spark plugs replace JEEP RENEGADE 2017 1.G Owners Manual

Mileage or time passed
(whichever comes first)
10,000
20,000
30,000
40,000
50,000
60,000
70,000
80,000
90,000
100,000
110,000
120,000
130,000
140,000
150,000
Or Years: 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Or Kilometers:
16,000
32,000
48,000
64,000
80,000
96,000
112,000
128,000
144,000
160,000
176,000
192,000
208,000
224,000
240,000
Inspect and replace, if required,
front end accessory drive belt,
tensioner, and, idler pulley. •
Inspect and replace PCV valve
if necessary. •
Change engine oil and replace
oil filter.*
Inspect the PTU fluid level. •• •
Inspect the rear differential fluid
level. •• •
Replace spark plugs
(1.4L Turbo engine). ** ••• • •
Replace spark plugs
(2.4L engine). ** •
Replace engine air filter. # ••• • •
Replace brake fluid every two
years. *** •••• • • •
Replace cabin filter. ○• ○ •○• ○•○ • ○• ○•○
8
SERVICING AND MAINTENANCE 379

* The oil and oil filter replacement must be carried out
when indicated by a warning light or message on the
instrument panel, or in any case should not exceed 1 year
or 10,000 miles (16,000 km).
** The spark plug change is distance based only, yearly
intervals do not apply. The following are essential to ensure
correct operation and prevent serious damage to the en-
gine:
•Only use spark plugs of the same make and type which
are specially certified for such engines (refer to “Fluids
and Lubricants” in “Technical Specifications” for further
information).
• Strictly comply with the spark plug replacement interval
given in the “Maintenance Schedule” for spark plug
replacement.
• Contact your authorized dealer if you have any ques-
tions.
*** The brake fluid change interval is time based only,
mileage intervals do not apply.WARNING!
• You can be badly injured working on or around a
motor vehicle. Do only service work for which you
have the knowledge and the right equipment. If you
have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
• Failure to properly inspect and maintain your vehicle
could result in a component malfunction and effect
vehicle handling and performance. This could cause
an accident.
8
SERVICING AND MAINTENANCE 381

Tilting.................................38
Security Alarm ......................... .28, 138
Arm The System ..........................28
Disarm The System ........................29
Selection Of Coolant (Antifreeze) ...............439
Sentry Key Key Programming .........................27
Sentry Key Replacement ....................21, 27
Service Assistance ......................... .494
Service Contract .......................... .496
Service Manuals .......................... .497
Shifting Manual Transmission ..................... .260
Shift Lever Override ....................... .365
Shoulder Belts ............................ .206
Side View Mirror Adjustment ...................50
Signals, Turn ....................... .55, 160, 247
Snow Chains (Tire Chains) ....................421
Snow Tires .............................. .417
Spare Tire ............................ .418, 419
Spark Plugs ............................. .439
Specifications Fuel (Gasoline) ......................... .439
Oil.................................. .439
Speed Control (Cruise Control) .................272Starting
.............................. .23, 251
Cold Weather .......................... .253
Engine Fails To Start ..................... .252
Remote ................................23
Starting And Operating ..................... .251
Starting Procedures ........................ .251
Steering Tilt Column .............................48
Wheel, Heated ...........................48
Wheel, Tilt ..............................48
Steering Wheel Audio Controls .................476
Steering Wheel Mounted Sound System Controls . . . .476
Storage, Vehicle .............................81
Stuck, Freeing ............................ .366
Sun Visor Extension .........................110
Supplemental Restraint System - Air Bag ..........216
Sway

Control, Trailer .....................171, 297
System, Remote Starting ......................23
Telescoping Steering Column ...................48
Temperature Control, Automatic (ATC) ............79
Tilt Steering Column .........................48
Time Delay, Headlight ........................54
Tip Start ................................ .252
Tire And Loading Information Placard ............407
510 INDEX
