2. Remove the back window.3. Release header latches from the windshield frame.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229

4. Release the sail panel retainers from the body sidechannel at the rear corners of the vehicle.
NOTE: When releasing the sail panel retainers, it is
helpful to pull down on the rear roof bow. 5. Make sure the plastic sleeves are slid rearward over
the Sunrider link to lock in the link (Sunrider Models
only).
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. As you begin to lower the top, fold the sail panels sothat they rest on top of the soft top. 7. Release the Sunrider latch (both sides).
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231

8. Open the swing gate and lower the top.
NOTE:Ensure fabric does not overhang the sides of the
vehicle.Quick Steps To Raising The Soft Top
Refer to “Raising The Soft Top” in this section for further
information.
1. Open the swing gate and raise the top, engaging the Sunrider latches (another person may be needed to
help with this operation).
232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Engage header latches.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233

3. Install rear corner panels.4. Install the back window.
5. Install the side windows.
234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. To install the side windows, affix the window tempo-rarily by attaching to the Velcro in the rear corner. Start
the zipper but close only about 1 in (2.5 cm). 7. Insert the front retainer of the window into the door
channel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do
so can result in wind and water leaks or damage to the
window.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235

8. Insert the retainer along the bottom edge of thewindow into the bottom side channel, beginning at the
front and working to the rear of the vehicle. Finish by
closing the zipper completely and attaching the Velcro
along the top and rear of the window. Repeat this step
for the opposite side.
1 — Incorrect Insertion
2 — Correct Insertion
236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Lowering The Soft Top
1 — Header Bow6 — Quarter Window
2 — 2–Bow 7 — Check Strap
3 — 3–Bow 8 — Front Retainer — Quarter Window
4 — Sail Panel 9 — Bottom Retainer — Quarter Window
5 — Body Side Retainer
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237

1 — Zipper Start
2 — Zipper Finish
3 — Swing Gate Bar
4 — Swing Gate Brackets
