Lexus ES300 2000 s (in English) Owner's Guide
Manufacturer: LEXUS, Model Year: 2000, Model line: ES300, Model: Lexus ES300 2000Pages: 501
Page 21 of 501
BASIC OPERATION
1
QUICK REFERENCE
Driver's seat2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering wheel 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 3
. . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight and turn signal switch 4
. . . . . . . . . . . . . . . . . .
Wiper switch 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 22 of 501
Seat position
Seat cushionangle
Seat cushion height
Seatback angle
Lumbar support
Head restraint height
Head restraint angle
BASIC OPERATION ± QUICK REFERENCE
2
1. DRIVER'S SEAT 2. STEERING WHEEL
TILT STEERING WHEEL
BE024
To tilt the steering wheel up or down to the desired
angle:
1. Pull the lever up while holding the steering wheel.
2. Push or pull the steering wheel to the desired
angle.
3. Release the lever.
Page 23 of 501
BE028
Note: When the cruise control is being used, even if you downshift the transmi\
ssion by turning off the overdrive switch, engine
braking will not be applied because the cruise control is not cancelled. For th\
e operation to decrease the vehicle speed, see page
298.
Parking, engine starting and key
removal position
Reverse position
Neutral position
Normal driving position
Position for engine braking
Position for stronger engine braking
than that in ª2º position
With the brake pedal depressed,
shift while holding the lock release
button in. (The ignition switch must
be in ªONº position.)
Shift while holding the lock release
button in.
Shift normally.
Overdrive switch
For selecting either a three±speed or
four±speed transmission
Lock release button (To prevent misshifting)
ªO/D OFFº indicator
light on the instrument
cluster
BASIC OPERATION ± QUICK REFERENCE
3
3. AUTOMATIC TRANSMISSION
Page 24 of 501
BE004
BE004
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights turn of at full
intensity.
Automatic light control
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on.
Automatic light control
BE005
BE006
High beam
Headlight flasher
Right or left turn
Lane change
(Right or left)
BASIC OPERATION ± QUICK REFERENCE
4
4. HEADLIGHT AND TURN
SIGNAL SWITCH
HEADLIGHT SWITCH
With the ignition OFF
With the engine started and parking
brake released
TURN SIGNAL SWITCH
Page 25 of 501
BE007
Washer on
Intermittent operation
Low speed operation
High speed operation
BASIC OPERATION ± QUICK REFERENCE
5
5. WIPER SWITCH
Page 26 of 501
BASIC OPERATION ± QUICK REFERENCE
6
Page 27 of 501
SECTION 1 ± 1
7
INSTRUMENTS AND CONTROLS
Keys and doors
Keys7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Engine immobiliser system 12
. . . . . . . . . . . . . . . . . . . . . .
Wireless remote control 14
. . . . . . . . . . . . . . . . . . . . . . . . .
Doors 24
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
KEYS
11E020
Page 28 of 501
KEYS AND DOORS
8
1Master key (black) ± The master key works in
every l ock. For your Lexus dealer to make you
a new key with built±in transponder chip, your
dealer will need it.
2 Sub key (gray) ± The sub key will not open the
trunk, glove box and armrest door in the rear
seat.
3Key number plate ± Keep the plate in a safe
place such as your wallet, not in the vehicle.
A transponder chip for engine immobiliser system has
been filled in the head of the master and sub keys.
These chips are needed to enable the system to function
correctly, so be careful not to lose these keys. If you
make your own duplicate key, you will not be able to
cancel the system or start the engine.
To protect things locked in the trunk or glove box when
you have your vehicle parked, leave the sub key with the
attendant. Since
the doors and trunk lid can be locked without a key,
you should always carry a spare master key in case you
accidentally lock your keys inside the vehicle.
If you should lose your keys or if you need additional
keys, duplicates can be made by a Lexus dealer using
the key number.
We recommend you to write down the key number and
keep it in safe place.
Page 29 of 501
KEYS AND DOORS
9
11L003a
Since a transponder chip is not built in this flat key,
you cannot start the engine with this key. Use this
key to release the lock in case you accidentally lock
your keys inside the vehicle or trunk.
Insert your flat key in its key case as shown. We
recommend that you always carry this with you for
emergency use. Do not leave it in your vehicle.NOTICE
Do not let the key case become bent as the keymay fall out or become bent also.
The flat key is designed for emergency useonly.
Page 30 of 501
KEYS AND DOORS
10
11E021
When using a key containing a transponder chip,observe the following precautions:
When starting the engine, do not use the keywith a key ring resting on the key grip and donot press the key ring against the key grip.Otherwise the engine may not start, or maystop soon after it starts.
