emergency towing JEEP WRANGLER 2017 JK / 3.G Owners Manual

The following indicators should be used to ensure that you
have engaged the transmission into the PARK position (P):
•When shifting into PARK, firmly move the gear selector
all the way forward and to the left until it stops and is
fully seated.
• Look at the transmission gear position display and
verify that it indicates the PARK position (P).
• With brake pedal released, verify that the gear selector
will not move out of PARK.
REVERSE (R)
This range is for moving the vehicle backward. Shift into
REVERSE only after the vehicle has come to a complete
stop.
NEUTRAL (N)
Use this range when the vehicle is standing for prolonged
periods with the engine running. The engine may be
started in this range. Apply the parking brake and shift the
transmission into PARK if you must leave the vehicle.
WARNING!
Do not coast in NEUTRAL and never turn off the
ignition to coast down a hill. These are unsafe practices
that limit your response to changing traffic or road
conditions. You might lose control of the vehicle and
have a collision.
CAUTION!
Towing the vehicle, coasting, or driving for any other
reason with the transmission in NEUTRAL can cause
severe transmission damage. Refer to “Recreational
Towing” in “Starting And Operating” and “Towing A
Disabled Vehicle” in “In Case Of Emergency” for
further information.
DRIVE (D)
This range should be used for most city and highway
driving. It provides the smoothest upshifts and downshifts,
and the best fuel economy. The transmission automatically
upshifts through underdrive first, second, and third gears,
direct fourth gear and overdrive fifth gear. The DRIVE
position provides optimum driving characteristics under
all normal operating conditions.
298 STARTING AND OPERATING

IN CASE OF EMERGENCY
CONTENTS
HAZARD WARNING FLASHERS ............342
 BULB REPLACEMENT ....................342
▫ Replacement Bulbs .....................342
▫ Bulb Replacement ..................... .343
 FUSES ............................... .346
▫ General Information .....................347
▫ Totally Integrated Power Module ...........348
 JACKING AND TIRE CHANGING ...........353
▫ Jack Location ........................ .353
▫ Spare Tire Removal .....................354
▫ Preparations For Jacking .................354
▫ Jacking Instructions .....................355
▫ Road Tire Installation ....................357
 JUMP-STARTING ....................... .358▫
Preparations For Jump-Start ...............359
▫ Jump-Starting Procedure ..................360
 IF YOUR ENGINE OVERHEATS .............361
 GEAR SELECTOR OVERRIDE ..............362
 FREEING A STUCK VEHICLE ..............363
 TOWING A DISABLED VEHICLE ............365
▫ Without The Ignition Key .................366
▫ Four–Wheel Drive Models ................366
▫ Emergency Tow Hooks — If Equipped .......367
 ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS) .............................. .368
 EVENT DATA RECORDER (EDR) ............368
7

TOWING A DISABLED VEHICLE
This section describes procedures for towing a disabled
vehicle using a commercial towing service. If the transmis-
sion and drivetrain are operable, disabled vehicles may
also be towed as described under “Recreational Towing” in
the “Starting And Operating” section.
Towing Condition Wheels OFF The Ground4WD MODELS
Flat Tow NONESee instructions under “Recreational Towing” in
“Starting And Operating”.
• Automatic Transmission in PARK
• Manual Transmission in gear
(NOT in NEUTRAL)
• Transfer Case in NEUTRAL
• To w i n forward direction
Wheel Lift Or Dolly Tow FrontNOT ALLOWED
Rear NOT ALLOWED
Flatbed ALL BEST METHOD
7
IN CASE OF EMERGENCY 365

Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for this purpose, following equipment
manufacturer ’s instructions. Use of safety chains is man-
datory. Attach a tow bar or other towing device to main
structural members of the vehicle, not to bumpers or
associated brackets. State and local laws regarding vehicles
under tow must be observed.
If you must use the accessories (wipers, defrosters, etc.)
while being towed, the ignition must be in the ON/RUN
position, not the ACC position.
If the vehicle’s battery is discharged, refer to “Gear Selector
Override” in this section for instructions on shifting the
automatic transmission out of PARK for towing.
CAUTION!
•Do not use sling type equipment when towing.
Vehicle damage may occur.
• When securing the vehicle to a flat bed truck, do not
attach to front or rear suspension components. Dam-
age to your vehicle may result from improper towing.
Without The Ignition Key
Special care must be taken when the vehicle is towed with
the ignition in the LOCK position. The only approved
method of towing without the ignition key is with a flatbed
truck. Proper towing equipment is necessary to prevent
damage to the vehicle.
Four–Wheel Drive Models
The manufacturer recommends towing with all wheels
OFF the ground. Acceptable methods are to tow the vehicle
on a flatbed or with one end of the vehicle raised and the
opposite end on a towing dolly.
If flatbed equipment is not available and the transfer case is
operable, the vehicle may be towed (in the forward direction,
with ALLwheels on the ground), IFthe transfer case is in
NEUTRAL (N) and the transmission is in PARK(for auto-
matic transmissions) or in gear ( NOTinNEUTRAL, for
manual transmissions). Refer to “Recreational Towing” in
“Starting And Operating” for detailed instructions.
366 IN CASE OF EMERGENCY

