6
SAFETY
SAFETY FEATURES........................................................... 239
Anti-Lock Brake System (ABS) ................................. 239Rear Seat Reminder Alert (RSRA) ............................ 240
Drowsy Driver Detection (DDD) — If Equipped ........ 240
Electronic Brake Control (EBC) System .................. 241
AUXILIARY DRIVING SYSTEMS ...................................... 247 Blind Spot Monitoring (BSM) .................................... 247
Forward Collision Warning (FCW)
With Mitigation .......................................................... 250
Tire Pressure Monitoring System (TPMS) ................ 252
OCCUPANT RESTRAINT SYSTEMS ................................ 256 Occupant Restraint Systems Features ................... 256Important Safety Precautions .................................. 256Seat Belt Systems .................................................... 257
Supplemental Restraint Systems (SRS) .................. 264Child Restraints ........................................................ 275
SAFETY TIPS ..................................................................... 287 Transporting Passengers .......................................... 287
Transporting Pets ...................................................... 287Connected Vehicles .................................................. 287
Safety Checks You Should Make Inside
The Vehicle ............................................................... 287
Periodic Safety Checks You Should Make
Outside The Vehicle .................................................. 289
Exhaust Gas .............................................................. 289Carbon Monoxide Warnings ..................................... 289
IN CASE OF EMERGENCY
HAZARD WARNING FLASHERS ..................................... 290
ASSIST AND SOS SYSTEM— IF EQUIPPED ................... 290
JACKING AND TIRE CHANGING...................................... 293 Preparations For Jacking ......................................... 293
Jack And Tools Location ........................................... 294Spare Tire Stowage................................................... 295
Spare Tire Removal .................................................. 295Jacking Instructions ................................................. 296
JUMP STARTING ............................................................. 300 Preparations For Jump Start .................................... 300Jump Starting Procedure.......................................... 301
REFUELING IN EMERGENCY........................................... 302
IF YOUR ENGINE OVERHEATS ........................................ 303
MANUAL PARK RELEASE .............................................. 303
FREEING A STUCK VEHICLE .......................................... 305
TOWING A DISABLED VEHICLE ..................................... 306 Rear-Wheel Drive Models......................................... 307
Four-Wheel Drive Models ......................................... 307
Emergency Tow Hooks — If Equipped ..................... 308
ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS) .............................................................................. 308
EVENT DATA RECORDER (EDR) ..................................... 308
SERVICING AND MAINTENANCE
SCHEDULED SERVICING .................................................. 309 Maintenance Plan ..................................................... 310
ENGINE COMPARTMENT ................................................. 313 3.0L Engine................................................................ 313
5.7L Engine................................................................ 314
6.4L Engine................................................................ 315
Checking Oil Level — 3.0L Engines .......................... 316
Checking Oil Level — 5.7L & 6.4L Engines .............. 317
Adding Washer Fluid ................................................ 317
Maintenance-Free Battery ....................................... 318Pressure Washing ..................................................... 318
VEHICLE MAINTENANCE .................................................. 318 Engine Oil .................................................................. 319
Engine Oil Filter ....................................................... 319
Engine Air Cleaner Filter ........................................ 319Air Conditioner Maintenance ................................. 320
Accessory Drive Belt Inspection ............................... 323Body Lubrication ....................................................... 323
Windshield Wiper Blades ......................................... 324
Exhaust System ........................................................ 325
Cooling System .......................................................... 326
Brake System ........................................................... 328
Automatic Transmission ........................................... 329
Front/Rear Axle Fluid ............................................... 330Transfer Case ............................................................ 330Fuses .......................................................................... 331Bulb Replacement .................................................... 349

23_WS_OM_EN_USC_t.book Page 6

88GETTING TO KNOW YOUR VEHICLE
NOTE:The activation zone is the same for vehicles equipped with
or without a trailer tow package.

