steering Lexus CT200h 2012 (in English) Repair Manual

419
3-4. Using the hands-free phone system (for cellular phones)
3
Interior features
CT200h_OM_OM76067E_(EE)
Steering wheel switches
Vo l u m e
The voice guidance volume
cannot be adjusted using this
button.
Off-hook switch
Turns the hands-free sys-
tem on/starts a call
On-hook switch
Turns the hands-free sys-
tem off/ends a call/refuses
a call
Ta l k s w i t c h
Turns the voice command
system on (press)/turns the
voice command system off
(press and hold)
Microphone

463
3-7. Other interior features
3
Interior features
CT200h_OM_OM76067E_(EE)
Heated steering wheel
: If equipped
The heated steering wheel can be used when
The “POWER” switch is in ON mode.
Timer
The heated steering wheel will automatically turn off after about 30 min-
utes.
If the indicator light flashes
Press the button to turn the heated steering wheel off and then press the but-
ton again. If the indicator light still flashes, a malfunction may be occurring.
Turn the heated steering wheel off and have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.
The heated steering wheel heats the side grips of the steering wheel.
Turns the heater on/off
The indicator light comes on
when the heater is operating.

464
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
CAUTION
Burns
Care should be taken to prevent injury if anyone in the following catego-
ries comes in contact with the steering wheel when the heated steering
wheel is on:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
Do not use the heated steering wheel more than necessary. Doing so may
cause minor burns or overheating.
NOTICE
To prevent 12-volt battery discharge
Turn the heater off when the hybrid system is off.

538
4-3. Do-it-yourself maintenance
CT200h_OM_OM76067E_(EE)
27DRL7.5 ADaytime running light system
28DOOR NO.225 APower door lock system
29P/I 160 AIG2, EFI MAIN, BATT FAN
30EPS60 AElectric power steering system
31PCU10 AHybrid system
32IGCT NO.210 A
Hybrid system, P position control
system, power management sys-
tem
33IGCT NO.310 ACooling system
34DOME10 A
Luggage compartment light, over-
head module, interior lights, per-
sonal lights, vanity lights, footwell
lights
35ECU-B7.5 A
Smart entry & start system, gauges
and meters, outside rear view mir-
rors, air conditioning system, driv-
ing position memory system,
electric power steering system,
clock
36H-LP LH HI10 ALeft-hand headlight (high beam)
37H-LP RH HI10 ARight-hand headlight (high beam)
FuseAmpereCircuit

541
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_OM_OM76067E_(EE)
2PANEL10 A
Audio system, Lexus parking
assist-sensor switch, windshield
wiper de-icer switch, navigation
system, fuel filler door opener,
glove box light, headlight cleaner
switch, emergency flasher switch,
manual headlight leveling dial, air
conditioning system, outside rear
view mirrors, driving mode select
switch, P position switch, instru-
ment panel light control dial, shift
position indicators, seat heater
switches, heated steering wheel
switch, pre-crash braking off
switch
3IGN10 A
Electronically controlled brake
system, smart entry & start system,
multiport fuel injection system/
sequential multiport fuel injection
system, stop/tail lights, SRS air-
bags
4MET7.5 AGauges and meters
FuseAmpereCircuit

542
4-3. Do-it-yourself maintenance
CT200h_OM_OM76067E_(EE)
5WIP30 AWindshield wipers
6RR WIP20 ARear window wiper and washer
7WASHER15 AWindshield washer
8A/C10 AAir conditioning system
9GAUGE10 A
Windshield wiper de-icer switch,
automatic headlight leveling sys-
tem
10ECU-IG NO.210 A
Windshield wipers, Lexus parking
assist monitor, Lexus parking
assist-sensor, electronically con-
trolled brake system, navigation
system, electric power steering
system, turn signal lights, emer-
gency flashers, yaw rate and G
sensor, headlight cleaner, outside
rear view mirrors, driving mode
select switch, overhead module,
pre-crash seat belts, seat heater
switches, heated steering wheel
switch, dynamic radar cruise con-
trol
11ECU-IG NO.110 ANo circuit
12S/ROOF30 AMoon roof
FuseAmpereCircuit

543
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_OM_OM76067E_(EE)
13DOOR RL25 APower windows
14DOOR RR25 APower windows
15D FR DOOR25 APower windows, outside rear view
mirrors
16P FR DOOR25 APower windows, outside rear view
mirrors
17STOP10 A
Emergency brake signal, stop/tail
lights, electronically controlled
brake system, pre-crash safety sys-
tem
18RR FOG7.5 ARear fog light, stop/tail lights
19FUEL OPEN7.5 AFuel filler door opener
20OBD7.5 AOn-board diagnosis system
21PWR SEAT30 APower seat
22FR FOG15 AFront fog lights
23DBL LOCK25 ADBL LOCK
24P-PWR SEAT30 APower seat
25PSB30 APre-crash seat belts
26STRG HTR10 AHeated steering wheel
27DOOR NO.125 APower door lock system
28SEAT HTR FL10 ASeat heaters
29SEAT HTR FR10 ASeat heaters
FuseAmpereCircuit

564
5-1. Essential information
CT200h_OM_OM76067E_(EE)
Emergency towing
If a tow truck is not available in
an emergency, your vehicle
may be temporarily towed
using a cable or chain secured
to the emergency towing eye-
let(s). This should only be
attempted on hard surfaced
roads for short distances at
under 30 km/h (18 mph).
A driver must be in the vehicle
to steer and operate the brakes.
The vehicle’s wheels, drive
train, axles, steering and brakes
must be in good condition.

568
5-1. Essential information
CT200h_OM_OM76067E_(EE)
CAUTION
Caution while towing
Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive
stress on the emergency towing eyelets and the cables or chains. Always
be cautious of the surroundings and other vehicles while towing.
Do not turn the “POWER” switch off.
This may lead to an accident as the front wheels will be locked by the
parking lock.
If the hybrid system is off, the power assist for the brakes and steering will
not function, making steering and braking more difficult.
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing. This
may lead to accidents that cause serious injury or even death.

5
573
5-2. Steps to take in an emergency
When trouble arises
CT200h_OM_OM76067E_(EE)
Have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional imme-
diately.
Failure to investigate the cause of the following warnings may lead
to the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
immediately.
Warning lightWarning light/Details
Malfunction indicator lamp
Indicates a malfunction in:
• The hybrid system;
• The electronic engine control system; or
• The electronic throttle control system
SRS warning light
Indicates a malfunction in:
• The SRS airbag system; or
• The seat belt pretensioner system
ABS warning light
Indicates a malfunction in:
• The ABS; or
• The brake assist system
Electric power steering system warning light (warning
buzzer)
Indicates a malfunction in the EPS system
