JEEP WRANGLER 2006 TJ / 2.G Owners Manual

TABLE OF CONTENTSSECTIONPAGE
1INTRODUCTION.............................................................3
2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE.............................11
3UNDERSTANDING THE FEATURES OF YOUR VEHICLE..............................49
4UNDERSTANDING YOUR INSTRUMENT PANEL...................................143
5STARTING AND OPERATING.................................................179
6WHAT TO DO IN EMERGENCIES..............................................251
7MAINTAINING YOUR VEHICLE...............................................263
8MAINTENANCE SCHEDULES..................................................317
9IF YOU NEED CONSUMER ASSISTANCE.........................................339
10INDEX....................................................................347
1
2
3
4
5
6
7
8
9
10

INTRODUCTION
CONTENTS

Introduction ........................... 4
▫ Roll Over Warning ..................... 4

How To Use This Manual .................. 7

Warnings And Cautions ................... 7

Vehicle Identification Number ............... 8

Vehicle Modifications / Alterations ........... 9
1

INTRODUCTION
Thank you for selecting a JeepWrangler and welcome to
our worldwide family.
This is a specialized utility vehicle designed for both
on-road and off-road use. It can go places and perform
tasks for which conventional two-wheel drive enclosed
vehicles were not intended. It handles and maneuvers
differently from many passenger cars both on-road and
off-road, so take time to become familiar with your
vehicle.
Before you start to drive this vehicle, read the Owner’s
Manual. Be sure you are familiar with all vehicle controls,
particularly those used for braking, steering, transmis-
sion, and transfer case shifting. Learn how your vehicle
handles on different road surfaces. Your driving skills
will improve with experience. When driving off-road or
working the vehicle, don’t overload it or expect it to overcome the laws of nature. Always observe federal,
state, provincial and local laws wherever you drive.
As with other vehicles of this type, failure to operate this
vehicle correctly may result in loss of control or an
accident. Be sure to read “On-Road/Off-Road Driving
Tips” in this manual.
Roll Over Warning
Utility vehicles have a significantly higher roll over rate
than other types of vehicles. This vehicle has a higher
ground clearance, higher center of gravity, and narrower
track than many passenger cars. It is capable of perform-
ing better in a wide variety of off-road applications.
Driven in an unsafe manner, all vehicles can be caused to
go out of control. Because of the higher center of gravity
and the narrower track, if this vehicle is out of control it
may roll over when some other vehicles may not.
Do not attempt sharp turns or abrupt maneuvers or other
unsafe driving actions that can cause loss of vehicle
4 INTRODUCTION

control. Failure to operate this vehicle safely may result
in an accident, roll over of the vehicle and serious injury
or death. Because of its open-body construction, your
vehicle offers less protection than closed vehicles in the
event of an accident. Failure to use driver and passenger seat belts
provided
is a major cause of severe or fatal injury. In fact, the U.S.
government notes that the universal use of existing seat
belts could cut the highway death toll by 10,000 or more
each year, and could reduce disabling injuries by 2
million annually. In a roll over crash, an unbelted person
is significantly more likely to die than a person wearing
a seal belt. Always buckle up.
Although your vehicle may be equipped with a soft top
or optional hard top to give the occupants protection
from the weather, these tops do not offer structural
protection in the event of an accident and do not change
the open-body characteristic of the vehicle. Even though
your vehicle has a sport bar and side bars for some extra
protection, it is a truly open vehicle-there is no structural
integrated top and it has low sides and a folding wind-
shield. Many of these vehicles do not have fully enclosed
hard doors.
Roll Over Warning Label
INTRODUCTION 5
1

Operating this vehicle at excessive speeds or while
intoxicated may result in loss of control, collision with
other vehicles or objects, going off the road, or overturn-
ing, any of which may lead to serious injury or death.
Also, failure to use standard seat belts subjects the
driver and passengers to a greater risk of being thrown
out of an open-body vehicle than out of a closed vehicle
in an accident which can result in injury or death.
This manual has been prepared with the assistance of
service and engineering specialists to acquaint you with
the operation and maintenance of your new vehicle. It is
supplemented by a Warranty Information Booklet and
various customer oriented documents. You are urged to
read these publications carefully. Following the instruc-
tions and recommendations in this manual will help
assure safe and enjoyable operation of your vehicle. NOTE: After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold so that the new owner will be
aware of all safety warnings.
When it comes to service, remember that your authorized
dealer knows your vehicle best, has the factory-trained
technicians and genuine Mopar
parts, and is interested
in your satisfaction.
6 INTRODUCTION

WARNING!
Engine exhaust, some of its constituents, and certain
vehicle components contain or emit chemicals
known to the State of California to cause cancer and
birth defects or other reproductive harm. In addition,
certain fluids contained in vehicles and certain prod-
ucts of component wear contain or emit chemicals
known to the State of California to cause cancer and
birth defects or other reproductive harm.
HOW TO USE THIS MANUAL
Consult the table of contents to determine which section
contains the information you desire.
The detailed index, at the rear of the manual, contains a
complete listing of all subjects.
WARNINGS AND CAUTIONS
This manual contains WARNINGSagainst operating
procedures which could result in an accident or bodily
injury. It also contains CAUTIONSagainst procedures
which could result in damage to your vehicle. If you do
not read this entire manual you may miss important
information. Observe all Warnings and Cautions.
INTRODUCTION 7
1

VEHICLE IDENTIFICATION NUMBER
The vehicle identification number (VIN) is found on a
stamped plate located on the left front corner of the
instrument panel pad, visible from outside of vehicle
through windshield. This number also appears on the
Automobile Information Disclosure Label affixed to a
window on your vehicle. Save this label for a convenient
record of your vehicle identification number and optional
equipment. NOTE: It is illegal to remove the VIN plate.
Vehicle Identification Number
8 INTRODUCTION

VEHICLE MODIFICATIONS / ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle
could seriously affect its roadworthiness and safety
and may lead to an accident resulting in serious
injury or death.
INTRODUCTION 9
1
