4WD JEEP WRANGLER 2006 TJ / 2.G Owners Manual

7. High Beam Indicator Light This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or low.
If the driver’s door is open, and the headlights or
parklights are left on, the “High Beam Indicator Light”
will flash and a chime will sound.
8. Seat Belt Indicator Light A warning chime and an indicator light will alert
you to buckle the seat belts. When the belt is
buckled, the chime will stop, but the light will stay
on until it times out (about 6 seconds).
9. Speedometer
Indicates vehicle speed. 10. Front Axle Lock Indicator Light — If Equipped
Indicates when the front axle lock has been
activated. (See page 199 for more information.)
11. Rear Axle Lock Indicator Light — If Equipped Indicates when the rear axle lock has been
activated. (See page 199 for more information.)
12. 4WD Indicator Light This light alerts the driver that the vehicle is in
the four-wheel drive mode, and the front and
rear driveshafts are mechanically locked to-
gether forcing the front and rear wheels to
rotate at the same speed. (See page 194 for more infor-
mation.)
148 UNDERSTANDING YOUR INSTRUMENT PANEL

NOTE:The transmission electronics constantly monitor
the transmission oil temperature. If the transmission gets
too hot, the transmission will change the way it shifts to
help control the condition. This may result in a slightly
different feeling or response during normal operation in
D (Drive) position. If the transmission becomes hot
enough, the TRANS TEMP warning light in the instru-
ment cluster will come on. After the transmission cools
down, it will return to normal operation.
Torque Converter Clutch
A feature designed to improve fuel economy has been
added to the automatic transmission of this vehicle. A
clutch within the torque converter engages automatically
at calibrated speeds. This may result in a slightly differ-
ent feeling or response during normal operation in high
gear. When the vehicle speed drops or during accelera-
tion, the clutch automatically and smoothly disengages.
FOUR–WHEEL DRIVE OPERATION
(COMMAND-TRAC™ OR ROCK-TRAC™) — IF
EQUIPPED
4WD Shift Controls
194 STARTING AND OPERATING

Operating Instructions/Precautions
The transfer case provides four mode positions — two
(rear) wheel drive high range, four wheel drive high
range, neutral, and four wheel drive low range.
This transfer case is intended to be driven in the two
wheel drive (2H) position for normal street and highway
conditions such as dry hard surfaced roads.
In the events when additional traction is required, the
transfer case 4H and 4L positions can be used to lock the
front and rear driveshafts together and force the front
and rear wheels to rotate at the same speed. This is
accomplished by simply moving the shift lever to these
positions. The 4H and 4L positions are intended for loose,
slippery road surfaces only. Driving in the 4H and 4L
positions on dry hard surfaced roads may cause in-
creased tire wear and damage to the driveline compo-
nents. The 4WD indicator light, located in the instrument panel,
alerts the driver that the vehicle is in four wheel drive
and that the front and rear driveshafts are locked to-
gether. This light illuminates when the transfer case is
shifted to either the 4H or 4L positions.
NOTE:
Do not attempt to make a shift while only the
front or rear wheels are spinning. The transfer case is not
equipped with a synchronizer and therefore the front and
rear driveshafts speeds must be equal for the shift to take
place. Shifting while only the front or rear wheels are
spinning can cause damage to the transfer case.
When operating your vehicle in 4L, the engine speed is
approximately three times that of the 2H or 4H positions
at a given road speed. Take care not to overspeed the
engine and do not exceed 25 mph (40 km/h).
STARTING AND OPERATING 195
5
