JEEP LIBERTY 2007 Owners Manual

Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MoparGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning inside rear windows
equipped with electric defrosters. Do not use scrapers or
other sharp instruments which may scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
MAINTAINING YOUR VEHICLE 351

Cavity Fuse Description
1 15 Amp Blue Horn Relay, Power Sunroof
Relay, Power Window Relay
2 10 Amp Red Rear Fog Lights (Export Only)
3 20 Amp Yel-
lowCigar Lighter
4 10 Amp Red Headlight Low Beam Right
5 10 Amp Red Headlight Low Beam Left
6 20 Amp Yel-
lowBody Control Module/Power
Door Locks
7 10 Amp Red Left Park Light/Left Tail
Lamp/License Plate Lamp
8 Spare
9 10 Amp Red Right Park Light/RightTail
Lamp/License Plate Lamp/
Cluster
10 Spare
11 15 Amp Blue Flasher

Cavity Fuse Description
20 Spare
21 10 Amp Red Radio
22 20 Amp Yel-
lowPower Sunroof Relay/Antenna
Module (Export Only)
23 Spare
24 10 Amp Red PDC Blower Motor
25 10 Amp Red Heated Seat Switches/HVAC
Control Head/Trailer Tow Bat-
tery Charge
26 10 Amp Red Headlight High Beam Right
27 10 Amp Red Headlight High Beam Left
28 Spare
29 10 Amp Red Heated Mirrors/Rear Window
Defroster Indicator
30 15 Amp Blue Heated Seat Module
31 Spare
354 MAINTAINING YOUR VEHICLE

Cavity Fuse Description
36 10 Amp Red Airbag Control Module/
Occupation Classification
Module (Right Front Seat)
37 10 Amp Red Airbag Control Module
38 10 Amp Red ABS Controller/Shifter Assem-
bly
39 10 Amp Red Hazard Flasher (Turn Signals)/
Backup Lamp Switch (Manual
Transmission Only)/
Transmission Range Switch
(Automatic Transmission
Only)
MAINTAINING YOUR VEHICLE 355

Cavity Fuse Description
F12 30 Amp Pink Light Bar
F13 40 Amp
GreenWindows
F14 40 Amp
GreenIgnition Switch
F15 50 Amp Red JB Power
F16 Open
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger (HBL)
F20 Open
F21 20 Amp Yel-
lowA/C Clutch
F22 Open
F23 Open
F24 20 Amp Yel-
lowFuel Pump
MAINTAINING YOUR VEHICLE 357

Cavity Fuse Description
R35 Half ISO Re-
layA/C Clutch
R36 Open
R37 Half ISO Re-
layNGC Trans
R38 Open
R39 Full ISO Relay ASD
R40 Full ISO Relay Rad. Fan Lo
358 MAINTAINING YOUR VEHICLE

Cavity Fuse Description
F12 30 Amp Pink Light Bar
F13 40 Amp
GreenWindows
F14 40 Amp
GreenIgnition Switch
F15 50 Amp Red JB Power
F16 15 Amp Blue ASD Feed
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger (HBL)
F20 Open
F21 20 Amp Yel-
lowA/C Clutch
F22 Open
F23 Open
F24 Open
MAINTAINING YOUR VEHICLE 359

Cavity Fuse Description
R35 Half ISO
RelayA/C Clutch
R36 Half ISO
RelayViscous Heat
R37 Open
R38 Open
R39 Full ISO Relay ASD
R40 Full ISO Relay Rad. Fan Lo
360 MAINTAINING YOUR VEHICLE
