KIA OPTIMA HYBRID 2014 Features and Functions Guide

www.kia.com
Consumer - Roadside Assistance
1-800-333-4KIA (4542)
See Back Cover for Vehicle Maintenance Schedule

Always check the Owner’s Manual for complete operating information and safety warnings.FEATURES & FUNCTIONS GUIDE

GETTING TO KNOW YOUR
OPTIMA HYBRID
Congratulations on Your New Kia Purchase!Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of
comfortable and dependable driving. Kia is committed to quality, innovation, safety and — above all —
your satisfaction.
Using This GuideThe information contained in this guide is a brief overview that will help you become familiar with the operation and
features of your new Kia vehicle. The flipbook format facilitates information access, while the detailed illustrations
ensure the instructions are easy to follow.
This Features & Functions Guide and the specific operational and safety information it provides is not a substitute
for your Owner’s Manual. In the interest of your safety and that of your family, and to help you avoid risks that
may result in death or serious injury, Kia reminds you to carefully read your Owner’s Manual in order to fully
familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change vehicle
specifications without notice in advance or after the fact, and assumes no liability in connection with
such changes.

VIDEOS & QR CODES . . . . . . . . . . . . .
02
INSTRUMENT CLUSTER
Instrument Cluster Overview . . . . . . . . . . .
03
Indicators & Warning Lights . . . . . . . . . . .
04
Fuel Efficiency . . . . . . . . . . . . . . . . . . . .
04
Advanced Tire Pressure Monitoring System
(ATPMS) . . . . . . . . . . . . . . . . . . . . . . .
05
Hybrid Indicators at Startup . . . . . . . . . . .
06
Active ECO System (ECODynamics) . . . . . .
07
LCD Controls and Modes* . . . . . . . . . . . . .
08
Trip Computer / Tripmeter . . . . . . . . . . . .
08
Service Mode . . . . . . . . . . . . . . . . . . . .
09
User Settings Mode. . . . . . . . . . . . . . . . .
09
HYBRID SYSTEM DISPLAYS
Instrument Cluster - Energy Flow . . . . . . . .
10
Instrument Cluster - ECO Level . . . . . . . . .
12
Navigation System Display*. . . . . . . . . . . .
13
DRIVER’S PANEL
Hood Release Lever and Latch . . . . . . . . . .
14
Fuel Door and Trunk Release Buttons . . . . .
14
ENGINE START/STOP Button . . . . . . . . . .
15
Electronic Stability Control (ESC) . . . . . . . .
16
Instrument Panel Dimmer . . . . . . . . . . . . .
16
Hill-Start Assist Control (HAC) . . . . . . . . . .
16
Power Windows, Window Lock
& Central Door Lock . . . . . . . . . . . . . . . .
17
Power/Heated Outside Mirrors* . . . . . . . . .
17
Electric Folding Mirrors* . . . . . . . . . . . . . .
17
Automatic Door Lock/Unlock . . . . . . . . . .
17
Blind Spot Detection (BSD) . . . . . . . . . . . .
18
Auto Hold . . . . . . . . . . . . . . . . . . . . . .
19
Electronic Parking Brake (EPB)* . . . . . . . . .
19
STEERING WHEEL CONTROLS
Headlights & High Beams . . . . . . . . . . . . .
20
Turn Signals & Fog Lights . . . . . . . . . . . . .
20
Windshield Wipers & Washers . . . . . . . . . .
21
Heated Steering Wheel Button. . . . . . . . . .
22
Tilt/Telescopic Steering Wheel* . . . . . . . . .
22
Audio Controls . . . . . . . . . . . . . . . . . . .
23
Cruise Control . . . . . . . . . . . . . . . . . . . .
23
Bluetooth® Wireless Technology . . . . . . . . .
24
AUDIO SYSTEM
Standard Audio System* . . . . . . . . . . . . .
