interior lights Lexus CT200h 2013 Owner's Manual (in English)

CT200h_OM_OM76102E_(EE)
Pictorial indexSearch by illustration
1For safety and
securityMake sure to read through them
2Instrument clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3Operation of each
componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advices which are necessary for driving
5Audio systemOperating the audio system and Lexus Display Audio
system
6Interior featuresUsage of the interior features, etc.
7Maintenance and
careCaring for your vehicle and maintenance procedures
8When trouble
arisesWhat to do in case of malfunction or emergency
9Vehicle specifica-
tionsVehicle specifications, customizable features, etc.
IndexSearch by symptom
Search alphabetically

TABLE OF CONTENTS6
CT200h_OM_OM76102E_(EE)
5-19. Bluetooth® Phone (Lexus Dis-
play Audio System)
Using a Bluetooth®
Phone.................................407
Making a call..................... 409
Receiving a call ................. 412
Speaking on the phone ...... 413
Using a Bluetooth® phone mes-
sages...................................415
Using the steering wheel
swithes............................418
Bluetooth® phone set-
tings................................419
5-20. Phonebook (Lexus Display Au-
dio System)
Contact settings ................. 421
Messaging setting.............. 424
5-21. Bluetooth® (Lexus Display Au-
dio System)
What to do if... (Troubleshoot-
ing)....................................425
Bluetooth® ........................ 428
5-22. Other function (Lexus Display
Audio System)
“Information” screen ......... 433
MirrorLink™..................... 434
USB photo ......................... 437
Speech command system .. 4396-1. Using the air conditioning sys-
tem and defogger
Automatic air conditioning sys-
tem (vehicles with a naviga-
tion system or Lexus Display
Audio Sys-
tem).................................442
Automatic air conditioning sys-
tem (Vehicles without a navi-
gation system or Lexus
Display Audio Sys-
tem).................................452
Heated steering wheel/seat heat-
ers.....................................459
• Heated steering wheel ... 460
• Seat heaters ................... 460
6-2. Using the interior lights
Interior lights list ............... 461
• Personal/interior light main
switch...............................462
• Front personal/interior
lights...............................462
• Rear interior light .......... 462
6-3. Using the storage features
List of storage features ...... 464
• Glove box...................... 465
• Console box .................. 465
• Cup holders/Bottle holders/
door pock-
ets.................................466
• Auxiliary boxes ............. 468
Luggage compartment fea-
tures...................................4706Interior features

25Pictorial index
CT200h_OM_OM76102E_(EE)
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
Sun visors
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Interior light
*3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Personal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Moon roof switches
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Intrusion sensor cancel switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . P. 96
1
2
3
4
5
6
*1: If equipped
*2: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 7 4 )
*3: The illustration shows the front, but they are also equipped in the rear.

33Pictorial index
CT200h_OM_OM76102E_(EE)
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
Sun visors
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Personal lights
*3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Moon roof switches
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Intrusion sensor cancel switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . P. 96
1
2
3
4
5
6
*1: If equipped
*2: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 7 4 )
*3: The illustration shows the front, but they are also equipped in the rear.

2824-6. Driving tips
CT200h_OM_OM76102E_(EE)
Delays
Repeated acceleration and deceleration, as well as long waits at traffic
lights, will lead to bad fuel economy. Check traffic reports before leav-
ing and avoid delays as much as possible. When driving in a traffic
jam, gently release the brake pedal to allow the vehicle to move for-
ward slightly while avoiding overuse of the accelerator pedal. Doing so
can help control excessive gasoline consumption.
Highway driving
Control and maintain the vehicle at a constant speed. Before stopping
at a toll booth or similar, allow plenty of time to release the accelerator
and gently apply the brakes. A greater amount of electrical energy can
be regenerated when slowing down.
Air conditioning
Use the air conditioning only when necessary. Doing so can help
reduce excessive gasoline consumption.
In summer: When the ambient temperature is high, use the recirculated
air mode. Doing so will help to reduce the burden on the air condition-
ing system and reduce fuel consumption as well.
In winter: Because the gasoline engine will not automatically cut out
until it and the interior of the vehicle are warm, it will consume fuel.
Fuel consumption can be improved by avoiding overuse of the heater.
Checking tire inflation pressure
Make sure to check the tire inflation pressure frequently. Improper tire
inflation pressure can cause poor fuel economy.
Also, as snow tires can cause large amounts of friction, their use on dry
roads can lead to poor fuel economy. Use tires that are appropriate for
the season.

441
6Interior features
CT200h_OM_OM76102E_(EE)
6-1. Using the air conditioning
system and defogger
Automatic air conditioning
system (Vehicles with
a navigation system or
Lexus Display Audio
System) ........................... 442
Automatic air conditioning
system (Vehicles without
a navigation system or
Lexus Display Audio
System) ........................... 452
Heated steering wheel/
seat heaters ...................... 459
• Heated steering wheel... 460
• Seat heaters ................... 4606-2. Using the interior lights
Interior lights list .............. 461
• Personal/interior light
main switch .................. 462
• Front personal/
interior lights ................ 462
• Rear interior light ......... 462
6-3. Using the storage features
List of storage features ..... 464
• Glove box ..................... 465
• Console box .................. 465
•Cup holders/
bottle holders/
door pockets ................. 466
• Auxiliary boxes ............ 468
Luggage compartment
features ........................... 470
6-4. Other interior features
Other interior features....... 473
• Sun visors ..................... 473
• Vanity mirrors............... 473
• Clock ............................ 474
• Power outlet.................. 475
• Assist grips ................... 477

4616-2. Using the interior lights
CT200h_OM_OM76102E_(EE)
6
Interior features
Interior lights list
Outer foot lights
Cup holder light (when the power switch is in ACCESSORY or ON
mode)
Front personal/interior lights (P. 462)
Rear interior light (P. 462)
Footwell lights
When the instrument panel light control dial is turned fully down, the cup
holder light and the footwell lights will turn off. (P. 106)
1
2
3
4
5

4626-2. Using the interior lights
CT200h_OM_OM76102E_(EE)
Turns the lights off
Turns the door position on
Turns the lights on
Turns the lights on/off
Turns the light on
Turns the door position on
*
*
: When the personal/interior light
main switch is in the off position, the
rear interior light will not turn on
even if the door is opened with the
rear interior light switch in door
position.
Personal/interior light main switch
1
2
3
Front personal/interior lights
Rear interior light
1
2

4636-2. Using the interior lights
CT200h_OM_OM76102E_(EE)
6
Interior features
Illuminated entry system: The lights automatically turn on/off according to
power switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are opened/closed.
If the interior lights remain on when the power switch is turned off, the lights
will go off automatically after 20 minutes.
Settings (e.g. the time elapsed before the lights turn off) can be changed.
(Customizable features: P. 655)
NOTICE
To prevent 12-volt battery discharge, do not leave the lights on longer than nec-
essary when the hybrid system is off.

4736-4. Other interior features
CT200h_OM_OM76102E_(EE)
6
Interior features
Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
Slide the cover to open.
The light turns on when the cover is
opened.
If the vanity lights remain on when the power switch is turned off, the light will
go off automatically after 20 minutes.
Sun visors
1
2
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge, do not leave the vanity lights on for
extended periods while the hybrid system is off.
