radio antenna Lexus CT200h 2013 Owner's Manual (in English)
[x] Cancel search | Manufacturer: LEXUS, Model Year: 2013, Model line: CT200h, Model: Lexus CT200h 2013Pages: 688
Page 11 of 688
11
CT200h_OM_OM76102E_(EE)The installation of an RF-transmitter system in your vehicle could affect elec-
tronic systems such as:
Multiport fuel injection system/sequential multiport fuel injection system
Dynamic radar cruise control system
Cruise control system
Anti-lock brake system
SRS airbag system
Seat belt pretensioner system
Be sure to check with any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional for precautionary measures or special
instructions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna positions
and installation provisions for the installation of RF-transmitters, is available on
request at any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
High voltage parts and cables on the hybrid vehicles emit approximately the
same amount of electromagnetic waves as the conventional gasoline powered
vehicles or home electronic appliances despite of their electromagnetic shielding.
Unwanted noise may occur in the reception of the radio frequency transmitter
(RF-transmitter).
Installation of an RF-transmitter system
Page 146 of 688
1463-2. Opening, closing and locking the doors
CT200h_OM_OM76102E_(EE)
Note for the entry function
Even when the electronic key is within the effective range (detection areas), the
system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near
the ground, or in a high place when the doors are locked or unlocked.
• The electronic key is near the ground or in a high place, or too close to the
rear bumper center when the back door is opened.
• The electronic key is on the instrument panel, luggage room, floor, or in the
door pockets or glove box when the hybrid system is started or power switch
modes are changed.
Do not leave the electronic key on top of the instrument panel or near the door
pockets when exiting the vehicle. Depending on the radio wave reception con-
ditions, it may be detected by the antenna outside the cabin and the door will
become lockable from the outside, possibly trapping the electronic key inside
the vehicle.
As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone.
Even if the electronic key is not inside the vehicle, it may be possible to start
the hybrid system if the electronic key is near the window.
The doors may unlock if a large amount of water splashes on the door handle,
such as in the rain or in a car wash when the electronic key is within the effec-
tive range. (The door will automatically be locked after approximately 30 sec-
onds if the doors are not opened and closed.)
If the wireless remote control is used to lock the doors when the electronic key
is near the vehicle, there is a possibility that the door may not be unlocked by
the entry function. (Use the wireless remote control to unlock the doors.)
Touching the door lock sensor while wearing gloves may delay or prevent lock
operation. Remove the gloves and touch the lock sensor again.
If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock repeatedly. Place the key in a position 2 m
(6 ft.) or more separate from the vehicle while the vehicle is being washed.
(Take care to ensure that the key is not stolen.)
If the electronic key is inside the vehicle and a door handle becomes wet during
a car wash, a message may be shown on the multi-information display and a
buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors.
The lock sensor may not work properly if it comes into contact with ice, snow,
mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock
sensor on the lower part of the door handle.
Page 158 of 688
1583-2. Opening, closing and locking the doors
CT200h_OM_OM76102E_(EE)
WA R N I N G
Caution regarding interference with electronic devices
People with implantable cardiac pacemakers, cardiac resynchronization ther-
apy-pacemakers or implantable cardioverter defibrillators should keep away
from the smart entry & start system antennas. (P. 143)
The radio waves may affect the operation of such devices. If necessary, the
entry function can be disabled. Ask any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional for details, such as the
frequency of radio waves and timing of the emitted radio waves. Then, con-
sult your doctor to see if you should disable the entry function.
Users of any electrical medical device other than implantable cardiac pace-
makers, cardiac resynchronization therapy-pacemakers or implantable cardio-
verter defibrillators should consult the manufacturer of the device for
information about its operation under the influence of radio waves.
Radio waves could have unexpected effects on the operation of such medical
devices.
Ask any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional for details on disabling the entry function.
Page 303 of 688
3005-3. Using the radio
CT200h_OM_OM76102E_(EE)
EON (Enhanced Other Network) system (for traffic announcement function)
If the RDS station (with EON data) you are listening to is not broadcasting a traf-
fic information program and the audio system is in the TA (traffic announce-
ment) mode, the radio will be switched automatically to a station broadcasting a
traffic information program in the EON AF list when traffic information begins.
When the 12-volt battery is disconnected
All preset stations are erased.
Reception sensitivity
Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.
When the “AST” button is used, automatic station selection may not be possi-
ble.
The radio antenna is mounted inside the rear window. To maintain clear radio
reception, do not attach metallic window tinting or other metallic objects to the
antenna wire mounted inside the rear window.
Digital Audio Broadcast (DAB) radio
The optional radio antenna and tuner are necessary for the use of Digital Audio
Broadcast (DAB) radio.
Page 356 of 688
3535-10. Bluetooth®
5
Audio system
CT200h_OM_OM76102E_(EE)
WA R N I N G
Caution while driving
Do not use a cellular phone or connect the Bluetooth® phone.
Caution regarding interference with electronic devices
An antenna for the Bluetooth® connection is built in the instrument panel.
People with implantable cardiac pacemakers, cardiac resynchronization ther-
apy-pacemakers or implantable cardioverter defibrillators should maintain a
reasonable distance between themselves and the Bluetooth
® antennas. The
radio waves may affect the operation of such devices.
Before using cellular phones, users of any electrical medical device other than
implantable cardiac pacemakers, cardiac resynchronization therapy-pacemak-
ers or implantable cardioverter defibrillators should consult the manufacturer
of the device for information about its operation under the influence of radio
waves. Radio waves could have unexpected effects on the operation of such
medical devices.
