Knowing your vehicle90
3
1
2
3
4
5
6
7
8
9
To operate the electric rearview mir-
ror
When the engine is running, the
glare is automatically controlled by
the sensor mounted in the rearview
mirror.
Whenever the shift lever is shifted
into reverse (R), the mirror will auto-
matically go to the brightest setting in
order to improve the drivers view
behind the vehicle.
• Type B
The electric day/night rearview mir-
ror automatically controls the glare
from the headlights of the car behind
you. Adjust the rearview mirror to the
desired position.
Press the “O”button to turn the auto-
matic- dimming function off. The mir-
ror indicator light will turn off.
Press the “I”button to turn the auto-
matic- dimming function on, the mir-
ror indicator light will illuminate.
2GHN3310
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 90

391
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Map light Front (if equipped)The lights are turned ON or OFF by
pressing the corresponding switch.
Dome light (if equipped)
➀
OFF - The light stays off evenwhen a door is open.
➁
DOOR - The light turns on or off when a door is opened
or closed.
Interior light goes out
slowly if the door is
closed.
When a door is unlocked by the transmitter, interi-
or light stays on for 30
seconds as long as the
door is not opened.
➂
ON - The light turns on and stays on even when the
doors are all closed. Door courtesy lamp
The door courtesy lamp comes ON
when the door is opened to assist
entering or exiting the vehicle. It also
serves as a warning to passing vehi-
cles that the vehicle door is open.
INTERIOR LIGHTS
2GHA2060
OFF DOOR
ON
E2BLA324
2GHB3004
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 91

Knowing your vehicle92
3
1
2
3
4
5
6
7
8
9
✽ ✽
NOTICE• To avoid possible theft, do not
leave valuables in the storage com-
partment.
• Since stored items may move while driving, be sure to position them
in the storage compartment so
that they do not make noise or
cause a potential safety hazard
when the vehicle is moving.
• Always keep the storage compart- ment covers closed while driving.
Do not attempt to place many
items in the storage compartment
that the storage compartment
cover can not close securely.
Center console storageTo open either of the console stor-
age compartments, press button
➀
or
➁.
These compartments can be used to
store small items required by the
driver or front passenger.
Multi boxFront (if equipped)To open the cover, push the button
and lift the cover up to open. It can
be used for storing small items
required by the driver or front pas-
senger.
STORAGE COMPARTMENT
WARNING
Do not store cigarette lighters,
propane cylinders, or other
flammable/explosive materials
in the vehicle. These items may
catch fire and/or explode if the
vehicle is exposed to hot tem-
peratures for extended periods.
1GHA2106
2GHN2109
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 92

393
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Rear (if equipped)To open the storage compartment,
pull the armrest down and pull up on
the locking tab (
➀). It can be used for
storing small items.
Glove boxThe glove box can be locked (
➀) and
unlocked (
➁) with a master key.
It cannot be locked/unlocked with the
sub key.
To open the glove box, make sure it
is unlocked, then pull the handle (
➂)
and the glove box will automatically
open (
➃). Close the glove box after
use.
✽ ✽ NOTICESince key is not fully inserted into
the glove box key set, do not apply
excessive force. Doing so may dam-
age the parts.
1GHA2234A
1GHA2086
CAUTION
To reduce the risk of injury in
case of an accident or suddenstop, always keep the glove boxdoor closed while driving.
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 93

Knowing your vehicle94
3
1
2
3
4
5
6
7
8
9
Sunglass holder A sunglass storage compartment is
provided on the overhead console.
To open the sunglass holder, press
the cover and the holder will slowly
open. Place your sunglasses in the
compartment door with the lenses
facing out. Push to close.
✽ ✽
NOTICEMake sure the sunglass holder is
closed while driving.
1GHA2060B
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 94