Valid Kicking Motion

When a valid kicking motion is completed, the liftgate will
chime, the hazard lights will flash and the liftgate will open
after approximately one second, or close after
approximately three seconds. These settings can be
enabled or disabled through Uconnect Settings
Úpage 197.
NOTE:
Opening or closing the Hands-Free Liftgate requires a
valid Passive Entry key fob within 5 ft (1.5 m) of the lift -
gate handle. If a valid Passive Entry key fob is not within
5 ft (1.5 m), the liftgate will not respond to any kicks,
and will perform inhibit chimes to inform the user about
the missing key fob.
 The distance from the rear fascia/bumper to the foot
shall be no more than 8 inches (20 cm) to be recog -
nized as a valid kick. 
The Hands-Free Liftgate feature may be turned on or
off through the Uconnect system
Úpage 197.
 The Hands-Free Liftgate feature should be turned off
during jacking, tire changing, manual car wash, and
vehicle service.
 The Hands-Free Liftgate feature can be activated by
any metallic object making a similar in-and-out motion
under the rear fascia/bumper, such as cleaning using
a metal broom.
 The Hands-Free Liftgate will only operate when the
transmission is in PARK.
 If anything obstructs the Hands-Free Liftgate while it is
opening or closing, the liftgate will automatically
reverse to the closed/open position, provided it meets
sufficient resistance.
 The Hands-Free Liftgate will not open with the key fob
in the cupholder or anywhere inside the vehicle.
 There are pinch sensors attached to the side of the lift -
gate opening. Light pressure anywhere along these
strips will cause the liftgate to return to the open posi -
tion.
 If the power liftgate encounters multiple obstructions
within the same cycle, the system will automatically
stop. If this occurs, the liftgate must be operated manu -
ally.
 The power liftgate will release, but not power open, in
temperatures below −12°F (−24°C). Be sure to
remove any buildup of snow or ice from the liftgate
before opening the liftgate. 
If the liftgate is left open for an extended period of time
(approximately one hour), the liftgate may need to be
closed manually to reset power liftgate functionality.
NOTE:Allow the power system to open the liftgate. Manually
pushing or pulling the liftgate may activate the liftgate
obstacle detection feature and stop the power operation
or reverse its direction.
WARNING!
Driving with the liftgate open can allow poisonous
exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the liftgate closed when you are operating the
vehicle.
 If you are required to drive with the liftgate open,
make sure that all windows are closed, and the
climate control blower switch is set at high speed.
Do not use the recirculation mode.
WARNING!
During power operation, personal injury or cargo
damage may occur. Ensure the liftgate travel path is
clear. Make sure the liftgate is closed and latched
before driving away.

23_WS_OM_EN_USC_t.book Page 88

IN CASE OF EMERGENCY293
(Continued)
Automatic SOS — If Equipped
Automatic SOS is a hands-free safety service that can
immediately connect you with help in the event that your
vehicle’s airbags deploy. Please refer to your provided
radio supplement for complete information.
JACKING AND TIRE CHANGING
NOTE:
If your vehicle is equipped with an air suspension system,
there is a feature which allows the automatic leveling to be
disabled before changing a tire. This feature can be acti
-
vated through the Uconnect system
Úpage 215.
PREPARATIONS FOR JACKING
Before changing a tire or using the jack please disable the
hands free lift gate, This feature can be disabled through
the Uconnect system
Úpage 197.

1. Park the vehicle on a firm, level surface as far from the edge of the roadway as possible. Avoid icy or
slippery areas.
2. Turn on the Hazard Warning Flashers.
3. Apply the parking brake.
4. Place the gear selector into PARK (P).
5. Turn OFF the ignition.
6. Block both front and rear of the wheel diagonally
opposite of the jacking position. For example, if
changing the driver’s front tire, block the passenger’s
rear wheel.

