start Lexus CT200h 2012 Owner's Manual (in English)

655
6-1. Specifications
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Lexus
recommends the use of approved “Toyota Genuine Motor Oil”.
Another motor oil of matching quality can also be used.
Oil grade:
0W-20, 5W-20, 5W-30 and 10W-30:
API grade SL “Energy-Conserving”, SM “Energy-Conserving”,
SN “Resource-Conserving” or ILSAC multigrade engine oil
15W-40 and 20W-50:
API grade SL, SM or SN multigrade engine oil
Recommended viscosity (SAE):
SAE 0W-20 is filled into your
Lexus vehicle at manufactur-
ing, and the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 oil is not avail-
able, SAE 5W-30 oil may be
used. However, it should be
replaced with SAE 0W-20 at
the next oil change.
If you use SAE 10W-30 or a
higher viscosity engine oil in
extremely low temperatures,
the engine may become diffi-
cult to start, so SAE 5W-30 or
lower viscosity engine oil is
recommended.
Temperature range anticipated
before
Preferred

656
6-1. Specifications
CT200h_OM_OM76067E_(EE)
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which
allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil
when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is oper-
ated at high speeds, or under extreme load conditions.
How to read oil container labels:
Either or both API registered marks are added to some oil contain-
ers to help you select the oil you should use.
API Service Symbol
Top portion: The oil quality des-
ignation by API (American
Petroleum Institute) (SN)
Center portion: The SAE vis-
cosity grade (SAE 0W-20)
Lower portion:
“Resource-Conserving” means
that the oil has fuel saving and
environmental protection capa-
bilities.
ILSAC Certification Mark
The ILSAC (International
Lubricant Standardization and
Approval Committee) Certifica-
tion Mark is displayed on the
front of the container.

672
6-2. Customization
CT200h_OM_OM76067E_(EE)
Smart
entry &
start sys-
tem
*1 and
wireless
remote
control
(
P. 62,
84)
LOCK FEED-
BACK VOL-
UME
(Adjust the
volume of
buzzer sounds)
7
Off
O–OO
1 to 6
LOCK/
UNLOCK
ANSWER
BACK
(Enable/dis-
able the opera-
tion of the
emergency
flashers when
the vehicle is
locked or
unlocked)
OnOffO–OO
ItemFunctionDefault
settingCustomized
setting

673
6-2. Customization
6
Vehicle specifica-
CT200h_OM_OM76067E_(EE)
Smart
entry &
start sys-
tem
*1 and
wireless
remote
control
(
P. 62,
84)
AUTO.
RELOCK
TIME
ADJUST-
MENT
(Adjust the
time elapsed
before the
automatic door
lock function
is activated if a
door is not
opened after
being
unlocked)
30 seconds
Off
O–OO
60 seconds
120 seconds
Open door
reminder
buzzer (When
locking the
vehicle)
OnOff–––O
ItemFunctionDefault
settingCustomized
setting

674
6-2. Customization
CT200h_OM_OM76067E_(EE)
Smart
entry &
start sys-
tem
*1
(P. 62)
SELECT
DOORS TO
UNLOCK
(The doors
that are
unlocked
using the
smart entry &
start system
can be
selected)
All the
doorsDriver’s doorO–OO
ENTRY AND
START SYS-
TEM
(Smart entry &
start system
can be dis-
abled)
OnOffO–OO
ItemFunctionDefault
settingCustomized
setting

678
6-2. Customization
CT200h_OM_OM76067E_(EE)
Illumina-
tion
(
P. 445)
Operation
after the
“POWER”
switch is
turned to OFF
OnOff–––O
Operation
when the
doors are
unlocked with
the Smart
entry & start
system or the
wireless
remote con-
trol function or
the mechanical
key
*2
OnOff–––O
Operation
when you
approach the
vehicle with
the electronic
key on your
person
*2
OnOff–––O
ItemFunctionDefault
settingCustomized
setting

686
6-2. Customization
CT200h_OM_OM76067E_(EE)
Vehicle customization
When “SPEED SENSITIVE AUTO LOCK” and “SHIFT-LINKED
AUTOMATIC LOCK” are both on, the door lock operates as follows.
• When shifting the shift position to any position other than P, all the
doors will be locked.
• If the vehicle is started with all the doors locked, “SPEED SENSI-
TIVE AUTO LOCK” would not operate.
• If the vehicle is started with any door unlocked, “SPEED SENSITIVE
AUTO LOCK” will operate.
When “ENTRY AND START SYSTEM” is off, “SELECT DOORS TO
UNLOCK” cannot be customized.
When the doors remain closed after unlocking the doors and “AUTO.
RELOCK TIME ADJUSTMENT” activates, the signals will be gener-
ated in accordance with the “LOCK/ FEEDBACK VOLUME” and the
“LOCK/UNLOCK ANSWER BACK” settings.
In the following situations, customize mode in which the settings can be
changed through the “DISP” switch will automatically be turned off.
A warning message appears after the customize mode screen is dis-
played.
The “POWER” switch is turned off.
The vehicle begins to move while the customize mode screen is dis-
played.