26
UVO System* . . . . . . . . . . . . . . . . . . . .
28
Navigation System*. . . . . . . . . . . . . . . . .
29
CENTER PANEL
Digital Clock . . . . . . . . . . . . . . . . . . . . .
30
Aux/USB/iPod® Port & Power Outlets* . . . . .
30
Automatic Climate Control (UVO System)* . .
31
Automatic Climate Control
(Navigation System)*. . . . . . . . . . . . . . . .
32
Seat Warmers/ Ventilated Seats* . . . . . . . .
33
Automatic Gear Shift / Sportmatic® Shifting*
33
SEATING
Driver Position Memory System*. . . . . . . . .
34
Power Adjustable Driver’s Seat* . . . . . . . . .
34
Manual Adjustable Driver’s Seat* . . . . . . . .
35
Front Seat Headrest Adjustment . . . . . . . .
35
OTHER KEY FEATURES
Smart Key . . . . . . . . . . . . . . . . . . . . . .
36
HomeLink ® / Auto-Dimming Rearview Mirror*
37
Map/Room/Dome Lamps . . . . . . . . . . . . .
38
Panoramic Sunroof Operation* . . . . . . . . .
39
Sunvisor. . . . . . . . . . . . . . . . . . . . . . . .
39
Back-up Warning System
(Rear Parking Assist System)* . . . . . . . . . .
40
Rear-Camera Display* . . . . . . . . . . . . . . .
40
Fuel Cap/Malfunction Indicator . . . . . . . . .
41
Tire Mobility Kit* . . . . . . . . . . . . . . . . . .
41
Service Plug (Safety Plug) & 12V Battery
Compartment . . . . . . . . . . . . . . . . . . . .
42
Hybrid Battery Vent (Air Intake) . . . . . . . . .
42
Child Safety Locks . . . . . . . . . . . . . . . . .
43
SAFETY
Safety Belts . . . . . . . . . . . . . . . . . . . . .
44
Safety Belt Retractor Inertial Locks . . . . . . .
44
Occupant Detection System (ODS) /
PASSENGER AIR BAG OFF Indicator . . . . . .
44
LEGAL DISCLAIMERS
(See Back Inside Cover Page)
MAINTENANCE
(See Back Cover)
ESSENTIAL FEATURESActive ECO System (ECODynamics) . . .
07
Advanced Tire Pressure Monitoring
System (ATPMS) . . . . . . . . . . . . . . .
05
Air Conditioning / Climate Control . . . .
31
Audio Controls* . . . . . . . . . . . . . . .
23
Audio System – Standard* . . . . . . . . .
26
Audio System – Navigation System*. . . .
29
Audio System – UVO System* . . . . . . .
28
Aux/USB/iPod® Port & Power Outlets* . .
30
Bluetooth® Wireless Technology* . . . . .
24
Cruise Control* . . . . . . . . . . . . . . . .
23
Digital Clock . . . . . . . . . . . . . . . . .
30
Fuel Efficiency . . . . . . . . . . . . . . . .
04
Hybrid Displays – Navigation System* . .
13
Instrument Cluster / Hybrid Displays . . .
03
PASSENGER AIR BAG OFF Indicator . . .
44
Rear-Camera Display* . . . . . . . . . . . .
40
Tire Mobility Kit* . . . . . . . . . . . . . . .
41
Windshield Wipers & Washers . . . . . . .
21
Driving while distracted can result in a loss of
vehicle control that may lead to an accident, severe
personal injury and death. The driver ’s primary
responsibility is in the safe and legal operation of
a vehicle, and use of any handheld devices, other
equipment or vehicle systems which take the
driver ’s eyes, attention and focus away from the safe
operation of a vehicle or that are not permissible by
law should never be used during operation of the
vehicle.OPTIMA HYBRID
FEATURES & FUNCTIONS GUIDE
*IF EQUIPPED

2
*IF EQUIPPED
OPTIMA HYBRID
FEATURES & FUNCTIONS GUIDE
How to snap a QR Code
1. With your mobile
device, download a QR
Code Reader App. With
many devices, you can
do this through an app
store or marketplace
2. Open the QR Code
Reader App on your
mobile device
3. The app will utilize your device’s camera. Center
the code in the camera viewing area:


