sensor JEEP LIBERTY 2002 KJ / 1.G Workshop Manual

(1) Disconnect and isolate the battery negative
cable.
(2) Remove the overhead console from the head-
liner. (Refer to 8 - ELECTRICAL/OVERHEAD CON-
SOLE - REMOVAL).
(3) From the back of the unit, use a small thin-
bladed screwdriver to rotate the compass mini-trip
illumination bulb holder counterclockwise about 30
degrees on the circuit board (Fig. 8).
(4) Pull the compass mini-trip illumination bulb
holder and bulb unit straight out of the circuit board
bulb mounting hole.
INSTALLATION
The Compass Mini-Trip Computer (CMTC) in the
overhead console includes either two or three incan-
descent illumination bulb and bulb holder units.
Three bulbs are used only on models that also fea-
ture the optional Universal Garage Door Opener
(UGDO).
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTALRESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
CAUTION: Always use the correct bulb size and
type for replacement. An incorrect bulb size or type
may overheat and cause damage to the lamp, the
socket and/or the lamp wiring.
(1) Align the compass mini-trip illumination bulb
holder and bulb unit with the circuit board bulb
mounting hole.
(2) Insert the compass mini-trip illumination bulb
holder and bulb unit straight into the circuit board
bulb mounting hole until it is firmly seated (Fig. 8).
(3) Using a small thin-bladed screwdriver, rotate
the compass mini-trip illumination bulb holder clock-
wise about 30 degrees on the circuit board.
(4) Reinstall the overhead console onto the head-
liner. (Refer to 8 - ELECTRICAL/OVERHEAD CON-
SOLE - INSTALLATION).
(5) Reconnect the battery negative cable.
COURTESY LAMP BULB
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Support the courtesy lamp unit housing with
one hand while firmly grasping the flange on the
outer circumference of the lens with the other hand,
then pull the lens straight down to unsnap it from
the housing (Fig. 9).
(3) Pull the courtesy lamp bulb straight out of the
lamp unit socket.
Fig. 8 Compass Mini-Trip Illumination Bulb
Remove/Install
1 - OVERHEAD CONSOLE
2 - BULB & HOLDER (3)
3 - COMPASS MINI-TRIP COMPUTER
KJLAMPS/LIGHTING - INTERIOR 8L - 75
COMPASS MINI-TRIP ILLUMINATION BULB (Continued)

INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
CAUTION: Always use the correct bulb size and
type for replacement. An incorrect bulb size or type
may overheat and cause damage to the lamp, the
socket and/or the lamp wiring.
(1) Align the base of the courtesy lamp bulb with
the receptacle in the lamp unit socket.
(2) Push the courtesy lamp bulb straight into the
lamp unit socket until it is firmly seated (Fig. 9).
(3) Align the courtesy lamp lens with the lamp
unit housing.
(4) Support the courtesy lamp unit housing with
one hand while firmly and evenly pushing the lensinto the housing with the other hand, until the lens
snaps into place.
(5) Reconnect the battery negative cable.
COURTESY LAMP UNIT
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the screw that secures the integral
mounting tab of the courtesy lamp unit to the lower
instrument panel (Fig. 10).
(3) Pull the courtesy lamp unit down from the
lower instrument panel far enough to access and dis-
connect the instrument panel wire harness connector
Fig. 9 Courtesy Lamp Lens Remove/Install
1 - COURTESY LAMP
2 - LOWER INSTRUMENT PANEL
3 - BULB
4 - LENS
Fig. 10 Courtesy Lamp Unit Remove/Install
1 - COURTESY LAMP UNIT
2 - SCREW (1)
3 - LOWER INSTRUMENT PANEL
8L - 76 LAMPS/LIGHTING - INTERIORKJ
COURTESY LAMP BULB (Continued)