Wheel Blocked Example

NOTE:Passengers should not remain in the vehicle when the
vehicle is being raised or lifted.
CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off the
road to avoid the danger of being hit when operating
the jack or changing the wheel.
 Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never put any part of your body
under a vehicle that is on a jack. If you need to get
under a raised vehicle, take it to a service center
where it can be raised on a lift.
 Never start or run the engine while the vehicle is on
a jack.
The jack is designed to be used as a tool for changing
tires only. The jack should not be used to lift the
vehicle for service purposes. The vehicle should be
jacked on a firm level surface only. Avoid ice or slip -
pery areas.
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off the
road to avoid being hit when operating the jack or
changing the wheel.
WARNING!
7

23_WS_OM_EN_USC_t.book Page 293

IN CASE OF EMERGENCY295

Jacking Tools Description

SPARE TIRE STOWAGE
The spare tire is stowed under the rear of the vehicle by
means of a cable winch mechanism. To remove or stow
the spare, use the jack handle/lug wrench connected to
the square socket extension to rotate the “spare tire drive”
nut. The nut is located under a rubber plug at the
center-rear of the cargo floor area, just inside the liftgate
opening.

Spare Tire Location

SPARE TIRE REMOVAL
Remove the spare tire before attempting to jack up the
vehicle. The spare tire is stowed underneath the rear
cargo area on the outside of the vehicle.

1. Assemble the jacking tools.

Jacking Tool Assembly

2. Locate and remove plug from the storage
compartment floor to expose the winch access hole.

Winch Nut Plug

1 — Tow Hook (If Equipped)
2 — Wheel Lug Wrench
3 — Jack Handle Extension
4 — Fuel Funnel
5 — Jack Handle
6 — Scissor JackCAUTION!
The winch mechanism is designed for use with the jack
wrench extension tool only. Use of air wrench or power
tool may damage the winch.
1 — Wheel Lug Wrench
2 — Jack Handle Extension
3 — Jack Handle
7

23_WS_OM_EN_USC_t.book Page 295

296IN CASE OF EMERGENCY
(Continued)
3. Fit the jack handle extension over the drive nut. Use
the wheel lug wrench and extension to completely
lower the spare tire. Keep turning the handle counter -
clockwise until the winch stops.

Winch Drive Nut Location
Wrench Rotation

4. Slide the tire out from under the vehicle and rotate it vertically behind the rear fascia/bumper.
5. Pull the metal retainer toward you to release it. 6. Slide the retainer up the steel extension tube and
winch cable. Rotate the retainer and push it through
the hole in the wheel.

Releasing Winch Retainer

JACKING INSTRUCTIONS

Jack Warning Label

WARNING!
Carefully follow these tire changing warnings to help
prevent personal injury or damage to your vehicle:
Always park on a firm, level surface as far from the
edge of the roadway as possible before raising the
vehicle.
 Turn on the Hazard Warning Flashers.
 Apply the parking brake firmly and set the transmis -
sion in PARK.
 Block the wheel diagonally opposite the wheel to be
raised.
Never start or run the engine with the vehicle on a
jack.
 Do not let anyone sit in the vehicle when it is on a
jack.
 Do not get under the vehicle when it is on a jack. If
you need to get under a raised vehicle, take it to a
service center where it can be raised on a lift.
 Only use the jack in the positions indicated and for
lifting this vehicle during a tire change.
 If working on or near a roadway, be extremely careful
of motor traffic.
 To assure that spare tires, flat or inflated, are
securely stowed, spares must be stowed with the
back of the wheel facing the ground.
WARNING!

23_WS_OM_EN_USC_t.book Page 296

IN CASE OF EMERGENCY297

1. Loosen (but do not remove) the wheel lug nuts,
using the lug wrench by turning them counter -
clockwise, one turn, while the wheel is still on the
ground.

Loosen Lug Nuts

2. Assemble the jack and tools Úpage 295.

Jack And Tool Assembled

NOTE:Placement for the front and rear jacking locations are
critical. Keep the jack and tools aligned while raising the
vehicle to prevent tool damage. See the following images
for proper jacking locations.

Jacking Locations

3. When changing a front tire, place the scissor jack under the front chassis lifting point, as indicated by
the triangular lift point symbol shown in the following
image. Do not raise the vehicle until you are sure the
jack is fully engaged.

Front Lifting Point
Front Jacking Location

CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the Jacking
Instructions for this vehicle.
7

23_WS_OM_EN_USC_t.book Page 297

298IN CASE OF EMERGENCY
4. When changing a rear tire, place the scissor jack
under the rear chassis lifting point, as indicated by
the triangular lift point symbol shown in the following
image. Do not raise the vehicle until you are sure the
jack is fully engaged.

