5388-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
(If equipped)
Indicates a malfunction in the intuitive parking assistAll the sensor lights flash.
A buzzer also sounds.
 Have the vehicle inspected by your Lexus dealer.
(If equipped)
Indicates that an intuitive par king assist sensor is dirty or
covered with ice
All the sensor lights flash.
A buzzer also sounds.
 Clean the sensor.
Indicates that the accelerator pedal is depressed while
the shift position is in N
A buzzer also sounds.
 Release the accelerator pedal and shift the shift
position to D or R.
Indicates that the accelerator pedal is depressed to stop
the vehicle on an upward slope etc.
A buzzer also sounds.
If this continues, the hy brid system may overheat.
 Release the accelerator pedal and depress the
brake pedal.
Indicates that the traction battery power has dropped
because a long period of time has elapsed after shifting
the shift position to N
A buzzer also sounds.
 Restart the hybrid system when starting the vehicle.
Wa r n i n g m e s s a g eDetails/Actions
(Flashes)
(Flashes)
(Flashes)

5398-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
Indicates a malfunction in the hybrid system A buzzer also sounds.
 Immediately stop the vehicle in a safe place and
contact your Lexus dealer.
Indicates that the traction battery is low
A buzzer also sounds.
 When stopping the vehicle for a long period of time,
shift the shift position to P. The battery cannot be
charged with the shift position in N.
Indicates that the vehicle is being driven at 3 mph (5 km/h)
or more with the parking brake still engaged.
A buzzer also sounds.
 Release the parking brake.
Indicates a malfunction in the shift control system
A buzzer also sounds.
 Have the vehicle inspected at your Lexus dealer
immediately.
• The hybrid system may not be able to start.
• The parking lock mechanism may not operate. Also,
shifting the shift position to P may not be possible.
When parking, choose a le vel place and apply the
parking brake securely.
• The automatically P position selection function ( P. 1 6 5 )
may not operate. Before turning the power switch off,
securely press the P position switch, and be sure to check
that the shift position is in P by verifying the shift position
indicator or P positi on switch indicator.
• The power switch may not be able to be turned off. In this case, the power switch can be turned off by apply-
ing the parking brake.
• The 12-volt battery may not be charged sufficiently. In this case, charge or replace the 12-volt battery.
After charging the 12-volt battery, the message may
continue to be displayed until the shift position is
shifted from P.
Wa r n i n g m e s s a g eDetails/Actions
(Flashes)
(U.S.A.) (Canada) (Flashes)

5618-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
Depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the power switch.
If any of the doors is opened or closed
while the key is being touched to the
switch, an alarm will sound to indicate
that the start function cannot detect the
electronic key.
Press the power switch within 10 second s of the buzzer sounding, keeping the
brake pedal depressed.
In the event that the hybrid system st ill cannot be operated, contact your Lexus
dealer.
■Stopping the hybrid system
Set the parking brake, shift the shift position to P and press the power switch as you nor-
mally do when stopping the hybrid system.
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the electronic
key battery be replaced immediatel y when the battery is depleted. (P. 5 0 4 )
■Changing power switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and press the power
switch.
The hybrid system does not start and mode s will be changed each time the switch is
pressed. ( P. 1 5 7 )
Starting the hybrid system
1
2
WA R N I N G
■When using the mechanical key and operating the power windows
Operate the power window after checking to make sure that there is no possibility of
any passenger having any of their body parts caught in the window.
Also, do not allow children to operate the mech anical key. It is possible for children and
other passengers to get caught in the power window.
3

5678-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
The coolant level is satisfactory if it is between the “FULL” and “LOW” lines
on the reservoir. Reservoir
“FULL” line
“LOW” line
Add coolant if necessary.
Water can be used in an emergency
if coolant is unavailable.
Start the hybrid system and turn the air conditioning system on to check
that the radiator cooling fans operate and to check for coolant leaks from
the radiator or hoses.
The fans operate when the air conditioning system is turned on immediately after a
cold start. Confirm that the fans are op erating by checking the fan sound and air
flow. If it is difficult to check these, tu rn the air conditioning system on and off
repeatedly. (The fans may not operate in freezing temperatures.)
If the fans are not operating:
Stop the hybrid system immediately and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer.
4
1
2
3
5
6
7