for the courtesy lamp from the connector receptacle
on the back of the lamp unit housing.
(4) Remove the courtesy lamp unit from under the
instrument panel.
INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Position the courtesy lamp unit under the
instrument panel.
(2) Reconnect the instrument panel wire harness
connector for the courtesy lamp to the connector
receptacle on the back of the lamp unit housing.
(3) Position the courtesy lamp unit to the lower
instrument panel (Fig. 10).
(4) Install and tighten the screw that secures the
integral mounting tab of the courtesy lamp unit to
the lower instrument panel.
(5) Reconnect the battery negative cable.
DOOR AJAR SWITCH
DESCRIPTION
This vehicle has four door ajar switches, one for
each door. Each switch is concealed within and inte-
gral to its respective door latch unit. The switches
are momentary leaf contact-type units that are actu-
ated by the door latch mechanisms. A short pigtail
wire and connector on each door latch connects the
door ajar switch to the vehicle electrical system
through its respective door wire harness. The door
ajar switches cannot be adjusted or repaired and, if
faulty or damaged, the door latch unit must be
replaced. (Refer to 23 - BODY/DOOR - FRONT/
LATCH - REMOVAL) or (Refer to 23 - BODY/DOOR -
REAR/LATCH - REMOVAL).
OPERATION
The door ajar switches are actuated by the door
latch mechanisms. When a door is closed and prop-
erly latched, its door ajar switch is an open circuit.
When a door is open or only partially latched, the
door ajar switch is a closed circuit. The door ajar
switches are hard wired between a body ground and
the Body Control Module (BCM). The driver side
front door ajar switch is connected to the BCM
through a driver door ajar switch sense circuit, while
the remaining three door ajar switches are connected
to the BCM through a passenger door ajar switch
sense circuit in a parallel-series arrangement. The
BCM reads the door ajar switch status through an
internal pull-up, then uses these inputs to control
many electronic functions and features of the vehicle.
The door ajar switches can be diagnosed using con-
ventional diagnostic tools and methods; however, for
proper diagnosis of the BCM, and both the hard
wired and electronic BCM outputs affected by the
door ajar switch inputs, a DRBIIItscan tool is
required. Refer to the appropriate diagnostic infor-
mation.
FLIP-UP GLASS AJAR SWITCH
DESCRIPTION
A flip-up glass ajar switch is standard equipment
in this vehicle. This switch is concealed within and
integral to the flip-up glass latch unit. The switch is
a momentary leaf contact-type unit that is actuated
by the flip-up glass latch mechanism. A dedicated
connector receptacle on the flip-up glass latch unit
connects the flip-up glass ajar switch to the vehicle
electrical system through the tailgate wire harness.
The flip-up glass ajar switch cannot be adjusted or
repaired and, if faulty or damaged, the flip-up glass
latch unit must be replaced. (Refer to 23 - BODY/
SWING GATE/FLIP-UP GLASS LATCH - REMOV-
AL).
OPERATION
The flip-up glass ajar switch is actuated by the
flip-up glass latch mechanism. When the flip-up glass
is closed and properly latched, the flip-up glass ajar
switch is an open circuit. When the flip-up glass is
open or only partially latched, the flip-up glass ajar
switch is a closed circuit. The flip-up glass ajar
switch is hard wired between a body ground, the
Body Control Module (BCM), and the rear wiper
motor. The output of the switch is connected to the
BCM and rear wiper motor through a flip-up glass
ajar switch sense circuit. The BCM reads the flip-up
glass ajar switch status through an internal pull-up,
then uses this input to control many electronic func-
KJLAMPS/LIGHTING - INTERIOR 8L - 77
COURTESY LAMP UNIT (Continued)

tions and features of the vehicle. The rear wiper
motor uses this input to restrict rear wiper operation
when the flip-up glass is ajar. The flip-up glass ajar
switch can be diagnosed using conventional diagnos-
tic tools and methods; however, for proper diagnosis
of the BCM, and both the hard wired and electronic
BCM outputs affected by the flip-up glass ajar switch
input, a DRBIIItscan tool is required. Refer to the
appropriate diagnostic information.
HEATER-A/C CONTROL
ILLUMINATION BULB
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the center bezel from the instrument
panel. (Refer to 23 - BODY/INSTRUMENT PANEL/
INSTRUMENT PANEL CENTER BEZEL - REMOV-
AL).
(3) From the back of the center bezel, use a small
thin-bladed screwdriver to rotate the heater-A/C con-
trol illumination bulb holder counterclockwise about
30 degrees on the circuit board (Fig. 11).
(4) Pull the heater-A/C illumination bulb holder
and bulb unit straight out of the circuit board bulb
mounting hole.
INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
CAUTION: Always use the correct bulb size and
type for replacement. An incorrect bulb size or type
may overheat and cause damage to the lamp, the
socket and/or the lamp wiring.
(1) Align the heater-A/C control illumination bulb
holder and bulb unit with the circuit board bulb
mounting hole.
(2) Insert the heater-A/C control illumination bulb
holder and bulb unit straight into the circuit board
bulb mounting hole until it is firmly seated (Fig. 11).
(3) Using a small thin-bladed screwdriver, rotate
the heater-A/C control illumination bulb holder clock-
wise about 30 degrees on the circuit board.
(4) Reinstall the center bezel onto the instrument
panel. (Refer to 23 - BODY/INSTRUMENT PANEL/
INSTRUMENT PANEL CENTER BEZEL - INSTAL-
LATION).
(5) Reconnect the battery negative cable.
Fig. 11 Heater-A/C Control Illumination Bulb
Remove/Install
1 - CENTER BEZEL
2 - BULB HOLDER & BULB (2)
3 - HEATER-A/C CONTROL
8L - 78 LAMPS/LIGHTING - INTERIORKJ
FLIP-UP GLASS AJAR SWITCH (Continued)

