FRONT WIPER MOTOR - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 V6 16DB/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 V55 16TN/RD FRONT WIPER PARK SWITCH SENSE
3- -
4 Z141 14BK GROUND
5 V3 14BR/WT FRONT WIPER HIGH/LOW RELAY LOW SPEED OUT-
PUT
6 V4 14RD/YL FRONT WIPER HIGH/LOW RELAY HIGH SPEED OUT-
PUT
FUEL HEATER (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A93 16RD/BK FUEL HEATER RELAY OUTPUT
2 Z246 16BK/GY GROUND
FUEL INJECTOR NO. 1 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K63 2.5mmDB/BK COMMON INJECTOR DRIVER
2 K11 2.5mmWT/DB FUEL INJECTOR NO. 1 CONTROL
FUEL INJECTOR NO. 1 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F142 18OR/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K11 18WT/DB FUEL INJECTOR NO. 1 DRIVER
FUEL INJECTOR NO. 2 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K63 2.5mmDB/BK COMMON INJECTOR DRIVER
2 K12 2.5mmTN FUEL INJECTOR NO. 2 CONTROL
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-59

FUEL INJECTOR NO. 2 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F142 18OR/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K12 18TN FUEL INJECTOR NO. 2 DRIVER
FUEL INJECTOR NO. 3 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K63 2.5mmDB/BK COMMON INJECTOR DRIVER
2 K13 2.5mmYL/WT FUEL INJECTOR NO. 3 CONTROL
FUEL INJECTOR NO. 3 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F142 18OR/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K13 18YL/WT FUEL INJECTOR NO. 3 DRIVER
FUEL INJECTOR NO. 4 (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K63 2.5mmDB/BK COMMON INJECTOR DRIVER
2 K14 2.5mmLB/BR FUEL INJECTOR NO. 4 CONTROL
FUEL INJECTOR NO. 4 (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F142 18OR/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K14 18LB/BR FUEL INJECTOR NO. 4 DRIVER
8Wa - 80 - 60 8W-80 CONNECTOR PIN-OUTSKJ

FUEL INJECTOR NO. 5 (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F142 18OR/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K38 18GY FUEL INJECTOR NO. 5 DRIVER
FUEL INJECTOR NO. 6 (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F142 18OR/DG FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K58 18BR/DB FUEL INJECTOR NO. 6 DRIVER
FUEL PRESSURE SENSOR (DIESEL) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K80 20BK/VT FUEL PRESSURE SENSOR GROUND
2 K78 20GY FUEL PRESSURE SENSOR SIGNAL
3 K7 20OR FUEL PRESSURE SENSOR 5 VOLT SUPPLY
FUEL PRESSURE SOLENOID (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
2 K46 18OR/BK FUEL PRESSURE SOLENOID CONTROL
FUEL PUMP MODULE - LT. GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 Z211 16BK (GAS) GROUND
2 K4 18BK/LB SENSOR GROUND
3 K226 18DB/WT FUEL LEVEL SENSOR SIGNAL
4 A141 16DG/WT (GAS) FUEL PUMP RELAY OUTPUT
G 202 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 Z12 16BK/TN GROUND
2 Z3 18BK/OR (BASE) GROUND
2 Z3 14BK/OR (EXCEPT BASE) GROUND
3 Z11 20BK/WT (EXCEPT BASE) GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-61

G 202 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
4- -
5- -
6 Z105 20BK/LG GROUND
7 Z231 16BK/WT GROUND
8 Z103 16BK/OR GROUND
9 Z131 10BK/GY GROUND
10 Z300 16BK GROUND
11 Z232 16BK/LB GROUND
12 - -
13 Z158 20BK/GY GROUND
14 Z110 20BK/TN (EXCEPT BASE) GROUND
GENERATOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD (DIESEL) FUSED AUTO SHUT DOWN RELAY OUTPUT
1 K20 18DG (GAS) GENERATOR FIELD DRIVER
2 K20 18DG (DIESEL) GENERATOR FIELD CONTROL
2 K125 18WT/DB (GAS) GENERATOR SOURCE
GLOW PLUG ASSEMBLY (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K154 10GY GLOW PLUG RELAY NO. 1 OUTPUT
2 K104 10RD/WT GLOW PLUG RELAY NO. 2 OUTPUT
HAZARD SWITCH/COMBINATION FLASHER - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 A15 18PK/OR FUSED B(+)
2 Z3 18BK/OR GROUND
3 L62 18BR/RD RIGHT TURN SIGNAL
4 L91 20DB/PK HAZARD LAMP CONTROL
5 L305 20LB/WT LEFT TURN SWITCH SENSE
6- -
7 L63 18DG/RD LEFT TURN SIGNAL
8 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
9 L302 20LB/YL RIGHT TURN SWITCH SENSE
10 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
8Wa - 80 - 62 8W-80 CONNECTOR PIN-OUTSKJ

