The sunroof and sunshade operation is controlled by a multidirectional switch/lever for the front and rear sunroofs
. The ignition needs to be in the ON position to operate the sunroof/sunshade .
Slide the sunshade and sunroof A :
Auto Open – Slide lever backward to the farthest position and release .
Auto Close – Slide the lever forward to the farthest position and release (manually close the Sunshade) .
Tilt the sunroof (front only) A :
Raise – Press lever upward
Lower – Push lever forward
Slide the rear sunshade B :
Auto Open – Slide the lever backward
Auto Close – Slide the lever forward
OTHER KEY FEATURES
See section 4 in the Owner’s Manual for more information .
Your vehicle’s sunroof controls may differ from that in the illustration .
Sunroof Operation*
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
Sunroof Operation Video
QR CODE
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
Cargo Cover & Storage Video
QR CODE
ALWAYS CHECK THE OWNER ’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS . *IF EQUIPPED59
AB
OTHER KEY

FEATURES
•To stop the sunroof/sunshade at any position, press or pull the sunroof control lever in any direction
QUICK TIP
•Inser t the third-row seat belts into the retaining clips on the left and right sides before removing/installing Cargo Cover
QUICK TIP
REMINDERS:
•When closing, be mindful of any objects or persons
•
Sunshade must remain OPEN while sunroof is open
•
If the ignition is turned off with the Sunroof not fully closed, the Instrument Cluster LCD will display a warning message and a chime will sound for a few seconds
•
Do not adjust the sunroof or sunshade while driving . This could result in loss of control of the vehicle
(But ton located within overhead lamp console)
Cargo Cover Storage*
To store the Cargo Cover*, close the Cargo Cover and remove it from the slots by pulling the Cargo Cover ends inward C . Remove the luggage box cover .
On the left side, remove the small storage cover D to expose the Cargo Cover storage slot . Insert the Cargo Cover on the right side first . Compress the left end of the Cargo
Cover to slide it into the left slot . Replace the small storage cover and the luggage box cover .
C
D
(View from the rear looking in;left end of the cover shown)

OTHER KEY FEATURES
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
HomeLink® Support Video
QR CODE
REMINDERS:
•
A ladder may be needed to access the garage door opener
•A second person may be needed to help
•Some of the steps are time sensitive
OTHER KEY

FEATURES
•If the indicator C flashes rapidly in red continuously, but if the garage door opener does not operate, please continue to follow Rolling Code Programming steps below
QUICK TIP
•Erasing programmed but tons will delete all trained transmitters
QUICK TIP
A HomeLink® button
B HomeLink® button
C Indicator light
D HomeLink® button
E Glare detection sensor
F Automatic dimming ON
G Automatic dimming OFF
Auto-Dimming Rearview Mirror
Designed to help reduce glare from a vehicle’s headlights located in the rear and also connect up to three electronic transmitters in one location . Press the on/off button F to turn the auto-dimming function on or off .
How to Sync Transmitter
1 . Press and release A , B or D button
–If the indicator C flashes slowly in red, go to Step 3 (Programming)
–If the indicator C is continuously turned ON or flashes rapidly in red several times, go to Step 2 (Erasing)
2 . Press and hold the button you wish to erase the program for approximately 15-25 seconds until the LED flashes slowly in Red
3 . Hold the Garage Door Opener Original Transmitter near the HomeLink Mirror
4 .
Press and hold the desired button (A , B or D ) and the Original Transmitter button until the indicator C is turned on continuously or flashes rapidly in red . This indicates the programming is completed
To complete programming of a Rolling Code garage door opener:
1 . Firmly press and release the “Learn,” “Smart,” or “Program” button of the garage door opener while the indicator C flashes slowly in red . Once the button is pressed, you have approximately 30 seconds to initiate the next step
2 . Return to the vehicle and firmly press and hold the HomeLink button for two seconds and release . Repeat this up to three times to complete the programming . Do not press the HomeLink button rapidly . At this point, programming is complete and your device should operate
Operating HomeLink®: Press one of the programmed HomeLink® buttons .
Erasing programmed buttons: Press and hold the left A and center D buttons simultaneously for approximately 20 seconds, until the indicator light begins to flash, and then release both buttons within 30 seconds .
HomeLink® with Auto-Dimming Rearview Mirror*†3
For more information, go to HomeLink .com or call (800) 355-3515 .
See section 4 in the Owner’s Manual for more information .
REMINDER: Mirror indicator light will illuminate when automatic dimming is on .
ABCDEFG
†LEGAL DISCL AIMERS ON BACK INSIDE COVER*IF EQUIPPED60TELLURIDE FEATURES & FUNCTIONS GUIDE