5698-2. Steps to take in an emergency
CT200h_OM_OM76197U_(U)
8
When trouble arises
Start the hybrid system and check for the multi-information display.
If the message does not disappear:
Stop the hybrid system and contact your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the nearest Lexus dealer.
WA R N I N G
■When inspecting under the hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
●If steam is seen coming from under the h ood, do not open the hood until the steam
has subsided. The engine compartment may be very hot.
●After the hybrid system has been turned of f, check that the indicator on the power
switch and the “READY” indicator are off.
When the hybrid system is operating, the gasoline engine may automatically start, or
the cooling fan may suddenly operate even if the gasoline engine stops. Do not touch
or approach rotating parts such as the fa n, which may lead to fingers or clothing
(especially a tie, a scarf or a muffler) ge tting caught, resulting in serious injury.
●Do not loosen the coolant reservoir cap while the hybrid system and radiator are hot.
High temperature steam or coolant could spray out.
NOTICE
■When adding engine/power control unit coolant
Add coolant slowly after the hybrid system has cooled down sufficiently. Adding cool
coolant to a hot hybrid system too quickly can cause damage to the hybrid system.
■To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust etc.).
●Do not use any coolant additive.
6

570
CT200h_OM_OM76197U_(U)8-2. Steps to take in an emergency
If the vehicle becomes stuck
Set the parking brake and shift the shift po
sition to P. Stop the hybrid system.
Remove the mud, snow or sand from around the stuck tire.
Place wood, stones or some other material under the tires to help provide
traction.
Restart the hybrid system.
Shift the shift position to D or R, release the parking brake and carefully apply
the accelerator to free the vehicle.
■When it is difficult to free the vehicle
Carry out the following procedures if the tires spin or the vehicle becomes
stuck in mud, dirt or snow:
Press to turn off TRAC. ( P. 2 3 6 )
WA R N I N G
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding
area is clear to avoid striking other vehicl es, objects or people. The vehicle may also
lunge forward or lunge back suddenly as it becomes free. Use extreme caution.
■When changing the shift position
Be careful not to change the shift positi on with the accelerator pedal depressed.
Changing the shift position to any positions other than P or N may cause the vehicle to
accelerate abruptly, causing an accident and resulting in death or serious injury.
NOTICE
■To avoid damage to the hybrid transmission and other components
●Avoid spinning the wheels and depressing the accelerator pedal more than neces-
sary.
●If the vehicle remains stuck even after th ese procedures are performed, the vehicle
may require towing to be freed.
1
2
3
4
5

614What to do if... (Troubleshooting)
CT200h_OM_OM76197U_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 5 3 1 )
●The parking brake indicator is on
Is the parking brake released? ( P. 1 6 8 )
Depending on the situation, other type s of warning buzzer may also sound.
( P. 5 2 9 , 5 3 6 )
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 76 )
To stop the alarm, turn the power switch to ON mode or start the hybrid system.
●Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. ( P. 5 3 6 )
●When a warning light turns on or a warning message is displayed, refer to
P. 5 2 9 , 5 3 6 . A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

620Alphabetical index
CT200h_OM_OM76197U_(U)
ECO lamp .................................................. 86
EDR (Event data recorder) ................... 12
Electric motorLocation .....................................................65
Specification .........................................573
Electric Power Steering (EPS) Function ..................................................235
Warning light ...................................... 530
Electronic key If the electronic key does not operate properly............................ 560
Replacing the battery ...................... 504
Emergency flashers ............................. 522
Emergency, in case of If a warning buzzer sounds...........529
If a warning light turns on...............529
If a warning message is displayed............................................ 536
If the 12-volt battery is discharged .........................................562
If the electronic key does not operate properly............................ 560
If the hybrid system will not start ............................................... 558
If you have a flat tire ......................... 549
If you lose your keys ................102, 104
If you think something is wrong .................................................. 528
If your vehicle becomes stuck ..................................................... 570
If your vehicle has to be stopped in an emergency ..........523
If your vehicle needs to be towed....................................................524
If your vehicle overheats ............... 566 Energy monitor .......................................... 91
Engine
Accessory mode ................................. 157
Compartment ..................................... 478
Engine switch ........................................156
Hood........................................................ 475
How to start the hybrid system ....................................................156
Identification number....................... 573
If your vehicle has to be stopped in an emergency.......... 523
Ignition switch (power switch) ..................................156
Overheating.........................................566
Power switch .........................................156
Engine compartment cover..............479
Engine coolant Capacity................................................. 575
Checking ............................................... 482
Preparing and checking before winter .................................... 246
Engine oil Capacity................................................. 574
Checking ............................................... 479
Oil pressure warning light ............ 529
Engine oil maintenance data ........... 468
Engine switch ........................................... 156 Auto power off function .................. 158
Changing the power switch modes .................................................... 157
If your vehicle has to be stopped in an emergency.......... 523
Starting the hybrid system...............156
EPS (Electronic Power Steering) Function .................................................. 235
Warning light .......................................530
E