READING LAMP BULB
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) If the vehicle is not equipped with the optional
Compass Mini-Trip Computer (CMTC), remove the
reading lamp unit from the headliner mounting hole.
(Refer to 8 - ELECTRICAL/LAMPS/LIGHTING -
INTERIOR/READING LAMP UNIT - REMOVAL). If
the vehicle is equipped with the optional CMTC,
remove the overhead console from the headliner.
(Refer to 8 - ELECTRICAL/OVERHEAD CONSOLE -
REMOVAL).
(3) From the back of the unit while pulling the
reading lamp socket away from the outside of the
lamp unit bulb housing, use a small thin-bladed
screwdriver to release the integral latch tabs of the
socket from the inside of the bulb housing (Fig. 12).
(4) Pull the reading lamp socket and bulb unit
straight out from the lamp unit bulb housing.
(5) Pull the ash reading lamp bulb straight out of
the lamp unit socket.
INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
CAUTION: Always use the correct bulb size and
type for replacement. An incorrect bulb size or type
may overheat and cause damage to the lamp, the
socket and/or the lamp wiring.
(1) Align the base of the reading lamp bulb with
the receptacle in the lamp unit socket.
(2) Push the reading lamp bulb straight into the
lamp unit socket until it is firmly seated.
(3) Align the reading lamp socket and bulb unit
with the mounting hole in the bulb housing (Fig. 12).
(4) Push the reading lamp socket and bulb unit
straight into the bulb housing until it is firmly
seated and the integral socket latches are engaged
within the bulb housing.
(5) If the vehicle is not equipped with the optional
Compass Mini-Trip Computer (CMTC), reinstall the
reading lamp unit into the headliner mounting hole.
(Refer to 8 - ELECTRICAL/LAMPS/LIGHTING -
INTERIOR/READING LAMP - INSTALLATION). If
the vehicle is equipped with the optional CMTC,
reinstall the overhead console onto the headliner.
(Refer to 8 - ELECTRICAL/OVERHEAD CONSOLE -
INSTALLATION).
(6) Reconnect the battery negative cable.
Fig. 12 Reading Lamp Bulb Remove/Install
1 - BEZEL
2 - BULB HOUSING
3 - SWITCH (2)
4 - BULB (2)
5 - SOCKET (2)
KJLAMPS/LIGHTING - INTERIOR 8L - 79

READING LAMP SWITCH
REMOVAL
The reading lamp switches are serviced as a unit
with the reading lamp sockets, wire harness, and
connector.
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Remove both reading lamp sockets and their
bulbs from the lamp unit housing. (Refer to 8 -
ELECTRICAL/LAMPS/LIGHTING - INTERIOR/
READING LAMP BULB - REMOVAL).
(3) From the back of the reading lamp unit hous-
ing, carefully depress the blocking tab that engages
the terminal end of the reading lamp wire harness
connector, then slide the connector over the tab and
off of the mount near the center of the lamp unit
housing.
(4) From the back of the reading lamp unit hous-
ing, firmly press each switch body toward the large
end of the keyed hole into which it is secured until it
unsnaps from the housing (Fig. 13).
(5) Remove the connector, wire harness, both sock-
ets, and both switches from the back of the reading
lamp unit housing.
INSTALLATION
The reading lamp switches are serviced as a unit
with the reading lamp sockets, wire harness, and
connector.
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Position the connector, wire harness, both sock-
ets, and both switches onto the back of the reading
lamp unit housing.
(2) Insert the plunger of each switch into the large
end of the keyed hole in the reading lamp unit hous-
ing.
(3) Firmly press each switch body toward the
small end of the keyed hole into which it is secured
until it snaps into the housing (Fig. 13).
(4) Engage the wire end of the reading lamp wire
harness connector onto the connector mount near the
center of the lamp unit housing, then slide the con-
nector over the mount until the blocking tab snaps
up into place.
(5) Reinstall both reading lamp bulbs and their
sockets into the lamp unit housing. (Refer to 8 -
ELECTRICAL/LAMPS/LIGHTING - INTERIOR/
READING LAMP BULB - INSTALLATION).
(6) Reconnect the battery negative cable.
Fig. 13 Reading Lamp Switch Remove/Install
1 - READING LAMP BULB
2 - SWITCH
3 - WIRE HARNESS CONNECTOR
8L - 80 LAMPS/LIGHTING - INTERIORKJ

