JEEP WRANGLER 2004 TJ / 2.G Owner's Manual

Adjustable Upper Shoulder Belt Anchorage
In the front seats, the shoulder belt anchorage can be
adjusted upward or downward to position the belt away
from your neck. Push in on the anchorage near your
outside shoulder and slide it up or down to reach the
position that serves you best.
As a guide, if you are shorter than average, you will
prefer a lower position, and if you are taller than average,
you'll prefer a higher position. When you release the
anchorage, try to move it up or down to make sure that
it is locked in position.
Seat Belts And Pregnant Women
We recommend that pregnant women use seat belts
throughout their pregnancy. Keeping the mother safe is
the best way to keep the baby safe.
Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.
Seat Belt Extender
If a seat belt is too short, even when fully extended and
when the adjustable upper shoulder belt anchorage (if
equipped) is in its lowest position, your dealer can
provide you with a seat belt extender. This extender
should be used only if the existing belt is not long
enough. When it is not required, remove the extender
and store it.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

WARNING!
Using a seat belt extender when not needed can
increase the risk of injury in a collision. Only use
when the seat belt is not long enough when it is
worn low and snug, and in the recommended seating
positions. Remove and stow the seat belt extender
when not needed.
Driver And Front Passenger Supplemental
Restraint Systems (SRS) Ð Airbags
This vehicle has front airbags for both the driver and
front passenger as a supplement to the seat belt restraint
system. The driver's front airbag is mounted in the center
of the steering wheel. The passenger's front airbag is
mounted in the instrument panel, above the glove com-
partment. The words SRS/AIRBAG are embossed on the
airbag covers.
NOTE:The front airbags are certified to the Federal
regulations that allow less forceful deployment.
NOTE:Airbag covers may not be obvious in the
interior trim; but they will open to allow airbag deploy-
ment.
WARNING!
Do not put anything on or around the front airbag
covers or attempt to manually open them. You may
damage the airbags and you could be injured be-
cause the airbags are not there to protect you. These
protective covers for the airbag cushions are de-
signed to open only when the airbags are inflating.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Airbags inflate in moderate to high speed impacts. Along
with the seat belts, front airbags work with the instru-
ment panel knee bolsters to provide improved protection
for the driver and front passenger.
The seat belts are designed to protect you in many types
of collisions. The front airbags deploy in moderate to
severe frontal collisions. But even in collisions where the
airbags work, you need the seat belts to keep you in the
right position for the airbags to protect you properly.
Here are some simple steps you can take to minimize the
risk of harm from a deploying airbag.
1.Children 12 years old and under should always ride
buckled up in a rear seat.
Infants in rear-facing child restraints (designed for chil-
dren up to 20 lbs (9 kg) and at least one year old) should
NEVERride in the front seat of a vehicle with a passen-
ger front airbag, unless the airbag is turned off. An airbag
deployment can cause severe injury or death to infants in
this position.Children that are not big enough to properly wear the
vehicle seat belt (Refer to ªChild Restraintº in this
section.) should be secured in the rear seat, in a child
restraint or belt-positioning booster seat. Older children
who do not use child restraints or belt-positioning
booster seats should ride properly buckled up in the rear
seat. Never allow children to slide the shoulder belt
behind them or under their arm.
If a child from 1 to 12 years old must ride in the front
passenger seat because the vehicle is crowded, move the
seat as far back as possible, and use the proper child
restraint. Refer to ªChild Restraintº in this section.
You should read the instructions provided with your
child restraint to make sure that you are using it properly.
2. All occupants should use their lap and shoulder belts
properly.
3. The driver and front passenger seats should be moved
back as far as practical to allow the front airbags room to
inflate.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

WARNING!
²Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won't deploy at all.
Always wear your seat belts even though you
have airbags.
²Being too close to the steering wheel or instru-
ment panel during airbag deployment could cause
serious injury. Airbags need room to inflate. Sit
back, comfortably extending your arms to reach
the steering wheel or instrument panel.
Airbag System Components
The airbag system consists of the following:
²Airbag Control Module (ACM)
²Airbag Warning Light
²Driver Airbag
²Passenger Airbag
²Steering Wheel And Column
²Instrument Panel
²Crash Sensor
²Interconnecting Wiring
²Knee Impact Bolsters
²Passenger Airbag ON/OFF Switch (If Equipped)
How The Airbag System Works
²
TheAirbag Control Module (ACM)determines if a
frontal collision is severe enough to require the airbags
to inflate.
²The ACM will not detect side, roll over, or rear
impacts.
²The ACM also monitors the readiness of the electronic
parts of the system whenever the ignition switch is in
the START or ON position. These include all of the
items listed above except the knee bolster, the instru-
ment panel, and the steering wheel and column. If the
ignition key is in the OFF or ACC position, or not in
the ignition, the airbags are not on and will not inflate.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