HEADLAMP LEVELING SWITCH (BUILT-UP-EXPORT)-4WAY
CAV CIRCUIT FUNCTION
1 L13 18BR/YL HEADLAMP ADJUST SIGNAL
2 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
3 Z12 18BK/TN GROUND
4- -
HEATED SEAT MODULE (HIGHLINE) - GREEN 14 WAY
CAV CIRCUIT FUNCTION
1 P133 20TN/DG LEFT SEAT HEATER SWITCH MUX
2 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
3 F98 16RD/WT PASSENGER HEATED SEAT FEED
4 A3 16RD/WT FUSED B(+)
5 F99 16RD/YL DRIVER HEATED SEAT FEED
6 A3 16RD/WT FUSED B(+)
7 P142 20TN/DB PASSENGER HEATED SEAT TEMPERATURE SENSOR
GROUND
8 P141 20TN/LB DRIVER HEATED SEAT TEMPERATURE SENSOR
GROUND
9 P134 20TN/LG RIGHT SEAT HEATER SWITCH MUX
10 P138 20VT/LG RIGHT SEAT LOW HEAT LED DRIVER
11 P140 20VT/BK RIGHT SEAT HIGH HEAT LED DRIVER
12 P137 20VT/DG LEFT SEAT LOW HEAT LED DRIVER
13 Z238 16BK/WT GROUND
14 P139 20VT/WT LEFT SEAT HIGH HEAT LED DRIVER
HIGH NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z141 18BK GROUND
HOOD AJAR SWITCH (EXCEPT BASE)-2WAY
CAV CIRCUIT FUNCTION
1 G70 18BR/TN HOOD AJAR SWITCH SENSE
2 Z142 18BK/WT GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-63

IDLE AIR CONTROL MOTOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K59 18VT/BK IDLE AIR CONTROL MOTOR NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
4 K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVER
IGNITION SWITCH - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 A1 12RD FUSED (+)
2 A21 12RD/DB IGNITION SWITCH OUTPUT (RUN-START)
3 F81 12TN IGNITION SWITCH OUTPUT (RUN-ACC)
4 A25 12DB FUSED B(+)
5 G26 20LB KEY-IN IGNITION SWITCH SENSE
6 A41 12YL IGNITION SWITCH OUTPUT (START)
7 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
8 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
9 A2 12PK/BK FUSED B (+)
10 Z232 16BK/LB GROUND
INPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T52 18RD/BK INPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
1 Z105 20BK/LG GROUND
2- -
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4- -
5 G18 20PK/BK LOW COOLANT FLUID LEVEL SENSE
6 L63 20DG/RD LEFT TURN SIGNAL
7 G9 20GY/BK PARK BRAKE SWITCH SENSE
8 G69 20BK/OR VTSS INDICATOR DRIVER
9- -
10 M1 20PK FUSED B(+)
11 L78 20DG/YL FUSED PARK LAMP RELAY OUTPUT
12 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
13 - -
14 D25 20YL/VT/RD PCI BUS
15 - -
8Wa - 80 - 64 8W-80 CONNECTOR PIN-OUTSKJ

INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
16 L62 20BR/RD RIGHT TURN SIGNAL
17 G11 20WT/BK RED BRAKE WARNING INDICATOR DRIVER
18 G29 20BK/TN LOW WASHER FLUID SENSE
19 F87 20TN/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
20 - -
INTAKE AIR TEMPERATURE SENSOR (GAS) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
INTRUSION SENSOR (BUILT-UP-EXPORT) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z2 20BK/LG GROUND
2- -
3 X75 20DG SIREN SIGNAL CONTROL
4- -
5 D25 20YL/VT PCI BUS
6 M1 20PK FUSED B(+)
JUNCTION BLOCK BODY CONTROL MODULE-JB - 26 WAY
CAV CIRCUIT FUNCTION
1 X3 (PREMIUM) HORN RELAY CONTROL
2 P334 DOOR UNLOCK RELAY CONTROL
3 L308 PARK LAMP RELAY CONTROL
4 L96 (PREMIUM) REAR FOG LAMP RELAY CONTROL
5 P109 (EXCEPT BASE) DRIVER DOOR UNLOCK RELAY CONTROL
6 C80 REAR WINDOW DEFOGGER RELAY CONTROL
7- -
8 Z300 GROUND
9 F35 FUSED B(+)
10 L309 HIGH BEAM RELAY CONTROL
11 P31 TAILGATE UNLOCK DRIVER
12 P37 DOOR LOCK SWITCH GROUND
13 L94 LOW BEAM RELAY CONTROL
14 F89 FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
15 M1 FUSED B(+)
16 F87 FUSED IGNITION SWITCH OUTPUT (RUN-START)
17 L26 (EXCEPT BASE) FRONT FOG LAMP RELAY CONTROL
18 P333 DOOR LOCK RELAY CONTROL
19 V16 FRONT WIPER HIGH/LOW RELAY CONTROL
20 V55 FRONT WIPER PARK SWITCH SENSE
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-65

JUNCTION BLOCK BODY CONTROL MODULE-JB - 26 WAY
CAV CIRCUIT FUNCTION
21 V14 FRONT WIPER ON/OFF RELAY CONTROL
22 P30 TAILGATE LOCK DRIVER
23 P36 DOOR LOCK SWITCH MUX
24 M2 COURTESY LAMP DRIVER
25 Z131 GROUND
26 M20 COURTESY LAMP LOAD SHED
JUNCTION BLOCK C1 - GRAY 42 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 A21 12RD/DB IGNITION SWITCH OUTPUT (RUN-START)
4 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
5 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
6- -
7 X3 20BK/RD HORN RELAY CONTROL
8 L78 20DG/YL (EXCEPT BUILT-UP-EX-
PORT)FUSED PARK LAMP RELAY OUTPUT
8 L78 18DG/YL (BUILT-UP-EXPORT) FUSED PARK LAMP RELAY OUTPUT
9 F1 20DB (PREMIUM) FUSED IGNITION SWITCH OUTPUT (RUN-START)
10 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
11 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
12 M1 20PK FUSED B(+)
13 F33 20PK/RD FUSED B(+)
14 - -
15 M1 20PK FUSED B(+)
16 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
17 Z300 16BK GROUND
18 - -
19 - -
20 Z131 10BK/GY GROUND
21 L309 20LG/WT HIGH BEAM RELAY CONTROL
22 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
23 M2 20YL COURTESY LAMP DRIVER
24 M2 20YL COURTESY LAMP DRIVER
25 F33 20PK/RD (PREMIUM) FUSED B(+)
26 F88 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
27 M1 20PK FUSED B(+)
28 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
29 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
30 - -
31 F87 20TN/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
32 - -
33 F38 16RD/WT FUSED B(+)
34 C16 20LB/YL FUSED DEFOGGER RELAY OUTPUT
35 F30 16RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
36 - -
37 F32 18PK/DB FUSED B(+)
38 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
39 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
40 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
41 A15 18PK/OR FUSED B(+)
42 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
8Wa - 80 - 66 8W-80 CONNECTOR PIN-OUTSKJ