READING LAMP UNIT
REMOVAL
If the vehicle is equipped with an optional Com-
pass Mini-Trip Computer (CMTC), the reading lamps
are housed in the overhead console. (Refer to 8 -
ELECTRICAL/OVERHEAD CONSOLE - REMOV-
AL).
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Using a trim stick or another suitable wide
flat-bladed tool, gently pry between the flange
around the edge of the reading lamp unit housing
and the headliner to release the metal snap clip on
each side of the housing from the receptacles in the
mounting bracket above the headliner (Fig. 14).
(3) Pull the reading lamp unit away from the
headliner far enough to access and disconnect the
body wire harness connector for the lamp from the
connector on the lamp unit housing.
(4) If the vehicle is equipped with an optional
power sunroof, disconnect the body wire harness con-
nector for the sunroof switch from the connector
receptacle on the back of the switch.
(5) Remove the reading lamp unit from the mount-
ing hole in the headliner.
INSTALLATION
If the vehicle is equipped with an optional Com-
pass Mini-Trip Computer (CMTC), the reading lamps
are housed in the overhead console. (Refer to 8 -
ELECTRICAL/OVERHEAD CONSOLE - INSTALLA-
TION).
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERINGWHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Position the reading lamp unit to the mounting
hole in the headliner.
(2) If the vehicle is equipped with an optional
power sunroof, reconnect the body wire harness con-
nector for the sunroof switch to the connector recep-
tacle on the back of the switch.
(3) Reconnect the body wire harness connector for
the reading lamp to the connector on the lamp unit
housing.
(4) With the curved corners of the reading lamp
lenses oriented towards the rear of the vehicle, posi-
tion the reading lamp unit housing into the headliner
mounting hole and align the metal snap clip on each
side of the housing with their receptacles in the
mounting bracket above the headliner (Fig. 14).
(5) Using hand pressure, press upward firmly and
evenly on both ends of the reading lamp unit until
both snap clips are fully engaged in their receptacles.
(6) Reconnect the battery negative cable.
Fig. 14 Reading Lamp Unit Remove/Install
1 - TRIM STICK
2 - SUNROOF SWITCH
3 - READING LAMP UNIT
4 - HEADLINER
5 - LENS (2)
KJLAMPS/LIGHTING - INTERIOR 8L - 81

TAILGATE AJAR SWITCH
DESCRIPTION
A tailgate ajar switch is standard equipment in
this vehicle. This switch is concealed within and inte-
gral to the tailgate latch unit. The switch is a
momentary leaf contact-type unit that is actuated by
the tailgate latch mechanism. A pigtail wire harness
and connector on the tailgate latch unit connects the
tailgate ajar switch to the vehicle electrical system
through the tailgate wire harness. The tailgate ajar
switch cannot be adjusted or repaired and, if faulty
or damaged, the tailgate latch unit must be replaced.
(Refer to 23 - BODY/SWING GATE/LATCH -
REMOVAL).
OPERATION
The tailgate switch is actuated by the tailgate
latch mechanism. When the tailgate is closed and
properly latched, the tailgate ajar switch is an open
circuit. When the tailgate is open or only partially
latched, the tailgate ajar switch is a closed circuit.
The tailgate ajar switch is hard wired between a
body ground and the Body Control Module (BCM).
The output of the switch is connected to the BCM
through a tailgate ajar switch sense circuit. The
BCM reads the tailgate ajar switch status through
an internal pull-up, then uses this input to control
many electronic functions and features of the vehicle.
The tailgate ajar switch can be diagnosed using con-
ventional diagnostic tools and methods; however, for
proper diagnosis of the BCM, and both the hard
wired and electronic BCM outputs affected by the
tailgate ajar switch input, a DRBIIItscan tool is
required. Refer to the appropriate diagnostic infor-
mation.
TRANSMISSION RANGE
INDICATOR ILLUMINATION
BULB
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the center console from the floor panel
transmission tunnel. (Refer to 23 - BODY/INTERI-
OR/FLOOR CONSOLE - REMOVAL).
(3) From the left side of the vehicle, reach between
transmission range indicator and the floor panel
transmission tunnel to grasp the illumination lamp
socket (Fig. 15).
Fig. 15 Transmission Range Indicator Illumination
Bulb Remove/Install
1 - AUTOMATIC TRANSMISSION SHIFT MECHANISM
2 - ILLUMINATION LAMP SOCKET
8L - 82 LAMPS/LIGHTING - INTERIORKJ

