JEEP YJ 1995 Service And Repair Manual

CONNECTOR PIN OUTS
GENERAL INFORMATION
The pages referenced in this section show the con-
nector, the circuits in the connector, and the pin thatcircuit occupies. Individual connector numbers are
referenced on diagram pages throughout Group 8W.
CONNECTOR LOCATIONS
Component Page
C101................................8W-80-3
C102................................8W-80-4
C103................................8W-80-4
C104................................8W-80-4
C105................................8W-80-4
C106................................8W-80-5
C107................................8W-80-5
C108...............................8W-80-6, 7
C109................................8W-80-8
C110................................8W-80-8
C111................................8W-80-9
C112................................8W-80-10
C113................................8W-80-10
C114................................8W-80-10
C115................................8W-80-10
C116................................8W-80-11
C117................................8W-80-11
C118................................8W-80-11
C119................................8W-80-11
C120................................8W-80-11
C121................................8W-80-12
C122................................8W-80-12
C123................................8W-80-12
C124................................8W-80-12
C125................................8W-80-12
C126................................8W-80-12
C127................................8W-80-13
C128................................8W-80-13
C129................................8W-80-13
C130................................8W-80-13
C131................................8W-80-13
C132................................8W-80-14
C133................................8W-80-14
C134................................8W-80-15
C135................................8W-80-15
C136................................8W-80-15
C137................................8W-80-15
C138................................8W-80-15
C139................................8W-80-16
C140................................8W-80-16
C141................................8W-80-16
C142................................8W-80-16
C143................................8W-80-16
C144................................8W-80-17
C145................................8W-80-17
C146................................8W-80-17
C147................................8W-80-17Component Page
C148................................8W-80-17
C149................................8W-80-18
C150................................8W-80-18
C151................................8W-80-18
C152................................8W-80-18
C153................................8W-80-18
C154................................8W-80-19
C155................................8W-80-19
C156................................8W-80-19
C157................................8W-80-19
C158................................8W-80-20
C159................................8W-80-20
C160................................8W-80-20
C161................................8W-80-20
C162................................8W-80-22
C163................................8W-80-21
C164................................8W-80-21
C202................................8W-80-21
C203................................8W-80-21
C204................................8W-80-22
C205................................8W-80-22
C206................................8W-80-22
C207................................8W-80-22
C208................................8W-80-23
C209................................8W-80-23
C210................................8W-80-23
C211................................8W-80-23
C212................................8W-80-23
C213................................8W-80-24
C214................................8W-80-24
C215................................8W-80-24
C216................................8W-80-24
C217................................8W-80-24
C218................................8W-80-25
C219................................8W-80-25
C220................................8W-80-25
C221................................8W-80-25
C222................................8W-80-25
C223................................8W-80-26
C224................................8W-80-26
C225................................8W-80-26
C226................................8W-80-26
C227................................8W-80-26
C228................................8W-80-27
C229................................8W-80-27
C230................................8W-80-27
C231................................8W-80-28
J8W-80 CONNECTOR PIN OUTSÐXJ VEHICLES 8W - 80 - 1

Component Page
C232................................8W-80-28
C233................................8W-80-28
C234................................8W-80-28
C235................................8W-80-29
C236................................8W-80-29
C237................................8W-80-29
C238................................8W-80-29
C239................................8W-80-30
C240................................8W-80-30
C241................................8W-80-30
C242................................8W-80-30
C243................................8W-80-30
C301................................8W-80-31
C302................................8W-80-31
C303................................8W-80-31
C304................................8W-80-31
C305................................8W-80-31
C306................................8W-80-32
C307................................8W-80-32
C308................................8W-80-32
C309................................8W-80-32
C310................................8W-80-32
C311................................8W-80-33
C312................................8W-80-33
C313................................8W-80-33
C314................................8W-80-33
C315................................8W-80-33
C316................................8W-80-34
C317................................8W-80-34
C318................................8W-80-34
C319................................8W-80-34
C320................................8W-80-35
C321................................8W-80-35
C322................................8W-80-35
C323................................8W-80-35
C324................................8W-80-36
C325................................8W-80-36
C326................................8W-80-36
C327................................8W-80-36
C328................................8W-80-36
C329................................8W-80-37
C331................................8W-80-37
C332................................8W-80-37
C333................................8W-80-37
C334................................8W-80-38
C335................................8W-80-38
C336................................8W-80-38
C338................................8W-80-38
C339................................8W-80-38
C340................................8W-80-39
C341................................8W-80-39Component Page
C342................................8W-80-40
C343................................8W-80-40
C344................................8W-80-40
C345................................8W-80-41
C346................................8W-80-41
C347................................8W-80-41
C348................................8W-80-41
C349................................8W-80-42
C350................................8W-80-42
C351................................8W-80-42
C352................................8W-80-42
C353................................8W-80-42
C354................................8W-80-43
C355................................8W-80-43
C356................................8W-80-43
C357................................8W-80-43
C358................................8W-80-43
C401................................8W-80-44
C402................................8W-80-44
C403................................8W-80-41
C404................................8W-80-44
C405................................8W-80-44
C406................................8W-80-45
C407................................8W-80-45
C408................................8W-80-45
C409................................8W-80-45
C410................................8W-80-45
C411................................8W-80-46
C412................................8W-80-46
C413................................8W-80-46
C414................................8W-80-46
C415................................8W-80-46
C416................................8W-80-47
C417................................8W-80-47
C418................................8W-80-47
C419................................8W-80-47
C420................................8W-80-47
C421................................8W-80-48
C422................................8W-80-48
C423................................8W-80-48
C424................................8W-80-48
C425................................8W-80-49
C426................................8W-80-49
C427................................8W-80-49
C428................................8W-80-49
C429................................8W-80-50
C430................................8W-80-50
C431................................8W-80-50
8W - 80 - 2 8W-80 CONNECTOR PIN OUTSÐXJ VEHICLESJ

1995 Jeep Cherokee/Wrangler
Publication No. 81-370-5146
TSB 26-07-95 September, 1995
