JEEP WRANGLER UNLIMITED 2008 Owners Manual

Folding Down The Soft Top

3

NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
1. If your vehicle has half-doors, remove each half-door
window by opening the door and lifting the half-door
window out.
NOTE: Stow half-door windows carefully outside of the
vehicle, never inside to avoid scratches.
2. Above the front of the rear door, place finger up into
the cutout in the plastic retainer and pull down, rolling
both the front and rear retainers out of the door frame.
Repeat this on the other side. 3. Unclip and move the sun visors to the side.

3

•Unzip the rear window starting at the right lower
corner of the window. Pull the zipper up, across the
top and down to the left lower corner.Zipper pulls
will stay on the rear window. Pull down on the rear
window to disengage from the zipper on the top
cover. Stow the windows carefully to avoid scratch-
ing. 7. Undo the Velcro
that runs along the top and rear
edge of the side window.
8. Beginning from the rear lower corner, completely
unzip the window.
9. Once unzipped, remove side window retainers from
the door channel and body side channel. Repeat this step
on the opposite side.

3

12. The swing gate brackets do not need to be removed
unless the hard top is being installed. To remove the
swing gate brackets, pull the front of the bracket forward
while rolling the entire bracket back in towards the
vehicle to disengage.13. Grasp the front side bow behind the header, and lift
the top.

3

16. Release the side bows by pressing down on the latch
above the front of the rear door. Push the top rearward to
disengage. Repeat this step on the other side.17. Grasp the folded side bows and slide the top along
the door frame track to the rear door frame.

3
