Page 3 of 688
3
1
8 7
6
5
4
3
2
CT200h_OM_OM76102E_(EE)
9
3-4. Adjusting the steering wheels
and mirrors
Steering wheel ................... 170
Inside rear view mirror...... 172
Outside rear view mirrors . 174
3-5. Opening, closing the windows
and moon roof
Power windows ................. 178
Moon roof ......................... 181
4-1. Before driving
Driving the vehicle ............ 186
Cargo and luggage............. 194
Trailer towing .................... 195
4-2. Driving procedures
Power (ignition) switch ..... 196
EV drive mode .................. 201
Hybrid transmission .......... 203
Turn signal lever ............... 209
Parking brake .................... 2104-3. Operating the lights and wipers
Headlight switch ............... 211
Fog light switch................. 216
Windshield wipers and
washer..............................218
Rear window wiper and
washer...............................222
Headlight cleaner switch ... 223
4-4. Refueling
Opening the fuel tank cap . 224
4-5. Using the driving support sys-
tems
Cruise control .................... 228
Dynamic radar cruise con-
trol....................................231
Lexus parking assist-sen-
sor.....................................245
Rear view monitor system. 253
Driving mode select
switch...............................265
Driving assist systems ....... 266
Hill-start assist control ...... 271
PCS (Pre-Crash Safety sys-
tem....................................273
4-6. Driving tips
Hybrid vehicle driving tips 281
Winter driving tips ............ 284
4Driving
Page 17 of 688
17Pictorial index
CT200h_OM_OM76102E_(EE)
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . P. 284
To prevent freezing (windshield wiper de-icer)
*1 . . . . . . . . P. 448, 455
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 483
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 639
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 510
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 645
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 285
Checking/rotation/tire pressure warning system
*1. . . . . . . . . . . . P. 510
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 590, 604
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 492
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 492
Engine compartment cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 496
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 639
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 628
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 577
Headlights/front position lights/daytime running lights . . . . . . P. 211
Front fog lights
*1/rear fog light*2. . . . . . . . . . . . . . . . . . . . . . P. 216
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Stop/tail lights
Emergency brake signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 267
Hill-start assist control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 271
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211
Back-up light
*2
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 203
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 538, Watts: P. 647)
*1: If equipped
*2: They may be located on the opposite side depending on the target region.
8
9
10
11
12
13
Page 19 of 688
19Pictorial index
CT200h_OM_OM76102E_(EE)
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . P. 109, 112
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 109, 112
Energy monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116
When the warning messages are displayed . . . . . . . . . . . . . . . . . . P. 575
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . P. 284
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 568, 580
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211
Headlights/front position lights/tail lights/daytime running lights P. 211
Front fog lights
*1/rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . P. 218
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 503
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 583
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 560
Fuel filler door opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 492
Tilt and telescopic steering lock release lever . . . . . . . . . . . . . P. 170
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . P. 442, 452
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 442, 452
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 447, 454
Audio system*1, 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 290
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 290
Hands-free system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 321
P position switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 205
*1: If equipped
*2: For vehicles with a navigation system, refer to
“NAVIGATION SYSTEM OWNER’S MANUAL”.
4
5
6
7
8
9
10
11
12
13
14
Page 27 of 688
27Pictorial index
CT200h_OM_OM76102E_(EE)
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . P. 109, 112
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 109, 112
Energy monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 116
When the warning messages are displayed . . . . . . . . . . . . . . . . . . P. 575
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 210
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . P. 284
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 568, 580
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 211
Headlights/front position lights/tail lights/daytime running lights P. 211
Front fog lights
*1/rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . P. 218
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 503
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 583
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 560
Fuel filler door opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 224
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 492
Tilt and telescopic steering lock release lever . . . . . . . . . . . . . P. 170
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . P. 442, 452
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 442, 452
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 447, 454
Audio system*1, 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 290
Audio system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 290
Hands-free system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 321
P position switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 205
*1: If equipped
*2: For vehicles with a navigation system, refer to
“NAVIGATION SYSTEM OWNER’S MANUAL”.
4
5
6
7
8
9
10
11
12
13
14
Page 102 of 688
1022. Instrument cluster
CT200h_OM_OM76102E_(EE)
*1: These lights turn on when the power switch is turned to ON mode to indicate
that a system check is being performed. They will turn off after the hybrid sys-
tem is on, or after a few seconds. There may be a malfunction in a system if
the lights do not turn on, or turn off. Have the vehicle inspected by any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped profes-
sional.
*2: The light flashes to indicate a malfunction.
*3: This light illuminates on the center panel.
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
Turn signal indicator
(P. 209)“ECO MODE” indica-
tor
(P. 265)
Tail light indicator
(P. 211)“SPORT MODE”
indicator (P. 265)
Headlight high beam
indicator (P. 212)
(if
equipped)
Cruise control indicator
(P. 228, 231)
(if
equipped)
Front fog light indicator
(P. 216)
(if
equipped)
Radar cruise control
indicator (P. 231)
Rear fog light indicator
(P. 216)
(if
equipped)
Lexus parking
assist-sensor indicator
(P. 245)
“READY” indicator
(P. 196)
*1, 2Slip indicator light
(P. 268, 271)
EV indicator (P. 79)
*1“TRC OFF” indicator
(P. 268)
Page 133 of 688
1333-2. Opening, closing and locking the doors
3
Operation of each component
CT200h_OM_OM76102E_(EE)
Operation signals
Doors:
The emergency flashers flash to indicate that the doors have been locked/
unlocked. (Locked: Once; Unlocked: Twice)
Windows:
A buzzer sounds to indicate that the windows are opening.
