAL
2 L78 18DG/YL (EXCEPT BUILT-UP-EX-
PORT)FUSED PARK LAMP RELAY OUTPUT
3 Z142 18BK/WT GROUND
RIGHT FRONT POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q22 16VT/WT RIGHT FRONT WINDOW DRIVER DOWN
2 Q12 16BR RIGHT FRONT WINDOW DRIVER UP
RIGHT FRONT WHEEL SPEED SENSOR (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
2 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
RIGHT HEADLAMP (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
2 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
3 Z142 18BK/WT GROUND
RIGHT HEADLAMP (EXCEPT BUILT-UP-EXPORT) - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
B Z142 18BK/WT GROUND
C L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-89

RIGHT HEATED SEAT ASSEMBLY (HIGHLINE) - LT. GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 F98 16RD/WT PASSENGER HEATED SEAT FEED
2 Z238 16BK/WT GROUND
3 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
4 P142 20TN/DB PASSENGER HEATED SEAT TEMPERATURE SENSOR
GROUND
RIGHT HEATED SEAT SWITCH (HIGHLINE) - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 P140 20VT/BK RIGHT SEAT HIGH HEAT LED DRIVER
3 P134 20TN/LG RIGHT SEAT HEATER SWITCH MUX
4 P138 20VT/LG RIGHT SEAT LOW HEAT LED DRIVER
5 Z238 20BK/WT GROUND
6- -
7- -
8- -
RIGHT INSTRUMENT PANEL SPEAKER - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 X84 18TN/BK (PREMIUM) AMPLIFIED HIGH RIGHT FRONT SPEAKER (+)
1 X54 18VT (BASE) RIGHT FRONT SPEAKER (+)
2 X86 18OR/RD (PREMIUM) AMPLIFIED HIGH RIGHT FRONT SPEAKER (-)
2 X56 18DB/RD (BASE) RIGHT FRONT SPEAKER (-)
RIGHT LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z142 18BK/WT GROUND
2 L13 18BR/YL HEADLAMP ADJUST SIGNAL
3 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
8Wa - 80 - 90 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT POSITION LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
2 Z142 18BK/WT GROUND
RIGHT POWER MIRROR (EXCEPT BASE) - WHITE 8 WAY
CAV CIRCUIT FUNCTION
1 P72 20YL/BK RIGHT MIRROR UP DRIVER
2 P76 20OR/YL MIRROR COMMON DRIVER
3 P74 20DB RIGHT MIRROR LEFT DRIVER
4- -
5 C16 20LB/YL FUSED DEFOGGER RELAY OUTPUT
6 Z351 20BK/LG GROUND
7 P99 20GY (WITH FOLD) FOLDING MIRROR FEED
8 P110 20YL (WITH FOLD) FOLDING MIRROR RETURN
RIGHT POWER SEAT MOTORS (MIDLINE/HIGHLINE) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 P10 14YL/WT PASSENGER SEAT REAR UP DRIVER
2 P12 14RD/WT PASSENGER SEAT REAR DOWN DRIVER
3 P18 14YL/LG PASSENGER SEAT FRONT UP DRIVER
4 P20 14RD/LG PASSENGER SEAT FRONT DOWN DRIVER
5 P16 14RD/YL PASSENGER SEAT HORIZONTAL REARWARD DRIVER
6 P14 14YL/LB PASSENGER SEAT HORIZONTAL FORWARD DRIVER
RIGHT POWER SEAT SWITCH (MIDLINE/HIGHLINE) - GREEN 10 WAY
CAV CIRCUIT FUNCTION
1 Z238 14BK/WT GROUND
2- -
3 P14 14YL/LB PASSENGER SEAT HORIZONTAL FORWARD DRIVER
4- -
5 F37 14RD/LB FUSED B(+)
6 P16 14RD/YL PASSENGER SEAT HORIZONTAL REARWARD DRIVER
7 P10 14YL/WT PASSENGER SEAT REAR UP DRIVER
8 P18 14YL/LG PASSENGER SEAT FRONT UP DRIVER
9 P20 14RD/LG PASSENGER SEAT FRONT DOWN DRIVER
10 P12 14RD/WT PASSENGER SEAT REAR DOWN DRIVER
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-91