(Located on Driver side kick panel)(Located inside of Hood’s center)
OTHER KEY FEATURES
REMINDERS:
•
Sunvisor may not shield all direct light
•
Sunvisor may impair visibilit y if not adjusted properly
•
Be aware of seating position when adjusting or swinging sunvisor around to or from the front or side windows
•
Do not operate the vehicle if the sunvisor is impairing your visibility
REMINDERS:
•While lowering and closing, keep hands away from under the Hood
•
Open the Hood only after turning the engine off, on a flat sur face, with the gear shift in P (Park) position and set ting the parking brake
•Make sure the hood is securely closed before driving
OTHER KEY

FEATURES
B
B
Sunvisor†1 8
Use the sunvisor to shield direct light through the front or side windows . Slide the sunvisor out and adjust as needed .
See section 4 in the Owner’s Manual for more information .
Opening the Hood:
1 .
Pull the hood release lever A to unlatch the hood
2 . In the front of the vehicle, lift the hood slightly, push the secondary latch B to the left inside of the hood’s center and lift the hood
Closing the Hood:
Lower the hood about halfway and then release hood to drop into place and securely latch .
Hood Release Lever and Latch
A
See section 4 in the Owner’s Manual for more information .
ALWAYS CHECK THE OWNER ’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS . †LEGAL DISCL AIMERS ON BACK INSIDE COVER*IF EQUIPPED61

*IF EQUIPPED62TELLURIDE FEATURES & FUNCTIONS GUIDE
CB
DREMINDER: The fuel filler lid lock will unlock/open only when driver ’s side door is unlocked .
See section 4 in the Owner’s Manual for more information .
•Place the Fuel Cap on the inside of the Fuel Filler Lid when fueling D
QUICK TIP
Fuel Cap / Malfunction Indicator (Check Engine Light)
To access the Fuel Cap, press the Fuel Filler Lid to open . Tighten for ONE CLICK to prevent malfunction indicator from illuminating .
Fuel Filler Lid Release
To open the Fuel Filler lid:
1 . Press the right edge of the Fuel Filler lid A
2 . Pull the Fuel Filler lid out to fully open B
To open the Fuel Cap, turn it counterclockwise C
See section 4 in the Owner’s Manual for more information .
Refer to the inside front cover for more information on QR codes .www .youtube .com/KiaFeatureVideos
One-Click Fuel Cap Video
QR CODE
REMINDER: It is normal operation when tightening to hear one click and then when Fuel Cap is released, it clicks back .
A
OTHER KEY FEATURES
OTHER KEY

FEATURES

SAFET Y FEATURES
SAFETYFEATURES
ALWAYS CHECK THE OWNER ’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS . †LEGAL DISCL AIMERS ON BACK INSIDE COVER*IF EQUIPPED63
B
REMINDER: For maximum protection, always wear your seatbelt .
For more detailed information regarding your vehicle’s safety belts, please refer to section 3 in the Owner’s Manual and the separate brochure titled “Understanding Your Safety Belt & Supplemental Restraint System . ”
•The seat belt warning chime operates for the driver ’s seat only unless the passenger seat is also occupied (or heavy cargo also placed in passenger seat)
QUICK TIP
A
Seat Belts†2 , 1 4
To properly fasten your safety belts:
1 . Insert the belt tongue plate A into the buckle until it clicks
2 . Position the lap portion of the belt across your lap as LOW ON THE HIPS as possible C . Adjust the belt to a SNUG FIT by pulling up on the shoulder portion B
Seat Belt Retractor Locks
Retractor locks allow lap/shoulder safety belts to remain unlocked during normal vehicle operation for freedom of movement and increased comfort .
During a STRONG STOP, SUDDEN TURN OR CERTAIN COLLISIONS, seat belt retractors will automatically lock the belts to help reduce the risk of injury .
A
C
ODS is designed to detect the presence and position of the front passenger and is designed to adjust or turn off airbag deployment accordingly .
Depending on the situation and type of accident, the system may:
•Deploy airbag (Adult)
•Not deploy the airbag (Unoccupied)
If the system determines that the airbag should not be deployed, the “PASSENGER AIRBAG OFF” light will illuminate D .
Occupant Detection System (ODS)†1 1 / Passenger Airbag Off
REMINDER: Do not allow an adult passenger to ride in the front seat when the Passenger Airbag Indicator is illuminated OFF because the airbag will not deploy in the event of a crash . The driver must instruct the passenger to reposition her/himself in the seat .
2PASSENGER
AIR BAG OFF
-PDBUFE
UP
UIF
SJHIU
PG
$MJNBUF
$POUSPMT

$FOUFS
1BOFM


2PASSENGERAIR BAG OFFD
See section 3 in the Owner’s Manual for more information .

