POWER DISTRIBUTION
GENERAL INFORMATION
This section covers the Power Distribution Center
(PDC) and all circuits involved with it. For additional
information on system operation refer to the appro-
priate section of the wiring diagrams.
DIAGRAM INDEX
Component Page
A/C Compressor Clutch Relay..............8W-11-3, 10
ABS Pump Motor Relay..................8W-11-3, 9
ABS Control Module.....................8W-11-8, 9
ABS Power Relay......................8W-11-3, 8
Automatic Shut Down Relay................8W-11-3, 6
Engine Starter Motor Relay................8W-11-3, 4
Fuel Pump Relay.......................8W-11-3, 6
Fuse 1 (Fuse Block).......................8W-11-8
Fuse 1 (PDC)...........................8W-11-6
Fuse 2 (PDC)...........................8W-11-7
Fuse 3 (PDC)...........................8W-11-7
Fuse 4 (PDC)......................8W-11-4, 8, 10
Fuse 5 (Fuse Block).......................8W-11-6
Fuse 5 (PDC)...........................8W-11-7Component Page
Fuse 6 (PDC)...........................8W-11-7
Fuse 7 (PDC)...........................8W-11-7
Fuse 8 (PDC)...........................8W-11-5
Fuse 9 (Fuse Block)......................8W-11-10
Fuse 9 (PDC)...........................8W-11-9
Fuse 10 (PDC)..........................8W-11-8
Fuse 11 (PDC)..........................8W-11-5
Fuse 12 (Fuse Block)......................8W-11-8
Fuse 12 (PDC)..........................8W-11-5
Headlamp Switch.........................8W-11-7
Horn Relay...........................8W-11-3, 5
Ignition Switch......................8W-11-4, 8, 10
Power Distribution Center...................8W-11-2
Powertrain Control Module..............8W-11-4, 6, 10
J8W-11 POWER DISTRIBUTIONÐYJ VEHICLES 8W - 11 - 1
