KIA Spectra 2006 2.G Owner's Manual

739
Maintenance
1
2
3
4
5
6
7
8
9
EXTERIOR CARE Exterior general caution It is very important to follow the label
directions when using any chemical
cleaner or polish. Read all warning
and caution statements that appear
on the label.Finish maintenanceWashing
To help protect your vehicle’s finish
from rust and deterioration, wash it
thoroughly and frequently at least
once a month with lukewarm or cold
water.
If you use your vehicle for off-road
driving, you should wash it after each
off-road trip. Pay special attention to
the removal of any accumulation of
salt, dirt, mud, and other foreign
materials. Make sure the drain holes
in the lower edges of the doors and
rocker panels are kept clear and
clean.Insects, tar, tree sap, bird droppings,
industrial pollution and similar
deposits can damage your vehicle’s
finish if not removed immediately.
Even prompt washing with plain
water may not completely remove all
these deposits. A mild soap, safe for
use on painted surfaces, may be
used.
After washing, rinse the vehicle thor-
oughly with lukewarm or cold water.
Do not allow soap to dry on the fin-
ish.
✽ ✽
NOTICEDo not use strong soap, chemical
detergents or hot water, and do not
wash the vehicle in direct sunlight or
when the body of the vehicle is
warm.
CAUTION
 Water washing in the engine
compartment may cause the
failure of electrical circuits
located in the engine compart-
ment.
 Pay extreme attention to wash the engine compartment by
using water.
WARNING
After washing the vehicle, test
the brakes while driving slowly
to see if they have been affected
by water. If braking performance
is impaired, dry the brakes by
applying them lightly while
maintaining a slow forward
speed.
LD CAN (ENG) 7.qxd 7/29/05 10:23 AM Page 39

Maintenance40
7
1
2
3
4
5
6
7
8
9
Waxing
Wax the vehicle when water will no
longer bead on the paint.
Always wash and dry the vehicle
before waxing. Use a good quality
liquid or paste wax, and follow the
manufacturer’s instructions. Wax all
metal trim to protect it and to main-
tain its luster.
Removing oil, tar, and similar materi-
als with a spot remover will usually
strip the wax from the finish. Be sure
to re-wax these areas even if the rest
of the vehicle does not yet need wax-
ing.
✽ ✽
NOTICE Wiping dust or dirt off the body
with a dry cloth will scratch the
finish.
 Do not use steel wool, abrasive cleaners, or strong detergents con-
taining highly alkaline or caustic
agents on chrome-plated or
anodized aluminum parts. This
may result in damage to the pro-
tective coating and cause discol-
oration or paint deterioration.
Finish damage repair Deep scratches or stone chips in the
painted surface must be repaired
promptly. Exposed metal will quickly
rust and may develop into a major
repair expense.✽ ✽ NOTICEIf your vehicle is damaged and
requires any metal repair or
replacement, be sure the body shop
applies anti-corrosion materials to
the parts repaired or replaced.
LD CAN (ENG) 7.qxd 7/29/05 10:23 AM Page 40

741
Maintenance
1
2
3
4
5
6
7
8
9
Bright-metal maintenance To remove road tar and insects,use a tar remover, not a scraper or
other sharp object.
 To protect the surfaces of bright- metal parts from corrosion, apply a
coating of wax or chrome preser-
vative and rub to a high luster.
 During winter weather or in coastal areas, cover the bright metal parts
with a heavier coating of wax or
preservative. If necessary, coat the
parts with non-corrosive petroleum
jelly or other protective compound.
Underbody maintenanceCorrosive materials used for ice and
snow removal and dust control may
collect on the underbody. If these
materials are not removed, acceler-
ated rusting can occur on underbody
parts such as the fuel lines, frame,
floor pan and exhaust system, even
though they have been treated with
rust protection.
Thoroughly flush the vehicle under-
body and wheel openings with luke-
warm or cold water once a month,
after off-road driving and at the end
of each winter. Pay special attention
to these areas because it is difficult
to see all the mud and dirt. It will do
more harm than good to wet down
the road grime without removing it.
The lower edges of doors, rocker
panels, and frame members have
drain holes that should not be
allowed to clog with dirt; trapped
water in these areas can cause rust-
ing.
WARNING
After washing the vehicle, test
the brakes while driving slowly
to see if they have been affected
by water. If braking performance
is impaired, dry the brakes by
applying them lightly while
maintaining a slow forward
speed.
LD CAN (ENG) 7.qxd 7/29/05 10:23 AM Page 41

Maintenance42
7
1
2
3
4
5
6
7
8
9
Aluminum wheel maintenance The aluminum wheels are coated
with a clear protective finish.
 Do not use any abrasive cleaner,
polishing compound, solvent, or
wire brushes on aluminum wheels.
They may scratch or damage the
finish.
 Use only a mild soap or neutral detergent, and rinse thoroughly
with water. Also, be sure to clean
the wheels after driving on salted
roads. This helps prevent corro-
sion.
 Avoid washing the wheels with high-speed car wash brushes.
 Do not use any acid detergent. It may damage and corrode the alu-
minum wheels coated with a clear
protective finish.
LD CAN (ENG) 7.qxd 7/29/05 10:23 AM Page 42