JUNCTION BLOCK C2 - GREEN 42 WAY
CAV CIRCUIT FUNCTION
1 F37 14RD/LB (MIDLINE/HIGHLINE) FUSED B(+)
2- -
3 C15 12BK/WT DEFOGGER RELAY OUTPUT
4 F89 18OR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
5 P37 20LG (EXCEPT BASE) DOOR LOCK SWITCH GROUND
6 P33 18OR/BK (EXCEPT BASE) DOOR LOCK RELAY OUTPUT
7 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
8 P34 18PK/BK (EXCEPT BASE) DRIVER DOOR UNLOCK RELAY OUTPUT
9 P35 18OR/VT (EXCEPT BASE) PASSENGER DOOR UNLOCK RELAY OUTPUT
10 P36 20PK/VT (EXCEPT BASE) DOOR LOCK SWITCH MUX
11 P37 20LG (EXCEPT BASE) DOOR LOCK SWITCH GROUND
12 M20 20BR COURTESY LAMP LOAD SHED
13 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
14 P36 20PK/VT (EXCEPT BASE) DOOR LOCK SWITCH MUX
15 P30 16OR/WT TAILGATE LOCK DRIVER
16 F70 18PK/BK FUSED B(+)
17 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
18 M1 20PK FUSED B(+)
19 M1 20PK FUSED B(+)
20 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
21 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
22 - -
23 V23 20BR/PK (HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN)
24 V23 20BR/PK (EXCEPT BASE) FUSED IGNITION SWITCH OUTPUT (RUN)
25 V23 20BR/PK (MIDLINE/HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN)
26 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
27 - -
28 A6 16RD/BK (PREMIUM GAS) FUSED B(+)
29 - -
30 M2 18YL COURTESY LAMP DRIVER
31 C16 18LB/YL (EXCEPT BASE) FUSED DEFOGGER RELAY OUTPUT
32 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
33 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
34 L38 18BR/WT (HIGHLINE) REAR FOG LAMP RELAY OUTPUT
35 P31 16PK/WT TAILGATE UNLOCK DRIVER
36 - -
37 F60 16DG/RD (PREMIUM) FUSED B(+)
38 F87 20WT/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
39 C16 18LB/YL (EXCEPT BASE) FUSED DEFOGGER RELAY OUTPUT
40 F85 16VT/WT (MIDLINE/HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
41 F41 16PK/VT FUSED B(+)
42 A3 16RD/WT (HIGHLINE) FUSED B(+)
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-67

JUNCTION BLOCK C3 - LT. BLUE 42 WAY
CAV CIRCUIT FUNCTION
1 A12 10RD/TN FUSED B(+)
2 A13 10PK/WT FUSED B(+)
3 A4 12BK/PK FUSED B(+)
4 L44 18VT/RD FUSED RIGHT LOW BEAM OUTPUT
5 L43 18VT FUSED LEFT LOW BEAM OUTPUT
6- -
7 V55 16TN/RD FRONT WIPER PARK SWITCH SENSE
8 F1 18DB (LHD) FUSED IGNITION SWITCH OUTPUT (RUN-START)
8 F1 20DB (RHD) FUSED IGNITION SWITCH OUTPUT (RUN-START)
9 V6 14DB/YL (RHD) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
9 VG 16DB/YL (LHD) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 - -
11 A12 10RD/TN FUSED B(+)
12 - -
13 - -
14 - -
15 V14 18RD/VT FRONT WIPER ON/OFF RELAY CONTROL
16 L34 18RD/OR FUSED RIGHT HIGH BEAM OUTPUT
17 - -
18 V16 18VT/YL WIPER HIGH/LOW RELAY CONTROL
19 F20 18WT FUSED IGNITION SWITCH OUTPUT (RUN)
20 - -
21 - -
22 - -
23 - -
24 L50 18WT/TN (ABS) BRAKE LAMP SWITCH OUTPUT
25 - -
26 - -
27 - -
28 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
29 M1 18PK FUSED B(+)
30 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
31 - -
32 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN)
33 L39 18LB FRONT FOG LAMP RELAY OUTPUT
34 A18 10PK FUSED B(+)
35 - -
36 - -
37 L33 18LG/BR FUSED LEFT HIGH BEAM OUTPUT
38 F22 18DB/PK (ABS) FUSED IGNITION SWITCH OUTPUT (RUN)
39 X2 18DG/RD HORN RELAY OUTPUT
40 A18 10PK FUSED B(+)
41 - -
42 A7 10RD/BK FUSED B(+)
8Wa - 80 - 68 8W-80 CONNECTOR PIN-OUTSKJ
