oil pressure Lexus CT200h 2011 Owner's Manual (in English)

466
CT200h_EE (OM76041E)
4-1. Maintenance and care
Cleaning and protecting the vehicle exterior
Automatic car washes
Fold the mirrors and remove the antenna before washing the vehicle.
Start washing from the front of the vehicle. Make sure to re-install the
antenna and extend the mirrors before driving.
Brushes used in automatic car washes may scratch the vehicle surface
and harm your vehicle’s paint.
Roof antenna, rear spoiler may not be washable in some automatic car
washes. There may also be an increased risk of damage to vehicle.
High pressure car washes
Do not allow the nozzles of the car wash to come within close proximity
of the windows.
Before using the car wash, check that the fuel filler door on your vehicle
is closed properly.
Perform the following to protect the vehicle and maintain it in prime
condition:
Working from top to bottom, liberally apply water to the
vehicle body, wheel wells and underside of the vehicle to
remove any dirt and dust.
Wash the vehicle body using a sponge or soft cloth, such as
a chamois.
For hard-to-remove marks, use car wash soap and rinse
thoroughly with water.
Wipe away any water.
Wax the vehicle when the waterproof coating deteriorates.
If water does not bead on a clean surface, apply wax when the
vehicle body is cool.

478
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
ItemsParts and tools
Engine oil level (P. 487)
• “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel
• Funnel (used only for adding
engine oil)
Fuses (P. 520)• Fuse with same amperage rating
as original
Light bulbs (P. 534)
• Bulb with same number and
wattage rating as original
• Phillips-head screwdriver
• Flathead screwdriver
•Wrench
Radiator and condenser (P. 4 9 4)
Tire inflation pressure (P. 507)• Tire pressure gauge
• Compressed air source
Washer fluid (P. 495)
• Water or washer fluid contain-
ing antifreeze (for winter use)
• Funnel (used only for adding
water or washer fluid)

5
559
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Stop the vehicle immediately.
The following warning indicates the possibility of damage to the
vehicle that may lead to an accident. Immediately stop the vehicle
in a safe place and contact any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
Warning lightWarning light/Details
Charging system warning light
Indicates a malfunction in the vehicle’s charging sys-
tem
Low engine oil pressure warning light
Indicates that the engine oil pressure is too low
High coolant temperature warning light
Changes from a flashing to a solid light when the
engine coolant temperature increases

690
Alphabetical index
CT200h_EE (OM76041E)
Vanity lights
Vanity lights .........................449
Wattage .................................652
Vanity mirrors ...........................449
Vehicle identification number ...639
Vehicle stability control ............285
VSC ...........................................285
VSC+ .........................................286
Warning buzzers
Brake system ........................558
Open door ............................562
Seat belt reminder .................562
Warning lights
Anti-lock brake system
(ABS) .................................560
Automatic headlight leveling
system.................................561
Brake system ................558, 561
Charging system ...................559
Electric power steering
system.................................560
High coolant temperature .....559
Low engine oil pressure........559
Low fuel level .......................562
Malfunction indicator lamp ..560
Master warning light ............562
Open door .............................562
Pre-crash safety system ........561
Seat belt reminder light ........562
Slip indicator ........................561
SRS airbags ..........................560Warning messages
Back door............................. 570
Cruise control ...................... 568
Dynamic radar cruise
control ....................... 568, 572
EV drive mode ..................... 574
Headlight ............................. 567
Hood .................................... 570
Hybrid system ...................... 573
Hybrid system overheat ....... 573
Key....................................... 577
Lexus parking
assist-sensor............... 568, 571
Light reminder ..................... 571
Moon roof ............................ 570
Open door ............................ 569
Parking brake ....................... 571
Pre-crash
safety system ..... 568, 572, 576
Rear passenger seat belt
reminder ............................ 570
Smart entry & start system .. 577
Washer fluid ........................ 576
Washer
Checking .............................. 495
Preparing and checking
before winter ..................... 304
Switch .................................. 239
Washing and waxing ................ 466
Weight
Weight ................................. 638
Wheels ...................................... 509
Window glasses ........................ 119
Window lock switch ................. 120V
W

693
What to do if...
CT200h_EE (OM76041E)
Warning lights
P. 5 5 8P. 561
P. 5 5 9P. 561
P. 5 5 9P. 561
P. 5 5 9P. 561
P. 5 6 0P. 562
P. 5 6 0P. 562
P. 5 6 0P. 562
P. 5 6 0P. 562
*: The indicator flashes to indicate a malfunction.
Brake system warning
light (red indicator)Pre-crash safety system
warning light
*
Charging system warn-
ing lightSlip indicator light
Low engine oil pressure
warning lightBrake system warning
light
High coolant temperature
warning light
Malfunction indicator
lampOpen door warning light
SRS warning lightLow fuel level warning
light
“ABS” warning lightSeat belt reminder light
Master warning light
Automatic headlight
leveling system
warning light
Electric power steering
system warning
light

696
CT200h_EE (OM76041E)
GAS STATION INFORMATION
Auxiliary catch lever
P. 4 8 1Fuel filler door
P. 1 2 7
Hood lock release lever
P. 4 8 1Fuel filler door opener
P. 1 2 7Tire inflation pressure
P. 6 4 9
Fuel tank capacity
(Reference)45 L (11.9 gal., 9.9 Imp.gal.)
Fuel typeUnleaded gasoline only P. 641
Cold tire inflation
pressureP. 649
Engine oil capacity
(Drain and refill
—reference)L (qt., Imp. qt.)
With filter 4.2 (4.4, 3.7)
Without filter 3.9 (4.1, 3.4)
Engine oil typeToyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil P. 642
Recommended oil viscosity: SAE-0W-20