RIGHT REAR DOOR AJAR SWITCH (BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z351 20BK/LG GROUND
RIGHT REAR DOOR LOCK MOTOR/AJAR SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z351 20BK/LG GROUND
3 P35 18OR/VT PASSENGER DOOR UNLOCK RELAY OUTPUT
4 P33 18OR/BK DOOR LOCK RELAY OUTPUT
RIGHT REAR DOOR SPEAKER-2WAY
CAV CIRCUIT FUNCTION
1 X52 18DB/WT (BASE) RIGHT REAR DOOR SPEAKER (+)
1 X94 18TN/VT (PREMIUM) AMPLIFIED LOW RIGHT REAR SPEAKER (+)
2 X58 18DB/OR (BASE) RIGHT REAR DOOR SPEAKER (-)
2 X92 18TN/BK (PREMIUM) AMPLIFIED LOW RIGHT REAR SPEAKER (-)
RIGHT REAR POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q24 16DG RIGHT REAR WINDOW DRIVER DOWN
2 Q14 16GY RIGHT REAR WINDOW DRIVER UP
RIGHT REMOTE RADIO SWITCH (PREMIUM) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X10 20RD/DB RADIO CONTROL MUX RETURN
2 X20 20RD/BK RADIO CONTROL MUX
8Wa - 80 - 92 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT SIDE IMPACT AIRBAG CONTROL MODULE (RSIACM) - YELLOW 8 WAY
CAV CIRCUIT FUNCTION
1 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
2- -
3 R76 18YL/DB RIGHT CURTAIN SQUIB LINE 2
4 R74 18YL/BR RIGHT CURTAIN SQUIB LINE 1
5 Z100 18BK/YL GROUND
6- -
7- -
8 D25 18YL/VT PCI BUS
RIGHT SIDE MARKER LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
2 L62 18BR/RD RIGHT TURN SIGNAL
RIGHT SIDE REPEATER LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L62 18BR/RD RIGHT TURN SIGNAL
2 Z142 18BK/WT GROUND
RIGHT SPEED CONTROL SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2 K4 20BK/LB SENSOR GROUND
3 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
4- -
RIGHT TAIL/STOP LAMP - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 L38 18BR/WT (BUILT-UP-EXPORT) REAR FOG LAMP RELAY OUTPUT
2 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
3 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
4 L10 18BR/LG BACK-UP LAMP FEED
5 Z151 18BK/WT GROUND
6 L62 18BR/RD RIGHT TURN SIGNAL
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-93

RIGHT VISOR/VANITY LAMP (EXCEPT BASE) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M20 20BR COURTESY LAMP LOAD SHED
SENTRY KEY IMMOBILIZER MODULE (EXCEPT BASE) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F33 20PK/RD FUSED B(+)
2 Z11 20BK/WT GROUND
3 F1 20DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
4 Z110 20BK/TN GROUND
5 D25 20YL/VT/BK PCI BUS
6- -
SHIFTER ASSEMBLY - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z21 20BK/LG GROUND
3 T6 20VT/WT OVERDRIVE OFF SWITCH SENSE
4 Z21 20BK/LG GROUND
5 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
6 K29 20WT/PK BRAKE SWITCH SENSE
SIREN (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 Z142 18BK/WT GROUND
2 X75 18DG SIREN SIGNAL CONTROL
3 M1 18PK FUSED B(+)
SPEED CONTROL SERVO - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 V36 18TN/RD SPEED CONTROL VACUUM SOLENOID CONTROL
2 V35 18LG/RD SPEED CONTROL VENT SOLENOID CONTROL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 Z212 18BK/OR GROUND
8Wa - 80 - 94 8W-80 CONNECTOR PIN-OUTSKJ

SUNROOF MOTOR - LT. GRAY 6 WAY
CAV CIRCUIT FUNCTION
1 F85 16VT/WT FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 Z111 16BK GROUND
3 Q44 20BR SUNROOF SWITCH GROUND
4 Q43 20VT SUNROOF VENT
5 Q42 20LB SUNROOF CLOSE
6 Q41 20WT SUNROOF OPEN
SUNROOF SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 Q41 20WT SUNROOF OPEN
2 Q42 20LB SUNROOF CLOSE
3 Q43 20VT SUNROOF VENT
4 Q44 20BR SUNROOF SWITCH GROUND
TAILGATE CYLINDER LOCK SWITCH - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 G910 20VT/BR TAILGATE SWITCH GROUND
2 G71 18VT/YL TAILGATE CYLINDER LOCK SWITCH MUX
TAILGATE FLIP-UP AJAR SWITCH - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
2 Z235 18BK GROUND
TAILGATE LOCK MOTOR/AJAR SWITCH - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 P31 16PK/WT TAILGATE UNLOCK DRIVER
2 P30 16OR/WT TAILGATE LOCK DRIVER
3 G78 20TN/BK TAILGATE AJAR SWITCH SENSE
4 G910 20VT/BR TAILGATE SWITCH GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-95