Rear Lifting Point
Rear Jacking Location

5. Raise the vehicle by using the wheel lug wrench and jack handle to turn the jack screw clockwise. Raise
the vehicle only until the tire just clears the surface
and enough clearance is obtained to install the spare
tire. Minimum tire lift provides maximum stability.
6. Remove the lug nuts and wheel.
7. Position the spare wheel/tire on the vehicle and install the lug nuts with the cone-shaped end toward
the wheel. Lightly tighten the nuts.

Mounting Spare Tire

8. Lower the vehicle by turning the jack screw counter -
clockwise, and remove the jack and wheel blocks.
WARNING!
Raising the vehicle higher than necessary can make the
vehicle less stable. It could slip off the jack and hurt
someone near it. Raise the vehicle only enough to
remove the tire.
CAUTION!
Be sure to mount the spare tire with the valve stem
facing outward. The vehicle could be damaged if the
inflatable spare tire is mounted incorrectly.
WARNING!
To avoid the risk of forcing the vehicle off the jack, do
not tighten the wheel nuts fully until the vehicle has
been lowered. Failure to follow this warning may result
in serious injury.

23_WS_OM_EN_USC_t.book Page 298

385
E
Electric Brake Control System..................................... 241 Anti-Lock Brake System ......................................... 239
Electronic Roll Mitigation .............................. 241
, 246
Electric Parking Brake ................................................. 122
Electric Remote Mirrors ..................................................52 Electrical Outlet, Auxiliary (Power Outlet) ...................... 79Electronic Range Select (ERS) .................................... 129
Electronic Speed Control (Cruise Control) .................. 138
Electronic Stability Control (ESC) ................................ 242
Electronic Throttle Control Warning Light................... 110
Emergency Braking ...................................................... 252
Emergency Gas Can Refueling .................................... 302
Emergency, In Case Of Freeing Vehicle When Stuck .................................. 305
Hazard Warning Flasher ......................................... 290
Jacking..................................................................... 293
Jump Starting .......................................................... 300
Emission Control System Maintenance...................... 118
Engine .................................................................. 313
, 315
Air Cleaner ............................................................... 319 Block Heater ........................................................... 122
Break-In Recommendations .................................. 122
Checking Oil Level ......................................... 316
, 317
Compartment ........................................313, 314, 315
Compartment Identification .......................... 313, 314
Cooling..................................................................... 326
Exhaust Gas Caution .............................................. 289
Fails To Start ........................................................... 121
Flooded, Starting .................................................... 121
Fuel Requirements ........................................ 372
, 375
Jump Starting .......................................................... 300
Oil .................................................................... 319
, 375
Oil Filler Cap ............................................................ 313
Oil Filter ................................................................... 319 Oil Selection .......................................... 319
, 375, 376
Oil Synthetic ............................................................. 319
Starting.....................................................................119
Engine Oil Life Reset

