3
1
8 7
6
5
4
3
2
CT200h_OM_OM76102E_(EE)
9
3-4. Adjusting the steering wheels
and mirrors
Steering wheel ................... 170
Inside rear view mirror...... 172
Outside rear view mirrors . 174
3-5. Opening, closing the windows
and moon roof
Power windows ................. 178
Moon roof ......................... 181
4-1. Before driving
Driving the vehicle ............ 186
Cargo and luggage............. 194
Trailer towing .................... 195
4-2. Driving procedures
Power (ignition) switch ..... 196
EV drive mode .................. 201
Hybrid transmission .......... 203
Turn signal lever ............... 209
Parking brake .................... 2104-3. Operating the lights and wipers
Headlight switch ............... 211
Fog light switch................. 216
Windshield wipers and
washer..............................218
Rear window wiper and
washer...............................222
Headlight cleaner switch ... 223
4-4. Refueling
Opening the fuel tank cap . 224
4-5. Using the driving support sys-
tems
Cruise control .................... 228
Dynamic radar cruise con-
trol....................................231
Lexus parking assist-sen-
sor.....................................245
Rear view monitor system. 253
Driving mode select
switch...............................265
Driving assist systems ....... 266
Hill-start assist control ...... 271
PCS (Pre-Crash Safety sys-
tem....................................273
4-6. Driving tips
Hybrid vehicle driving tips 281
Winter driving tips ............ 284
4Driving

16Pictorial index
CT200h_OM_OM76102E_(EE)
Pictorial index
Exterior
The shape of the headlights may differ depending on the grade, etc. (P. 538)
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 132
Locking/unlocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 132
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . . . . P. 178
Locking/unlocking by using the mechanical key . . . . . . . . . . . . . P. 621
Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . P. 570, 577
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 139
Warning lights/warning messages . . . . . . . . . . . . . . . . . . . . . P. 570, 577
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 174
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 174
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 175
Driving position memory
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 163
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 447, 454
1
2
3

20Pictorial index
CT200h_OM_OM76102E_(EE)
Switches (Left-hand drive vehicles)
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . . .P. 174
Instrument panel light control dial . . . . . . . . . . . . . . . . . . . . . . P. 106
Lexus parking assist-sensor switch
* . . . . . . . . . . . . . . . . . . . . P. 245
Heated steering wheel switch
*. . . . . . . . . . . . . . . . . . . . . . . . . P. 459
Windshield wiper de-icer switch
* . . . . . . . . . . . . . . . . . . . . . . P. 455
Manual headlight leveling dial
*. . . . . . . . . . . . . . . . . . . . . . . . P. 213
Headlight cleaner switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
1
2
3
4
5
6
7

25Pictorial index
CT200h_OM_OM76102E_(EE)
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
Sun visors
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Interior light
*3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Personal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Moon roof switches
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Intrusion sensor cancel switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . P. 96
1
2
3
4
5
6
*1: If equipped
*2: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 7 4 )
*3: The illustration shows the front, but they are also equipped in the rear.

28Pictorial index
CT200h_OM_OM76102E_(EE)
Switches (Right-hand drive vehicles)
Instrument panel light control dial . . . . . . . . . . . . . . . . . . . . . . P. 106
Outside rear view mirror switches . . . . . . . . . . . . . . . . . . . . . . P. 174
Manual headlight leveling dial
*. . . . . . . . . . . . . . . . . . . . . . . . P. 213
Headlight cleaner switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
Windshield wiper de-icer switch
* . . . . . . . . . . . . . . . . . . . . . . P. 455
Heated steering wheel switch
*. . . . . . . . . . . . . . . . . . . . . . . . . P. 459
Lexus parking assist-sensor switch
* . . . . . . . . . . . . . . . . . . . . P. 245
1
2
3
4
5
6
7

33Pictorial index
CT200h_OM_OM76102E_(EE)
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 172
Sun visors
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 473
Interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Personal lights
*3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 461
Moon roof switches
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 181
Intrusion sensor cancel switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . P. 96
1
2
3
4
5
6
*1: If equipped
*2: NEVER use a rearward facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it,
DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 7 4 )
*3: The illustration shows the front, but they are also equipped in the rear.

381-1. For safe use
CT200h_OM_OM76102E_(EE)
For safety drive
Adjust the angle of the seatback
so that you are sitting straight up
and so that you do not have to
lean forward to steer. (P. 1 5 9 )
Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. (P. 159)
Lock the head restraint in place with the center of the head restraint
closest to the top of your ears. (P. 167)
Wear the seat belt correctly. (P. 40)
Make sure that all occupants are wearing their seat belts before driving
the vehicle. (P. 4 0 )
Use a child restraint system appropriate for the child until the child
becomes large enough to properly wear the vehicle’s seat belt. (P. 5 9 )
Make sure that you can see backward clearly by adjusting the inside and
outside rear view mirrors properly. (P. 172, 174)
For safe driving, adjust the seat and mirror to an appropriate position
before driving.
Correct driving posture
1
2
Correct use of the seat belts
Adjusting the mirrors
3
4

125
3
Operation of
each component
CT200h_OM_OM76102E_(EE)
3-1. Key information
Keys .................................. 126
3-2. Opening, closing and
locking the doors
Side doors ......................... 132
Back door.......................... 138
Smart entry & start system 143
3-3. Adjusting the seats
Front seats ......................... 159
Rear seats .......................... 161
Driving position memory.. 163
Head restraints .................. 167
3-4. Adjusting the steering
wheel and mirrors
Steering wheel .................. 170
Inside rear view mirror ..... 172
Outside rear view mirrors . 174
3-5. Opening, closing the windows
and moon roof
Power windows................. 178
Moon roof ......................... 181

163
3 3-3. Adjusting the seats
Operation of each component
CT200h_OM_OM76102E_(EE)
Driving position memory
Your preferred driving position (the position of the driver’s seat and out-
side rear view mirrors) can be recorded and recalled by pressing a button.
Three different driving positions can be recorded into memory.
Recording procedure
Turn the power switch to ON mode.
Check that the shift position is in P.
Adjust the driver’s seat and outside rear view mirrors to the desired
positions.
While pressing the “SET” but-
ton, or within 3 seconds after
the “SET” button is pressed,
press button “1”, “2” or “3”
until the buzzer sounds.
If the selected button has already
been preset, the previously
recorded position will be over-
written.
: If equipped
This feature automatically adjusts the driver’s seat and outside rear view
mirrors to suit your preferences.
Driving position memory
1
2
3
4

1653-3. Adjusting the seats
3
Operation of each component
CT200h_OM_OM76102E_(EE)
Each electronic key (including a card key) can be registered to recall your
preferred driving position.
Registering procedure
Record your driving position to button “1”, “2” or “3” before perform-
ing the following:
Carry only the key you want to register, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.
Turn the power switch to ON mode.
Check that the shift position is in P.
Recall the driving position that you want to record.
While pressing the recalled
button, press and hold the door
lock switch (either lock or
unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds continu-
ously for approximately 3
seconds.
Recall procedure
Carry the electronic key that has been registered to the driving posi-
tion, and then unlock and open the driver’s door using the smart entry
& start system or wireless remote control.
The driving position will move to the recorded position.
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.
Memory recall function
1
2
3
4