743
Maintenance
1
2
3
4
5
6
7
8
9
INTERIOR CARE Interior general precautions Prevent caustic solutions such as
perfume and cosmetic oil from con-
tacting the dashboard because they
may cause damage or discoloration.
If they do contact the dashboard,
wipe them off immediately. See the
instructions that follow for the proper
way to clean vinyl.Cleaning the upholstery and
interior trim Vinyl
Remove dust and loose dirt from
vinyl with a whisk broom or vacuum
cleaner. Clean vinyl surfaces with a
vinyl cleaner.Fabric
Remove dust and loose dirt from fab-
ric with a whisk broom or vacuum
cleaner. Clean with a mild soap solu-
tion recommended for upholstery or
carpets. Remove fresh spots imme-
diately with a fabric spot cleaner. If
fresh spots do not receive immediate
attention, the fabric can be stained
and its color can be affected. Also, its
fire-resistant properties can be
reduced if the material is not proper-
ly maintained.
Cleaning the lap/shoulder belt
webbing Clean the belt webbing with any mild
soap solution recommended for
cleaning upholstery or carpet. Follow
the instructions provided with the
soap. Do not bleach or re-dye the
webbing because this may weaken
it.Cleaning the interior window
glass If the interior glass surfaces of the
vehicle become fogged (that is, cov-
ered with an oily, greasy or waxy
film), they should be cleaned with
glass cleaner. Follow the directions
on the glass cleaner container.✽ ✽
NOTICEDo not scrape or scratch the inside
of the rear window. This may result
in damage to the rear window
defroster grid.
CAUTION
Using anything but recommend-
ed cleaners and procedures
may affect the fabric’s appear-
ance and fire-resistant proper-
ties.
LD CAN (ENG) 7.qxd 7/29/05 10:23 AM Page 43

1
2
3
4
5
6
7
8
9
Specifications / 8-2
Specifications
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 1

Specifications28
1
2
3
4
5
6
7
8
9
Dimensions
WeightsSPECIFICATIONSThe specifications given here are for general information only. Please check with an authorized Kia dealer for more
precise and more up-to-date information.
Item4 Door 5 Door
Overall length 4,480 (176.4)4,340 (170.9)
Overall width 1,735 (68.3)1,735 (68.3)
Overall height 1,470 (57.9)1,470 (57.9)
Front tread 1,495 (58.9)1,495 (58.9)
Rear tread 1,485 (58.5)1,485 (58.5)
Wheelbase 2,610 (102.8)2,610 (102.8)
mm (in)
Refer to the label describing GVWR & GAWR weights attached to your vehicle.
(see page 5-19, Label information)
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 2

83
1
2
3
4
5
6
7
8
9
Specifications
Engine
ItemGasoline Engine
BoreXStroke 82 mm × 93.5 mm (3.23 in X 3.68 in)
Displacement 1975 cc (120.5 cu.in)
Compression Ratio 10.1
SizeGasoline Engine
Battery 12V / 60AH (20HR)
Alternator 13.5V / 90A
Starter 12V-1.2kW
Gap 1.0 mm ~ 1.1 mm
Platinum coated PFR5N-11, RC10PYPB4
Iridium coated
IFR5G-11
Spark
Plug Spec.
Item Inflation Pressure
Wheel lug nut torque
Tire size Wheel size kPa (psi) kg·m (lb·ft, N·m)
P195/60R15 87H 6.0J x 15 210 (30) 9~11
(65~79, 88~107)
P205/50R16 86H 6.0J x 16 210 (30) 9~11
(65~79, 88~107)
Compact spare tire
T125/70D15, T125/70R15 420 (60) 9~11
(65~79, 88~107)
Tires Electrical system
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 3

Specifications48
1
2
3
4
5
6
7
8
9
Light bulbsCapacities
LubricantVolume Classification
Engine oil
*1
4.0 l
API Service SJ, SL or above,
(4.2 qt.)
ILSAC GF-3 or above
Manual transaxle fluid
2.15
l API SERVICE GL-4
(
2.27 qt.)
SAE 75W-85 (fill for-life)
Automatic transaxle
7.8 l DIAMOND ATF SP-III,
fluid (8.2 qt.) SK ATF SP-III
Power steering 0.8
l
PSF-III
(0.8 qt.)
Coolant 8.14
l
Ethylene glycol base for
(8.6 qt.)
aluminum radiator
Brake fluid 0.7~0.8
l
FMVSS116 DOT-3
(0.7~0.8 qt.)
or DOT-4
Fuel 55
l Unleaded gasoline with
(14.5 gal) AKI 87 or higher
*¹Refer to the recommended SAE viscosity numbers on the page 7-38.
Light Bulb 4 Door 5 Door
Headlights (Low/High) 55/60 55/60
Front turn signal lights 2828
Position lights 88
Front fog lights (if equipped) 27 27
Stop and tail lights 28/8 28/8
Rear turn signal lights 2727
Back-up lights 1717
High mounted stop light 27 or LED LED
License plate lights 55
Front map lamp 1010
Center dome lamp 1010
Door courtesy lamps 55
Trunk room lamp 55
Glove box lamp 55
Wattage
LD CAN (ENG) 8.qxd 7/29/05 10:24 AM Page 4

1
2
3
4
5
6
7
8
9
Index