Security feature
If a door is not opened within approximately 30 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
Welcome light illumination control
The front position, tail and license plate lights automatically turn on at night
when the doors are unlocked using the entry function or wireless remote control
if the light switch is in the “AUTO” position.
When the door cannot be locked by the lock sensor on the upper part of the door
handle (vehicles with entry function)
Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a buzzer
sounds continuously for 5 seconds. Fully close the door to stop the buzzer, and
lock the vehicle once more.
Setting the alarm (if equipped)
Locking the doors will set the alarm system. (P. 93)
If the smart entry & start system or the wireless remote control does not operate
properly
Use the mechanical key to lock and unlock the doors. (P. 621)
Replace the key battery with a new one if it is depleted. (P. 530) If the door will not lock even when the top-
side sensor area is touched, try touching
both the topside and underside sensor areas
at the same time.
Page 185 of 688
185
4Driving
CT200h_OM_OM76102E_(EE)
4-1. Before driving
Driving the vehicle............ 186
Cargo and luggage ............ 194
Trailer towing.................... 195
4-2. Driving procedures
Power (ignition) switch ..... 196
EV drive mode .................. 201
Hybrid transmission .......... 203
Turn signal lever ............... 209
Parking brake .................... 2104-3. Operating the lights
and wipers
Headlight switch ................211
Fog light switch ................ 216
Windshield wipers and
washer ............................. 218
Rear window wiper and
washer ............................. 222
Headlight cleaner switch .. 223
4-4. Refueling
Opening the fuel tank cap . 224
4-5. Using the driving support
systems
Cruise control ................... 228
Dynamic radar cruise
control ............................. 231
Lexus parking
assist-sensor .................... 245
Rear view monitor system 253
Driving mode select
switch.............................. 265
Driving assist systems ...... 266
Hill-start assist control ...... 271
PCS (Pre-Crash Safety
system)............................ 273
4-6. Driving tips
Hybrid vehicle driving tips 281
Winter driving tips ............ 284
Page 209 of 688
209
4 4-2. Driving procedures
Driving
CT200h_OM_OM76102E_(EE)
Turn signal lever
Right turn
Lane change to the right (push
and hold the lever partway)
The right hand signals will flash
until you release the lever.
Lane change to the left (push and
hold the lever partway)
The left hand signals will flash until
you release the lever.
Left turn
Turn signals can be operated when
The power switch is in ON mode.
If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned out.
Operating instructions
1
2
3
4
Page 271 of 688
271
4 4-5. Using the driving support systems
Driving
CT200h_OM_OM76102E_(EE)
When the “TRC OFF” indicator comes on even if the TRC OFF switch has not
been pressed
TRC cannot be operated. Contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
Sounds and vibrations caused by the ABS, brake assist, VSC and TRC
A sound may be heard from the engine compartment when the hybrid system is
started, just after the vehicle begins to move, if the brake pedal is depressed
forcefully or repeatedly, or 1-2 minutes after the hybrid system is stopped. This
sound does not indicate that a malfunction has occurred in any of these systems.
Any of the following conditions may occur when the above systems are operat-
ing. None of these indicates that a malfunction has occurred.
• Vibrations may be felt through the vehicle body and steering.
• A motor sound may be heard after the vehicle comes to a stop.
• The brake pedal may pulsate slightly after the ABS is activated.
• The brake pedal may move down slightly after the ABS is activated.
EPS operation sound
When the steering wheel is operated, a motor sound (whirring sound) may be
heard. This does not indicate a malfunction.
Reduced effectiveness of the EPS system
The effectiveness of the EPS system is reduced to prevent the system from over-
heating when there is frequent steering input over an extended period of time.
The steering wheel may feel heavy as a result. Should this occur, refrain from
excessive steering input or stop the vehicle and turn the hybrid system off. The
EPS system should return to normal within 10 minutes.
Automatic reactivation of TRC system
After turning the TRC system off, the system will be automatically re-enabled in
the following situations:
When the power switch is turned off
The TRC will turn on when vehicle speed increases
Operating conditions of emergency brake signal
When the following three conditions are met, the emergency brake signal will
operate:
The emergency flashers are off.
Actual vehicle speed is over 55 km/h (35 mph).
The brake pedal is depressed in a manner that cause the system to judge from
the vehicle deceleration that this is a sudden braking operation.
Automatic system cancelation of emergency brake signal
The emergency brake signal will turn off in any of the following situations:
The emergency flashers are turned on.
The brake pedal is released.
The system judges from the vehicle deceleration that is not a sudden braking
operation.
Page 302 of 688
2995-3. Using the radio
5
Audio system
CT200h_OM_OM76102E_(EE)
Traffic information
Press the “TA” button.
TP mode:
The system automatically switches to traffic information when a
broadcast with a traffic information signal is received.
The station returns to the previous one when the traffic information ends.
TA m o d e :
Traffic information can be heard only when a signal is received. The sys-
tem switches to the mute mode when a signal is not received. In CD or
MP3/WMA mode, the system automatically switches to traffic informa-
tion when a signal is received.
The audio system returns to the mute, CD or MP3/WMA mode when the
traffic information ends.
Audio system mode changes as follows each time the “TA” button is
pressed:
FM modes: “TP” “TA” off
Modes other than the radio modes: “TA” off
Emergency broadcast reception mode
“ALARM” appears in the display in the event that an emergency
broadcast is received, and the emergency broadcast is aired.