NOTICE
To prevent damage to cellular phones
Do not leave cellular phones in the vehicle. The temperature inside the vehicle
may become high, resulting in damage to the phone.
Page 384 of 688
3805-14. Using the radio (Lexus Display Audio System)
CT200h_OM_OM76102E_(EE)
Manual tuning (manual screen)
Turn the “TUNE•SCROLL” knob or turn the controller.
Station list (preset or station list screen)
Select the desired station by pressing “<” or “>”, turn the
“TUNE•SCROLL” knob or controller.
Radio stations can be preset.
Search for desired stations.
Turn the controller to select one of the stations and then press the
controller until you hear a beep while on the preset selection screen.
The broadcast you are currently listening to can be re-listened to at any
time.
Move the controller to the right and then select “Time shift”.
Turn the “TUNE•SCROLL” knob to set the desired offset.
An offset playback time can also be set on the menu screen. (P. 3 7 6 )
To cancel the time shift operation while in time shift mode, move the control-
ler to the left and select “Time shift off”. If the time shift display is left show-
ing “-0’ 00”” for 6 seconds without any operation, the time shift operation will
be canceled.
Reception sensitivity
Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.
The radio antenna is mounted inside the rear window. To maintain clear radio
reception, do not attach metallic window tinting or other metallic objects to the
antenna wire mounted inside the rear window.
Traffic announcement operation
When traffic announcement is set to on, “TP” will appear on the screen and the
radio will begin seeking a TP station. If the radio seeks out a TP station, the pro-
gram name will appear on the screen. If a traffic announcement station is
received, the radio will be switched to the traffic information program automati-
cally. When the program ends, the initial operation will resume.
Setting station presets (preset screen)
Time shift operation (DAB)
1
2
1
2
Page 436 of 688
4325-21. Bluetooth® (Lexus Display Audio System)
CT200h_OM_OM76102E_(EE)
WA R N I N G
While driving
Do not operate the portable audio player, cellular phone or connect a device to
the Bluetooth
® system.
Caution regarding interference with electronic devices
Your audio unit is fitted with Bluetooth® antennas. People with implantable
cardiac pacemakers, cardiac resynchronization therapy-pacemakers or
implantable cardioverter defibrillators should maintain a reasonable distance
between themselves and the Bluetooth
® antennas. The radio waves may
affect the operation of such devices.
Before using Bluetooth® devices, users of any electrical medical device other
than implantable cardiac pacemakers, cardiac resynchronization therapy-
pacemakers or implantable cardioverter defibrillators should consult the man-
ufacturer of the device for information about its operation under the influence
of radio waves. Radio waves could have unexpected effects on the operation
of such medical devices.
NOTICE
When leaving the vehicle
Do not leave your portable audio player or cellular phone in the vehicle. The
inside of the vehicle may become hot, causing damage to the portable audio
player or cellular phone.
Page 672 of 688
668Alphabetical index
CT200h_OM_OM76102E_(EE)
Alphabetical index
A/C ....................................442, 452
Air conditioning filter ...........527
Automatic air conditioning
system.........................442, 452
Humidity sensor ...........449, 456
Pollen removal mode ....447, 454
ABS (Anti-lock Brake System) .268
Function ................................268
Warning light........................569
Air conditioning filter ...............527
Air conditioning system ....442, 452
Air conditioning filter ...........527
Automatic air conditioning
system.........................442, 452
Humidity sensor ...........449, 456
Pollen removal mode ....447, 454
Airbag manual on-off system ......56
Airbags ........................................45
Airbag manual on-off system .56
Airbag operating conditions ...51
Airbag precautions
for your child........................47
Airbag warning light ............569
Correct driving posture ...........38
Curtain shield airbag
operating conditions .............51
Curtain shield airbag
precautions ...........................49General airbag precautions .... 47
Locations of airbags............... 45
Modification and disposal
of airbags ............................. 50
Side airbag operating
conditions ............................ 51
Side airbag precautions.......... 48
Side and curtain shield airbags
operating conditions ............ 51
Side and curtain shield airbags
precautions .......................... 49
SRS airbags............................ 45
Alarm .......................................... 93
Alarm ..................................... 93
Warning buzzer.................... 568
Anchor brackets.......................... 67
Antenna
Radio.................... 300, 380, 480
Smart entry & start system .. 143
Anti-lock brake system
(ABS) ..................................... 268
Function ............................... 268
Warning light ....................... 569
Approach warning .................... 237
Assist grips ............................... 477
A
Page 673 of 688
669Alphabetical index
CT200h_OM_OM76102E_(EE)
Audio system
(with navigation system)
*
Audio system (with Lexus
Display Audio System) ...........354
Antenna ................................380
Audio input ...........................362
AUX port ..............................362
Bluetooth
® audio ..................405
CD player .............................381
iPod.......................................387
MP3/WMA disc ...................381
Optimal use...........................371
Portable music player ...........396
Radio ....................................379
Setup menu ...........................363
Steering wheel audio
switches ..............................361
USB memory ........................391Audio system (without Lexus
Display Audio System) .......... 290
Audio input .......................... 320
AUX port ............................. 320
Bluetooth
® audio ................. 342
CD player............................. 301
iPod ...................................... 309
MP3/WMA disc................... 301
Optimal use .......................... 295
Portable music player .......... 320
Radio.................................... 297
Steering wheel audio
switches ............................. 326
USB memory ....................... 315
Automatic air conditioning system
Air conditioning filter .......... 527
Automatic air conditioning
system........................ 442, 452
Automatic headlight leveling
system .................................... 214
Automatic light control
system .................................... 214
AUX port .......................... 293, 362
Auxiliary boxes ........................ 468
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
