Lexus ES300 1997 Interior Equipment
Manufacturer: LEXUS, Model Year: 1997, Model line: ES300, Model: Lexus ES300 1997Pages: 12, PDF Size: 0.18 MB
Page 1 of 12
37
SECTION 1 ± 4
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors 38
Interior light 39
Personal light 39
Ignition switch light 40
Clock 41
Cigarette lighter and ashtray 41
Power outlet 42
Glovebox 43
Cup holder 43
Overhead console box 44
Auxiliary box 47
Floor mat 47
Luggage stowage precautions 48
Page 2 of 12
INTERIOR EQUIPMENT
38
VANITY MIRRORS
To use the vanity mirrors, swing the sun visor down and
open the cover.
The vanity light comes on when you open the cover.
Sun visors
To block out glare from the front, swing the sun
visor down.
To block out glare from the side, remove the sun
visor from the hook and swing it to the side.
To block out coming obliquely from behind you,
pull out an extension plate from the inside of the
sun visor.
NOTICE
Take care not to swing back the sun visor without
pushing back the extension plate so as not to
damage the extension plate.
Page 3 of 12
INTERIOR EQUIPMENT
39
INTERIOR LIGHT
To turn on the interior light, slide the switch.
With the switch in the ªDOORº position, the light comes on
when any of the doors are opened. After all the doors are
closed, the light remains on for about 15 seconds and then
goes out.
However, in the following cases, the light goes out
immediately:
1. All the doors are closed when the ignition key is in ªACCº
or ªONº position.
2. The ignition key is turned to ªACCº or ªONº when the light
is still on.
3. All the doors are locked when the light is still on.
4. One door is closed with the lock button pushed in while
the other doors are locked.
PERSONAL LIGHT
Vehicles without moon roof
To turn on the personal light, push the switch. To turn
it off, push the switch again.
Page 4 of 12
INTERIOR EQUIPMENT
40
Vehicle with moon roof
To turn on the personal light, push the switch. To turn
it off, push the switch again.
IGNITION SWITCH LIGHT
For easy access to the ignition switch, the ignition
switch light comes on when any of the doors are
opened.
The light remains on for about 15 seconds and goes out after
all the doors are closed. However, the light goes out
immediately when all the doors are locked or the ignition key
is in the ªACCº or ªONº position.
Page 5 of 12
INTERIOR EQUIPMENT
41
CLOCK
The digital clock indicates the time with the ignition key
at the ªONº position. To reset the hour, press the ªHº
button. To reset the minutes, press the ªMº button. To
adjust the time to the nearest hour, press the ª:00º
button.
For example, if the ª:00º button is pressed when the time is
between 9:30 ± 9:59 or between 10:01 ± 10:29, the time will
change to 10:00.
With the tail lights on, the background brightness of the time
indication will be reduced.
Once the electrical power source has been disconnected
from the clock, the time is automatically set to 1:00.
CIGARETTE LIGHTER AND
ASHTRAY
Front cigarette lighter and ashtray
To use the cigarette lighter and ashtray, first push
against the ashtray cover. Then when the ashtray opens
out, press in the cigarette lighter. When it becomes
heated, it automatically pops out for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in the
ªACCº position.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching
fire. After using the ashtray, push it back in completely.
To remove the ashtray, just pull it out.
Use a Lexus genuine cigarette lighter or equivalent for
replacement.
