Lexus ES300 1995 Comfort Adjustment

COMFORT ADJUSTMENT
57
Rear outside seat belts
Sit up straight and well back in the seat. To fasten your
belt, pull it out of the retractor and insert the tab into the
buckle.
You will hear a click when the tab locks into the buckle.
The seat belt length automatically adjusts to your size.
The retractor will lock the belt during a sudden stop or on
impact. It also may lock if you lean forward too quickly. A slow,
easy motion will allow the belt to extend, and you can move
around freely. When the shoulder belt is completely extended
and is then retracted even slightly, the belt is locked in that
position and cannot be extended. This feature is used to hold
the child restraint system securely. (For details, see “Child
restraint” on page 66.)
To free the belt again, fully retract the belt and then pull the belt
out once more.If the seat belt cannot be pulled out of the retractor, firmly pull
the belt and release it. You will then be able to smoothly pull the
belt out of the retractor.
CAUTION:
After inserting the tab, make sure the tab and buckle are
locked and that the belt is not twisted.
Take up slack
Keep as low on hip bone
as possible
Too high
Adjust the position of the lap and shoulder belts.
Position the lap belt as low as possible on your hips − not on
your waist, then adjust it to a snug fit by pulling the shoulder
portion upward through the latch plate.
CAUTION:

High-positioned lap belts and loose-fitting shoulder
belts both could increase the chance of injury due to
sliding under the lap belt during an accident.

For your safety, do not place the shoulder belt under
your arm.

COMFORT ADJUSTMENT
58
To release the belt, press the buckle release button and
allow the belt to retract.
If the belt does not retract smoothly, pull it out and check for
kinks or twists. Then make sure it remains untwisted as it
retracts.
Rear center seat belt
Lengthen
Sit up straight and well back in the seat. To fasten your
belt, insert the tab into the buckle.
You will hear a click when the tab locks into the buckle.
If the belt is not long enough for you, hold the tab at a right angle
to the belt and pull on the tab.
CAUTION:
After inserting the tab, make sure the tab and buckle are
locked and that the belt is not twisted.
Adjust to a snug fit
Keep as low on hip bone
as possible
Too high
Remove excess length of the belt and adjust the belt
position.
To shorten the belt, pull the free end of the belt.
Position the lap belt as low as possible on your hips − not on
your waist, then adjust it to a snug fit.
CAUTION:
High-positioned lap belts could increase the chance of
injury due to sliding under the lap belt during an accident.

COMFORT ADJUSTMENT
59
To release the belt, press the buckle release button.
Seat belt extender
If your seat belt cannot be fastened securely because it is not
long enough, a personalized seat belt extender is available
from your Lexus dealer free of charge.
Please contact your local Lexus dealer so that the dealer can
order the proper required length for the extender. Bring the
heaviest coat you expect to wear for proper measurement and
selection of length. Additional ordering information is available
at your Lexus dealer.
CAUTION:
When using the seat belt extender, observe the following.
Failure to follow these instructions could result in less
effectiveness of the seat belt restraint system in case of
vehicle accident, increasing the chance of personal injury.

Never use the seat belt extender if you can fasten the
seat belt without it.
Remember that the extender provided for you may not
be safe when used on a different vehicle, or for another
person or at a different seating position than the one
originally intended for.To connect the extender to the seat belt, insert the tab into
the seat belt buckle so that the “PRESS” signs on the
buckle release buttons of the extender and the seat belt
are both facing outward as shown.
You will hear a click when the tab locks into the buckle.
When releasing the seat belt, press on the buckle release
button on the extender, not on the seat belt. This helps prevent
damage to the vehicle interior and extender itself.
When not in use, remove the extender and store in the vehicle
for future use.
CAUTION:
After inserting the tab, make sure the tab and buckle are
locked and that the belt is not twisted.

COMFORT ADJUSTMENT
60
SRS AIRBAGS
The SRS (Supplemental Restraint System) airbags are
designed to provide further protection to the driver and
front passenger when added to the primary protection
provided by the seat belts.
In response to a severe frontal impact, the SRS airbags
work together with the seat belts to prevent or reduce
injury by inflating, in order to decrease the likelihood of
the driver’s or front passenger’s head or face directly
hitting the steering wheel or dashboard.
The passenger airbag is activated even with no passenger in
the front seat.
This indicator comes on when the ignition key is turned to
the “ACC” or “ON” position. It goes off after about 6
seconds. This means the SRS airbags are operating
properly.
The SRS airbag warning light system monitors the front airbag
sensors, center airbag sensor assembly, inflators, warning
light, interconnecting wiring and power sources.

COMFORT ADJUSTMENT
61
The SRS airbag system is designed to activate in
response to a severe frontal impact within the shaded area
between the arrows in the illustration.
The SRS airbags will deploy if the severity of the impact is
above the designed threshold level, comparable to an
approximate 20 km / h (14 mph) collision when impacting
straight into a fixed barrier that does not move or deform.
If the severity of the impact is below the above threshold level,
the SRS airbags may not deploy.
However, this threshold velocity will be considerably higher if
the vehicle strikes an object, such as a parked vehicle or sign
pole, which can move or deform on impact, or if it is involved
in an underride collision (a collision in which the nose of the
vehicle “underrides”, or goes under, the bed of a truck).
It is possible with collision severity at the marginal level of
airbag sensor detection and activation that only one of your
vehicle’s two airbags will deploy.
For your safety, be sure to always wear your seat belts.
Collision from the rear
Vehicle roll-overCollision from the side
The SRS airbags are not designed to inflate if the vehicle
is subjected to a side or rear impact, if it rolls over, or if it
is involved in a low-speed frontal collision.