MAINTENANCE
TELLURIDE NORMAL MAINTENANCE SCHEDULE
‡ If equipped .A . See the Owner ’s Manual for complete maintenance schedule .B . If necessar y, adjust, correct, clean or replaceC . If TOP TIER detergent gasoline is not available, one bot tle of fuel additive is recommended . Additives are available from your authorized Kia dealer along with information on how to use them . Do not mix other additives .D . As it is normal for engine oil to be consumed during driving, the engine oil level should be checked on a regular basis . The engine oil change inter val for normal operating conditions is based on the use of the recommended engine specification . If the recommended engine oil specification is not used, then replace the engine oil according to the maintenance schedule under severe operating conditions .E . Both the fuel filter & fuel tank air filter are generally considered to be maintenance free, depending on fuel qualit y being used . However, periodic inspection is recommended . If your vehicle is having issues like fuel flow restriction, power surging, loss of power, difficult y star ting, etc ., replace the fuel filter immediately and consult an authorized Kia dealer for service .
F . Transfer case oil and rear axle oil should be changed any time they have been submerged in water .G . Inspect for excessive tappet noise and/or engine vibration and adjust if necessar y .H . The drive belt should be replaced when cracks occur or tension is reduced excessively .
P=Per form R=Replace I=InspectB
See the Owner’s Manual for more details and complete maintenance information, including severe maintenance schedule . Warranty may be voided if maintenance schedule is not followed .
64TELLURIDE FEATURES & FUNCTIONS GUIDE
•Check your Maintenance Schedule or schedule an appointment with a dealer using your UVO link account by logging into your Kia Access with UVO link App or your account on ht tps://owners .Kia .com (Vehicles equipped with UVO link only – See page 39 for setup information)
QUICK TIP
(up to , miles)AMAINTENANCE INTERVALS (MILES)
MAINTENANCE ITEMS,,,,,,,,
Add fuel additivesC (ever y , miles or  months)PPPPPPPP
Rotate tiresPPPPPPPP
Engine oil and oil filterDRRRRRRRR
#rake lines, hoses and connectionsIIIIIIII
#rake discs and padsIIIIIIII
Vacuum hoseIIIIIIII
Steering gear rack, linkage  bootsIIIIIIII
Suspension ball Koints and mounting boltsIIIIIIII
Air conditioner compressorrefrigerantIIIIIIII
Tire (pressure and tread wear)IIIIIIII
#oltsnuts on chassis and bodyIIIIIIII
Air cleaner filterIIRIIRII
#rake fluid (Inspect ever y , miles or  months)IIIIIIIR
Parking brake IIIIIIII
Climate control air filterIRIRIRIR
Drive shafts and bootsIIII
Propeller shaftIIII
Fuel tank air filter