b
...........................................101
Enhanced Accident Response Feature ............. 273, 308
Ethanol .......................................................................... 373
Exhaust Gas Cautions ..................................................289
Exhaust System .................................................. 289
, 325
Exterior Lights .............................................. 57, 289, 349
FFamCam System...........................................................171
Filters Air Cleaner ............................................................... 319
Air Conditioning ...................................... 72
, 320, 321
Engine Oil ................................................................. 319
Engine Oil Disposal..................................................319
FireTV.............................................................................232
Flashers ......................................................................... 290 Hazard Warning ....................................................... 290
Turn Signals ................................................... 116
, 289
Flash-To-Pass .................................................................. 58
Flooded Engine Starting ............................................... 121
Fluid Capacities ............................................................375
Fluid Leaks ....................................................................289
Fluid Level Checks Brake ........................................................................ 328
Engine Oil ....................................................... 316
, 317
Fluids And Lubricants ...................................................377
Fold-Flat Seats ................................................................ 33
Forward Collision Warning ...........................................250
Four Wheel Drive ................................................ 129
, 131
Operation ................................................................. 129
System .....................................................................129 Four Wheel Drive Operation ........................................ 129
Four-Way Hazard Flasher ............................................. 290
Freeing A Stuck Vehicle ............................................... 305
Front Axle (Differential) ................................................ 330
Fuel................................................................................ 372 Additives .................................................................. 373
Clean Air .................................................................. 373
Ethanol..................................................................... 373Gasoline ................................................................... 372
Materials Added ...................................................... 373
Methanol ................................................................. 373
Octane Rating.......................................................... 372
Requirements .................................................372
, 375
Specifications .......................................................... 376
Tank Capacity .......................................................... 375
Fueling .......................................................................... 177
Fully Automated ParkSense Active Park Assist .......... 162
Fuses ............................................................................. 331
GGarage Door Opener (HomeLink) .................................. 53 Gasoline, (Fuel) ............................................................ 372
Gasoline, Clean Air ....................................................... 373
Gasoline, Reformulated ............................................... 373
Gear Ranges ................................................................. 127
Glass Cleaning .............................................................. 370
Glove Compartment Storage ......................................... 73Gross Axle Weight Rating ............................................. 179
Gross Vehicle Weight Rating ....................................... 179
GVWR ............................................................................ 178
11

23_WS_OM_EN_USC_t.book Page 385

386H
Hazard Warning Flashers ............................................ 290
Head Restraints .............................................................. 44
Head Up Display ........................................................... 105 Head Up Display (HUD
) — If Equipped
b
................106
Headlights
Automatic ...................................................................58
Cleaning................................................................... 368
High Beam/Low Beam Select Switch .......................58
Lights On Reminder ...................................................59
On With Wipers ..........................................................59
Passing ....................................................................... 58
Heads Up Display ......................................................... 105
Heated Mirrors ................................................................53 Heated Seats...................................................................43
Heated Steering Wheel...................................................31Heater, Engine Block ................................................... 122
Hill Descent Control ..................................................... 243
Hill Descent Control Indicator ..................................... 243
Hill Start Assist ............................................................. 244
Hitches Trailer Towing .......................................................... 182
HomeLink (Garage Door Opener) ..................................53
Hood Prop ........................................................................85 Hood Release ..................................................................85
IIgnition .............................................................................20 Key Fob Battery Low Or Dead ...................................20
Key Fob Not Detected ...............................................20
Keyless Ignition..........................................................20
Keyless Push Button .................................................20
Push Button Ignition ..................................................20
Switch .........................................................................20 Immobilizer (Sentry Key) ................................................ 20
Inside Rearview Mirror ..........................................50
, 290
Instrument Cluster ............................................ 96, 98, 99
Display........................................................................ 99
Menu Items .............................................................. 104
Instrument Panel Lens Cleaning ................................. 370
Integrated Trailer Brake Control ..................................186
Interior And Instrument Lights ....................................... 60 Interior Appearance Care ............................................. 369
Interior Lights .................................................................. 60
Interior Monitoring Camera ..........................................171
Intermittent Wipers (Delay Wipers) ............................... 62Inverter Power ......................................................................... 80
JJack Location ................................................................ 294
Jack Operation .............................................................. 296
Jacking And Tire Changing Instructions ...................... 293
Jacking Instructions ...................................................... 296
Jump Starting ................................................................ 300
KKey FobArm The System......................................................... 24
Disarm The System ................................................... 24
Programming Additional Key Fobs ........................... 20
Key Fob Battery Service (Remote Keyless Entry) ......... 18
Key Fob Programming (Remote Keyless Entry) ............ 20
Keyless Enter 'n Go™ ...................................................119 Passive Entry ............................................................. 27
Passive Entry Programming ...................................... 27 Keys ................................................................................. 16
Replacement ............................................................. 20
Sentry (Immobilizer) .................................................. 20
Know & Go ¹ ......................................................................9
LLane Change Assist ........................................................ 60 Lap/Shoulder Belts ...................................................... 258
Latches ......................................................................... 289 Hood........................................................................... 85
Lead Free Gasoline ...................................................... 372
Leaks, Fluid................................................................... 289
Life Of Tires ................................................................... 359
Liftgate ............................................................................ 86 Closing ....................................................................... 86
Hands-Free ................................................................ 87
Opening............................................................... 86
, 87
Liftgate Window Wiper/Washer .................................... 64
Light Bulbs .................................................................... 289
Lights ............................................................................. 289 Air Bag............................................................. 265
, 287
Ambient...................................................................... 62
Automatic Headlights ............................................... 58
Brake Assist Warning.............................................. 243
Brake Warning......................................................... 109
Bulb Replacement .................................................. 349
Cargo.......................................................................... 89
Cruise ....................................................................... 116
Daytime Running....................................................... 58
Dimmer Switch, Headlight ................................. 57
, 61
Electronic Stability Program(ESP) Indicator .......... 110
Exterior.............................................................. 57
, 289