CAUTION!
•Front or rear wheel lifts must not be used. Internal
damage to the transmission or transfer case will
occur if a front or rear wheel lift is used when
towing.
• Towing this vehicle in violation of the above require-
ments can cause severe transmission and/or transfer
case damage. Damage from improper towing is not
covered under the New Vehicle Limited Warranty.
Emergency Tow Hooks — If Equipped
If your vehicle is equipped with tow hooks, they are
mounted in the front and the rear.
NOTE: For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of damage
to the vehicle. Always use an appropriately rated tow
strap.
WARNING!
• Do not use a chain for freeing a stuck vehicle. Chains
may break, causing serious injury or death.
• Stand clear of vehicles when pulling with tow hooks.
Tow straps may become disengaged, causing serious
injury.
CAUTION!
Tow hooks are for emergency use only, to rescue a
vehicle stranded off road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle. Tow straps are recommended
when towing the vehicle, chains may cause vehicle
damage.7
IN CASE OF EMERGENCY 367

NOTE:
•The emergency number dialed is based on the country
where the vehicle is purchased (911 for the U.S. and
Canada and 060 for Mexico). The number dialed may
not be applicable with the available mobile service and
area.
• If supported, this number may be programmable on
some systems. To do this, push the Phone
button and
say “Setup,” followed by “Emergency.”
• The Uconnect Phone does slightly lower your chances of
successfully making a phone call as to that for the
mobile phone directly.
WARNING!
To use your Uconnect Phone System in an emergency,
your mobile phone must be:
• Turned on.
• Paired to the Uconnect System.
• Have network coverage.
Roadside Assistance/Towing Assistance
If you need roadside assistance:
• Push the Phone
button to begin.
•After the “Ready” prompt and the following beep, say
“Towing Assistance.”
NOTE: You should program the desired Towing Assistance
phone number using the Voice Command system. To do
this, push the Phone
button and say “Setup,” fol-
lowed by “Towing Assistance.” When prompted say
1-800-521-2779 for U.S./Canada, say 55-14-3454 for
Mexico City and 1-800-712-3040 for outside Mexico City
in Mexico.
Paging
To learn how to page, refer to “Working With Automated
Systems.” Paging works properly except for pagers of
certain companies, which time out a little too soon to work
properly with the Uconnect Phone.
Voice Mail Calling
To learn how to access your voice mail, refer to “Working
With Automated Systems.”
10
MULTIMEDIA 483

Safety............................ .405, 413
Snow Tires ............................ .420
Spare Tire ....................354, 420, 421, 422
Spinning .............................. .416
Tread Wear Indicators .....................416
Tire Safety Information ...................... .405
Tongue Weight/Trailer Weight .................323
Tow Hooks, Emergency ..................... .367
Towing .......................... .315, 319, 365
24-Hour Towing Assistance .................483
Disabled Vehicle ........................ .365
Recreational ........................... .327
Weight ............................... .319
Towing Assistance ......................... .483
Towing Vehicle Behind A Motorhome ............327
Trac-Lok Rear Axle ........................ .305
Traction Control .......................... .218
Trailer Sway Control (TSC) ....................225
Trailer Towing ............................ .315
Cooling System Tips ..................... .326
Hitches ............................... .318
Trailer And Tongue Weight ..............319, 323
Wiring ............................... .324
Trailer Towing Guide ....................... .319
Trailer Weight ............................ .319Transaxle
Autostick ............................. .300
Transfer Case ............................ .402
Fluid ................................ .445
Four-Wheel-Drive Operation ................301
Maintenance ........................... .402
Transmission Automatic ......................... .295, 402
Fluid ................................ .445
Maintenance ........................... .402
Manual ............................... .290
Shifting .............................. .293
T

ransporting Pets ......................... .278
Tread Wear Indicators ...................... .416
Turn Signals ....................... .54, 344, 345
UCI Connector ........................... .470
Uconnect Advanced Phone Connectivity ...............486
Phone Call Features ...................... .479
Phone Features ......................... .482
Uconnect (Hands-Free Phone) ..................472
Uniform Tire Quality Grades ..................425
Universal Consumer Interface (UCI) Connector .....470
522 INDEX
