service schedule Lexus CT200h 2013 Owner's Manual (in English)

4877-2. Maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
Maintenance requirements
Scheduled maintenance should be performed at specified intervals
according to the maintenance schedule.
For full details of your maintenance schedule, refer to the “Lexus Service
Booklet” or “Lexus Warranty Booklet”.
What about do-it-yourself maintenance?
Many maintenance items are easy to do yourself if you have a little mechani-
cal ability and a few basic automotive tools.
Note, however, that some maintenance tasks require special tools and skills.
These are best performed by qualified technicians. Even if you’re an experi-
enced do-it-yourself mechanic, we recommend that repairs and maintenance
be conducted by any authorized Lexus dealer or repairer, or another duly qual-
ified and equipped professional. Any authorized Lexus dealer or repairer will
keep a record of maintenance, which could be useful should you ever require
Warranty Service. Should you choose to select a qualified and equipped pro-
fessional other than an authorized Lexus repairer to service or maintain your
vehicle, we recommend that you request that a record of maintenance be kept.
To ensure safe and economical driving, day-to-day care and regular
maintenance are essential. Lexus recommends the following mainte-
nance:
Scheduled maintenance
Do-it-yourself maintenance

4887-2. Maintenance
CT200h_OM_OM76102E_(EE)
Where to go for maintenance service?
In order to maintain your vehicle in the best possible condition, Lexus recom-
mends that maintenance service operations as well as other inspections and
repairs be carried out by authorized Lexus dealers or repairers or other duly qual-
ified and equipped professionals. For repairs and services covered by your war-
ranty, please visit an authorized Lexus dealer or repairer, who will use genuine
Lexus parts in repairing any difficulties you may encounter. There can also be
advantages in utilizing authorized Lexus dealers or repairers for non-warranty
repairs and services, as members of the Lexus network will be able to expertly
assist you with any difficulties you may encounter.
Your Lexus dealer or repairer, or another duly qualified and equipped profes-
sional will perform all of the scheduled maintenance on your vehicle reliably and
economically due to their experience with Lexus vehicles.
Does your vehicle need repairs?
Be on the alert for changes in performance and sounds, and visual tip-offs that
indicate service is needed. Some important clues are:
Engine missing, stumbling or pinging
Appreciable loss of power
Strange engine noises
A fluid leak under the vehicle (However, water dripping from the air condition-
ing system after use is normal.)
Change in exhaust sound (This may indicate a dangerous carbon monoxide
leak. Drive with the windows open and have the exhaust system checked imme-
diately.)
Flat-looking tires, excessive tire squeal when cornering, uneven tire wear
Vehicle pulls to one side when driven straight on a level road
Strange noises related to suspension movement
Loss of brake effectiveness, spongy feeling brake pedal, pedal almost touches
the floor, vehicle pulls to one side when braking
Engine coolant temperature continually higher than normal (P. 570, 583)
If you notice any of these clues, take your vehicle to any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional as soon as possi-
ble. Your vehicle may need adjustment or repair.

5297-3. Do-it-yourself maintenance
CT200h_OM_OM76102E_(EE)
7
Maintenance and care
If the filter is dirty, clean by blow-
ing compressed air through the fil-
ter from the underside.
Hold the air gun 5 cm (2 in.)
from the filter and blow for
approximately 2 minutes at 500
kPa (5.0 kgf/cm
2 or bar, 72 psi).
If an air gun is not available,
have the filter cleaned by any
authorized Lexus dealer or
repairer, or another duly qualified
and equipped professional.
Checking interval
Inspect, clean and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement may
be required. (For scheduled maintenance information, please refer to the “Lexus
Service Booklet” or “Lexus Warranty Booklet”.)
If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
Cleaning method
NOTICE
To prevent damage to the system
When using the air conditioning system, make sure that a filter is always
installed.
When cleaning the filter, do not clean with water.