23_WS_OM_EN_USC_t.book Page 386

388 P
Pages, Off Road ........................................................... 236
Paint Care ..................................................................... 368
Panic Alarm .....................................................................17
Parking Brake ...................................................... 112
, 122
ParkSense Front And Rear ........................................................ 154
ParkSense Active Park Assist ...................................... 160
ParkSense System, Rear ............................................. 154
Passenger Screen ........................................................ 221
Passive Entry ...................................................................27
Pedals, Adjustable ..........................................................49 Permissions .................................................................. 221
Pets ............................................................................... 287
Phone Storage.................................................................74Pinch Protection .............................................................. 85
Placard, Tire And Loading Information ....................... 354
Power Brakes ..................................................................... 371
Distribution Center (Fuses) ..................331
, 338, 343
Door Locks .................................................................27
Inverter ....................................................................... 80
Mirrors ........................................................................52
Outlet (Auxiliary Electrical Outlet) ............................. 79
Seats...........................................................................38
Side Steps ..................................................................27
Steering .......................................................... 135
, 377
Sunroof ....................................................................... 83
Tilt/Telescoping Steering Column ............................ 30
Windows .....................................................................82
Power Rear Seats............................................................41 Power Seats
Down .......................................................................... 39
Forward ...................................................................... 39
Rearward.................................................................... 39
Up ............................................................................... 39
Pregnant Women And Seat Belts ................................ 263
Preparation For Jacking ............................................... 293
Pretensioners Seat Belts................................................................. 263
QQuadra-Lift ....................................................................132
Quadra-Trac ........................................................ 129, 130
RRadial Ply Tires ............................................................. 358
Radiator Cap (Coolant Pressure Cap) ......................... 327
RadioSound Setting .......................................................... 216
Radio Operation ............................................................238
Radio Remote Controls ................................................ 221
Rain Sensitive Wiper System ......................................... 63
Rear Air Conditioning...................................................... 69
Rear Axle (Differential) ................................................. 330
Rear Camera ....................................................... 170
, 175
Rear Cross Path ............................................................249
Rear ParkSense System............................................... 154
Rear Seat Entertainment ............................................. 228 Rear Seat Reminder ..................................................... 240
Rear Wiper/Washer ....................................................... 64
Recreational Towing ..................................................... 190
Reformulated Gasoline ................................................ 373
Refrigerant .................................................................... 321
Release, Hood ................................................................ 85
Reminder, Seat Belt ..................................................... 257
Remote Control Starting System ......................................................... 22
Remote Keyless Entry .................................................... 16 Arm The Alarm ........................................................... 24
Disarm The Alarm ..................................................... 24
Programming Additional Key Fobs ........................... 20
Remote Sound System (Radio) Control ...................... 221
Remote Starting Exit Remote Start Mode............................................ 23
Remote Starting System ................................................ 22 Replacement Bulbs ...................................................... 349
Replacement Keys ......................................................... 20
Replacement Tires ....................................................... 360
Reporting Safety Defects ............................................. 381
Restraints, Child ........................................................... 275
Restraints, Head............................................................. 44
Roll Over Warning........................................................... 10
Roof Luggage Rack ........................................................ 91Rotation, Tires .............................................................. 366

23_WS_OM_EN_USC_t.book Page 388