O
With some apps, as soon as the app recognizes
the code, it will launch the corresponding video


O
With other apps, you will have to snap or take
a picture of the code. The app will then launch
the corresponding video


O
For operation specifics, refer to the instructions
that come with the QR Code Reader App
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERSKia provides a number of video resources at your disposal to assist you with becoming
familiar with the features and functions found in your Kia vehicle. You can access these
resources by snapping the QR Codes with your smartphone/tablet (mobile devices) or by
visiting the following website: www.KuTechVideos.com/tf23/2014. Continue reading for a
more in-depth look at QR Codes and for instructions on how to use them.
What are QR Codes?

A QR Code is a square, 2-dimensional barcode that can be read by mobile devices loaded with
an appropriate Bar Code or QR Code Reader App. The app reads the Bar Code image and
then launches/uploads the specific information the code contains, such as URLs, text, photos,
videos, and so much more.
1.
1. If you’re having trouble scanning codes, check the following:


OThe code should be centered and focused in your mobile
device’s camera screen


OConsider moving your device closer to or farther away from the
code


OThe code should be well lit, without significant shadow


OAvoid scanning from a significant angle


OConfirm that the device’s app supports 2-D QR Code Scanning.
Try another QR Code Reader app; not all apps are created equal
2. After scanning, a “connecting” message appears and then
nothing happens or there’s a “connection error” message, this
typically indicate that your device is having trouble connecting to
the Internet
QUICK TIPS
How to Use QR Codes
If you have a mobile device with a QR Code Reader App, you
can snap the code with your phone, and you’ll be provided a
video with additional information pertaining to the topic. For
example, in the Kia One-Click Fuel Cap section, if you would
like additional information, just snap the code with your mobile
device to view the selected Kia Features & Functions Video.


Kia One-Click
Fuel Cap Video

To view a video on your
mobile device, snap this
QR Code or visit the
listed website.
QR CODE
www.KuTechVideos.com/tf23/2014
REMINDER: When accessing videos on your mobile device, standard
cellular data rates may apply.

3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED
A ECO GuideB Temperature GaugeC State of Charge (SOC) GaugeD Turn Signal Indicators
E Gear Shift Position Indicator F Indicator and Warning LightsG SpeedometerH Fuel Gauge
Instrument Cluster Overview
1
023 4 5 6rpm
x 1000
ODO
000456
miles
D
A
B
C
D
D
E
G
F
H
REMINDER: Your vehicle’s instrument cluster & indicator light locations may differ from
those in the illustration. See your Owner’s Manual for more details.
INSTRUMENT CLUSTER


Optima Hybrid Cluster
Overview Video
To view a video on your
mobile device, snap this
QR Code or visit the
listed website.
Refer to page 2 for more
information.

QR CODE
www.KuTechVideos.com/tf23/2014

OPTIMA HYBRID
FEATURES & FUNCTIONS GUIDE
4
*IF EQUIPPED
Fuel EfficiencyThere are several factors that
contribute to your vehicle’s fuel
efficiency, including maintenance
of your vehicle, driving style,
environmental conditions, vehicle
weight and vehicle aerodynamics.
Below are tips on how to help
improve fuel efficiency:


OKeep your vehicle in good
condition with regular
maintenance


ODon’t let the engine idle longer
than necessary


ODrive at a moderate speed,
accelerating smoothly and at a
moderate rate


OKeep tires inflated to the
recommended pressure


OTravel lightly, without carrying
unnecessary weight in your vehicle


OAvoid placing large or heavy items
on roof racks


OAvoid hilly, winding or poorly
maintained roadsREMINDER: Driving range will vary depending
on your vehicle’s fuel tank size (e.g., 12 gal. vs. 24
gal.), even though the MPG may be the same.
For more information on Fuel Economy, refer to
the brochure “GET TING MORE OUT OF E VERY
GALLON, FUEL-SAVING TIPS TO DRIVE BY ”
available at your local dealership.
Indicators & Warning Lights
For more information on the function of all indicator and warning lights, please refer to
the Owner’s Manual.
QUICK TIPS

