CONTENTS
20 CONTENTS
LIGHTING.................................................................................................. 86-2-1
ADJUSTMENTS
Headlamps - pair - align beam - up to 04MY .................................................................................. 86-2-1
Headlamps - pair - align beam - from 04MY ................................................................................... 86-2-1
REPAIRS
Headlamp assembly - up to 04MY.................................................................................................. 86-2-3
Headlamp assembly - from 04MY .................................................................................................. 86-2-4
Lamp assembly - flasher side repeater - front ................................................................................ 86-2-5
Lamp assembly - tail ....................................................................................................................... 86-2-5
Lamp assembly - number plate ...................................................................................................... 86-2-6
Lamp assembly - fog/driving - from 04MY ...................................................................................... 86-2-6
Lamp assembly - rear ..................................................................................................................... 86-2-7
Lamp assembly - centre high mounted stop (CHMSL) ................................................................... 86-2-7
Lamp assembly - glove compartment ............................................................................................. 86-2-8
Lamp assembly - load space .......................................................................................................... 86-2-8
Switch - headlamp levelling ............................................................................................................ 86-2-9
Switch - glove compartment ........................................................................................................... 86-2-9
Switch - hazard warning ................................................................................................................. 86-2-10
Switch - combined direction indicator/headlight/horn ..................................................................... 86-2-10
Switch - rear fog lamp ..................................................................................................................... 86-2-11
CONTROL UNITS ..................................................................................... 86-3-1
REPAIRS
Control unit - window lift ................................................................................................................. 86-3-1
Relay - power folding mirrors - from 02MY ..................................................................................... 86-3-1
Central Control Unit (CCU) ............................................................................................................. 86-3-2
Control Unit - power fold mirrors - up to 02MY ............................................................................... 86-3-3
SECURITY................................................................................................. 86-4-1
REPAIRS
Solenoid/motor - taildoor................................................................................................................. 86-4-1
Switch/push - horn .......................................................................................................................... 86-4-2
Horn ................................................................................................................................................ 86-4-2
Immobilisation - electronic control unit (ECU) - ............................................................................. 86-4-3
Sensor - volumetric - alarm system - 3 door ................................................................................... 86-4-3
Module (ECU) - volumetric - alarm system - 5 door - without sunroof ........................................... 86-4-5
Module (ECU) - volumetric - alarm system - 5 door - with sunroof ................................................ 86-4-7
Receiver - alarm system ................................................................................................................. 86-4-10
Coil - passive immobilisation - alarm system .................................................................................. 86-4-10

EXTERIOR FITTINGS
REPAIRS 76-2-13
Bumper valance - rear - up to 04MY
$% 76.22.74
Remove
1.Remove rear mud flaps.

+ EXTERIOR FITTINGS, REPAIRS,
Mud flap - rear.
2.Remove both rear tail lamps.

+ LIGHTING, REPAIRS, Lamp
assembly - tail.
3.Remove rear wheel arch extensions.

+ EXTERIOR FITTINGS, REPAIRS,
Wheelarch extension - rear wing part.
4.Remove 10 screws securing bumper valance to
body.
5.Remove 2 nuts and bolts securing bumper
valance to armature.
6.Remove 5 scrivets securing bumper valance to
body.
7.Remove 2 mud flap brackets.
8. NAS Models: Release side repeater,
disconnect multiplug and remove repeater.
9.With assistance remove bumper valance.
Refit
1.With assistance fit bumper valance and secure
with scrivets, screws, nuts and bolts.
2. NAS Models: Feed side repeater harness
through bumper, connect multiplug and fit
repeater.
3.Fit mud flap brackets and secure with screws.
4.Fit rear wheel arch extensions.

+ EXTERIOR FITTINGS, REPAIRS,
Wheelarch extension - rear wing part.
5.Fit both rear tail lamps.

+ LIGHTING, REPAIRS, Lamp
assembly - tail.
6.Fit rear mud flaps.

+ EXTERIOR FITTINGS, REPAIRS,
Mud flap - rear.
Bumper valance - rear - from 04MY
$% 76.22.74
Remove
1.Remove rear mud flaps.

+ EXTERIOR FITTINGS, REPAIRS,
Mud flap - rear.
2.Remove both rear fog lamps.

+ LIGHTING, REPAIRS, Lamp
assembly - rear.
3.Remove rear wheel arch extensions.

+ EXTERIOR FITTINGS, REPAIRS,
Wheelarch extension - rear wing part.
4.Remove 2 screws and remove both mud flap
retaining brackets.
5.Remove 6 Torx screws securing luggage
compartment carpet retainer to body.
6.Remove luggage compartment carpet retainer.

EXTERIOR FITTINGS
REPAIRS 76-2-15
17.Release 2 retaining clips and remove parking
aid sensor from finisher.
18.Remove parking aid sensor finisher from
bumper valance.
19.Repeat above procedure for remaining 3
parking aid sensors.
20.Remove tail lamp speed nuts from bumper
valance.Refit
1.Fit tail lamp speed nuts to bumper valance.
2.Fit and secure parking aid finishers and
sensors to bumper valance.
3.Fit and secure parking aid harness to sensors
and bumpers valance.
4.Fit both rear tail lamps.

+ LIGHTING, REPAIRS, Lamp
assembly - tail.
5.With assistance, position bumper valance to
body.
6.Connect parking aid harness multiplug, fit
retaining clip and secure to body.
7.Align bumper valance to body and secure with
retaining screws and scrivets.
8.Fit Torx screws securing bumper valance to
bumper armature and tighten to 5 Nm (3.7
lbf.ft).
9.Fit tailgate aperture seal to body.
10.Fit luggage compartment carpet retainer and
secure with Torx screws.
11.Fit both mud flap retaining brackets and secure
with screws.
12.Fit rear wheel arch extensions.

+ EXTERIOR FITTINGS, REPAIRS,
Wheelarch extension - rear wing part.
13.Fit both rear fog lamps.

+ LIGHTING, REPAIRS, Lamp
assembly - rear.
14.Fit rear mud flaps.

+ EXTERIOR FITTINGS, REPAIRS,
Mud flap - rear.

LIGHTING
86-2-6 REPAIRS
Lamp assembly - number plate
$% 86.40.86
Remove
1.Remove 2 screws securing lamp to tail door
handle.
2.Disconnect 2 Lucars from number plate lamp.
Refit
1.Position number plate lamp and connect
Lucars.
2.Fit number plate lamp and secure with screws.
Lamp assembly - fog/driving - from 04MY
$% 86.40.96
Remove
1.Release and remove fog/driving lamp finisher
from bumper.
2.Remove 3 screws securing fog/driving lamp to
bumper.
3.Release fog/driving lamp from bumper,
disconnect multiplug and remove lamp.
Refit
1.Position fog/driving lamp to bumper and
connect multiplug.
2.Fit fog/driving lamp to bumper and secure lamp
with screws.
3.Fit fog/driving lamp finishers to bumper.

LIGHTING
REPAIRS 86-2-11
Switch - rear fog lamp
$% 86.65.65
Remove
1.Remove instrument cowl.

+ INSTRUMENTS, REPAIRS, Cowl -
instrument - up to 04MY.
2.Remove rear fog lamp switch from instrument
cowl.
Refit
1.Fit switch to instrument cowl.
2.Fit instrument cowl.

+ INSTRUMENTS, REPAIRS, Cowl -
instrument - up to 04MY.
