Page 44 of 527
Manual Rear Seats
Removing the Rear Seat — Two-Door Models
NOTE:
•Prior to folding the rear seat, it may be necessary to
reposition the front seats.
• Be sure that the front seats are fully upright and posi-
tioned forward. This will allow the rear seat to fold
down easily.
1. Lift the seatback release lever and fold the seatback forward. 2. Slowly flip the entire seat forward.
WARNING!
Do not drive the vehicle with the seat in the forward
tumble position. The seat must be latched to all floor
attachments when the vehicle is in motion.
Rear Seat Release
Folding Rear Seat
42 GETTING TO KNOW YOUR VEHICLE
Page 45 of 527
3. Push down on the release bar on each side, and pull theseat out and away from the lower bracket.
4. Remove the seat from the vehicle.
WARNING!
• It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
(Continued)
WARNING! (Continued)
•Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
• In a collision, you or others in your vehicle could be
injured if seats are not properly latched to their floor
attachments. Always be sure that the seats are fully
latched.
Replacing The Rear Seat — Two-Door Models
Reverse the steps for removing the seat.
WARNING!
• To help protect against personal injury, passengers
should not be seated in the rear cargo area with the
rear seat folded down or removed from the vehicle.
• The rear cargo space is intended for load carrying
purposes only, not for passengers who should sit in
seats and use seat belts.Release Bar Location
3
GETTING TO KNOW YOUR VEHICLE 43
Page 46 of 527
60/40 Split Folding Rear Seat — Four-Door Models
To provide additional storage area, each rear seat can be
folded flat to allow for extended cargo space.
NOTE:
•Prior to folding the rear seat, it may be necessary to
reposition the front seat to its mid-track position.
• Be sure that the front seats are fully upright and posi-
tioned forward. This will allow the rear seat to fold
down easily.
WARNING!
• It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly. To Fold Down The Rear Seat
Locate the release lever (upper outboard side of seat), and
lift it upward until the seatback releases.
Slowly fold down the seatback.
NOTE:
You may experience deformation in the seat cush-
ion from the seat belt buckles if the seats are left folded for
an extended period of time. This is normal. By simply
opening the seats to the open position, the seat cushion will
return to its normal shape over time.
Release Levers
44 GETTING TO KNOW YOUR VEHICLE
Page 245 of 527
Lap/Shoulder Belt Untwisting Procedure
Use the following procedure to untwist a twisted lap/
shoulder belt.
1. Position the latch plate as close as possible to the anchorpoint.
2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees
to create a fold that begins immediately above the latch
plate.
3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the
latch plate.
4. Continue to slide the latch plate up until it clears the folded webbing and the seat belt is no longer twisted.
Adjustable Upper Shoulder Belt Anchorage
In the driver and front passenger seats, the top of the
shoulder belt can be adjusted upward or downward to
position the seat belt away from your neck. Push or
squeeze the anchorage button to release the anchorage, and
move it up or down to the position that serves you best. As a guide, if you are shorter than average, you will prefer
the shoulder belt anchorage in a lower position, and if you
are taller than average, you will prefer the shoulder belt
anchorage in a higher position. After you release the
anchorage button, try to move it up or down to make sure
that it is locked in position.
Adjustable Upper Anchorage
5
SAFETY 243
Page 522 of 527
Front Seat...................... .237, 239, 241
Inspection ............................. .280
Operating Instructions .....................241
Pregnant Women ........................ .245
Pretensioners .......................... .245
Rear Seat ............................. .239
Reminder ............................. .201
Untwisting Procedure .....................243
Seats ....................................37
Adjustment .............................37
Easy Entry ..............................39
Fold And Tumble Rear .....................42
Heated .................................45
Height Adjustment ........................38
Rear Folding .............................44
Removal ...............................43
Seatback Release ..........................38
Tilting .................................38
Security Alarm ......................... .26, 201
Security System ............................26
Selection Of Coolant (Antifreeze) ...............443
Sentry Key (Immobilizer) ......................24
Sentry Key Programming ......................25
Sentry Key Replacement ......................25
Service Assistance ......................... .502Service Contract
.......................... .504
Service Manuals .......................... .506
Settings, Personal ......................... .191
Setting The Clock ...................... .449, 457
Shifting ................................ .293
Automatic Transmission ....................293
Manual Transmission ..................... .290
Transfer Case, Shifting Into Transfer Case
Neutral (N) ............................ .328
Transfer Case, Shifting Out Of Transfer Case
Neutral (N) ............................ .329
Shift Lever Override ....................... .362
Shoulder Belts ............................ .239
Signals, Turn .....................54, 282, 344, 345
Snow Chains (Tire Chains) ....................423
Snow Tires .............................. .420
Soft
Top ............................. .100, 131
Spare Tire ..................... .354, 420, 421, 422
Spark Plugs ............................. .443
Specifications Fuel (Gasoline) ......................... .443
Oil.................................. .443
Speed Control Accel/Decel ............................311
520 INDEX