395
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Cigarette lighterFrontTo use the cigarette lighter, press
the front face then release it to allow
the cigarette lighter and ashtray to
slowly extend from center panel.
To operate the cigarette lighter, press
it in and release it. When it is heated,
it automatically pops out ready for
use.
If the engine is not running, the igni-
tion switch must be in the ACC posi-
tion for the lighter to operate.
✽ ✽NOTICE• Do not hold the lighter in after it is
already heated because it will
overheat.
• Only a genuine Kia lighter should be used in the cigarette lighter
socket. The use of plug-in acces-
sories (shavers, hand-held vacu-
ums, and coffee pots, for example)
may damage the socket or cause
electrical failure.
• If the lighter does not pop out within 30 seconds, remove it to
prevent overheating.
Ashtrays Front To use the ashtray, press the front
face and release it to allow the ciga-
rette lighter and ashtray to slowly
extend from center panel.
To remove the ashtray, grasp the
ashtray bucket (
➀) and carefully pull
it out.
INTERIOR FEATURES
1GHA2084
1GHA2084A
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 95

Knowing your vehicle96
3
1
2
3
4
5
6
7
8
9
Cup holderCups or small beverage cans may be
placed in the cup holders.
FrontTo open the cup holder cover, press
the cover and it will automatically
open. Push the cover to close after
use.
WARNING
- Ashtray use
 Do not use the vehicle ’s ash-
trays as waste receptacles.
 Putting lit cigarettes or match-
es in an ashtray with other
combustible materials may
cause a fire.
WARNING
- Hot liquids
 Do not place uncovered cups
of hot liquid in the cup holder
while the vehicle is in motion.
If the hot liquid spills, you
could be burned. Such a burn
to the driver could cause a
loss of control of the vehicle.
 To reduce the risk of personal
injury in the event of sudden
stop or collision, do not place
uncovered or insecure bot-
tles, glasses, cans, etc., in the
cup holder while the vehicle is
in motion.
2GHN2088
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 96

397
1
2
3
4
5
6
7
8
9
Knowing your vehicle
RearTo use cup holders in rear seat, pull
down the rear seat armrest.
✽ ✽NOTICEDo not place heavy cups or cans in
cup holders. Cup holders could be
damaged.
SunvisorUse the sunvisor to shield direct light
through the front or side windows.
To use a sunvisor, pull it downward.
To use a sunvisor for a side window,
pull it downward, unsnap it from the
bracket (
➀) and swing it to the side.
To use the vanity mirror, pull down
the visor and pull up the mirror cover
(
➁).
Pull the extension panel (
➂) of the
sunvisor to lengthen the sunvisor.
1GHA2089
2GHN482
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 97

Knowing your vehicle98
3
1
2
3
4
5
6
7
8
9
✽ ✽
NOTICEClose the vanity mirror cover
securely and return the sunvisor to
its original position after use. If the
vanity mirror is not closed securely,
the lamp will stay on and could
result in battery discharge and pos-
sible sunvisor damage.
Power socket (if equipped)The power outlets are designed to
provide power for mobile telephones
or other devices designed to operate
with vehicle electrical systems. The
devices should draw less than 10
amps with the engine running.
2GHN33401GHA2234
Front (if equipped)Rear
2GHN3350
Center (if equipped)
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 98

399
1
2
3
4
5
6
7
8
9
Knowing your vehicle
✽ ✽NOTICE• Use when the engine is running.
• Only use the electric appliances
which are less than 12V and 10A
in electric capacity.
• Adjust the air-conditioner or heater to the lowest operation
level when you have to use the
power socket while using air-con-
ditioner or heater.
• Close the cover when not in use.
ClockDigital (if equipped)Whenever the battery terminals, A/V
CLOCK fuse, or Power Connect are
disconnected, you must reset the
time.
Press the Clock Control PUSH but-
ton in front of the monitor to access
the mode set buttons. Use these
buttons to adjust the time/date dis-
played on the monitor. 1. Press the MODE button (
➀).
2. Select the mode to be reset; hour (
➁), minute (
➂), month (
➃) and
date (
➄).
3. Reset the data using button  (
\b)
or button  (
➆) while the selected
mode blinks.
If the  (
\b) or  (
➆) button(s) are
pressed for more than 3 seconds,
the display will begin to change
rapidly. When the  (\b) or  (
➆)
button(s) are pressed then
released, the display will change
in single increments.
4. Press the SET (
➇) button when
the data is correctly set.
1GHA2110
➀
➆
➇
\b
➁
➂
➃
➄
