JEEP WRANGLER 2016 JK / 3.G Owners Manual
Manufacturer: JEEP, Model Year: 2016, Model line: WRANGLER, Model: JEEP WRANGLER 2016 JK / 3.GPages: 705, PDF Size: 5.5 MB
Page 341 of 705

Push and release the STEP button on the steering wheel
to access the options in the Compass display.NOTE:
The system will display the last known outside
temperature when starting the vehicle and may need to
be driven several minutes before the updated tempera-
ture is displayed. Engine temperature can also affect the
displayed temperature; therefore, temperature readings
are not updated when the vehicle is not moving.
The following displays can be reset or changed:
• Compass/Temperature
• AVG ECO (changes to present fuel economy)
• ET (will reset display)
• DTE (distance to empty)
These messages can be cycled through by pushing the
STEP button on the steering wheel. To reset the AVG ECO
or ET, push and hold the STEP button for approximately
three seconds.
Mini-Trip Control Buttons
4
UNDERSTANDING YOUR INSTRUMENT PANEL 339
Page 342 of 705

Compass/Temperature Display
NOTE:If the vehicle is equipped with a Uconnect Navi-
gation Radio, the NAV system will provide the compass
direction, and the variance and calibration menus will be
unavailable. The compass will perform accurately, based
on GPS signals instead of the Earth’s magnetic field.
Compass Variance
Compass Variance is the difference between Magnetic
North and Geographic North. To compensate for the
differences, the variance should be set for the zone where
the vehicle is driven, per the zone map. Once properly set,
the compass will automatically compensate for the differ-
ences and provide the most accurate compass heading.
To Set The Variance
Start the engine and leave the transmission gear selector
lever in the PARK position. Push and hold the RESET
button on the steering wheel (for approximately ten
seconds) until the current variance zone number is dis-
played. To change the zone, push and release the STEP
Compass Variance Map
340 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 343 of 705

button to increase the variance one step. Repeat as
necessary until the desired variance is achieved.
NOTE:The factory default zone is 8. During program-
ming, the zone value will wrap around from zone 15 to
zone 1.
Manual Compass Calibration
If the compass appears erratic, inaccurate or abnormal,
you may wish to calibrate the compass. Prior to calibrat-
ing the compass, make sure the proper zone is selected.
1. Start the engine and leave the transmission in the PARK position.
2. Push and hold the RESET button (for approximately 10 seconds) until the current variance zone number is
displayed. 3. Release the RESET button, then push and hold again
for approximately 10 seconds, until the direction is
displayed, with the CAL indicator on continuously in
the display.
4. To complete the compass calibration, drive the vehicle in one or more complete 360–degree circles, under
5 mph (8 km/h) in an area free from power lines and
large metallic objects, until the CAL indicator turns
off. The compass will now function normally.
NOTE:
• A good calibration requires a level surface and an
environment free from large metallic objects such as
buildings, bridges, underground cables, railroad
tracks, etc.
• Magnetic materials should be kept away from the top
of the center of the instrument panel. This is where the
compass sensor is located.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 341
Page 344 of 705

Average Fuel Economy / Distance To Empty (DTE)
/ Elapsed Time
•Average Fuel Economy
Shows the average fuel economy since the last reset.
When the fuel economy is reset, the digits will go blank
while the history information is erased. The averaging
will restart when enough new distance and fuel data is
accumulated.
• Distance To Empty (DTE)
Shows the estimated distance that can be traveled with
the fuel remaining in the tank. This estimated distance is
determined by a weighted average of the instantaneous
and average fuel economy, according to the current fuel
tank level. DTE cannot be reset. •
Elapsed Time
Shows the total elapsed time of travel since the last reset.
Elapsed time will increment when the ignition switch is
in the RUN or START positions. The elapsed timer
displays minutes:seconds. After 59minutes:59seconds, it
displays hours:minutes:seconds.
Trip Conditions
Trip Odometer (ODO) / ECO (Fuel Saver Indicator)
— If Equipped
This display shows the distance traveled since the last
reset. Push and release the right button (on the instru-
ment cluster) to switch from odometer to Trip A or Trip B
or to ECO. Push and hold the right button while the
odometer/trip odometer is displayed to reset.
342 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 345 of 705

Trip A
Shows the total distance traveled for trip A since the last
reset.
Trip B
Shows the total distance traveled for trip B since the last
reset.
ECO (Fuel Saver Indicator) — If Equipped
The ECO indicator will illuminate when you are driving
in a fuel efficient manner and can be used to modify
driving habits in order to increase fuel economy.
Trip Display Button
4
UNDERSTANDING YOUR INSTRUMENT PANEL 343
Page 346 of 705

ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) — IF EQUIPPED
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver-interactive display that is located in the
instrument cluster.This system conveniently allows the driver to select a
variety of useful information by pushing the switches
mounted on the steering wheel. The EVIC consists of the
following:
•
Compass Heading (N, S, E, W, NE, NW, SE, SW)
• Outside Temperature (°F or °C)
• ECO Display
• Digital Speedometer
• Average Fuel Economy
• Distance To Empty
• Tire Pressure Monitor System — If Equipped
• Elapsed Time
• Vehicle Info
• EVIC Units Selection
Electronic Vehicle Information Center (EVIC)
344 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 347 of 705

•System Status and Warnings (Door Ajar, etc.)
• Personal Settings (Customer-Programmable Features)
The system allows the driver to select information by
pushing the following buttons mounted on the steering
wheel: •
MENU Button
Push and release the MENUbutton to advance
the display to each of the EVIC Main Menu
features or to return to the Main Menu from a
sub-menu. Upon reaching the last item in the
Main Menu the EVIC will advance to the first item in the
Main Menu with the next MENUbutton push and
release.
• COMPASS Button
Push and release the COMPASSbutton to
return to the Compass/Outside Temperature/
Audio Information/ECO screen whenever the
current display is not the Compass/Outside
Temperature/Audio Information/ECO screen.
EVIC Steering Wheel Buttons
4
UNDERSTANDING YOUR INSTRUMENT PANEL 345
Page 348 of 705

•RIGHT Arrow Button
Push and release the RIGHTarrow button
when prompted by the EVIC to Reset Main
Menu features with a reset capability or to
change Personal Settings.
• DOWN Arrow Button
Push and release the DOWNarrow button
when prompted by the EVIC to step through
Vehicle Info submenu or stored system warn-
ing messages or Personal Settings features.
Electronic Vehicle Information Center (EVIC)
Displays
When the appropriate conditions exist, the EVIC displays
the following messages:
• Low Tire Pressure
• Low Fuel •
Service TPM System (refer to Tire Pressure Monitor-
ing System inStarting and Operating)
• Damaged Key
• Key in Ignition
• Turn Signal On (with a continuous warning chime)
• Left Front Turn Signal Lamp Out (with a single chime)
• Left Rear Turn Signal Lamp Out (with a single chime)
• Right Front Turn Signal Lamp Out (with a single
chime)
• Right Rear Turn Signal Lamp Out (with a single chime)
• Key Fob Battery Low (with a single chime)
• Personal Settings Not Avail. – Vehicle Not in Park —
automatic transmission
346 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 349 of 705

•Personal Settings Not Avail. – Vehicle in Motion —
manual transmission
• Door Open (with vehicle graphic showing which door
is open. A single chime sounds if the vehicle is in
motion).
• Gate Open (with vehicle graphic showing the
Liftgate/back door open and a single chime sounds if
the vehicle is in motion)
• Check Gascap (refer to “Adding Fuel” in “Starting
And Operating” for further information)
• Oil Change Required (with a single chime)
• ECO (Fuel Saver Indicator) — if equippedEVIC Main Menu
To step to each main menu feature push and release the
MENU button once for each step. A step from the last
item in the list will cause the first item in the feature list
to be displayed. The following features are in the Main
menu:
• Compass, Outside Temperature, and ECO display
• Digital Speedometer
• Average Fuel Economy
• Distance to Empty
• Tire Pressure — If Equipped
• Elapsed Time
• Vehicle Information
• Coolant Temp
• Oil Pressure
4
UNDERSTANDING YOUR INSTRUMENT PANEL 347
Page 350 of 705

•Transmission Temp — Automatic Transmission Only
• Oil Life Remaining (Automatic Oil Change Indica-
tor)
• EVIC Units Selection
• System Status and Warnings
• Personal Settings
NOTE:
For features in the EVIC that can be reset (Average
Fuel Economy and Elapsed Time), the EVIC prompts a reset
with the RIGHT
arrow button graphic and the word
RESET next to it.
When the RIGHTarrow button is pushed, the
selected feature will reset and RESET ALL will display
next to the RIGHT
arrow button . Pushing the
RIGHT
arrow button a second time will reset both
Average Fuel Economy and Elapsed Time. After three seconds without pushing the
RIGHT
arrow but-
ton, RESET ALL will return to RESET and only the
selected feature will have been reset.
Compass, Outside Temperature Display / ECO
(Fuel Saver Mode) — If Equipped
The compass readings indicate the direction the vehicle is
facing. Push and release the COMPASSbutton to display
one of eight compass headings, the outside temperature/
ECO if the EVIC display is not already displaying this
screen.
NOTE: The system will display the last known outside
temperature when starting the vehicle and may need to
be driven several minutes before the updated tempera-
ture is displayed. Engine temperature can also affect the
displayed temperature; therefore, temperature readings
are not updated when the vehicle is not moving.
348 UNDERSTANDING YOUR INSTRUMENT PANEL