Seat Belt Warning Light
High Beam Indicator
Front Fog Light Indicator* Tail Light Indicator
Engine Oil Pressure Warning
Light
Engine Coolant Temperature
Warning Light* Door Ajar Warning Light
Anti-lock Braking System
(ABS) Warning Light
Active ECO Indicator Cruise ON/OFF Indicator*
Cruise SET Indicator*
Electronic Stability Control
(ESC) Indicator / ESC
Malfunction Indicator
Electronic Stability Control
(ESC) OFF Indicator
Malfunction Indicator
12V Charging System Warning
Light
Service Indicator
Airbag Warning Light
Low Tire Pressure Light / Tire
Pressure Monitoring System
(TPMS) Malfunction Indicator
Parking Brake & Brake Fluid
Warning Light
Trunk Open Warning Light
Immobilizer Indicator*
Electronic Power Steering
(EPS) System Warning Light*
Low Fuel Level Warning Light
REMINDER: Your vehicle’s instrument cluster & indicator light locations may differ from those in
the illustrations. See your Owner’s Manual for more details.INSTRUMENT CLUSTER

5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED The TPMS indicator
functions as both Low Tire
Pressure Light and TPMS Malfunction Indicator.
The TPMS indicator
A
will illuminate if one or more
tires is significantly underinflated, the vehicle has
a spare tire installed without TPMS or the outside
temperature becomes significantly colder.
The LCD screen in the instrument cluster will display
the Low Tire Pressure indicator
B showing which
tire(s) are underinflated.


OInflate tire(s) to specifications to turn off Low Tire
Pressure Light
by using an accurate digital tire
pressure gauge. See front driver’s door jamb for
PSI specification


OThe TPMS Malfunction Indicator
will illuminate
after it blinks for approximately one minute
when there is a problem with the Tire Pressure
Monitoring System. See your dealer for service
Advanced Tire Pressure Monitoring System (ATPMS)

Kia Tire Pressure
Monitoring System
Video
To view a video on your
mobile device, snap this
QR Code or visit the
listed website.
Refer to page 2 for more
information.

QR CODE


O


OEven with TPMS, tire pressure should be checked manually at least once a month. Only adjust
tire pressure on “cold tires”


OFor proper maintenance, safety, and optimal fuel economy, maintain recommended tire
inflation pressures and stay within the load limits and weight distribution recommended for
your vehicle


OIn winter or cold weather, the TPMS light may illuminate if the tire pressure was adjusted to the
recommended tire inflation pressure during warm weather
QUICK TIPS
www.KuTechVideos.com/tf23/2014
REMINDER: Consult your dealer for service if Low Tire Pressure Light remains illuminated after inflating
your tire(s).
AB
INSTRUMENT CLUSTER

OPTIMA HYBRID
FEATURES & FUNCTIONS GUIDE
6
*IF EQUIPPED
A ECO GUIDE — Indicates how economically the vehicle is being driven.

O

OGreen zone: High-efficiency range

O

O
White zone: Normal-efficiency range

O

ORed zone: Low-efficiency range B EV MODE — Illuminates when the
electric motor is powering the
vehicle.C READY — Illuminates when the
hybrid system is operational.
Even if the engine is off, the
vehicle can be driven.D State of Charge (SOC) — Displays
the hybrid battery charge status.E Active ECO — Automatically activated each time the vehicle is started. Turn system
ON/OFF using the ECO button on the steering wheel.

