JEEP WRANGLER 2006 TJ / 2.G Owners Manual

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Inspect the drive belt and replace as needed. Not
required if belt was previously replaced. X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze, if
not replaced at 102,000 miles (170 000 km). X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
† Applies only if vehicle is used for frequent trailer
towing or fleet/commercial service.
 This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty. ‡Off-highway operation, trailer towing, taxi, limousine,
bus, snow plowing, or other types of commercial service
or prolonged operation with heavy loading, especially in
hot weather, require front and rear axle service indicated
witha‡in Schedule “B”. Perform these services if the
vehicle is usually operated under these conditions.
SCHEDULE “B” 331
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “A”
Miles 6,000 12,000 18,000 24,000 30,000
(Kilometers) (10 000) (20 000) (30 000) (40 000) (50 000)
[Months] [6] [12] [18] [24] [30]
Change the engine oil and engine oil filter. X X X X X
Rotate the tires. X X X X X
Inspect the engine air filter element, and replace
if necessary. X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie
rod ends. X X XXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the manual transmission fluid, add as nec-
essary. X
Inspect the transfer case fluid. X
332 SCHEDULE “A”
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (60 000) (70 000) (80 000) (90 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Lubricate the steering and suspension ball joints. X X
Lubricate the steering linkage joints and outer tie rod
ends. XXXX
Inspect the brake linings. X X
SCHEDULE “A” 333
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the engine air filter element, and replace if nec-
essary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the ignition cables (2.4L Only). X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie rod
ends. XXXX
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the drive belt, and replace as needed. X
Inspect the drive belt, and replace as needed. Not re-
quired if belt was previously replaced. X
334 SCHEDULE “A”
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (100 000) (110 000) (120 000) (130 000)
[Months] [60] [66] [72] [78]
Flush and replace the engine coolant/anti-freeze. X
Inspect the manual transmission fluid, add as necessary. X
Inspect transfer case fluid. X
SCHEDULE “A” 335
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 84,000 90,000 96,000 102, 000
(Kilometers) (140 000) (150 000) (160 000) (170 000)
[Months] [84] [90] [96] [102]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the engine air filter element, and replace if necessary. X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie rod ends. X X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Inspect the drive belt, and replace as needed. Not required if
previously replaced. XX
Flush and replace the engine coolant/anti-freeze if not done at
60 months. X
Inspect the manual transmission fluid, add as necessary. X
Inspect the transfer case fluid. X
336 SCHEDULE “A”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Rotate the tires. X X X
Inspect the engine air filter element, and replace if necessary. X
Replace the ignition cables (2.4L Only). X
Inspect the PCV Valve, and replace if necessary.  X
Replace the spark plugs. X
Lubricate the steering linkage joints and outer tie rod ends. X X X
Lubricate the steering and suspension ball joints. X X
Inspect the brake linings. X
Replace the timing belt (2.4L Only).  X
Inspect the drive belt, and replace as needed. Not required if pre-
viously replaced. X
SCHEDULE “A” 337
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Inspect the manual transmission fluid, add as necessary. X
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze, if not done at
102,000 miles (170 000 km). X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
 This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.
338 SCHEDULE “A”
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For
Your Vehicle ..........................340
▫ Prepare For The Appointment ............340
▫ Prepare A List ........................340
▫ Be Reasonable With Requests .............340

If You Need Assistance ...................340

Warranty Information (U.S. Vehicles Only) .....343

Mopar Parts.........................343

Reporting Safety Defects ..................343
▫ In Canada ..........................343

Publication Order Forms ..................344

Department Of Transportation Uniform Tire
Quality Grades ........................345
▫ Treadwear ..........................345
▫ Traction Grades ......................345
▫ Temperature Grades ...................346
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
340 IF YOU NEED CONSUMER ASSISTANCE