(4) Rotate the transmission range indicator illumi-
nation lamp socket counterclockwise about 30
degrees on the bottom of the range indicator.
(5) Pull the transmission range indicator illumina-
tion lamp socket and bulb unit straight out of the
bulb mounting hole in the bottom of the indicator.
(6) Pull the transmission range indicator illumina-
tion lamp bulb straight out of the socket.
INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
CAUTION: Always use the correct bulb size and
type for replacement. An incorrect bulb size or type
may overheat and cause damage to the lamp, the
socket and/or the lamp wiring.
(1) Align the base of the transmission range indi-
cator illumination lamp bulb with the receptacle in
the lamp socket.
(2) Push the transmission range indicator illumi-
nation lamp bulb straight into the lamp socket until
it is firmly seated.
(3) Align the transmission range indicator illumi-
nation lamp socket and bulb unit with the mounting
hole on the bottom of the indicator (Fig. 15).
(4) Push the transmission range indicator illumi-
nation lamp socket and bulb unit straight into the
bottom of the indicator until it is firmly seated.
(5) Rotate the transmission range indicator illumi-
nation lamp socket clockwise about 30 degrees on the
bottom of the indicator.
(6) Reinstall the center console onto the floor panel
transmission tunnel. (Refer to 23 - BODY/INTERI-
OR/FLOOR CONSOLE - INSTALLATION).
(7) Reconnect the battery negative cable.
VANITY LAMP BULB
REMOVAL
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
(1) Disconnect and isolate the battery negative
cable.
(2) Using a small thin-bladed tool, gently pry out-
ward on either side near the top or bottom of the
vanity lamp lens until the lens unsnaps from the
lamp unit housing (Fig. 16).
Fig. 16 Vanity Lamp Lens Remove
1 - LENS (2)
2 - MIRROR
3 - SUN VISOR
KJLAMPS/LIGHTING - INTERIOR 8L - 83
TRANSMISSION RANGE INDICATOR ILLUMINATION BULB (Continued)

(3) Using small needle-nose pliers, carefully pull
the vanity lamp bulb straight out from the lamp
socket (Fig. 17).INSTALLATION
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE SUPPLEMENTAL RESTRAINT
SYSTEM BEFORE ATTEMPTING ANY STEERING
WHEEL, STEERING COLUMN, DRIVER AIRBAG,
PASSENGER AIRBAG, SEAT BELT TENSIONER,
FRONT IMPACT SENSORS, SIDE CURTAIN AIRBAG,
OR INSTRUMENT PANEL COMPONENT DIAGNOSIS
OR SERVICE. DISCONNECT AND ISOLATE THE
BATTERY NEGATIVE (GROUND) CABLE, THEN
WAIT TWO MINUTES FOR THE SYSTEM CAPACI-
TOR TO DISCHARGE BEFORE PERFORMING FUR-
THER DIAGNOSIS OR SERVICE. THIS IS THE ONLY
SURE WAY TO DISABLE THE SUPPLEMENTAL
RESTRAINT SYSTEM. FAILURE TO TAKE THE
PROPER PRECAUTIONS COULD RESULT IN ACCI-
DENTAL AIRBAG DEPLOYMENT AND POSSIBLE
PERSONAL INJURY.
CAUTION: Always use the correct bulb size and
type for replacement. An incorrect bulb size or type
may overheat and cause damage to the lamp, the
socket and/or the lamp wiring.
(1) Using small needle-nose pliers, carefully grasp
the vanity lamp bulb and align the base of the bulb
with the receptacle in the lamp socket (Fig. 17).
(2) Carefully push the vanity lamp bulb base
straight into the lamp socket until it is fully seated.
(3) Insert one tab on the top or the bottom of the
vanity lamp lens into the proper slot in the lamp unit
housing.
(4) Carefully flex the vanity lamp lens far enough
to engage the loose tab into its slot in the lamp unit
housing.
(5) Reconnect the battery negative cable.
Fig. 17 Vanity Lamp Bulb Remove/Install
1 - HOUSING
2 - MIRROR
3 - SOCKET
4 - NEEDLE-NOSE PLIERS
5 - BULB
8L - 84 LAMPS/LIGHTING - INTERIORKJ
VANITY LAMP BULB (Continued)