622Alphabetical index
CT200h_OM_OM76197U_(U)
High mounted stoplightReplacing ................................................ 519
Hill-start assist control ........................ 235
Hood .......................................................... 475 Warning message .............................537
Hooks Cargo hooks ........................................434
Retaining hooks (floor mat) ............. 28
Horn ............................................................ 130
Hybrid battery (traction battery) Location .....................................................69
Specification .........................................574
Hybrid battery air vent .......................... 70
Hybrid system ........................................... 65 Emergency shut off system.............. 70
Energy monitor/consumption screen ..........................91
EV drive mode..................................... 160
High voltage components ...............69
Hybrid System Indicator ...................86
Hybrid system precautions..............69
Hybrid vehicle driving tips............. 244
If the hybrid system will not start ....................................................... 558
Overheating ........................................ 566
Power switch......................................... 156
Regenerative braking ......................... 67
Starting the hybrid system .............. 156
Vehicle proximity notification system .....................................................66
Hybrid System Indicator....................... 86
Hybrid transmission ..............................162 I/M test ...................................................... 472
Identification
Engine ..................................................... 573
Vehicle .................................................... 572
Ignition switch (Power switch).......... 156 Auto power off function .................. 158
Changing the power switch modes .................................................... 157
If your vehicle has to be stopped in an emergency.......... 523
Starting the hybrid system...............156
Illuminated entry system ................... 428
Immobilizer system ................................. 74
Indicators .................................................... 80
Initialization Engine oil maintenance data .......468
Items to initialize .................................599
Tire pressure warning system ....................................................491
Inside rear view mirror......................... 132
Instrument panel light control ............ 85
Interior lights ........................................... 427 Switch ...................................................... 428
Wattage ................................................. 579
Intuitive parking assist Function .................................................. 202
Warning message.............................538I

625Alphabetical index
CT200h_OM_OM76197U_(U)
P position switch .....................................163
Panic mode ................................................ 101
Parking brakeOperation ............................................... 168
Parking brake engaged warning buzzer/m essage..........529
Parking lights Light switch ............................................ 169
Replacing light bulbs ......................... 519
Parking lock ..............................................163
PCS (Pre-Collision System) ............ 239 Function ..................................................239
Pre-collision braking off switch....................................................239
Warning light ...................................... 530
Warning message ..................... 537, 542, 543
Personal lights.........................................427 Switch.......................................................428
Wattage ..................................................579
Power control unit coolant Capacity .................................................575
Checking................................................482
Preparing and checking before winter ....................................246
Radiator ................................................. 484
Power outlets ......................................... 440
Power steering (Electric Power
Steering system) ................................ 235 Warning light ...................................... 530 Power switch............................................ 156
Auto power off function .................. 158
Changing the power switch modes .................................................... 157
If your vehicle has to be stopped in an emergency.......... 523
Starting the hybrid system...............156
Power windows Jam protection function................... 138
Operation................................................ 137
Window lock switch .......................... 137
Pre-Collision System (PCS)............ 239 Function .................................................. 239
Pre-collision braking off switch ................................................... 239
Warning light .......................................530
Warning message.....537, 542, 543
Radar cruise control (dynamic radar cruise control)..........................189
Radiator.................................................... 484
Radio ......................................................... 259
Radio data system................................ 260
RDS ............................................................ 260
Rear seat Folding down the rear seatbacks ............................................. 122
Rear side marker lights Light switch.............................................169
Replacing light bulbs .........................519
P
R
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
