JEEP LIBERTY 2006 KJ / 1.G Owners Manual

Miles 18,000 21,000 24,000 27,000 30,000
(Kilometers) (30 000) (35 000) (40 000) (45 000) (50 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if
necessary. X
Replace the spark plugs. X
Inspect and replace the PCV valve, if necessary. X
Inspect the brake linings. X
Inspect the manual transmission fluid, add as nec-
essary. X
Drain and refill the front and rear axle fluid‡ X
Inspect the transfer case fluid, add if necessary. X
SCHEDULE “B” — GASOLINE ENGINES 371
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 33,000 36,000 39,000 42,000 45,000
(Kilometers) (55 000) (60 000) (65 000) (70 000) (75 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. X
372 SCHEDULE “B” — GASOLINE ENGINES
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 48,000 51,000 54,000 57,000 60,000
(Kilometers) (80 000) (85 000) (90 000) (95 000) (100 000)
Change the engine oil and engine oil filter, if not replaced
at 3 months. XXXXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if necessary. X
Replace the spark plugs. X
Inspect and replace the PCV valve, if necessary. X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid‡ X
Inspect the manual transmission fluid, add as necessary. X
Drain and refill the automatic transmission fluid, replace
main sump filter, and spin-on cooler return filter (if
equipped).† X
Inspect the drive belt and replace as needed. Not required
if belt was previously replaced. X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze. X
SCHEDULE “B” — GASOLINE ENGINES 373
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 63,000 66,000 69,000 72,000 75,000
(Kilometers) (105 000) (110 000) (115 000) (120 000) (125 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
374 SCHEDULE “B” — GASOLINE ENGINES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 78,000 81,000 84,000 87,000 90,000
(Kilometers) (130 000) (135 000) (140 000) (145 000) (150 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if
necessary. X
Replace the spark plugs. X
Inspect and replace the PCV valve, if necessary. X
Inspect the brake linings. X
Inspect the manual transmission fluid, add as nec-
essary. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
Inspect the transfer case fluid, add if necessary. X
SCHEDULE “B” — GASOLINE ENGINES 375
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (155 000) (160 000) (165 000) (170 000) (175 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X
Inspect the engine air filter element, replace if
necessary. X
Inspect the brake linings. X
Drain and refill the front and rear axle fluid‡ X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
Flush and replace the engine coolant/anti-freeze, if
not done at 60 months. X
376 SCHEDULE “B” — GASOLINE ENGINES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change the engine oil and engine oil filter, if not
replaced at 3 months. X X XXX
Rotate the tires. X X X
Inspect the engine air filter element, replace if
necessary. X
Replace the spark plugs. X
Inspect and replace the PCV valve, if necessary. X
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid‡ X
Inspect the manual transmission fluid, add as nec-
essary. X
Drain and refill the automatic transmission fluid,
replace main sump filter, and spin-on cooler return
filter (if equipped).† X
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
SCHEDULE “B” — GASOLINE ENGINES 377
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze at
120 months, if not replaced at 102,000 miles (170
000 km). X
Inspection and service should be performed anytime a
malfunction is observed or suspected. Retain all receipts.
† Applies only if vehicle is used for frequent trailer
towing, or fleet/commercial service.
This maintenance is recommended by the manufac-
turer to the owner, but it is not required to maintain
emissions warranty. ‡Off-highway operation, trailer towing, taxi, limousine,
bus, snow plowing, or other types of commercial service
or prolonged operation with heavy loading, especially in
hot weather, require front and rear axle service indicated
witha‡in Schedule “B”. Perform these services if the
vehicle is usually operated under these conditions.
378 SCHEDULE “B” — GASOLINE ENGINES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “A” — Gasoline Engines
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Rotate the tires. X X X X X
Inspect the engine air filter element, and replace
if necessary. X
Replace the spark plugs. X
Inspect the manual transmission fluid, add as nec-
essary. X
Inspect the brake linings. X
Inspect the transfer case fluid. X
SCHEDULE “A” — GASOLINE ENGINES 379
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 36,000 42,000 48,000 54,000
(Kilometers) (60 000) (70 000) (80 000) (90 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the brake linings. X X
380 SCHEDULE “A” — GASOLINE ENGINES
