manual transmission Lexus ES300 1992 Starting And Driving

SECTION 3 – 1
95
STARTING AND DRIVING
Starting and driving
Catalytic converter96 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust caution
97 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Before starting the engine
97 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch with steering lock98 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission101 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission106 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control107 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system11 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pad wear limit indicators111 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires11 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

STARTING AND DRIVING
99 CAUTION (for manual transmission):
Never remove the key when the vehicle is moving, as this
will lock the steering wheel and result in loss of steering
control.
PARKING BRAKE
Set
Unlock
Release
To set: Pull up the lever.
To release: Pull up the lever slightly, press the thumb
button, then lower the lever.
Before leaving your vehicle, firmly apply the parking brake.
CAUTION:
Before driving, be sure the parking brake is fully released
and the parking brake reminder light is off.
HOW TO START THE ENGINE
Before cranking
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3.Manual transmission: Press the clutch pedal to the floor
and shift the transmission into neutral. Hold the clutch pedal to
the floor until the engine is started. A starter safety device will
prevent the starter from operating if the clutch pedal is not fully
depressed.
Automatic transmission: Put the selector lever in “P”. If you
need to restart the engine while the vehicle is moving, put the
selector lever n “N”. A starter safety device will prevent the
starter from operating if the selector lever is in any drive
position.
4.Automatic transmission only: Depress the brake pedal
and hold it to the floor until you are ready to drive off.
Starting the engine
Before starting the engine, be sure to follow the instructions in
“Before cranking”.
Normal starting procedure
The electronic fuel injection system in your engine
automatically controls the proper air-fuel mixture for starting.
You can start a cold or hot engine as follows:

STARTING AND DRIVING
106
(f) Good driving practice

If the transmission repeatedly upshifts and downshifts
between the third and overdrive gears when climbing a
gentle slope, turn off the overdrive switch. Be sure to turn the
switch on immediately after climbing the slope.

When towing a trailer, in order to maintain efficient engine
braking and electrical charging performance, do not use
overdrive.
CAUTION:
Always keep your foot on the brake pedal while stopped
with the engine running. This prevents the vehicle from
creeping.
NOTICE:
Do not hold the vehicle on an upgrade with the
accelerator pedal. This can cause the transmission to
overheat. Always use the brake pedal or parking brake.
Shift lock override button:
If you cannot shift the selector lever from the “P” range to the
other ranges with the brake pedal depressed, push the shift
lock override button. For your safety, keep the brake pedal
depressed during the operation.
Transmission failure warning
If the “O/D OFF” indicator light flashes, contact your Lexus
dealer as soon as possible. There may be trouble in the
transmission system.
MANUAL TRANSMISSION
The shift pattern is the conventional pattern shown above.
Press the clutch pedal down fully while shifting, and then
release it slowly. Do not rest your foot on the pedal while
driving, because it will cause needless wear. And do not
slightly release the pedal to hold the vehicle when stopped on
an uphill grade − use the parking brake.
Recommended shifting speeds
The transmission is fully synchronized and upshifting or
downshifting is easy.

STARTING AND DRIVING
109 CAUTION (for manual transmission):
While driving with the cruise control on, do not shift to
neutral without depressing the clutch pedal, as this may
cause engine racing or overrevving. If this happens,
depress the clutch pedal or turn the main switch off
immediately.
Cancelling the preset speed
You can cancel the preset speed by:
a. Pulling the control lever in the “CANCEL” direction.
b. Depressing the brake pedal.
c. Depressing the clutch pedal (manual transmission)
If the vehicle speed falls below 40 km/h (25 mph), the preset
speed will automatically be cancelled.
If the vehicle speed drops 16 km/h (10 mph) below the preset
speed, the preset speed will also automatically be cancelled.
If the preset speed automatically cancels out for other than
these reasons, have your vehicle checked by your Lexus
dealer at the earliest opportunity.
Resetting to a faster speed
Press the control lever upward in the “RES/ACC” direction and
hold it. Release the lever when the desired speed is attained.
While the lever is held upward, the vehicle will gradually gain
speed.When the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
increased 1.6 km/h (1 mph) each time by pressing the control
lever upward in the “RES/ACC” direction quickly.
However, a quicker way to reset is to accelerate the vehicle
and then press the control lever downward in the “SET/
COAST” direction.
Resetting to a slower speed
Press the control lever downward in the “SET/COAST”
direction and hold it. Release the lever when the desired speed
is attained. While the lever is held downward, the vehicle
speed will gradually decrease.
When the difference between the actual vehicle speed and the
set speed is less than 5 km/h (3 mph), the set speed can be
lowered 1.6 km/h (1 mph) each time by pressing the control
lever downward in the “SET/COAST” direction quickly.
However, a quicker way to reset is to depress the brake pedal
and then press the control lever downward in the “SET/
COAST” direction.
Resuming the preset speed
Press the control lever upward in the “RES/ACC” direction.
The vehicle will resume the speed set prior to cancellation
unless the vehicle speed is less than 40 km/h (25 mph) or is 16
km/h (10 mph) below the preset speed.
