AUTOMATIC TRANSMISSION
CAUTION!
Damage to the transmission may occur if the follow-
ing precautions are not observed:
²Shift into ªPº (Park) only after the vehicle has
come to a complete stop.
²Shift into or out of ªRº (Reverse) only after the
vehicle has come to a complete stop and the engine
is at idle speed.
²Do not shift from ªRº (Reverse), ªPº (Park), or ªNº
(Neutral) into any forward gear when the engine is
above idle speed.
²Before shifting into any gear, make sure your foot
is firmly on the brake pedal.
WARNING!
It is dangerous to shift the selector lever out of ªPº
(Park) or ªNº (Neutral) if the engine speed is higher
than idle speed. If your foot is not firmly on the
brake pedal, the vehicle could accelerate quickly
forward or in ªRº (Reverse). You could lose control of
the vehicle and hit someone or something. Only shift
into gear when the engine is idling normally and
when your foot is firmly on the brake pedal.
Shift Lock Manual Override Ð If Equipped
Your vehicle may be equipped with a shift lock manual
override. The manual override may be used in the event
that the shift lever should fail to move from ªPº (Park)
with the key in the ON position and the brake pedal
depressed. To operate the shift lock manual override,
perform the following steps:
STARTING AND OPERATING 281
5

1. Firmly set the parking brake.
2. Using a flat blade screwdriver, carefully remove the
shift lock manual override cover, which is located on the
PRNDL bezel.
3. Depress and maintain firm pressure on the brake
pedal.
4. Using the screwdriver, reach into the manual override
opening. Press and hold the shift lock lever down.
5. Move the shift lever into the ªNº (Neutral) position.
6. The vehicle may then be started in ªNº (Neutral).
Have your vehicle inspected by your local authorized
dealer, if the shift lock manual override has been used.
282 STARTING AND OPERATING

Brake/Transmission Interlock System
This system prevents you from moving the gear shift out
of ªPº (Park) and into any gear unless the brake pedal is
pressed. Always depress thebrake pedal first,before
moving the gear selector out of ªPº (Park).
4±Speed Automatic Transmission
Shifting from ªDº (Drive) to ªPº (Park) or ªRº (Reverse)
(or from ªPº or ªRº to ªDº) should be done only after the
accelerator pedal is released and the vehicle is stopped.
Be sure to keep your foot on the brake when moving the
selector lever between these gears.
Gear Ranges
DO NOT race the engine when shifting from ªPº (Park)
or ªNº (Neutral) position into another gear range.
Automatic Shift Controls
STARTING AND OPERATING 283
5

ªPº (Park)
This gear position supplements the parking brake by
locking the transmission. The engine can be started in
this range. Never use ªPº (Park) while the vehicle is in
motion. Apply the parking brake when leaving the
vehicle in this range. Always apply parking brake first,
and then place the selector in ªPº (Park) position.
WARNING!
Never use ªPº (Park) position as a substitute for the
parking brake. Always apply parking brake fully
when parked to guard against vehicle movement and
possible injury or damage.
WARNING!
It is dangerous to shift the selector lever out of ªPº
(Park) or ªNº (Neutral) if the engine speed is higher
than idle speed. If your foot is not firmly on the
brake pedal, the vehicle could accelerate quickly
forward or in ªRº (Reverse). You could lose control of
the vehicle and hit someone or something. Only shift
into gear when the engine is idling normally and
when your right foot is firmly on the brake pedal.
ªRº (Reverse)
Use this range only after the vehicle has come to a
complete stop.
284 STARTING AND OPERATING

ªNº (Neutral)
Shift into ªNº (Neutral) when the vehicle is standing for
prolonged periods with the engine running. The engine
may be started in this range. Set the parking brake if you
must leave the vehicle.
NOTE:Towing the vehicle, coasting, or driving for any
other reason with selector lever in ªNº (Neutral) can
result in severe transmission damage. Refer to ªRecre-
ational Towingº in Section 5 and ªTowing a Disabled
Vehicleº in Section 6 of this manual.
ªDº (Drive)
For most city and highway driving.
ª2º (Second)
For moderate grades and to assist braking on dry pave-
ment or in mud and snow. Begins at a stop in low gear
with automatic upshift to 2nd gear. Will not shift to 3rd.ª1º (First)
For hard pulling at low speeds in mud, sand, snow, or on
steep grades. Begins and stays in low gear with no
upshift. Provides engine compression braking at low
speeds.
Overdrive Operation
The overdrive automatic transmission contains an elec-
tronically controlled fourth speed (Overdrive). The trans-
mission will automatically shift from 3rd gear to Over-
drive if the following conditions are present:
²The transmission selector is in ªDº (Drive).
²The vehicle speed is above approximately 30 mph (48
km/h).
²The ªTOW/HAULº button has not been activated.
STARTING AND OPERATING 285
5

