Totally Integrated Power Module
The Totally Integrated Power Module is located in the
engine compartment near the battery. This center contains
cartridge fuses, mini fuses, and relays. A label that identi-
fies each component is printed on the inside of the cover.
CavityCartridge Fuse Mini Fuse Description
J1 –– –
J2 30 Amp Pink –Transfer Case Module
J3 –– –
J4 25 Amp Clear –Driver Door Node
J5 25 Amp Clear –Passenger Door Node
J6 40 Amp Green –Anti-Lock Brake System (ABS) Pump/
Stability Control System
J7 30 Amp Pink –Anti-Lock Brake System (ABS) Valve/
Stability Control System
J8 –– –
Totally Integrated Power Module
348 IN CASE OF EMERGENCY

CavityCartridge Fuse Mini Fuse Description
J9 40 Amp Green –PZEV Sec Motor/Flex Fuel – If Equipped
J10 30 Amp Pink –Headlamp Wash Relay/Manifold Tuning
Valve
J11 30 Amp Pink – Sway Bar
J12 –– –
J13 60 Amp Yellow –Ignition Off Draw (IOD) – Main
J14 40 Amp Green –Rear Defroster
J15 40 Amp Green –Front Blower
J17 40 Amp Green –Starter Solenoid
J18 20 Amp Blue –Powertrain Control Module (PCM) Trans
Range
J19 60 Amp Yellow –Radiator Fan
J20 30 Amp Pink –Front Wiper LO/HI
J21 20 Amp Blue –Front/Rear Washer
J22 –– Spare
M1 –15 Amp Blue Center High-Mounted Stop Light (CHMSL)/
Switch Stop Lamp Feed
M2 –20 Amp Yellow Relay Trailer Lighting (Stop lamp)
M3 –20 Amp Yellow Front/Rear Axle Locker Relay
M4 –2 Amp Grey Clock Spring
7
IN CASE OF EMERGENCY 349

CavityCartridge Fuse Mini Fuse Description
M30 –15 Amp Blue Wiper Motor Frt, J1962 Diagnostic Feed
M31 –20 Amp Yellow Backup Lamps
M32 –10 Amp Red Airbag Controller, TT EUROPE
M33 –10 Amp Red Powertrain Controller
M34 –10 Amp Red Park Assist, Climate Control System,
Headlamp Wash, Compass
M35 –10 Amp Red Heated Mirrors
M36 –20 Amp Yellow Power Outlet
M37 –10 Amp Red Anti-Lock Brake System, Electronic Stability
Control, Stop Lamp Switch, Fuel PumpRelay
M38 –25 Amp Clear Lock/Unlock Motors
CAUTION!
•When installing the Integrated Power Module cover,
it is important to ensure the cover is properly posi-
tioned and fully latched. Failure to do so may allow
water to get into the Integrated Power Module, and
possibly result in an electrical system failure.
(Continued)
CAUTION! (Continued)
•When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it indicates a
problem in the circuit that must be corrected.
352 IN CASE OF EMERGENCY

Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY)
To assist customers who have hearing difficulties, the
manufacturer has installed special TDD (Telecommunica-
tion Devices for the Deaf) equipment at its customer center.
Any hearing or speech impaired customer, who has access
to a TDD or a conventional teletypewriter (TTY) in the
United States, can communicate with the manufacturer by
dialing 1-800-380-CHRY.
Canadian residents with hearing difficulties that require
assistance can use the special needs relay service offered by
Bell Canada. For TTY teletypewriter users, dial 711 and for
Voice callers, dial 1-800-855-0511 to connect with a Bell
Relay Service operator.
Service Contract
You may have purchased a service contract for a vehicle to
help protect you from the high cost of unexpected repairs
after the manufacturer’s New Vehicle Limited Warranty
expires. The manufacturer stands behind only the manufac-
turer’s service contracts. If you purchased a manufacturer’s
service contract, you will receive Plan Provisions and an
Owner Identification Card in the mail within three weeks of
the vehicle delivery date. If you have any questions about the
service contract, call the manufacturer’s Service Contract
National Customer Hotline at 1-800-521-9922 (Canadian resi-
dents, call (800) 465-2001 English / (800) 387-9983 French).