COMFORT ADJUSTMENT
62
Front airbag sensor
Steering wheel
pad assembly
(airbag and
inflator)
SRS airbag warning light
Passenger airbag module
(airbag and inflator)
Center airbag sensor assembly
Front airbag sensor
The center airbag sensor assembly consists of a safing sensor
and center airbag sensor.
In a severe frontal impact, sensors detect deceleration and the
system triggers the airbag inflators. Then a chemical reaction
in the inflators momentarily fills the airbags with non-toxic
nitrogen gas to help restrain the forward motion of the
occupants.
When the airbags inflate, they produce a fairly loud noise and
release some smoke along with the nitrogen gas. This is not
harmful and does not indicate a fire. Be sure to wash off any
residue as soon as possible to prevent minor skin irritation.
Deployment of the airbags happen in a fraction of a second, so
the airbags must inflate with considerable force. While the
system is designed to reduce serious injuries, it may also
cause minor burns or abrasions and swellings.Parts of the airbag module (steering wheel hub, dashboard)
may be hot for several minutes, but the airbags themselves will
not be hot. The airbags are designed to inflate only once.
A crash severe enough to inflate the airbags may break the
windshield as the vehicle buckles. In vehicles with a passenger
airbag the windshield may also be damaged by absorbing
some of the force of the inflating airbag.
CAUTION:

The SRS airbag system is designed only as a
supplement to the primary protection of the seat belt
systems of the driver and front passenger. The front
seat occupants are particularly susceptible to injury if
they do not wear their seat belts; when sudden braking
or a collision occurs, they may be thrown forward. To
obtain further protection in an accident, the driver and
all passengers in the vehicle should always wear their
seat belts when driving. For instructions and
precautions concerning the seat belt system, see
“SEAT BELTS” on page 54.

A baby or small child who is too small to use a seat belt
should be properly secured in a rear seat using a child
restraint system.

COMFORT ADJUSTMENT
63

Do not use a rear-facing child restraint system in the
front seat because the force of the rapid inflation of the
passenger airbag may cause severe injury to the child.
Move fully back

When using a forward-facing child restraint system in
the front seat, the seat must be moved as far back as
possible. For instructions concerning the installation
of a child restraint system, see “CHILD RESTRAINT” on
page 66.

Do not sit on the edge of the seat or lean over the
dashboard when the vehicle is in use. The airbags
inflate with considerable speed and force; you may be
severely injured. Sit up straight and well back in the
seat, and always use your seat belt.

COMFORT ADJUSTMENT
64

Do not put objects on or in front of the dashboard or
steering wheel pad that houses the airbag system. They
might restrict inflation or cause personal injury as they
are projected rearward.

Do not modify, remove or open any component or
wiring, such as the steering wheel, column cover, front
passenger airbag cover, front passenger airbag, center
airbag sensor assembly or front airbag sensors. Doing
any of these may cause sudden SRS airbag inflation or
disable the system, which could result in personal
injury.
Failure to follow these instructions can result in severe
injuries.
NOTICE:
Do not perform any of the following changes without
consulting your Lexus dealer. Such changes can
interfere with proper operation of the SRS airbag system
in some cases.

Installation of electronic items such as a mobile
two-way radio, cassette tape player or compact disc
player.

Modification of the suspension system.

Repairs made on or near the front fenders, front
console, steering column, steering wheel or
dashboard near the front passenger airbag.

COMFORT ADJUSTMENT
65
This SRS airbag system has a service reminder indicator to
inform the driver of operating problems. If either of the following
conditions occurs, this indicates a malfunction of the airbags.
Contact your Lexus dealer as soon as possible to service the
vehicle.

The light does not come on when the ignition key is turned
to the “ACC” or “ON” position, or remains on.

The light comes on while driving.
In the following cases, contact your Lexus dealer as soon as
possible:

The SRS airbags have been inflated.

The front part of the vehicle (shaded in the illustration) was
involved in an accident not of the extent to cause the SRS
airbags to inflate.

COMFORT ADJUSTMENT
66
The pad section of the steering wheel or front passenger
airbag cover (shaded in the illustration) is scratched,
cracked, or otherwise damaged.
CHILD RESTRAINT
Child restraint precautions
Lexus strongly urges the use of child restraint system for
children small enough to use it.
The laws of all fifty states in the U.S.A. and Canada now
require the use of a child restraint system.
CAUTION:
For effective protection in automobile accidents and
sudden stops, children must be properly restrained.
Holding a child in your arms is not a substitute for a child
restraint system. In an accident, the child can be crushed
against the windshield, or between you and the vehicle’s
interior if you are unrestrained.
Child restraint system
A child restraint system for a small child or baby must
itself be restrained on the seat with either the lap belt or
the lap portion of the lap / shoulder belt.
The child restraint system should conform to the size of the
child and properly fit the vehicle seat. For greater safety, the
child restraint system should be installed in the rear seat.
According to accident statistics, children are safer when
properly restrained in the rear seat than in the front seat.
When installing a child restraint system, refer to the
instructions provided by its manufacturer and follow the
directions under the following illustrations.
CAUTION:
After installing the child restraint system, make sure it is
secured in place. If it is not restrained securely, it may
cause injury to the child in the event of a sudden stop or
accident.
When not using the child restraint system, keep it secured with
the seat belt or place it in the trunk or somewhere other than
in the passenger compartment. This will prevent it injuring
passengers in the event of a sudden stop or accident.
