4456-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
Vehicles with a navigation system
Adjust the left-hand side
temperature setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side
temperature setting
Display the option control
screen (P. 445)
Turn the fan off
Select to set automatic mode on/off
To adjust or select settings, move the Remote Touch knob to select
the screen button, and then press the Remote Touch knob to enter the
selected function.
Option control screen
Select on the climate screen to display the option control screen.
The functions can be switched on and off.
Select to set cooling and dehumidification function on/off
Adjust the temperature for driver and passenger seats separately
(“DUAL” mode) (P. 446)
Prevent ice from building up on the windshield and wiper blades
(if equipped) (P. 448)
Remove pollen from the air (Pollen removal mode) (P. 447)
1
2
3
4
5
6
7
Vehicles with a Lexus Display
Audio SystemVehicles with a navigation sys-
tem
1
2
3
4

4486-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield
and wiper blades.
Select on the option control screen.
When the windshield wiper de-icer is on, is displayed on the air con-
ditioning control screen.
The windshield wiper de-icer will automatically turn off after a period of
time.
Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
Air outlets
1
2

4556-1. Using the air conditioning system and defogger
CT200h_OM_OM76102E_(EE)
6
Interior features
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield
and wiper blades.
Turns on/off.
The indicator comes on when the
windshield wiper de-icer is on.
The windshield wiper de-icer will
automatically turn off after a
period of time.
Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
Air outlets
1
2

4827-1. Maintenance and care
CT200h_OM_OM76102E_(EE)
WA R N I N G
When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.
When cleaning the windshield (vehicles with rain-sensing windshield wipers)
When the upper part of the windshield where the raindrop sensor is located is
touched by hand
When a wet rag or similar is held close to the raindrop sensor
If something bumps against the windshield
If you directly touch the raindrop sensor body or if something bumps into the
raindrop sensor
Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled
sufficiently, as touching a hot exhaust pipe can cause burns.
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the wip-
ers may operate unexpectedly in the fol-
lowing situations, and may result in hands
being caught or other serious injuries and
cause damage to the wiper blades.
Off

4837-1. Maintenance and care
7
Maintenance and care
CT200h_OM_OM76102E_(EE)
NOTICE
To prevent paint deterioration and corrosion on the body and components (alu-
minum wheels etc.)
Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the paint
surface
• After driving in an area contaminated with soot, oily smoke, mine dust,
iron powder or chemical substances
• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface
If the paint is chipped or scratched, have it repaired immediately.
To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.
Cleaning the exterior lights
Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.
Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.
To prevent damage to the windshield wiper arms
When lifting the wiper arms away from the windshield, pull the driver side
wiper arm upward first, and repeat for the passenger side. When returning the
wipers to their original position, do so from the passenger side first.
When using an automatic car wash (vehicles with rain-sensing windshield wip-
ers)
Set the wiper switch to the off position.
If the wiper switch is in “AUTO”, the wipers may operate and the wiper blades
may be damaged.