LEGAL DISCL AIMERS
Drivingwhiledistracted isdangerous andshould beavoided. Driversshouldremain attentive todriving andalways exercise cautionwhenusingthesteering-wheel-mountedcontrolswhiledriving.
Drivingwhiledistracted canresult inaloss ofvehicle control thatmay lead toan accident, severepersonal injuryanddeath. Thedriver’s primary responsibility isin the safe andlegal operation ofavehicle, andanyhandheld devices,otherequipment orvehicle systems whichtakethedriver’s eyes,attention andfocus awayfromthesafe operation ofavehicle orthat arenotpermissiblebylawshouldneverbeusedduringoperationofthevehicle.
Safety Features: Nosystem, nomatter howadvanced, cancompensate foralldriver errorand/or driving conditions. Alwaysdrivesafely.
1. UVO link: Purchase/lease of certain 2020 and newer Kia vehicles with UVO link includes a complimentary 1-year subscription starting from new vehicle retail sale/lease date as recorded by the dealer. After your complimentary 1-year UVO link subscription expires, continued access to the full suite of UVO link available on your Kia will require a paid subscription at the then current subscription rate or your use of certain UVO link features may immediately terminate. Use of UVO is subject to agreement to the UVO Privacy Policy (available at https://owners.kia.com/us/en/privacy-policy.html.html) and Terms of Service (available at https://owners.kia.com/us/en/terms-of-service.html.html). UVO link is transferable to subsequent owner during the original UVO link service term. Only use UVO link when safe to do so. Kia Access with UVO link App is available from the Apple® App Store® or Google Play™. Kia America, Inc. reserves the right to change or discontinue UVO link at any time without prior notification or incurring any future obligation. Message and data rates may apply. Cellular and GPS coverage is required to use most features. UVO link features may vary by model, model year, and trim level. Features, specifications, and fees are subject to change. For more on details and limitations, visit https://owners.kia.com or your authorized Kia dealer. Apple and App Store are registered trademarks of Apple Inc. Google and logos are trademarks of Google, LLC.
UVO link is currently unavailable for model year 2022 vehicles sold or purchased in Massachusetts. See UVO Terms of Service at owners.kia.com for more information.
2. Airbags: For maximum protection, always wear your seat belt.
3. Android Auto™,Apple CarPlay®,Bluetooth®Wireless Technology, GooglePlay™Store, iPhone, SiriusXM®,HomeLink®: Fair Use of Trademark – The commentary reference to trademarked material is for educational purposes only and not an endorsement by or of the holder of the mark.
4. DriverAssistFeatures —Forward Collision-Avoidance Assist(FCA), Blind-Spot Collision-Avoidance Assist(BCA),Blind-Spot ViewMonitor (BVM)System, RearCross-Traffic Collision-Avoidance Assist(RCCA), LaneKeeping Assist(LKA), LaneFollowing Assist(LFA),RearViewMonitor (RVM),Reverse ParkingAidFunction, Forward/ReverseParkingDistance Warning(PDW),SmartCruiseControl (SCC),Navigation-based SmartCruise Control -(NSCC), SafeExitAssist (SEA), RearOccupant Alert(ROA) withUltrasonic Sensors,Highway DrivingAssist(HDA),Leading VehicleDeparture Alert(LVDA): These features are not substitutes for safe driving, and may not detect all objects surrounding vehicle. Always drive safely and use caution.
5. Driver Attention Warning(DAW): Driver Attention Warning is not a substitute for safe driving and may not detect all instances of inattentive driving practices. Failure to pay attention to travel conditions and vehicle operation could result in loss of vehicle control. Always drive safely and use caution.
6. Electronic StabilityControl(ESC)/Traction ControlSystem (TCS)/Hill-start AssistControl (HAC): No system, no matter how advanced, can compensate for all driver error and/or driving conditions. Always drive safely.
7. EngineStart/Stop ButtonwithSmart Key: Always come to a complete stop before turning the engine on or off. However, if you have an emergency while the vehicle is in motion and must turn the engine off, you can turn the engine off to the ACC position by pressing the Start/Stop button for more than 3 seconds or 3 times in succession. If the vehicle is still moving, you can restart the engine by pressing the Start/Stop button with the shift lever in Neutral (N). With the engine off, hydraulic power assist for steering and braking will be disabled and the vehicle will be more difficult to control.
8. FrontSeatHeadrest Adjustment: Never attempt to adjust headrests when vehicle is in motion.
9. Head-Up Display(HUD): Failure to pay attention to travel conditions and vehicle operation could result in loss of vehicle control. Always drive safely and use caution.
10. Navigation: Distracted driving can result in a loss of vehicle control. When operating a vehicle, never use a vehicle system that takes your focus away from safe vehicle operation. Navigation is for information purposes only, and Kia does not make any warranties about the accuracy of the information.
11. Occupant Detection System(ODS): Kia vehicles use a number of different ODS types that vary by model.
12. Roadside Assist: 24-hour Enhanced Roadside Assistance is a service plan provided by Kia America, Inc. Certain limitations apply. Coverage details are available in the Kia Warranty and Consumer Information Manual. For access to Enhanced Roadside Assistance, a connected mobile phone via Bluetooth® within the cellular service coverage area is required.
13. SeatAdjustments: Reclining the passenger seats can reduce the effectiveness of the safety restraint system and may lead to additional injury in an accident.
14. Seat Belts: For maximum protection, always wear your seatbelt.
15. SeatWarmers: Use extreme caution when using the seat warmers to avoid burns. Refer to the Owner’s Manual for more information.
16. Smart Power Liftgate: Driving with the liftgate open may be unlawful and can draw dangerous exhaust fumes into your vehicle.
17. Steering-Wheel-Mounted Controls: Driving while distracted is dangerous and should be avoided. Remain attentive to driving and be cautious when using steering-wheel-mounted controls while driving.
18. Sunvisors: Sunvisor may not shield all direct light. Do not operate the vehicle if sunvisor is impairing your visibility.
19. Tilt/Telescoping SteeringWheel: Never attempt to adjust steering wheel position when vehicle is in motion.
20. Tire Pressure Monitoring System(TPMS): Even with Tire Pressure Monitoring System, check tire pressure on a regular basis.