NOTE:
²If the vehicle is started in extremely cold temperatures,
the transmission may not shift into Overdrive. It will
however, automatically select the most desirable gear
for operation at this temperature. Normal operation
will resume when the transmission fluid temperature
has risen to a suitable level.
²If the transmission temperature gets extremely hot, the
transmission will automatically select the most desir-
able gear for operation at this temperature. If the
transmission temperature becomes hot enough, the
ªTransmission Temperature Warning Lightº may illu-
minate, and the transmission may downshift out of
Overdrive until the transmission cools down. After a
cool down, the transmission will resume normal op-
eration.The transmission will downshift from Overdrive to Drive
if the accelerator pedal is fully depressed at vehicle
speeds above approximately 35 mph (56 km/h).
When To Use ªTOW/HAULº Mode
When driving in hilly areas, towing a trailer, carrying a
heavy load, etc., and frequent transmission shifting oc-
curs, press the ªTOW/HAULº button. This will improve
performance and reduce the potential for transmission
overheating or failure due to excessive shifting. When
operating in ªTOW/HAULº mode, the transmission will
shift to 3rd gear.
NOTE:ªTOW/HAULº mode locks out Overdrive.
286 STARTING AND OPERATING

The ªTOW/HAUL Indicator Lightº will illuminate in the
instrument cluster to indicate when the switch has been
activated. Pressing the switch a second time restores
normal operation. If the ªTOW/HAULº mode is desired,
the switch must be pressed each time the engine is
started.
Torque Converter Clutch
A feature designed to improve fuel economy has been
added to the automatic transmission of this vehicle. A
clutch within the torque converter engages automatically
at calibrated speeds. This may result in a slightly differ-
ent feeling or response during normal operation in high
gear. When the vehicle speed drops or during accelera-
tion, the clutch automatically and smoothly disengages.
Transmission Limp Home Mode
The transmission is monitored for abnormal conditions.
If a condition is detected that could cause damage, the
transmission shifts automatically into second gear if the
vehicle speed is appropriate. If not, it will wait until the
conditions are appropriate and then it will shift into
second gear. The transmission will then remain in second
gear despite the forward gear selected. ªPº (Park), ªRº
(Reverse), and ªNº (Neutral) will continue to operate.
Tow/Haul Button
STARTING AND OPERATING 287
5

A Reset feature allows the vehicle to be driven to a dealer
for service without damaging the transmission. To reset
the transmission, perform the following procedure:
1. Stop the vehicle.
2. Move the selector lever to the ªPº (Park) position.
3. Turn off the engine; be sure to turn the key to the
LOCK position.
4. Wait approximately 10 seconds, and then restart the
engine.
5. Move the selector lever to the desired gear range.
If the problem is no longer detected, the transmission will
return to normal operation. If the problem persists, ªPº
(Park), ªRº (Reverse), and ªNº (Neutral) will continue to
operate. Only Second gear range will operate in the ªDº
(Drive) position. Have the transmission checked at your
authorized dealer as soon as possible.MANUAL TRANSMISSION Ð IF EQUIPPED
Clutch Interlocking Ignition System
Vehicles equipped with a manual transmission are
equipped with a clutch interlock safety feature. The
clutch pedal must be fully depressed to allow cranking of
the engine.
To enhance off-road performance, 4-wheel drive models
equipped with a manual transmission will start with or
without pressing the clutch pedal when in 4-wheel drive
low range. The 4 LOW indicator light will illuminate
when the transfer case is in 4-wheel drive low range.
288 STARTING AND OPERATING

6-Speed Manual Transmission
WARNING!
You or others could be injured if you leave the
vehicle unattended without having the parking
brake fully applied. The parking brake should al-
ways be applied when the driver is not in the vehicle,
especially on an incline.
Follow the shift pattern on the gearshift knob.
NOTE:The backup lights will come on when your
vehicle is in ªRº (Reverse) gear and the ignition is in the
ON position.
Manual Shift Controls
STARTING AND OPERATING 289
5

WARNING!
When parking your vehicle, always leave a manual
transmission in first gear and apply the parking
brake fully to guard against vehicle movement and
possible injury or damage. Never use any gear as a
substitute for the parking brake.
CAUTION!
To drive as safely as possible and to prolong the life
of your manual transmission, follow these tips:
²Before shifting from a forward gear into reverse, or
from reverse to a forward gear, stop vehicle com-
pletely. Otherwise, accelerated transmission wear may
result.
²Do not operate at sustained high engine or road
speeds in lower gears. Engine damage may result.
²Do not downshift into a low gear while traveling at too
high a speed for that gear. Engine, clutch, or transmis-
sion damage may result.
²Do not rest your foot on the clutch pedal. This causes
heat buildup and damages the clutch.
²When you slow down or go up a grade, downshift as
speed requires or the engine may overheat.
²Never hold the vehicle stopped on a hill by using the
clutch pedal. The clutch may be damaged.
²During cold weather, you may experience increased
effort in shifting until the transmission fluid warms
up. This is normal.
²Push in the clutch pedal completely when shifting.
Otherwise, transmission or clutch damage may result.
