KEYS AND DOORS15
Locking with rear door child±protector
11E006±2

1Lock 2Unlock
Whenever small children are in the vehicle, lock the rear door so that it
does not open from the inside. To do this, move the knob to the lock
position as shown on the label next to the knob.

SWITCHES17
HEADLIGHT SWITCH
12E001±1
To turn the lights on, twist the knob on the end of the lever.
FIRST CLICKSTOP: Only the parking, tail, license plate, side marker and
instrument panel lights turn on.
SECOND CLICKSTOP: Headlights also turn on.
THIRD CLICKSTOP (ºAUTOº): The headlights and all other lights
automatically turn on depending on the darkness of the surroundings.
Vehicles sold in U.S.A.: When the headlights are on, the headlight indicator
lights up in the instrument cluster.
Vehicles sold in Canada: When the tail lights are on, the tail light indicator
lights up in the instrument cluster. Manually twist the knob to the second clickstop to turn on the headlights
if they are needed immediately when entering a dark tunnel, parking
structure, etc.
When the headlight switch is turned to the first or second clickstop, the
brightness of the instrument cluster will be reduced slightly unless the
instrument panel light control knob is turned fully on.
12E002
The automatic light control sensor is on top of the driver's side instrument
panel.
Do not place anything on the instrument panel, and/or do not affix anything
on the windshield to block this sensor.
The lights automatically turn off when the driver's door is opened with the
ignition
key turned to the ºACCº or ºLOCKº position. To turn them on again,
turn the ignition key to the ºONº position, or turn the headlight switc\
h off and
then twist the knob until the first or second clickstop. If you are going to park
for over one week, make sure the headlight switch is off.

SWITCHES19
12E004±1
For signaling turns, move the lever up or down in the conventional
manner.
The ignition key must be in the ºONº position.
The turn signal is self±cancelling after a turn, but after a lane change\
, you may
have to cancel it by hand. You can also signal a lane change by moving the
turn signal lever partway and holding it there.
If the green light in the instrument cluster flashes faster than normal, it
indicates that the front or rear turn signal bulb has burned out. If this indicator
light does not come on, the fuse or the indicator light itself has probably failed.
FOG LIGHT SWITCH
12E005±1
To turn on the fog lights, turn the switch to the ºONº position. Th\
e fog
lights come on only when the headlights are on low beam.

SWITCHES
20
WINDSHIELD WIPER AND WASHERSWITCH
12E006

1Interval adjuster 2Washer on
To turn the wipers on, move the lever down until you reach the desired
speed setting.
The ignition key must be in the ºONº position.
There are 3 settings: ºINTº position: Intermittent operation
ºLOº position: Low speed operation
ºHIº position: High speed operation
Twist the interval adjuster upward to increase the wiping time interval
between sweeps, and downward to decrease it.
The wiper lever must be in the ºINTº position. To make the washer squirt, pull the lever toward you and release it.
Also, the wipers will automatically operate a couple of times after the washe\
r
squirts even with the lever in the ºOFFº position.
The low washer fluid warning light in the instrument cluster comes on when
the fluid level in the tank becomes nearly empty. For information on adding
washer fluid, see ºAdding washer fluidº on page 227.
In cold weather, warm the windshield with the defroster before using the
washer. This will help prevent icing, which could block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the glass.

SWITCHES
22
REAR WINDOW AND OUTSIDE REARVIEW MIRROR DEFOGGER SWITCH
12E011±1
To turn the electric rear window and outside rear view mirror defogger
on, push the switch.
The ignition key must be in the ºONº position.
The thin heater wires on the inside of the rear window and the heater pa\
nels
in the outside rear view mirrors will quickly clear the surface. An ind\
icator
light is on when the defogger is operating.
The system will automatically shut off when the defogger has operated about
15 minutes.
CAUTION
Since the mirror surfaces can get hot, keep your hands off
them when the switch is on.
If further defrosting or defogging is desired, simply actuate the switch\
again.
When the surface has cleared, push the switch once again to turn the defogge\
r
off. Continuous use may cause the battery to discharge, especially during
stop±and±go driving. The rear window defogger is not designed to dry rain
water or to melt snow.
If the outside rear view mirrors are heavily coated with ice, use a spray d\
e±icer
before operating the switch.
NOTICE
 When cleaning the inside of the rear window, be careful not to scratch
or damage the heater wires.
 To prevent the battery from being discharged, do not operate the
defogger continuously longer than necessary.

SWITCHES23
POWER WINDOW SWITCHES
12E012±1

1For driver's window
2For front passenger's window
3For left rear window
4For right rear window
To raise or lower the windows, use the switch on each door. The
passengers' windows can also be controlled by the switches on the
driver's door.
The ignition key must be in the ºONº position. However, even if the ignition
key is turned to the ºACCº or ºLOCKº position, the window ca\
n be operated
until a front door is opened (or for about 45 seconds).
12L010
Operating the driver's switch
To lower the window, push the switch halfway down. Pull it up to raise
the window. The window glass moves as long as the switch is operated.
To fully lower the driver's window automatically, push the switch fully
down.
In automatic operation, the window will fully open even if you let go of\
the
switch. To stop the window partway, lightly pull the switch up and then
release it.
Operating the passengers' switches
To lower the window, push the switch down. Pull it up to raise the window.
The window moves as long as the switch is operated.