²Also, the ACM turns on the ªAirbag Warning Lightº in
the instrument panel for 6 to 8 seconds when the
ignition is first turned on, then turns the light off. If it
detects a malfunction in any part of the system, it turns
on the light either momentarily or continuously. If the
ACM detects a malfunction, the ªAirbag Warning
Lightº will illuminate for a minimum of 12 seconds
and will remain illuminated as long as the malfunction
exists.
WARNING!
Ignoring the ªAirbag Warning Lightº in your instru-
ment panel could mean you won't have the airbags
to protect you in a collision. If the light does not
come on, stays on after you start the vehicle, or if it
comes on as you drive, have the airbag system
checked right away.
²TheDriver and Passenger Airbag/Inflator Unitsare
located in the center of the steering wheel and in the
instrument panel. When the ACM detects a collision
requiring the airbags, it signals the inflator units. A
large quantity of nontoxic gas is generated to inflate
the airbags. The airbag covers separate and fold out of
the way as the bags inflate to full size. The bags fully
inflate in about 50 milliseconds. This is about half of
the time it takes to blink your eyes. The airbags then
quickly deflate while helping to restrain the driver and
front passenger. The driver's front airbag gas is vented
through the airbag material towards the instrument
panel. The passenger's front airbag gas is vented
through vent holes in the sides of the airbag. In this
way the airbags do not interfere with your control of
the vehicle.
²TheKnee Impact Bolstershelp protect the knees and
position the driver and front passenger's for the best
interaction with the front airbag.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

Passenger Airbag On/Off Switch Ð If Equipped
NOTE:
The Passenger Airbag ON/OFF Switch is de-
signed so that the switch position can be changed using
the ignition key. The key inserts into the switch far
enough to fully depress a spring-loaded locking plunger,
and then rotates to the desired position. The key will not
insert fully into the switch, and the spring-loaded locking
plunger prevents the key from remaining in the switch.
The Passenger Airbag ON/OFF Switch is located on the
instrument panel. The switch is to be turned off only if
the passenger is an infant (less than 1 year old) or a child
(age 1 to 12) who must ride in the front seat because there
is no rear seat.
WARNING!
Whenever an airbag is turned off, even a lap/
shoulder belted passenger may hit their head, neck,
or chest on the dashboard (instrument panel) or
windshield in a crash. This may result in serious
injury or death.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Shut Off the Passenger Airbag
1. Turn ignition to OFF position.
2. Remove the water-resistant plug.
3. Place the ignition key in the Passenger Airbag ON/
OFF Switch, press inward and turn the key to the right to
the OFF position. This will shut off the passenger airbag.
4. Reinstall the water-resistant plug.
NOTE:When the Passenger Airbag ON/OFF Switch is
in the OFF position, a indicator light will illuminate when
the ignition is ON. If the indicator light does not illumi-
nate for 3 seconds after the ignition is turned ON, or
when the Passenger Airbag ON/OFF Switch is turned
OFF (while ignition is in the ON position), have an
authorized dealer service the system immediately.
To Turn On the Passenger Airbag
1. Turn ignition to OFF position.
2. Remove the water-resistant plug.3. Place the ignition key in the Passenger Airbag ON/
OFF Switch, press inward and turn the key to the left to
the ON position. This will turn on the passenger airbag.
4. Reinstall the water-resistant plug.
NOTE:Do not turn the Passenger Airbag ON/OFF
Switch on or off with the ignition in the ON/RUN or
START positions, as the ACM could cause the ªAirbag
Warning Lampº to illuminate.
If A Deployment Occurs
The airbag system is designed to deploy when the impact
sensors detect a moderate-to-severe frontal collision, to
help restrain the driver and right front passenger, and
then to immediately deflate.
NOTE:A frontal collision that is not severe enough to
need airbag protection will not activate the system. This
does not mean something is wrong with the airbag
system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
2