Sales Consultant:
Sales Manager:
Customer:
Date:
Date:
Date:
SmartCruiseControl
(SCC)– page 19
Demonstrate operation
KeyFeatureWalkthrough
DuringDelivery
Multimedia USB Por ts, Power Outlets & USB Charger Por t – page 42
Blind-Spot Collision-Avoidance Assist (BCA) – page 15
Clock Setup – page 42
Electronic Parking Brake (EPB) / Auto Hold* - pages 46-47
Engine Star t/Stop Button – page 31
Head-Up Display (HUD)* – page 27
Sunroof Operation – page 59
For ward*/Reverse Parking Distance Warning (PDW) – page 26

Passenger Air Bag Off Indicator – page 63
Front Seat Headrest Adjustment* – page 50
Seat Warmers/ Ventilated Seats – page 49
Smar t Key – page 55
Sunvisor – page 61
Tire Pressure Monitoring System (TPMS) – page 09
Explain first service process and schedule first service appointment
Tour Par ts & Service depar tments, introduce staff and explain value of Kia Par ts and Service
Review recommended maintenance schedule and maintenance requirements to validate warranty
Review business hours
Review the Kia 10-year/100,000-mile warranty program
Ensure 100% satisfaction with sales and delivery process and no problems with the vehicle
Confirm time and best contact number for initial dealer follow-up
Bluetooth® Wireless
Technology
– pages 36-37
Demonstrate operation
Auto-DimmingRearview
MirrorwithHomeLink®
– page 60
Front&RearWindshield
Wipers&Washers
– page 33
CUSTOMERDELIVERYCHECKLISTTELLURIDE
CRUISE
MODE
CRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
MODECRUISE
CANCEL
RES
OK SET
MODE
CANCEL
RES
OK SET
MODECRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
CRUISE
MODECRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
MODE CRUISE
CANCEL
RES
OK SET
MODE
CANCEL
RES
OK SET
MODECRUISE
CANCEL
RES
OK SET
CRUISE
CANCEL
RES
OK SET
HI
LO
OFF

Confirm “Good Bat tery” with bat tery tester
Verify all tire pressures are to spec (see driver ’s door label) LF LR
RF RR
Verify proper operation of Smar t Key* lock/unlock
Ensure floormats are snapped into place (if applicable)
Verify vehicle is clean (interior and exterior), in good condition, free of chips and scratches
Ensure all key documents are in the vehicle (Owner ’s Manual, Warranty and Consumer Information
booklet, Tire Warranty booklet, Features & Functions Guide and any supplemental audio/video/navigation user ’s guides)
AutomaticTransmission/
ManualShiftMode* – page 43
Automatic Climate Control – page 44
Demonstrate Air Flow Modes, Defog and
Defrosting Windshield Fan Speed.
UVOlinkwithNavigation – page 41
For further system operation, refer
to the Car Multimedia System User’s
Manual.
UVOlinkActivation – page 39
UVOlinkAssistance – page 39
AndroidAuto™/AppleCarPlay®S et up*
– page 38
KiaAccesswithUVOlinkApp
Download – page 40
KiaAccesswithUVOlinkApp
Features Guide – page 40
Before Delivery
KeyFeatureWalkthrough
Owner’s Name: _________________________________ VIN:
Mileage: __________________ Dealership Name: ______________________
Sales Consultant: _________________________________ Date: __________
CUSTOMERDELIVERYCHECKLISTTELLURIDE
SHIFT
LOCK
RELEASEP•R•N•D•
+
•-
AUTOOFFA/CSYNC888ADS OFFAUTO888AUTO888
MAP RADIO
N AV MEDIASEEK<
SETUPL
MAP RADIO
N AV MEDIASEEK<
SETUPL

© 2021 Kia America, Inc. All rights reser ved. Par t Number: ON220-PS-004