SWITCHES
24
Operating the window lock switch
12E013±1

Indicator light
With the window lock switch pressed in, only the driver's window can be
raised or lowered.
The indicator lights on the switch tell you which of the switches can be
operated.
CAUTION
To avoid serious personal injury, you must do the following.
 Always make sure the head, hands and other parts of the
body of all occupants are kept completely inside the vehicle
before you close the power windows. If someone's neck,
head or hands gets caught in a closing window, it could
result in a serious injury. When anyone closes the power
windows, be sure that they operate the windows safely.
 When small children are in the vehicle, never let them use
the power window switches without supervision. Use the
window lock switch to prevent them from making
unexpected use of the switches.
 Never leave small children alone in the vehicle, especially
with the ignition key still inserted. They could use the
power window switches and get trapped in a window.
Unattended children can become involved in serious
accidents.

SWITCHES25
EMERGENCY FLASHER SWITCH
12E014±1
To turn on the emergency flashers, push the switch.
All the turn signal lights will flash. The emergency flashers will work with
the engine running or off and with or without the ignition key.
Turn on the emergency flashers to warn other drivers if you must stop your
vehicle where it might be a traffic hazard.
Always pull your vehicle as far off the road as possible.
The turn signal light switch will not work when the emergency flashers are in
operation.
NOTICE
To prevent the battery from being discharged, do not leave the switch on
longer than necessary when the engine is not running.
SEAT HEATER SWITCHES
12E015±2

1For driver's seat 2For front passenger's seat
To turn on the seat heater, push the switch.
The ignition key must be in the ºONº position.
CAUTION
Occupants must use caution when operating the seat heater
because it may make them feel too hot or cause burns at low
temperatures (erythema, varicella). Use extra caution for;
 Baby, small child, elderly person, sick person or
handicapped person
 Persons who have delicate skin
 Persons who are exhausted
Persons who have taken alcohol or drugs which induce sleep
(sleeping drug, cold remedy, etc.)
To prevent the seat overheating, do not use the seat heater with a
blanket, cushion, or other insulating objects which cover the seat.

GAUGES, METERS AND SERVICE REMINDER INDICATORS31
(f) Add engine oil.
(g) Take vehicle to Lexus dealer.
(h) Take vehicle to Lexus dealer.
(i) Close all doors.
(j) Replace bulb.
(k) Take vehicle to Lexus dealer.
(l) Add washer fluid.
(m) Low fuel level Fill up tank.
warning light
(n) Key reminder buzzer Remove key.
(a) Brake System Warning Light
This light has the following two functions:
Parking brake reminder
If this light is on, make sure the parking brake is fully released. The\
light
should go off.
Low brake fluid level warning
If this light comes on and stays on while you are driving, slow down and p\
ull
off the road. Then stop the vehicle carefully. Remember that stopping
distance and pedal effort may be increased. There may be a problem
somewhere in the brake system. Check the fluid level of the see±through
reservoir.
To make sure the parking brake has not caused the warning light to come on\
,
check to see that the parking brake is fully released.
If the brake fluid level is low ...
At a safe place, test your brakes by starting and stopping.
 If you judge that the brakes still work adequately, drive cautiously to your
nearest dealer or shop for repairs.
 If the brakes are not working, have the vehicle towed in for repairs. (\
For
towing information, see page 173.)
CAUTION
It is dangerous to continue driving normally when the brake
fluid level is low.
or

GAUGES, METERS AND SERVICE REMINDER INDICATORS
32
If the brake fluid level is correct ...
Have the warning system checked by your Lexus dealer.
(b) Seat Belt Reminder Light and Buzzer
Once the ignition key is turned to ºONº or ºSTARTº, the reminder light and
buzzer come on if the driver's seat belt is not fastened. Unless the driver
fastens the belt, the light stays on and the buzzer stops after about 4 to 8
seconds.
(c) SRS Warning Light
The indicator comes on when the ignition key is turned to the ºACCº o\
r
ºONº position. It goes off after about 6 seconds. This means the SRS is
operating properly.
The SRS warning light system monitors the airbag sensor assemblies,
inflators, seat belt pretensioners, warning light, interconnecting wiring and
power sources.
If either of the following conditions occurs, this indicates a malfunction
somewhere in the parts monitored by the warning light system. Contact your
Lexus dealer as soon as possible to service the vehicle.

The light does not come on as described above.
 The light stays on or flashes.
 The light comes on or starts flashing while driving.
If the light stays on, it indicates that the driver and front passenger air\
bags fail.
If the light flashes, the side airbags and/or seat belt pretensioners fa\
il.
(d) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the engine, and
check for the cause. Look first at the engine drive belt.
 If it is loose or broken, the generator will not charge the battery properly.
 If the belt is O.K., there is a problem somewhere in the charging system.
The engine ignition will continue to operate, however, until the battery is
discharged. Turn off the air conditioning, blower, radio, etc., and drive
directly to the nearest Lexus dealer or repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken or loose.