O

O
OActive ECO ON (Eco indicator illuminated): Adjusts the engine, transaxle and A/C system to conserve fuel

O

O
OActive ECO OFF (Eco indicator not illuminated): Provides more power when driving up steep roads or carrying
heavy loadsF
Service Indicator — Illuminates when a malfunction occurs in the vehicle’s hybrid system. Have an authorized
hybrid Kia dealer address the concern as soon as possible.
Hybrid Indicators at Startup
REMINDER: Avoid starting or driving the vehicle when the fuel tank is
empty. As the engine will be incapable of charging the high-voltage
hybrid battery, the battery will lose its charge and may be damaged.
1
023 4 5 6rpm
x 1000
ODO
000456
miles
Active
ON
1
023 4 5 6rpm
x 1000
ODO
000456
miles
Active
ON


O
If Active ECO is turned off, switch back to Active ECO as
soon as possible for maximum fuel efficiency and to restore
the ECODynamics ON center display.
QUICK TIPS
AB
C
D
F
E


Optima Hybrid Overview
Video

To view a video on your
mobile device, snap this
QR Code or visit the
listed website.
Refer to page 2 for more
information.
QR CODE
www.KuTechVideos.com/tf23/2014
INSTRUMENT CLUSTER

7
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFET Y WARNINGS. *IF EQUIPPED
1
023 4 5 6rpm
x 1000
ODO
000456
miles
Active
ON
1
023 4 5 6rpm
x 1000
ODO
000456
miles
Active
ON
Active ECO System*
(ECODynamics)Active ECO helps to improve fuel
efficiency by controlling several
vehicle components. When
activated, it optimizes drivetrain
operations such as engine power
and transmission to help improve
fuel economy.
To turn ON, press the ECO button A. The button light will turn on and
the green ECO indicator light
B in
the instrument cluster will illuminate
(indicating that you are getting
optimal fuel efficiency).The Active
ECO System will remain on even
when the engine is turned off and
restarted.
To turn Active ECO OFF, press the
button
A again.


O
To help improve your fuel efficiency:


O

Drive at a moderate speed, accelerating smoothly and at a moderate rate


OKeep tires inflated to the recommended pressure


OBe sure the wheels are properly aligned
QUICK TIPS
For more information on the Active ECO System, refer to your Owner’s Manual or contact your local dealership.
SET
CANCEL OK
ECO
A
B

Active ECO System
Video
To view a video on your
mobile device, snap this
QR Code or visit the
listed website.
Refer to page 2 for more
information.
QR CODE
www.KuTechVideos.com/tf23/2014
(Eco button located on right
side of Steering Wheel)
INSTRUMENT CLUSTER

OPTIMA HYBRID
FEATURES & FUNCTIONS GUIDE
8
*IF EQUIPPED
INSTRUMENT CLUSTER
REMINDER: Appearance of Tripmeter display may differ as equipped.
REMINDER: All stored driving information (except Odometer and
Range) is reset if the battery is disconnected.Trip Computer / TripmeterThe Trip Computer is a driver
information system that
displays information related
to driving when the ENGINE
START/STOP button is in the
ON position.
To cycle through the LCD
modes, press the MENU/
MODE button
A.
When in the TRIP COMPUTER
mode, press the SELECT button
B to cycle through the screens.
When displaying TRIP A or
TRIP B screens, press and hold
the ENTER/RESET button
C to
reset the Tripmeter to zero.
LCD Controls and Modes* Press Mode button
A to scroll through different LCD modes.
Press Select button B to scroll through the menu items.
Press OK button
C to select the item.
CRUISECANCEL
RESSET
OK
A
(LCD Display Control buttons located on Steering Wheel)
B
C
Ty p e B
Trip Computer Mode:
Displays driving information for tripmeter, fuel
economy, etc. Hybrid Information Mode:
Displays the Eco Level and Hybrid Energy Flow status
Tu r n - by -Tu r n M o d e : Displays the state of the
Navigation System
Service Modes: Informs on upcoming service
intervals A/V Mode: Displays the state of the A/V System
User Settings Mode: Change settings of the doors,
lamps and other features
LCD modes:
.
Range
.
Average MPG
.
Instant MPG.
Trip A
.
Average MPH
.
Elapsed Time (E/T ).
Trip B
.
Average MPH
.
Elapsed Time (E/T )