If you do have a collision which deploys the airbags, any
or all of the following may occur:
²The nylon airbag material may sometimes cause abra-
sions and/or skin reddening to the driver and front
passenger as the airbags deploy and unfold.
The abrasions are similar to friction rope burns or
those you might get sliding along a carpet or gymna-
sium floor. They are not caused by contact with
chemicals. They are not permanent and normally heal
quickly. However, if you haven't healed significantly
within a few days, or if you have any blistering, see
your doctor immediately.
²As the airbags deflate you may see some smoke-like
particles. The particles are a normal by-product of the
process that generates the nontoxic gas used for airbag
inflation. These airborne particles may irritate the skin,
eyes, nose, or throat. If you have skin or eye irritation,
rinse the area with cool water. For nose or throat
irritation, move to fresh air. If the irritation continues,
see your doctor.If these particles settle on your clothing, follow the
garment manufacturer's instructions for cleaning.
²It is not advisable to drive your vehicle after the
airbags have deployed. If you are involved in another
collision, the airbags will not be in place to protect you.
WARNING!
Deployed airbags cannot protect you in another
collision. Have the airbags replaced by an autho-
rized dealer as soon as possible.
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Maintaining Your Airbag System
WARNING!
²Modifications to any part of the airbag system
could cause it to fail when you need it. You could
be injured because the airbags are not there to
protect you. Do not modify the components or
wiring, including adding any kind of badges or
stickers to the steering wheel hub trim cover or
the upper right side of the instrument panel. Do
not modify the front bumper, vehicle body struc-
ture, or frame.
²You need proper knee impact protection in a
collision. Do not mount or locate any aftermarket
equipment on or behind the knee bolster.
²It is dangerous to try to repair any part of the
airbag system yourself. Be sure to tell anyone who
works on your vehicle that it has airbags.
Airbag Warning Light
You will want to have the airbags ready to inflate for your
protection in an collision. While the airbag system is
designed to be maintenance free, if any of the following
occurs, have an authorized dealer service the system
immediately.
²The ªAirbag Warning Lightº does not come on or
flickers during the 6 to 8 seconds when the ignition
switch is first turned on.
²The ªAirbag Warning Lightº remains on or flickers
after the 6 to 8 second interval.
²The ªAirbag Warning Lightº flickers or comes on and
remains on while driving.
Child Restraint
Everyone in your vehicle needs to be buckled up all the
time-babies and children, too. Every state in the United
States and all Canadian provinces require that small
children ride in proper restraint systems. This is the law,
and you can be prosecuted for ignoring it.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29
2

Children 12 years and under should ride properly buck-
led up in a rear seat, if available. According to crash
statistics, children are safer when properly restrained in
the rear seats rather than in the front.
WARNING!
In a collision, an unrestrained child, even a tiny
baby, can become a missile inside the vehicle. The
force required to hold even an infant on your lap can
become so great that you could not hold the child, no
matter how strong you are. The child and others
could be badly injured. Any child riding in your
vehicle should be in a proper restraint for the child's
size.
Infants and Small Children
There are different sizes and types of restraints for
children from newborn size to the child almost large
enough for an adult safety belt. Always check the child
seat owner's manual to ensure that you have the right
seat for your child. Use the restraint that is correct for
your child.
²The rearward-facing infant carrier is for babies weigh-
ing up to about 20 lbs (9 kg), and one year old or more.
The infant restraint mustNEVERbe used in the front
seat of a vehicle with a front passenger airbag unless
the airbag is turned off. An airbag deployment could
cause severe injury or death to infants in this position.
The infant carrier is held in the vehicle by the lap belt,
lap/shoulder belt, or the LATCH child restraint an-
chorage system.
²Children under one year of age should continue to ride
in a rear-facing infant seat, even if they weigh more
than 20 lbs (9 kg). A ªconvertibleº child seat, one that
is designed to be used either rearward-facing or
forward-facing, should be used for children who are
too heavy for the infant carrier, but who are too young
to face forward in the vehicle.
²The forward-facing child seat is for children from
about 20±40 lbs (9±18 kg), and more than one year old.
The child seat is held in the vehicle by the lap belt,
lap/shoulder belt, or the LATCH child restraint an-
chorage system.
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