693
Alphabetical index
CT200h_OM_OM76067E_(EE)
Back door
Back door ...............................93
Smart entry & start system .....62
Wireless remote control..........84
Back-up lights
Replacing light bulbs ............546
Wattage .................................664
Battery
Checking ...............................508
If the vehicle has a discharged
12-volt battery ....................633
Preparing and checking
before winter ......................311
Bluetooth
®*..............................388
Bottle holders ............................452
Brake
Fluid......................................660
Parking brake ........................217
Brake assist................................291
Break-in tips ..............................188
Brightness control
Instrument panel light
control ................................221Care
Exterior ................................ 476
Interior ................................. 482
Seat belts .............................. 483
Cargo hooks.............................. 469
CD changer
*............................ 341
CD player
*............................... 341
Chains ....................................... 313
Child restraint system
Baby seats, definition .......... 166
Baby seats, installation ........ 177
Child seats, definition .......... 166
Child seats,
installation ......................... 177
Installing child restraint system
with ISOFIX rigid anchor . 180
Installing child restraint system
with seat belts .................... 177
Installing child restraint system
with top tether strap........... 181
Junior seats, definition ......... 166
Junior seats, installation....... 177
BC
*: For vehicles with a navigation system, refer to
the “Navigation System Owner’s Manual”.

694
Alphabetical index
CT200h_OM_OM76067E_(EE)
Child safety
Airbag precautions................158
Back door precautions ............95
Child restraint system ...........166
Child-protectors ......................90
How your child should wear
the seat belt.........................111
Installing child restraints ......176
Moon roof precautions .........130
Power window lock switch...124
Power window precautions...126
Removed electronic key battery
precautions .........................531
Seat belt precautions .............112
Seat heater precautions .........466
12-volt battery precautions ...512
Child-protectors...........................90
Cleaning
Exterior .................................476
Interior ..................................482
Seat belts...............................483
Clock
*.......................................459
Condenser ..................................506
Console box ...............................450
Cooling system
Engine overheating ...............639
Hybrid system overheating ...639
Cruise control
Cruise control .......................250
Dynamic radar cruise control .....
255
Cup holders ...............................451Curtain shield airbags ............... 151
Customizable features .............. 667
Daytime running light system .. 237
Defogger
Rear window ........................ 330
Side mirrors ......................... 330
Dimensions ............................... 650
Display
Dynamic radar cruise
control ............................... 255
Multi-information display.... 229
Trip information .................. 231
Warning message................. 578
Do-it-yourself maintenance ...... 488
Door lock
Back door............................... 93
Side doors .............................. 89
Smart entry & start system .... 62
Wireless remote control ......... 84
Doors
Back door............................... 93
Door glasses......................... 123
Door lock ................... 62, 84, 89
Rear door child protector ....... 90
Side doors .............................. 89
Driver’s seat belt reminder light575
Driver’s seat position memory . 102
Driving
Break-in tips ........................ 188
Correct posture .................... 149
Procedures ........................... 186
Winter driving tips ............... 311
Driving position memory ......... 102
D

695
Alphabetical index
CT200h_OM_OM76067E_(EE)
Electric power steering ..............291
Electronic key
If the electronic key does not
operate properly .................630
Replacing battery ..................527
Emergency, in case of
If a warning buzzer sounds ...571
If a warning light turns on ....571
If a warning message is
displayed ............................578
If the electronic key does not
operate properly .................630
If the hybrid system will not
start .....................................627
If the 12-volt battery is
discharged ..........................633
If you have a flat tire ...599, 613
If you lose your keys ............629
If you think something is
wrong .................................570
If your vehicle becomes stuck ....
644
If your vehicle has to be stopped
in an emergency .................646
If your vehicle needs to be
towed ..................................563
If your vehicle overheats ......639
Emergency brake signal ............292
Emergency flashers ...................562Engine
Accessory mode................... 200
Compartment ....................... 496
Hood .................................... 492
How to start the hybrid
system................................ 198
Identification number .......... 651
If the hybrid system will not
start .................................... 627
Ignition switch ..................... 198
Overheating ......................... 639
“POWER” switch ................ 198
Engine compartment cover....... 497
Engine coolant
Capacity ............................... 657
Checking .............................. 503
Preparing and checking
before winter ..................... 311
Engine/power control unit coolant
Capacity ............................... 657
Checking .............................. 503
Preparing and checking
before winter ..................... 311E
*: For vehicles with a navigation system, refer to
the “Navigation System Owner’s Manual”.
